user_3622428580

Benjamin Kott

<h3>Organizer Box (Fully Parameterized) with Fusion 360 Source Files.</h3><p>Use the available print profiles if you want to have a specific size, if you are more into tinkering fetch the Fusion 360 file and enjoy all the customizable parameters. The model is designed so that all punch holes are auto-calculated and evenly spaced. No need to fiddle around with manual settings, just define the basic parameters and watch the magic math 😊. Punchhole rows are auto-calculated and will center on the outer wall.</p><p>&nbsp;</p><figure class="media"><oembed url="https://youtu.be/_2nHOIhereM"></oembed></figure><h3><strong>Customizable Parameters:</strong></h3><ul><li>Height</li><li>Width</li><li>Length</li><li>Wall thickness</li><li>Punchhole Diameter</li><li>Punchhole Spacing</li><li>Corner Radius</li><li>Save space on the top and bottom</li></ul><h3><strong>Customizing Tips:</strong></h3><ol><li>If you adjust the width and length, it can be helpful to adjust the corner radius before making changes.</li><li>If you adjust the corner radius, ensure that the desired size fits your desired width and length.</li><li>If you want to create a round object. please ensure the width and length are matching. Configure the corner radius to ½ - 0.01 of the width or the length. Example: You have a width of 80, set the corner radius to 39.99.</li></ol><h3><strong>Why another box model?</strong></h3><p>There are a lot of box models already available, but all I found were static,</p><p>or have features or design aspects that did not fit my needs.</p><p>&nbsp;</p><p>I need a model flexible, that can easily adapt to any size I need - and also would be approved by my wife.</p><p>Maybe I also wanted to play around with repeating auto-calculating patterns in Fusion 360, okay okay - you got me.</p><p>&nbsp;</p><p><strong>I hope you enjoy the design, please leave a comment/rating if you enjoy it or share your feedback!</strong></p><p>&nbsp;</p><h3><strong>Updates:</strong></h3><ul><li>30.06.2024<ul><li>Added 18x14x6cm <a target="_blank" href="https://makerworld.com/en/models/103266#profileId-434003" rel="nofollow noopener">https://makerworld.com/en/models/103266#profileId-434003</a> </li><li>Added 18x14x10cm <a target="_blank" href="https://makerworld.com/en/models/103266#profileId-434006" rel="nofollow noopener">https://makerworld.com/en/models/103266#profileId-434006</a> </li></ul></li><li>20.02.2024<ul><li>Added 20x10x6cm <a target="_blank" href="https://makerworld.com/en/models/103266#profileId-214791" rel="nofollow noopener">https://makerworld.com/en/models/103266#profileId-214791</a></li><li>Added 10x10x6cm <a target="_blank" href="https://makerworld.com/en/models/103266#profileId-214795" rel="nofollow noopener">https://makerworld.com/en/models/103266#profileId-214795</a></li><li>Added 15x10x6cm <a target="_blank" href="https://makerworld.com/en/models/103266#profileId-214801" rel="nofollow noopener">https://makerworld.com/en/models/103266#profileId-214801</a></li></ul></li><li>01.01.2024<ul><li>Added 2 new cylindric versions<ul><li>10x10x13cm <a target="_blank" href="https://makerworld.com/de/models/103266#profileId-126695" rel="nofollow noopener">https://makerworld.com/de/models/103266#profileId-126695</a></li><li>8x8x10cm <a target="_blank" href="https://makerworld.com/de/models/103266#profileId-126713" rel="nofollow noopener">https://makerworld.com/de/models/103266#profileId-126713</a></li></ul></li><li>Changed extrusion for the holes in the Fusion 360 model</li></ul></li><li>24.12.2023<ul><li>Fixed baseplate calculation in the Fusion 360 model</li></ul></li></ul><h3>More Fusion 360 Parameterized Models</h3><ul><li>Stackable Storage Bin<br><a target="_blank" href="https://makerworld.com/en/models/114250" rel="nofollow noopener">https://makerworld.com/en/models/114250</a></li><li>Organizer Box Diamond Edition<br><a target="_blank" href="https://makerworld.com/en/models/147775" rel="nofollow noopener">https://makerworld.com/en/models/147775</a></li><li>Modern Vase 1<br><a target="_blank" href="https://makerworld.com/en/models/108166" rel="nofollow noopener">https://makerworld.com/en/models/108166</a></li><li>Under Desk Drawer<br><a target="_blank" href="https://makerworld.com/en/models/145324" rel="nofollow noopener">https://makerworld.com/en/models/145324</a></li></ul><p>&nbsp;</p><p>&nbsp;</p><figure class="table"><table><tbody><tr><td style="width: 50%"><figure class="image"><a href="https://makerworld.com/en/models/114250" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000103266/design/2024-03-23_519e073d57512.jpg"></a></figure><p><a target="_blank" href="https://makerworld.com/en/models/114250" rel="nofollow noopener"><strong>Stackable Storage Boxes</strong></a></p></td><td style="width: 50%"><figure class="image"><a href="https://makerworld.com/en/models/147775" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000103266/design/2024-03-23_fb6186fdc76a4.jpg"></a></figure><p><a target="_blank" href="https://makerworld.com/en/models/147775" rel="nofollow noopener"><strong>Boxes Diamond Edition</strong></a></p></td></tr><tr><td style="width: 50%"><figure class="image"><a href="https://makerworld.com/en/models/392542" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000103266/design/2024-03-24_bbcd7d56b5ac1.jpg"></a></figure><p><a target="_blank" href="https://makerworld.com/en/models/392542" rel="nofollow noopener"><strong>Stackable Boxes</strong></a></p></td><td style="width: 50%"> </td></tr></tbody></table></figure>

