GOPRO MOTORCYCLE HELMET MOUNT
Print Profile(1)
Description
đď¸ Universal Chin Mount for Action Cam (GoPro, DJI, Insta360)
Tired of bulky strap mounts or spending a fortune on dedicated brackets? This is a lightweight, sturdy, and cleanly designed chin mount, engineered to capture the perfect first-person view (POV) from your motorcycle rides!
Originally developed and tested on a Nolan N60 helmet, its smart curvature and versatile positioning mean it easily adapts to many other full-face helmets on the market.
⨠Main Features
- Perfect POV Shot: The chin position is absolutely the best for motorcycle vlogging: the camera records exactly what you see.
- Universal Compatibility: Designed for GoPro, DJI Osmo Action, Insta360, and any action camera with a standard mount.
- Aerodynamic and Discreet: Low profile that doesn't create air resistance and doesn't spoil your helmet's aesthetics.
- Easy to Print: Optimized geometry for simple printing and high structural resistance.
đ¨ď¸ Recommended Print Settings
To ensure maximum safety and durability on the road, the use of PLA is strongly discouraged.
- Material: PETG, ASA, or ABS (Highly recommended for UV, heat, and impact resistance).
- Infill: 40% - 50% (Gyroid or Grid for maximum rigidity).
- Perimeters (Wall Loops): 4 or 5 perimeters to ensure the screw and pin area do not yield under stress.
- Supports: Yes (Tree Supports are perfect for clean removal).
đ§ Installation Tips
- Thoroughly clean the helmet surface with isopropyl alcohol to remove grease and dirt.
- Use high-quality structural double-sided adhesive (e.g., 3M VHB) to attach the mount to the chin bar.
- Press firmly and allow the adhesive to cure for at least 24 hours before your first motorcycle ride!
đ If you like the project, leave a âââââ review and upload a photo of your print! It helps the community a lot!
