XT90 unisex panel mount
IP Report
Print Profile(4)
For 3.0mm thick panel
Designer
20 min
1 plate
For 1.5mm thick panel
Designer
21 min
1 plate
For 2.0mm thick panel
Designer
21 min
1 plate
For 2.5mm thick panel
Designer
20 min
1 plate
Open in Bambu Studio
Boost
40
107
4
1
116
71
Released
Description
Boost Me (for free)
Couldn't find an Amass XT90 panel mount that had all my requirements so I designed this based on ideas from my previous XT60 remix.
My aims for this design:
- No support needed.
- Can be used for both Male and Female connector.
- Can be removed from the panel afterward without de-soldering (= it can be installed from inner side)
- Easy parameter change to adapt to multiple panel thickness.
- Can be secured without damaging the connector.
