Description

Self-watering device for houseplants



This device is designed to allow you to water your houseplants. Unlike just watering on the surface, this has two key benefits:

  • Water is delivered down into the root-ball, where it is needed, rather than laying on the surface of the soil.
  • Water is delivered slowly, rather than as a deluge that gets wasted as instant run-off. Just how slowly depends on your soil - if its dry or free-draining, it may just go straight in, but if it's moist and solid, the hydrostatic back-pressure will make it take longer.

NEW - If you're looking for something to deliver water over days or weeks, you need something which isn't open at the top, so atmospheric pressure can also hold the water back. Try this:

Ultra-slow release plant water spike

https://makerworld.com/en/models/1065529





This particular design has some extra features:



To reduce loss caused by evaporation, the container at the top is mostly enclosed with a funnel lid: you pour water in, and most of it will be protected below the funnel surface and won't evaporate off before it is needed:





At the bottom, there are additional lateral holes. These ensure that when you push the device into the soil device doesn't get clogged up, which can be a problem with traditional designs that only have a single hole at the bottom.



A couple of bonus features:



The base of the funnel lid has a trap to prevent dirt getting into the main storage area.

The small hole near the top of the funnel is to let air escape from under the funnel lid as you fill it with water.



Printing notes



This prints without supports.



This prints well in PLA. You can scale it up if you want, but I wouldn't recommend printing it any smaller.



The dirt-trap at the base of the funnel may string a little bit as it prints, but this doesn't affect the print - and is actually helpful in keeping the dirt out!



The 3MF file settings include some brim. This is recommended to avoid the model getting knocked off the plate during printing, but may be a little fiddly to remove. (You can just leave the brim on the model - it looks good either way!)
