I&#39;ve been working on making 3D-printable fishing reel from skratch for a while now and finally got it done. I will continue to work on this design to provide different options and visual appearances.   Introducing my 3D-printable fly fishing reel, engineered for simplicity and performance. Designed to be easily assembled, this reel integrates seamlessly with a 608 ball bearing and utilizes standard hardware including threaded inserts and bolts.&nbsp;Bill of materials, main dimensions and assembly instructions in better resolution are attached as PDF-file.&nbsp;Key features:<ul><li>Efficient Design: The entire reel requires just 93 grams of filament, making it lightweight and economical to produce.</li><li>User-Friendly Assembly: Designed with DIY enthusiasts in mind, the assembly process is straightforward, requiring only common tools and components.</li><li>High Compatibility: The reel uses a 608 ball bearing, a standard part that&#39;s widely available, ensuring smooth operation and easy replacement.</li><li>Durable and Reliable: Constructed with sturdy materials and standard hardware, this reel is built to withstand the rigors of fly fishing.</li></ul>&nbsp;Options:<ul><li>As per revision 02 on June 8th 2024 - Reel base has right and left handed option. Seperate print profiles for both are created.</li><li>As per revision 03 on June 13th 2024 - Introducing the &#39;Sleek Spiral&#39; design – featuring elegant, concentric curves that enhance style with a modern twist. Fully backwards compatible with the original version. Files for the new design (Items 1-3) are uploaded as a seperate plate and raw STLs.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-13_ea225e47a4eb7.png"></figure>&nbsp;&nbsp;Hardware:<ul><li>1 x 608 Ball Bearing</li><li>2 x CNS 4557 - M4 x 0.7 x 10 bolt or similar socket head bolt</li><li>2 x CNS 4355 - M 4 x 6 bolt or similar</li><li>1 x AS 1427 - M2 x 6 or similar countersunk M2 bolt</li><li>4 x M4 threaded inserts</li><li>1 x M2 threaded insert</li></ul>&nbsp;Bill of materials, exploded view:<figure class="image"><a href="https://postimg.cc/5H1V2m0y" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_e7d6ed362a347.png"></a></figure> Main dimensions:<figure class="image"><a href="https://postimg.cc/jD7MzKmF" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_74a6da39c96c7.png"></a></figure> Assemble instructions:&nbsp;<figure class="image"><a href="https://postimg.cc/XZNynkfk" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_149224db36446.png"></a></figure><figure class="image"><a href="https://postimg.cc/jW9qBHZ5" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_38b22746d2376.png"></a></figure><figure class="image"><a href="https://postimg.cc/SYGhQC7c" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_0166a75eab6bc.png"></a></figure><figure class="image"><a href="https://postimg.cc/7fY6GZGq" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_ed9a70a34cd6e.png"></a></figure><figure class="image"><a href="https://postimg.cc/HVJqPqFQ" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_92f05a45f33cd.png"></a></figure><figure class="image"><a href="https://postimg.cc/qhzwvTsw" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_f51501cc49b33.png"></a></figure><figure class="image"><a href="https://postimg.cc/7GF3PTYP" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000486875/design/2024-06-08_d4afb4a22ec46.png"></a></figure>&nbsp;@Update, Revision 02 | June 8th 2024&nbsp;General revision descriptionAs few of you have already mentioned in the comment section, I forgot to include items 8 and 9. These are now included in the print profiles. Original file included base meant for left-handed, I now added option for right-handed. &nbsp;Geometry updates<ul><li>Item 4 - Mounting hole diameter increased from 6 mm to 7.2 mm to provide more options for bolt selection.</li><li>Item 7 -  Hole diameter increased from 5 mm to 5.5 mm for easier installation of M4 threaded inserts.</li><li>Item 15 - BOM had a mistake M3 bolts instead of M4 bolts. Preferable bolts replaced with correct size different type and size. </li></ul>BOM<ul><li>Replaced Item 15 with correct sized bolts. M3 → M4</li></ul>&nbsp;@Update, Revision 03 | June 13th 2024&nbsp;General revision descriptionIntroducing the &#39;Sleek Spiral&#39; design – featuring elegant, concentric curves that enhance style with a modern twist. Fully backwards compatible with the original version. Files for the new design (Items 1-3) are uploaded as a seperate plate and raw STLs.
