<p>With the anticipation of the Dune sequel, I thought it'd be a fantastic opportunity to craft a unique gift for my friends.</p><p>This creation is inspired by the House Atreides Ornithopter, as depicted in Denis Villeneuve's recent film adaptation.</p><p><strong>Available in 256x256 to 120x120 </strong><i>(check details for 120x120)</i><strong> printing plate sizes.</strong></p><p>&nbsp;</p><p><span style="color:#E14747;"><strong><u>Assembly Guide avalaible further down</u></strong></span></p><h3><strong>Features:</strong></h3><p>The model can be displayed in either flight or landed modes.</p><p>The parts are designed to fit together with tight fit, eliminating the need for glue. However, given I tunned the fitting with the specific calibration of printer, minor adjustments with a dab of glue might be necessary for others.</p><ol><li><strong>Foldable Wings:</strong> Transition the wings between flight or landed positions. Be mindful that when fully folded, the weight of the wings could tip the model backward.</li><li><strong>Landed configuration:</strong> This is the default configuration in the kit so you can display the model without anything else.</li></ol><figure class="image image_resized image-style-align-center" style="width:75%;"><img src="https://media.printables.com/media/prints/783683/rich_content/f045ae31-46f9-46b8-b5c1-46b0dd05fe5a/screenshot-2024-03-05-160105.png#%7B%22uuid%22%3A%22c21f633d-eca5-4e2e-8576-fc394b5ff88c%22%2C%22w%22%3A1118%2C%22h%22%3A733%7D"></figure><ol><li><strong>Flight configuration:</strong> For those who favor a flight display, you can swap out the ramp and front landing gear with the upgrade kit provided in the downloadable file. I recommend downloading the Stand I created for displaying the model as if it's flying, which you can find below.</li></ol><figure class="image image_resized" style="width:75%;"><img src="https://media.printables.com/media/prints/783683/rich_content/e5ddc8bc-242a-474a-937a-bc8c30309b75/screenshot-2024-03-05-160129.png#%7B%22uuid%22%3A%22193f17cc-9449-4f4c-892c-06cb6c8f1208%22%2C%22w%22%3A1145%2C%22h%22%3A640%7D"></figure><h3>Download the Stand for this kit <a target="_blank" href="https://makerworld.com/en/models/223117#profileId-241123" rel="nofollow noopener">here</a></h3><figure class="image image_resized" style="width:71.7%;"><a href="https://makerworld.com/en/models/223117#profileId-241123" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-03-03_e2feda12f81c6.jpg"></a></figure><h3><strong>Recommended Printing Settings:</strong></h3><p>For optimal assembly, I strongly suggest the following settings, fine-tuned for this kit's precision:</p><ul><li><strong>First layer height :</strong> 0.2 mm</li><li><strong>Layer height :</strong> 0.08 mm</li><li><strong>Wall loops :</strong> 4</li><li><strong>Infill density :</strong> 100%</li></ul><h3>Kit options:</h3><p>I designed the kit with printing bed size in mind so those with small printing bed won't have to scale it down :</p><h4><strong>Standard Kit with Full-Length Wings:</strong></h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_jzh98rsxd7yk.png"></figure><p>Ideal for a 256x256 printing plate, this version boasts the ornithopter's impressive wingspan.</p><blockquote><p>For X and P series of Bambulap Printer you need for this kit to adjust the printer settings as indicated <a target="_blank" href="https://wiki.bambulab.com/en/knowledge-sharing/print-volume-limitations" rel="nofollow noopener">in the official Bambulab Wiki</a></p><figure class="image image_resized" style="width:58.24%;"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_eac8eea287d96.jpg"></figure></blockquote><h4><strong>Compact Kit with Short Wings:</strong></h4><p>For those preferring a smaller footprint, this edition offers abbreviated wings, suitable for a 256x256 printing plate.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_ubbm0hxoi9as.png"></figure><h4><strong>Small bed Kit:</strong></h4><p>An adjusted option without wings for printers with a 180x180 printing plate.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_faebmzhm7e29.png"></figure><h4><strong>Separate Wing Kits:</strong></h4><p>Choose either the full-scale or short wings to pair with the Miniature Kit for custom wing dimensions.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_emccbnkolm6l.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_zvvyu8oxfmcw.png"></figure><h4><strong>Individual Components:</strong></h4><p>Every part is also available separately for those looking to print without the kit aspect or specific replacements.