Organizer Box / Boxes

办公文具

benlevi

<h2>BLV - AMS Riser for X1C V3.1 Final</h2><figure class="table"><table><tbody><tr><td style="background-color: hsl(0, 0%, 30%)"><h3><span style="color: hsl(0,0%,100%)">Introduction</span></h3></td></tr><tr><td><p>I&#39;m Ben Levi, and I want to talk to you about this BLV AMS Riser that I designed:<br>So, when the AMS is sitting on top of the printer, you can&#39;t really see what the printer is doing, and you can&#39;t even open the top glass cover to let some air in when you&#39;re printing High temp stuff. basically, something that will hold the AMS and free your Glass top cover will be a good solution for that. Now I&#39;ve seen some similar AMS risers before, but none of them really wowed me.. i think..</p><p>That&#39;s why I decided to come up with this sleek BLV AMS Riser design, easy to use, easy to put together, and reliable. I even added two handy drawers for your tools and stuff, a special shelf that can hold up to 4pcs Build Plates, built-in Dual LED strips. Sure, it took me a while, but I got it (almost..) done.</p><p>As some of you may know, I love contributing to this wonderful community, which is why I chose to share with you my project without any fee or money. Among other things, I&#39;ve also given you access to the original CAD files (F3D,STEP) so that you can easily make changes, add, and improve as you see fit. Please, if you publish a remix, make sure to link it to the original project as a remix so that others can benefit from your effort. I kindly request not to use the files for commercial purposes without explicit permission from me.</p><p>&nbsp;</p><p>Thanks,<br><strong>Ben Levi</strong></p><p><a target="_blank" href="https://www.paypal.com/paypalme/BenBLV" rel="nofollow noopener">If you want, buy me a beer </a>:)</p><p>&nbsp;</p></td></tr></tbody></table></figure><figure class="image image_resized" style="width: 58.95%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-09-25_370cc55ef0c1d.png"></figure><h2>Main features</h2><p>These are just a few design features I&#39;ve planned. If you have more ideas, please share them with me, and I can incorporate them into the design. Also, feel free to add remixes (CAD files are available for download).</p><ul><li>Easy installation</li><li>Dual LED strip<br>installed in optimal angle for LiDAR.</li><li>AMS riser</li><li>Top glass Holder</li><li>2 drawers for tools (with version for tools)</li><li>4 x Build Plates holder</li><li>Rubber Gasket for the glass</li><li>Customised Panels</li><li>access to original buttons</li><li>No screws required</li><li>CAD files available (F3D,STEP)</li></ul><figure class="table"><table><tbody><tr><td><p>&nbsp;</p><figure class="image image_resized" style="width: 92.39%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_18d41f48cf37f.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_a237ff37d0da5.png"></figure></td></tr></tbody></table></figure><h2> </h2><h2>How to print and where to begin?</h2><p>I must admit, if you&#39;re in search of a quick two-hour print and you&#39;re finished, this may not be the right place for it. To initiate and successfully complete this project, a considerable amount of filament and time investment is necessary. Here are the essential resources you&#39;ll be required to invest:</p><figure class="table" style="width: 70.13%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td><p style="text-align: center"><strong>Printing Time</strong></p></td><td>70~85 print hours - including color switching!</td></tr><tr><td><p style="text-align: center"><strong>Printer</strong></p></td><td>X1 Carbon, P1S, P1P, X1 or Other + AMS (Optional).</td></tr><tr><td><p style="text-align: center"><strong>Filament</strong></p></td><td><ul><li>2 kg - PLA/PETG Main filament color (GREY)</li><li>0.5 kg - PLA/PETG Secondary filament color (GREEN)</li><li>14 g - PLA/PETG Black filament for text (BLACK)</li><li>34 g - TPU flexible filament for your Gasket (BLACK)</li></ul><p>* Feel free to choose your own colors.