x4code

marcopolo

simple clamping jaw mechanism e.g. for soldering printed circuit boards. no screws/nuts required. not suitable for large forces. enjoy! :)

Holding Jaw Mechanism

工具

Saber3D

Check all my models out at <a target="_blank" href="https://saber-3d.com/" rel="nofollow noopener">www.Saber-3D.com</a> &nbsp;New dragons, creatures, and more released every month to my patrons, thank you for supporting my work! &nbsp;Follow our socials to see new models! <a target="_blank" href="https://www.instagram.com/saber.3d" rel="nofollow noopener">Instagram</a><a target="_blank" href="https://www.tiktok.com/@saber3d" rel="nofollow noopener">TikTok</a>&nbsp;This flexi dragon was designed to take less time but still give you the awesome look of a large dragon as well as make custom designs as easy as possible! Every part of this dragon can be easily painted in your slicer of choice, just make sure edge detection is turned off 😉&nbsp;Want to sell prints or just enjoy the instant access to all my models? join our All Access tier on <a target="_blank" href="https://www.patreon.com/Saber3D" rel="nofollow noopener">Patreon</a>. &nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

Articulated Crystal Dragon by Saber3D

玩具

A1xyz轴上润滑油小部件&nbsp;2024.1.28 重新设计了Y轴上油的小部件

A1xyz润滑油小部件

我自己的

Vergil

<blockquote>2023-10-02 Update!I've updated the Lid frame & Complete Lid files thanks to the feedback. I know it's funny to do an update on a literal bin, but here we go I guess!<ol><li>The update adds a small retainer radius for the trap door so it doesn't fall out by itself anymore. You can still “force remove” it, but if you clip it back it actually stays put now. </li><li>I've also increased the height of the inner wall so it sits more securely in the bin. Adds a tiny bit of material but it feels more roboust.</li></ol>Important to note: You don't need to print out the whole complete Lid assembly again! If you already have the parts you just need the frame! I've added a profile just for that and replaced the lid assembly with R2. Old files are removed as of now.&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/60098/2023-10-02_7649a13ad0209.png"></figure></blockquote>&nbsp;&nbsp;Bin dimensions: 100x100x115 mm so it fits quite a bit of mess before needing to be emptied.---The Bin can be used by itself and should be printed in Vase mode. It's a solid model. I highly suggest using the following settings (if not the project files are used):<ul><li>Line/wall width: 0.8 mm</li><li>First layer width: 0.8 mm</li><li>Bottom layers: at least 3</li><li>Layer height: 0.2 mm (text looks better with 0.16, otherwise doesn't matter much)</li></ul>I uploaded the .3mf files with the settings. You can change the material etc… but it contains the 0.8 settings for thicker walls. You can print it fine with the default 0.4 Nozzle. Makes the Bin a lot more rigid but still print fast. I used Fillamentum's Crystal Clear PLA to print it with basically the generic PLA settings.Print time: ~1h26m with 0.2 layers Material: 46 g---The Complete Lid consists of 2 parts. You can print them together at once and move the trapdoor a little to release them after printing. Or if you want to mix up the colors without AMS, I added them separately as well. Uploaded the .3mf file for this one too. Generally this part is not that picky for settings, but here's a few suggestions:<ul><li>Print with the text facing the build plate</li><li>Bottom layers: 3-4</li><li>Top layers 2-3</li><li>Textured PEI plate for nice look</li><li>10% Grid infill at least so the lid has some weight to close itself, you can use combine infill option to save a little time</li></ul>Print time: ~37m with 0.2 layers Material: 26 gYou can remove the trapdoor if it annoys you flapping around. The frame alone gives a nice touch too if you print in a different color than the base.

Plastic Waste Bin

玩意

Deviian

Version 2.1 added with a modified peg for people experiencing issues with complete insertion of the holder. In case version 2.1 is loose in your case, use the original version 2.0. New version of securing the printer head cable to prevent snagging on the Z-axis structure.The cable is routed further away from the Z-axis. The overall design has been modified for a more aesthetically pleasing appearance. Printed using standard settings with PLA.
