ARC Raiders Shield Recharger - Assembly Guide
Listen up, Raider—getting vaporized by ARC drones because your shields are down is embarrassing, so print this recharger and stay in the fight!
Instructions
Print all parts using your preferred filament settings or from the prepared 3mf file. Every Part needs to be printed once. I would suggest to use a brim for better print adhesion and support enabled.
Building the Recharger:
- Take the Connector and screw it onto the Tip.
- Assemble the power core: Screw together the Copper Coil, the Middle Coil, and the Upper Coil.
- Screw this completed coil assembly into the Tip.
- Screw the Main Body onto the Connector.
- Prepare the electronics housing: Press-fit the Sideplate onto the Top Cover.
- Screw the assembled Top Cover onto the Main Body.
- Insert the Trigger Screw into the Trigger, then press-fit it into the hole on the Top Cover.
- Tip: You can use a screwdriver or a pen to push it securely into place.
You are finished. Enjoy your recharged shields!
