Broom Holder with Print-in-Place Hinges

German:

Broom Holder with Print-in-Place Hinges

This versatile broom holder was initially designed for wall-mounted broom storage, but it also excels at securing tools with cylindrical handles. While drilling a hole in the broom handle and hammering a nail into the wall might appear simpler, this holder offers compelling advantages:

• Nail-Free Solution: Our apartment prohibits nails, making this holder the perfect solution.
• Print-in-Place Design: This design fulfills my passion for print-in-place hinges; it requires no metal rivets or nuts and bolts. The hinges are integrated, eliminating assembly.

Features:

• Compatibility: The uploaded STL files are tailored to the telescopic handle of my LEIFHEIT broom (~≥24 mm diameter).
• Tension: For adapting the internal diameter to other tools, I recommend reducing it by approximately 0.2-0.4 mm to generate tension. The integrated spring possesses ample reserve to grip the handle firmly.
• Mounting: The holder features vertical holes for secure screwing onto shelves or similar surfaces.

This broom holder is perfect for anyone seeking a practical and nail-free solution for broom and tool storage.

Inspiration and Adaptation:

This design draws inspiration from an original by wavedash on Printables and has been remixed to integrate additional features and customizations.

English:

Broom Holder with Print-in-Place Hinges

This versatile broom holder was originally designed to hang a broom on the wall, but it is also perfect for attaching tools with cylindrical handles. While it might seem easier to drill a hole in the broom handle and nail it to the wall, there are several reasons to use this holder:

• Nail-Free Solution: We are not allowed to use nails in our apartment, making this holder the perfect solution.
• Print-in-Place Design: This design satisfies my print-in-place hinge addiction, as it requires no metal rivets or nuts & bolts. The hinges are built-in, so no assembly is needed.

Features:

• Compatibility: The uploaded STL files are sized to fit my LEIFHEIT broom's telescopic handle (~≥24 mm diameter).
• Tension: If you wish to adjust the internal diameter for other tools, I advise reducing it by ~0.2-0.4 mm to create some tension. The built-in spring has enough reserve to hold the handle tightly.
• Mounting: The holder has vertical holes that allow it to be screwed onto a shelf or similar surface.

This broom holder is ideal for anyone looking for a practical, nail-free solution for storing brooms and other tools.

Inspiration and Adaptation:

This design was inspired by an original from wavedash on Printables and has been remixed to incorporate additional features and customizations.