</p><p>&nbsp;</p><h4>120x120 printing beds</h4><p>for 120x120 you will need to print indivudual parts without the kit version, you will need to download specificaly those parts instead of those in the general indivudual parts component. Those parts fit diagonally in your plate</p><ul><li>120x120_Airframe_main</li><li>120x120_Horizontal_tail</li><li>120x120_wings_left</li><li>120x120_wings_right</li></ul><p>&nbsp;</p><p><i>(yes I got a bit carried away by the fun of designing the kit versions :p)</i></p><p>&nbsp;</p><h3><strong>Assembly Guide:</strong></h3><p>Follow the instructions below to build yours, or don't and enjoy the 3D puzzle.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_80f0f7ba085cc.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_643d4851aa544.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-03-04_1da6163b84e0e.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_b42cc82d0dad3.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/696408/2024-02-28_e9d83f36c793d.jpg"></figure><p>I hope you find joy in assembling this model. I'd be thrilled to see your completed builds and hear your valuable feedback.</p>

Dune - House Atreides Ornithopter - Kit

Models

thrutheframe

<h3>NOTE:</h3><p>Please read the instruction guide below. I try to make the guide as comprehensive as possible and will fine-tune it along the way with user inputs.</p><p>I do my best to double-check and test the print profile I create. <span style="background-color:rgb(255,255,255);color:rgb(33,43,54);font-size:16px;">They are up to date with whatever changes I made to the designs. If you are using profiles made by others, please check if they are updated.</span></p><p>&nbsp;</p><h3><strong>UPDATE 06 Mar 2024</strong></h3><p>Expanding the CUE ecosystem, I have added a bracket for Prusa Mk3/4 and a tabletop bracket (CUE UP) for A1 mini and Prusa Mini. Please choose the correct print profile for the different printers. In addition, I am working with US and EU vendors<span style="background-color:rgb(255,255,255);color:rgb(15,20,25);"> to provide CUE and also CUE hardware kit (pre-cut acrylic cover, and all the parts in the Bill of Material) . Users can buy CUE read-to-use or print their own and assemble with the hardware as a project. More information on vendors coming soon. </span></p><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_616e37ccd788c.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-03-06_89d0ba053233f.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-03-06_5be333ad41862.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-03-06_83cc98398603c.png"></figure></td></tr></tbody></table></figure><h3> </h3><h3>INTRODUCTION</h3><p>Living in Singapore, South East Asia, the high humidity makes printing pet-g challenging due to the hygroscopic nature of the material. A spool of pet-g cannot be left in the open for long prints and can result in stringing and print failure. I enjoy printing with <a target="_blank" href="https://store.bambulab.com/collections/petg/products/petg-cf?variant=40741030461555" rel="nofollow noopener">Bambu Lab PETG-CF</a>, but it requires a dry box to use on the Bambu Lab A1. So I designed <strong>CUE</strong>.</p><p>&nbsp;</p><p><strong>CUE</strong> is an acronym for Cute, Unique, and Enclosed. It is a single-spool passive dry box CU-case that can be slotted into the CU-bracket (mounted on the A1);</p><ul><li>The CU-case with the filament spool inside can be removed and stored away when not in use.</li><li>The spool rolls on PTFE tubes for smooth movement.</li><li>A reusable silica bead cartridge (Dri-Cell) can be easily replaced without the need to open the CU-case.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_616e37ccd788c.png"></figure><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_2f2f8c7ff0a08.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_f5f4cfd5311a8.png"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><figure class="table"><table><tbody><tr><td><p>Due to design limitations, CUE will fit spools with the following dimensions.