Toy Train BNSF locomotive BRIO / IKEA compatible
Print Profile(2)
Bill of Materials
Description
BNSF diesel locomotive toy train (BRIO / IKEA compatible). This is the older model with 2 types of screws - the newer ones are far better designed and use only 1 type of screws for everything (check the link to my premium toy trains below). Happy printing!
You will need the following screws to put everything together:
14x ISO 14585 (DIN7981) 2.9mm x 13mm
2x ISO 14585 (DIN7981) 2.9mm x 19mm
Get the screws directly from Bambu Lab Maker's Supply - check the purchase link for Bill of Materials - scroll all the way down!
Add ring magnets on each side of the train. Use 2x ISO 14585 (DIN7981) 2.9mm x 13mm screws a plastic washer and small neodymium ring magnets diameter 10mm outer / 4mm inner with height of 5mm.
The GCODE of "bnsf_train_body.gcode" contains 2 filament color changes at 2.80mm (Layer 24) and 4.80mm (Layer 42) and the support enforcer.
If you enjoy these models and want to support me, check out my new toy trains with wagons, here:
Lovely 3D printed Toy Trains
Print instructions
You will need to add supports for the following parts:
belly.stl (normal supports for counterbored holes)
bnsf_train_body.stl (support enforcer for counterbored holes)
roof.stl (support enforcer for the roof at the back)
Prusament Galaxy Black PLA
Prusa Yellow PLA
Prusa Orange PLA
Prusa Silver PLA
