Description

This is recreation of the esp32 case by Sabedje (https://makerworld.com/en/models/731190#profileId-662718), PureRandom (https://makerworld.com/en/models/410199?designId=410199#profileId-674458) and sirfragalot (https://makerworld.com/en/models/41778?from=search#profileId-42297)

I needed a case for my ESP32 D1 Mini, However, mine needed more power than the USB allows. So I combined the case from these 3 profiles to create my version of the ESP32 D1 Mini case. This version uses Sirfragalot's D1 mini case to hold the board in place, while using Sabedje/PureRandom's Case to be able to uses a Barrel Plug Connector for more power. I widened the Case and increase the height to allow the use of the D1 Mini with the soldered prongs.

PLEASE NOTE

During my testing, I found that the Barrel Plug Connector used in this profile can get Really HOT. Please make sure to limit the Amperage to 4A MAX. the plug itself is rated for 5A but its still gets too hot. Mine came with a 10A power supply, so I assumed 8A should be fine, however, after using for 8 hours, I noticed it warped the case and it was REALLY HOT. 4A is still warm, but seems to hold up fine.

USE AT YOUR OWN RISK PLEASE.