</p><ul><li>OD 200-201mm</li><li>ID 52-54mm</li><li>Thickness ≤ 71mm</li></ul><p>Spools tested:</p><ol><li>Bambu Lab spool</li><li>Polymaker cardboard spool</li><li>Hatchbox</li><li>Prusament spool</li><li>Esun plastic spool</li><li>FusRock clear plastic spool</li><li>Creality spool</li></ol></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-16_695be7f03b932.png"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><p>&nbsp;</p><p>As with all my design process, I set a few parameters and requirements when designing <strong>CUE</strong>:</p><ul><li>Easy and lean design to print.</li><li>Easy to use ( as much as possible)</li><li>Mounting on the top gantry of the A1</li><li>Sturdy and reliable when fully loaded.</li><li>Secure mounting using screws.</li><li>Keeps the air within the case dry using reusable silica desiccant.</li></ul><p>&nbsp;</p><h3>BOM</h3><figure class="table" style="float:left;width:66.02%;"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td>Ø6mmxL3mm magnets</td><td>6pcs</td></tr><tr><td>M3xOD5mmxL4mm (or M3xOD5mmxL3mm) Brass Inserts</td><td>6pcs</td></tr><tr><td>M3x10mm BHCS (or M3x8mm BHCS)</td><td>6pcs</td></tr><tr><td>3mm Acrylic Cover</td><td>1pcs (svg & dxf in zip file)</td></tr><tr><td><p>PTFE tube OD4mmID2.5mm</p><ul><li>72mm</li><li>130mm</li></ul></td><td><p>&nbsp;</p><p>4pcs (use the 72mm rig)</p><p>1pcs</p></td></tr><tr><td>PC4-M10 Pneumatic Coupler</td><td>1pcs</td></tr></tbody></table></figure><p>&nbsp;</p><p>&nbsp;</p><h3> </h3><h3> </h3><h3> </h3><h3> </h3><h3> </h3><h3> </h3><p>&nbsp;</p><p>&nbsp;</p><h3>PRINT GUIDE</h3><p>One set of <strong>CUE</strong> (plates 1,3,4) uses about 418gm of filament and takes 11h10m</p><p>The rigs and accessories (plate 6) use 63gm of filament and takes 1h55m</p><p>The project profile is tuned for Bambu Lab A1 using <a target="_blank" href="https://store.bambulab.com/products/pla-basic-filament" rel="nofollow noopener">Bambu Lab PLA Basic filaments</a>.</p><p>&nbsp;</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-03-06_421fd33756403.png"></figure><p>&nbsp;</p><h4><u>Build Plate 1 & 2</u></h4><ul><li>You only need to print either plate 1(dual colour) or plate 2 (single colour).</li><li>The time taken to print single or dual colour is about the same as there are only 3 layer changes.</li><li>I prepare 2 sets of Dri-Cell to be printed because it's always good to keep a spare set.</li></ul><p>&nbsp;</p><h4><u>Build Plate 3</u></h4><ul><li>This is the CU-case for the filament spool.</li><li>Support is needed.</li><li>Print time is about 7h30m and uses 288gm of filament using my print profile.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_0a0cb0e1a49dd.png"></figure><p>&nbsp;</p><h4><u>Build Plate 4</u></h4><p>Consist of the cu-bracket for A1 (or Prusa Mk3/4 if you are the 3mf for Mk3/4)</p><p>&nbsp;</p><h4><u>Build Plate 5</u></h4><p>Consists of the stl for CUE UP, a tabletop stand for A1 mini and Prusa mini.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-03-06_c25c17b52bfd4.png"></figure><h4> </h4><h4><u>Build Plate 6</u></h4><p>Consist of:</p><ul><li>2 sets of ptfe tube covers and connectors.</li><li>72mm rig to cut the ptfe rollers. You will need 4 pcs per CU-case</li><li>Cu-case magnet installation rig.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_62f9fd0020a9b.png"></figure><p>&nbsp;</p><h3>INSTALLATION GUIDE</h3><p>Before installation, remove the support structures on the CU-case. You will also need to get the acrylic cover cut to size: the OD=215.6mm and ID=32mm. I have included the dxf and svg in a zip file under the<i> RAW Model Files</i> section.</p><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-12_e51738603c08a.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-12_9be5183d39e2c.png"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><ol><li>Install the Ø6mmxL3mm magnets into the CU-key and CU-bracket. Ensure the polarity is right so that both parts snap together.</li><li>Install the M3xOD5mmXL4mm brass inserts into the CU-bracket.</li><li>Slot the CU-bracket onto the top aluminium gantry of the A1, roughly at the centre. Do not install the CU-bracket at the edge of the top gantry. This is because it will knock against the x-axis gantry. You need a minimum of 35mm gap.</li><li>Use the M3x10mm screws to secure the CU-bracket with the CU-bracket cover.</li></ol><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_04e68d5a469b2.png"><figcaption>1</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_2d18be8cbbf19.png"><figcaption>2</figcaption></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_12b5fc3cfdce2.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_4a74dbebcb304.png"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><ol><li>Install the M3xOD5mmXL4mm brass inserts into the Dri-Cell.