Description
This is a food dispenser for the meowton project. You can use it standalone as well.
Differences compared to most other printable dispensers out there:
- Easy to print and assemble
- Only one simple servo needed
- No glue/screws or extra stuff needed. 100% printed.
- Does not jam or crush food
- Does not make loud scary noises.
- Reliable
- Hard to cheat by cat. :)
- Servo can run for only 100mS to dispense minimal portions.
Print instructions:
- Print as is
- Only the motor holder needs support. The rest has nice 45 degrees angles that all print fine.
- You can slide and click everything, no need for tools or glue.
Build instructions and more info: https://github.com/psy0rz/meowton/wiki/Meowton-food-dispenser
(C)DatuX - For commercial use/support/development contact us at http://datux.nl/index.php/contact-info