</p></td></tr><tr><td colspan="2"><figure class="image image_resized" style="width: 98.07%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-04_77b29f1dbec36.jpg"></figure></td></tr></tbody></table></figure><p>I tried to keep the project in as few parts as possible and minimize the use of screws and glue. I&#39;ve also included three images that show all the parts and file names to help you easily know what to print and what to remove. <strong>Click on the pictures to enlarge.</strong></p><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_5539d72c1e42.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_1698b67225759.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_34f66213cbfb2.jpg"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><p>&nbsp;</p><h2>Printing settings</h2><p>Under each file name, I&#39;ve added a recommendation on how to print that component. Please note that these are just suggestions, and you can choose the filament type, infill percentage, and wall count according to your preferences.</p><p>Additionally, I&#39;ve attached an image below that illustrates how to orient each component on the print bed for optimal results <strong>(click to enlarge):</strong></p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_c8a5b6a960393.jpg"></figure><p>Please note that you will find in also wonderful print profiles from the community too :)</p><h2> </h2><h2>Assembly instructions</h2><p>I think the best way to demonstrate the assembly is through a video. Therefore, I&#39;ve created a short animation video for you that illustrates the assembly process and the sequence of the project&#39;s components. Enjoy:</p><h3> </h3><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_f7b5fb7649351.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_0604a5a98bf6d.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_4edcdff3d535e.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_f3764fb52c104.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_7b9abe53ec9f3.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_611a02308f5c5.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_d8d2275f63acd.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_f59c54b41a2bd.png"></figure></td></tr></tbody></table></figure><h3>Buttons assembly:</h3><p>Please print x2 Button insert.stl files and assemble as the photo below:</p><p><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-09-29_89172a00d321c.jpg"></p><p>&nbsp;</p><h2>Recommended Remix:</h2><ul><li><a target="_blank" href="https://makerworld.com/en/models/27690#profileId-24067" rel="nofollow noopener">Front Panels for P1P remix</a></li><li><a target="_blank" href="https://makerworld.com/en/models/28098#profileId-24385" rel="nofollow noopener">new Drawers with Clean look and version with Text</a></li><li><a target="_blank" href="https://makerworld.com/en/models/28948" rel="nofollow noopener">Spool Holder add on on the rear</a></li><li><a target="_blank" href="https://makerworld.com/en/models/29315" rel="nofollow noopener">Honeycomb panels for the sides</a></li></ul><h2>Links:</h2><ul><li><a target="_blank" href="https://s.click.aliexpress.com/e/_Dk1tOEL" rel="nofollow noopener">COB 5mm Dimmable LED strip</a> suitable to the project.<br>please make sure to choose: “white” and “Strip-USB Button” options.<br> </li></ul><h2>Colors ideas:</h2><figure class="image image_resized" style="width: 59.65%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_5f2218eae1ea7.jpg"></figure><h2>How to download CAD (f3d,Step) files:<br><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-03_16ad19d8f61ba.jpg"></h2><h2> </h2><h2>Selected User makes:</h2><figure class="table" style="width: 90.79%"><table class="ck-table-resized" style="border: 1px solid hsl(0, 0%, 100%)"><colgroup><col><col><col></colgroup><tbody><tr><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-04_3aaa07d5a3c1e.png"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 86.34%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-03_f5f9b0b8d1086.jpg"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 100%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-03_ee05726581f83.