</li><li>Use the M3x10mm screws to secure the grill cover to the Dri-Cell when in use.</li><li>Insert Dri-Cell into CU-case to check fitting. If fitting is an issue, you will need to reprint the grill cover with more elephant-foot compensation (0.18mm)</li><li>If the fitting is good, press fit 2 Ø6mmxL3mm magnets into the Dri-cell.<ul><li>Please ensure the polarity of the magnets is in the same direction. <strong>(VERY IMPORTANT).</strong></li><li>The holes are supposed to be tight (Ø6.1mm) , I use a mallet to tap them in.</li><li>The Dri-Cell holds up to 60 grams of silica desiccant which for me can last around 3 weeks.</li></ul></li></ol><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_c48f8a8fc7b71.png"><figcaption>1</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_9d2a2a81b3149.png"><figcaption>2</figcaption></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_0d932618cbc42.png"><figcaption>3</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_acacbfdabb841.png"><figcaption>4</figcaption></figure></td></tr></tbody></table></figure><p>&nbsp;</p><ol><li>Insert the CU-case into the CU-case magnet rig</li><li>Place the setup on a solid table to press fit 2 Ø6mmxL3mm magnets into the CU-case.</li><li>Please ensure the polarity of the magnets is in the same direction and attracts the Dri-Cell.<ul><li>These magnets are what keep the Dri-Cell firmly attached to the CU-case. <strong>(VERY IMPORTANT).</strong></li><li>The holes are designed at Ø6.2mm, I use a mallet to tap them in.</li><li>If they happen to be loose-fitting, use super glue.</li></ul></li><li>Install the PC4-M10 pneumatic coupler and insert the 120mm PTFE tube thru the coupler.</li><li>Use the ptfe tube rig to cut 4 pcs of 72mm each. These tubes will act as rollers for the spool.</li><li>Use a 4mm drill bit to push thru the 4 roller holes on the CU-case to remove the single-layer support (optional)</li><li>Inset the ptfe tube into the holes.</li><li>Ensure that the ptfe tube is flush to the edge.</li></ol><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_ddf4ec6a0f75.png"><figcaption>1</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_8afe4cc5dfe68.png"><figcaption>2</figcaption></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_c6447598a8eed.png"><figcaption>3</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_e83df434604b.png"><figcaption>4</figcaption></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-10_009add9b093e8.png"><figcaption>5</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_149e32398a77.png"><figcaption>6</figcaption></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-21_1a3e6bb3e3e18.png"><figcaption>7</figcaption></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-10_70118446991aa.png"><figcaption>8</figcaption></figure></td></tr></tbody></table></figure><p>&nbsp;</p><p>Images below show how to install the spool into the CUE and onto the bracket.</p><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-22_1f77eee5bd7b1.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-22_b764e8fb942ce.png"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><p>&nbsp;</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/648695/2024-01-22_433c74edc0242.gif"></figure><p>&nbsp;</p><p>&nbsp;</p><p>It might take a while to get used to loading and unloading filament. I have testing it for a month now (different prototypes and the first release). So far it has been keeping my filament relatively dry. All the best and happy printing.</p><p>&nbsp;</p><h3>CONCLUSION</h3><p>To date, my designs are free to download and use. There is no Patreon or OnlyFan (hahaha). If you like my designs and wish to contribute to my coffee addiction & help fund the filaments and materials needed for prototyping, a donation of $5-$10 to <a target="_blank" href="https://ko-fi.com/thrutheframe" rel="nofollow noopener">Ko-fi</a> or <a target="_blank" href="https://www.paypal.com/paypalme/shannonheng" rel="nofollow noopener">paypal.me</a> will be greatly appreciated.</p><p>&nbsp;</p><h3><strong>CAVEAT</strong></h3><p>As with all my designs, Prototyping and testing were conducted to ensure printability and meet my own expectations. However, I understand it may and may not work for you. I would request that you read all instructions and print and install them at your own discretion.</p><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p>
