Print-in-place fidget ring

Print-in-place fidget ring

Boost
40
80
18

Print Profile(68)

All
P1S
P1P
X1
X1 Carbon
X1E
A1
A1 mini

16.2mm inner diameter - 0.2mm layer, 2 walls, 15% infill
16.2mm inner diameter - 0.2mm layer, 2 walls, 15% infill
Designer
13 min
1 plate
5.0(1)

16.5mm diameter, 0.2mm layer, 2 walls, 15% infill
16.5mm diameter, 0.2mm layer, 2 walls, 15% infill
Designer
14 min
1 plate
4.0(1)

16.8mm inner diameter - 0.2mm layer, 2 walls, 15% infill
16.8mm inner diameter - 0.2mm layer, 2 walls, 15% infill
Designer
13 min
1 plate

17.1mm inner diameter, 0.2mm layer, 2 walls, 15% infill
17.1mm inner diameter, 0.2mm layer, 2 walls, 15% infill
Designer
14 min
1 plate
5.0(2)
Click to see more

Open in Bambu Studio
Boost
40
80
18
4
101
84
Released

Description

👉 Please rate the print profiles - It would help tremendously. 👈

Have fun with this fidget ring! I uploaded many sizes (inner diameter in mm from 12.3mm for kids to 24mm for big fingers, please use the conversion table below in case you are used to your local ring sizes and use the closest value in millimeter) and three ring widths ("normal" - as seen in the picture, "thin" and "wide").



Only a few sizes are available as "print profile", you get more sizes and variations via the customizer button above and as STL.

The STL filenames have both the style (normal/thin/wide) and the inner diameter in mm in the filename. For conversion of ring sizes, please use the “Ring size conversion table” at the end of this instructions page.



Thanks go out to aubenc for the knurledFinishLib_v2 and to Betsy Weber for her fotos of the multicolor rings.



If you like it, check out the dual fidget ring:

And the discrete (as in discontinuous/quantized) fidget ring:

And the discrete fidget ring - Mark II:

Then the slim fidget ring:

The Longitudinal fidget ring:

And the geared fidget ring:

The alternative geared fidget ring II:

And there are bracelets available as well:

Please have a look at all my customizable creations


Or check out the 1250 keychain name tags:

Printing

You can print it without any support, and it prints very fast. Standard settings will be fine, like infill of 20%, layer height of .2mm, 2 perimeters.

After printing, turn the ring a few times to make it spin better.



In case the inner ring does not stick well enough to the build plate, use the STLs in the folder "OnlyIfYouHaveProblems__Big_inner_Ring_for_more_adhesion”. It has a thicker inner ring, but also more area on the build plate.
In the unlikely event that the ring is fused together(e.g. possible when your printer is not calibrated properly and has overextrusion), use an STL from the folder “OnlyIfYouHaveProblems__Ring_with_extra_wide_clearance”. It has not 0.7mm clearance but 1.4mm(!) clearance.



Ring size conversion table:

Ring inner diameter in mmUSA
Canada
United KingdomFranceGermany
14.0 mm3F4414
14.4 mmG45¼14½
14.8 mm446½15
15.2 mm47¾15¼
15.6 mm54915¾
16.0 mmL50¾16
16.5 mm6M51½16½
16.9 mmN52¾17
17.3 mm7O5417¼
17.7 mmP55¼17¾
18.2 mm8Q56¾18
18.6 mm5818½
19.0 mm959¼19
19.4 mm60¾19½
19.8 mm1061¾20
20.2 mm10½62¾20¼
20.6 mm1164¼20¾
21.0 mm11½6621
21.4 mm12Y67¼21¼
21.8 mm12½Z6821¾
22.2 mm13-6922
22.6 mm13½---
