Description

Check my crowdfunding project OE OTF RE: Redefine and Evolve

Have a knife day!

Another OTF over-engineered one. Enhanced! Lubricate the inside with cooking oil. Prefer PETG. Not suitable for silk filament due to its stickiness.

Link to watch the build video instruction

utility blade disposal

double action

automatic

Comment & Rating (202)

@justinwille9666

Boosted

Pinned by Designer

I printed your previous model to and was really happy with it. But this one is phenomenal! I really like that the "closing llid" is more stable now! Great work, keep up!

GIF

@Ostrichsak

Is this the bold pattern flat handle? Do I just print the three pieces on the right for this extension length? I assume the three on the left allow the blade to extend further in the same handle? I want to print this, but the documentation is confusing. Many users report difficulty identifying parts despite claims they are labeled. The assembly video is too fast and lacks explanation, leaving the various options unclear. It feels like the creator assumes everyone already knows the system. A simple 5-minute video of a single assembly and a guide linking specific parts to completed versions would be far more useful. I love the concept, but getting started is unnecessarily complex. If the creator focused more on clarity and less on self-promotion or dismissing questions, this amazing print would be much more accessible. Currently, many people give up due to a lack of basic instructions.

@user_870668120

Hey, I printed the trapezoidal 18mm narrow pattern extended handle but looks like a lot more spare components. can you please advice which components are actually needed and if you can share an assembly guide that will help. the video has too many options and some don’t match what I’ve got in the print ? thanks. looking forward to getting this set up. Ive this printed using the default settings for PETG-HF.

@nickmv

You ever get this figured out? I was gonna print it out but then saw this post. Looks like way too many parts for a single unit.

@user_870668120

Replying to @nickmv :

Nope. I ended up printing something else altogether which works way better and doesn’t have any springs either. This is what I printed. https://makerworld.com/models/1870926?appSharePlatform=copy

(Edited)

@DuDu_Studio

Are you done? I am as confused as you are

Show original

@3DRIO

Print Profile

Trapezoid &18mm (Narrow patten. Flat handle) 35g only

This is super cool! And it hasn't broken like all the other oft's after 2 billion uses 😅🤣

(Edited)

The profile uploader has replied

@iczfirz

Try my Gravity knife.

@3DRIO

Replying to @iczfirz :

Alright 👌

@makerboy13

Nicely done. I've already printed/assembled 3. Only 2 shown as I gifted the 3rd.

The designer has replied

@iczfirz

Nice build!

@logges

Print Profile

Trapezoid &18mm (Narrow patten. Flat handle) 35g only

Such an awesome design. Works flawlessly for me first try! but added a couple drops of dry lube for some extra smoothness. Printed with Bambu Translucent PETG and Sunlu Elite PETG. I’ll definitely be printing a few more! thanks! quick note: I do think some more specific instructions would be helpful, but the video works good enough for now.

(Edited)

The profile uploader has replied

@iczfirz

This is my crowdfunding project. Have a look :P https://makerworld.com/en/crowdfunding/164

@skjalg78

Print Profile

Trapezoid &18mm (Narrow patten. Flat handle) 35g only

I have to say this the coolest thing I have printed. Afte trial and error I got it working. I didn’t get the other working with metal I don’t know why, cause it worked with a plastic blade.

The profile uploader has replied

@iczfirz

This is my crowdfunding project. Have a look :P https://makerworld.com/en/crowdfunding/164

@JBrownies

Print Profile

Trapezoid &18mm (Narrow patten. Flat handle) 35g only

sanding smooth the contact points helps with deploy and retract

The profile uploader has replied

@iczfirz

Try lube with cooking oil as well. :P

(Edited)

@JBrownies

I did add lube as well! Great print!

@Julian_zet

Print Profile

Trapezoid &18mm (Narrow patten. Expanded Handle) 35g only

Sigma

@Bardownskiiz

🤨

@user_2301081681

quite sad with the results I had high hopes but it’s too hard to open and the blade doesn’t lock forward properly

The designer has replied

@iczfirz

Try lube with cooking oil.

@user_1447627658

Great OTF, if not the best!

@mihauHome

which is the best?

Show original

@WheelOfFortune

Boosted

amazing design!!! Printed in petg and this work super nice. Does not work in petg-cf for me, but the print quality was not great maybe for someone who knows how to handle petg-cf better. I have questions, does printing the parts in pla except the spring works well? I don't like the shine of petg, and it's not a pleasure to touch. And would it be possible that you give use the model without pattern on it? I think the casing would look amazing with a fuzzy skin.
