UNIVERSAL CARDBOARD SPOOL AMS ADAPTER by claudiogirolami

claudiogirolami

3D Printer>3D Printer Accessories

Print Profile(1)

All

P1S

P1P

X1 Carbon

X1E

0.20 Standard printing

Designer

59 min

1 plate

4.8(24)

Boost

104

211

239

192

Released

Description

Hello friends,here is a cardboard spool adapter for AMS.
This adapter is "almost" universal.In fact, thanks to its shape and the elasticity of the plastic (preferably PETG) this tool adapts to most cardboard spool formats.This feature is also useful in the case of smaller formats: the springs also work as shock absorbers during the rotation of the spool.

Edit: A model for thicker cardboards has been added. Find it on STL Download.
Edit Fri 21 Jun 2024: Other 2 spools adapters with a thinner external circumference walls (0.40 only) added available in the STL downloads.

NOTE: some cardboard models are slightly different from the standard measurements declared by the manufacturer. Please note that AMS accepts coils up to 202mm in diameter and so even a slight oversize from the factory could render the coil unusable with any adapter.

Happy printing!
