Crested Gecko was test printed down to 50%. &nbsp;10% infill3 to 4 lines .1 or .2 height No support Print in place. Print with raft or brim if doesn't stick.&nbsp;Please feel free to post pics of your makes. I would love to see them. &nbsp;If you would like to sell the prints join us on Tribes or Patreon for a seller's permit. &nbsp;Copyright:All The Dragons Dens designs are protected by the Copyright Law. By purchasing, you do not have the right to sell any digital files or printed models.The Digital files are never to be re-sold, shared, or given away.&nbsp;To legally sell the printed models, you can get my permission by joining our community- <a target="_blank" href="http://patreon.com/TheDragonsDen411" rel="nofollow noopener">patreon.com/TheDragonsDen411</a>&nbsp;You can join The Dragon's Den Discord to exchange with me and the community. <a target="_blank" href="http://discord.gg/k2KFnXNuBV" rel="nofollow noopener">discord.gg/k2KFnXNuBV</a>

Crested Gecko

toys

bust4rhymes

I wanted a side spool holder that doesn't require the BL metal bracket wich i didn't have.After searching for different models, none was satisfying or didn't work fine (Filament too hard to pull and leads to under extrusion).So, i came up with the idea or merging two different design all together to do what i intended.I simply used the idea from <a target="_blank" href="https://makerworld.com/en/models/65069#profileId-68397" rel="nofollow noopener">Poli27</a> but I’ve redone the whole design from scratch with Onshape.I adapted the design so i can fit the spool design from <a target="_blank" href="https://www.printables.com/fr/model/243318-ender-5-plus-filler-filament-holder-compact-update" rel="nofollow noopener">Termiman</a>.&nbsp;BENEFITS:<ul><li>No OEM bracket required.</li><li>Easy spool swap</li><li>Easy to feed filament inside the PTFE</li></ul><img src="https://makerworld.bblmw.com/makerworld/draft/692779/2024-03-12_c67922d214fd6.gif">&nbsp;BOM:<ul><li>2pcs 608 bearing <a target="_blank" href="https://tinyurl.com/mpwy9uv6" rel="nofollow noopener">Amazon link</a></li><li>1pcs PC4-M10 PTFE connector <a target="_blank" href="https://tinyurl.com/2vmkw2a7" rel="nofollow noopener">Amazon link</a></li><li>4pcs M4 x 20 Bolts</li><li>4pcs M4 x 20 Bolts</li><li>8 pcs M4 Nuts</li><li>17cm PTFE from Bambu Lab *Important so the filament slide freely.</li></ul>&nbsp;PRINTING:<ul><li>Nozzle: 0.4mm</li><li>Layer Height: 0.2mm</li><li>Walls: 4+</li><li>Infill: Gyroid</li><li>Infill : 15%</li><li>Brims: Disabled</li><li>Textured PEI plate</li></ul>Support required for the roller (under and at both ends) *This part will require a little bit of sanding for the bearing to fitOther parts only need support for the nut’s holes, so they are clean of any lost filaments.&nbsp;Keep the profile's orientation and settings for better strenght.I used Sunlu PLA+ which is enough for the weight from a 1kg spool.Make sure to use the profile settings or use PETG if you prefer.&nbsp;AMS:&nbsp;There seems to be different versions of the AMS. So before you print the clamps, check the rib size of your AMS.This should enable all model to be compatible but i only have one model, so this have to be checked.&nbsp;ASSEMBLING:<ul><li>Insert One bearing on the spool and fit the roller where the four mountings’ holes are. Then insert the second bearing and gently fit the bearing at the other end of the "Guide".</li></ul>&nbsp;<img src="https://makerworld.bblmw.com/makerworld/draft/692779/2024-03-12_d7442db12779d.png" alt="Une image contenant Quincaillerie, fournitures de bureau, intérieurDescription générée automatiquement"> <img src="https://makerworld.bblmw.com/makerworld/draft/692779/2024-03-12_bf02f2ffd5e83.png" alt="Une image contenant intérieur, fournitures de bureau, outil, solDescription générée automatiquement">&nbsp;<ul><li>Insert 4x M4 Nut on the back of the "Side Bracket" also on each "clamp"</li><li>Screw the "Guide" with 4x M4 x 20 screws.</li><li>Screw all three clamps at the bottom with 3x M4x16 screws but don’t tight them yet.</li><li>Screw the M4-10 pneumatic connector making sure not to tear of the mount (should be pretty strong but...)</li></ul>&nbsp;INSTALLING:<ol><li>Take off the AMS from the printer.</li><li>Loosen the 3x M4 screws and slide the clamp inside the ribs making sur they seat all the way in and tight all three screws.</li><li>Put the AMS flat on a table a make sure its stays on all four rubber feet (not the printed bracket).</li><li>Put the AMS back on the printer.</li><li>Attached the PTFE tube with the Y connector you are using. (I'm using 17cm PTFE reaching the Y connector on the back side.)</li></ol>&nbsp;NOTE:This design is compatible with the Y connector "The Smoothy". Longer PTFE tube may be required with another Y connector.Go check this excellent design: <a target="_blank" href="https://makerworld.com/en/models/18174#profileId-17021" rel="nofollow noopener">https://makerworld.com/en/models/18174#profileId-17021</a>&nbsp;SPECIAL THANKS:&nbsp;Big shout out to Poli27 and Termiman for their work that inspire this remix.Go check the original design:<a target="_blank" href="https://makerworld.com/en/models/65069#profileId-68397" rel="nofollow noopener">https://makerworld.com/en/models/65069#profileId-68397</a><a target="_blank" href="https://www.printables.com/fr/model/243318-ender-5-plus-filler-filament-holder-compact-update" rel="nofollow noopener">https://www.printables.com/fr/model/243318-ender-5-plus-filler-filament-holder-compact-update</a>&nbsp;&nbsp;