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr><tr><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 100%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_8efeadcf004be.jpg"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 79.61%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-04_c0866329e4121.jpg"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 92.92%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_f106d497bd601.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr><tr><td style="border: 1px solid hsl(0, 0%, 100%)" colspan="3"><figure class="image image_resized" style="width: 94.67%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_d8fbe88a9ea.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr><tr><td style="border: 1px solid hsl(0, 0%, 100%)" colspan="3"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_0d0d9ff1ec084.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr></tbody></table></figure><p>&nbsp;</p><figure class="table"><table><tbody><tr><td style="background-color: hsl(0, 0%, 60%)"><h2><span style="color: hsl(0,0%,100%)">Changelog</span></h2></td></tr><tr><td><ul><li>19/9/23 - published first prototype. not meant yet to print.</li><li>19/9/23 - uploaded v1.1 with angled glass holder and fixed Size drawer, stronger rear part.</li><li>23/09/23 - Left/Right/Rear Panel edges optimization for better surface finish.</li><li>24/9/23 - Huge update v1.2 !<ul><li>Extreme optimization to main parts, now it&#39;s 6 parts but much less support and faster to print.</li><li>Added wire channel for the LED&#39;s wires.</li><li>Added lock pins to TPU gasket.</li><li>new secure method to front and rear parts in addition to the dovetails.</li><li>Optimization to all decorative panels.</li><li>2 x Button frame cover with logo for P1P and P1S.</li><li>increased glass holder degrease to prevent movements.</li><li>Deeper AMS leg&#39;s socket, securing the AMS in it&#39;s place.</li><li>Added special drawer with accessories. it has a place for the H1.0-H2.0 HEX keys, 2 x Hotends, 5 cutters, 4 x wipers, screws, glue and needle.</li></ul></li><li>25/09/23 - updated new version 1.3 with measurements fix.</li><li>29/9/23 - added 2 remixes: clean front drawer, drawers with text, Dash front parts for P1P.</li><li>29/9/23 - added Button insert.stl + button images assembly.</li><li>30/9/23 - remix section update! spool holder, honeycomb panels added.</li><li>4/10/23 - New optimized slicing profile! faster, less filament, better support!</li><li>02/03/24 - added more support to side model.</li><li>04/04/24 - changed print profile for wider base.</li><li>22/05/24 - optimized structure for vibrations.</li><li>31/05/24 - changed Internal structure to be more rigid.</li><li>29/06/24 - added BOM items<br> </li></ul></td></tr></tbody></table></figure>

BLV - AMS Riser for X1C / P1P / P1S V3.1 Final

工具

MyisSs

<p>我很喜欢 <a target="_blank" href="https://makerworld.com/zh/models/252931?from=search#profileId-269297" rel="nofollow noopener">Apple Watch Charging Stand 来自 Dan_ID - MakerWorld</a> 的设计，但是我没有苹果手表，我只有华为GT3pro ,所以我按照前的设计师的样式进行了重新画图，并修改了尺寸，手表支架内部直径为37.5毫米，现在底座完全匹配我的无线充电器。</p><p>&nbsp;</p><p>I really like the design of the  <a target="_blank" href="https://makerworld.com/zh/models/252931?from=search#profileId-269297" rel="nofollow noopener">Apple Watch Charging Stand 来自 Dan_ID - MakerWorld</a> , but I don't have an Apple Watch, I only have a Huawei GT3pro, so I redrew it in the style of the previous designer and modified the size, the watch stand has an internal diameter of 37.5 mm, which perfectly matches my wireless charger.</p><p>&nbsp;</p><p>&nbsp;</p>

办公文具

工具

家居个护
