Toroidal Launcher Mini Rings - 150mm pitch

This is an add-on design for my Toroidal Launcher that features four different toroidal ring designs. The rings are a smaller 100mm diameter and range from two to five blades angled at 150mm pitch. The included launcher bit works with all mini ring designs making it easy to try them all!

Printing Tips

For best results clean build plate and run flow rate calibration before printing
Recommend to use PETG or other impact resistant filament
Designed to print without supports and the following changes to the default profiles
- 0.6mm line thickness
- Arachne wall generator
- Slower outer wall print speed

Boost Me (for free)

If you enjoy my Toroidal Launcher and add-on designs please consider supporting with a boost as it greatly helps support the creation of more complex designs. Thank you and I hope you enjoy the launcher!

Comment & Rating (127)

@jorge.lchinea

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

good design, but somewhat fragile in pla, finally I printed it in petg

@ibjonathan

Most silk and glitter and some other special filaments are known to be more brittle. You may have more success with matte or standard PLA. Or as you have already done, with PETG or even better, ABS. Cheers.

@acevalsl

Print Profile

[All Labelled for Mini]: 0.2mm layer, 2 walls

Nice but not original

The designer has replied

@moonrakerone

These require the pin and screw setup on the last plate to work! The screw/pin thing is different.

@Flyrockets

Boosted

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

print and fly great

@benpark20

Print Profile

[All Labelled for Mini]: 0.2mm layer, 2 walls

printed amazing

@gccsilk

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

works 👍

(Edited)

@nadnerb33

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

Printed fine, perhaps a tad under extruded with Bambu PLA matte

@plomdawg

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

flies great

@JulesPrint3D

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

easy to print, nice design

@SpaceGamer

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

These are awesome. Great work.

@aguszurlo12

Print Profile

Toroidal Rings Mini - All variants (150mm pitch)

These work better than the original bigger one since they have less mass and moment
