可乐不加冰

FunkyArt

A 100% 3D printed Smartphone-holder-arm that offers, at least, three axes. And the option of double braces between the axes. In the standard configuration, the arm easily supports around 500 grams in any position. &nbsp;The versatility of this arm enables secure and flexible positioning of smartphones or even tablets and cameras (coming soon) in any desired orientation. Print with high infill and clean up the prints carefully, the minimal gap dimensions of the 3D printed parts ensure reliable function and solid haptic but could also be hard for some printers. &nbsp;You find more additional features and alternatives in the Download section. I will provide more Instructions soon.&nbsp;<figure class="media"><div data-oembed-url="https://www.youtube.com/watch?v=FxNsubX2KjE"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/FxNsubX2KjE" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>&nbsp;There are some additional upgrades in the download section, such as additional phone rotating movement and counterscrews, less tight screws and a bigger phoneholder.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/752785/2023-11-18_f7836c4a1c65.png"></figure><figure class="image image_resized" style="width:98.24%;"><img src="https://makerworld.bblmw.com/makerworld/draft/752785/2023-11-18_a6107c3f6e376.gif"></figure>What to Print?<ul><li>1x CZFA_Flexframe_BaseA_part11x CZFA_FlexFrame_BaseA_part2</li><li>1x CZFA_FlexFrame_PhoneMount (or the optional bigger one)</li><li>1x CZFA_FlexFrame_Mount-Mount (or the optional one with rotating axis)</li><li>1x CZFA_FlexFrame_Screw_cap-lid</li><li>1x CZFA_FlexFrame_Screw_small_Phoneholder</li><li>3x CZFA_FlexFrame_Frame_25cm</li><li>4x CZFA_FlexFrame_Screw</li></ul>Additional parts for rotating your phone, small phones adapter or counters crews..<ul><li>CZFA_FlexFrame_mount-mount-additional-movement-2-2</li><li>CZFA_FlexFrame_mount-mount-additional-movement-1-2 (you will need also one more small screw)</li><li>CZFA_FlexFrame_PhoneMount-small_phones_adapter</li><li>CZFA_FlexFrame_XL-PhoneMount</li><li>CZFA_FlexFrame_Counterscrew (optional to add more weight)</li></ul>Also less_tight versions of the screws.

Flexible & sturdy phone arm (100% Printed)

工具

blecheimer

This is a toy plane that is based on the famous Boeing Stearman Model 75 biplane. <a target="_blank" href="https://en.wikipedia.org/wiki/Boeing-Stearman_Model_75" rel="nofollow noopener">https://en.wikipedia.org/wiki/Boeing-Stearman_Model_75</a> The toy plane has a wingspan of 240mm and a length of 196mm. It can be completely assembled without using glue. All necessary clips and bolts are printed. I even included a small screwdriver.&nbsp;Use the following settings for the wings: 0,12 layer height, 4 walls, 4 bottoms, 8 tops, 16% gyroid infill The rest can be printed with 0,2 layers, 4 walls, 4 bottoms, 5 tops, 6% gyroid infill. I recommend a brim only for the bolts. See my 3mf for more details and how I positioned the parts on the build plates.&nbsp;Print the following parts with support:<ul><li>Fuselage (only for the cockpit)</li><li>Wings (only for th bottom of the threads)</li><li>Engine (not for the thread)</li><li>Bolts (only for the head)</li><li>Struts (use small tree support)</li><li>Supports (use small tree support)</li><li>Cockpit (only for the bottom of the thread)</li></ul>Do not use support on the threads.&nbsp;All parts will fit into a 200x200x200 build space.  A1 mini users need to split the wings into two parts (can be done with Bambu Studio) and glue them together after printing.&nbsp;For assembly follow these steps:<ul><li>put the front cover on the engine</li><li>screw the engine to the fuselage</li><li>insert the cockpit into the fuselage and secure it with a short bolt</li><li>insert the lower wing into the fuselage and secure it with a short bolt</li><li>insert the rear wing into the fuselage and secure it with a short bolt</li><li>this is now a bit tricky: insert the middle supports into the fuselage and put the top wing on the supports</li><li>now put one strut between the lower and top wing</li><li>insert a long bolt through the lower wing into the strut and screw it to the top wing</li><li>repeat for the other side</li><li>clip the propeller and the wheels with the pins to the plane</li><li>make funny engine noises and play with your new plane  </li></ul>Update 2023-12-11:Thanks to sgioja and CatWhisker I was able to correct two design flaws (cockpit + wings) and re-oriented the wing support in the print profile. The STLs and the print profile have been updated accordingly.&nbsp;Update 2024-02-17: User doppelt-05 made a very creative add-on to this model. He added a pinwheel propeller so that the propeller spins when the wind is blowing. You can find his model here on makerworld: <a href="https://makerworld.com/en/models/190364#profileId-210130" rel="nofollow"> https://makerworld.com/en/models/190364#profileId-210130</a>&nbsp;&nbsp;Disclaimer: This work by blecheimer is licensed under <a target="_blank" href="https://creativecommons.org/licenses/by-nc-nd/4.0/" rel="nofollow noopener">CC-BY-NC-ND 4.0</a>. You are not allowed to copy this model to other 3D printing websites without my permission.

工具

玩具

顶盖

11
