Happy Halloween! heres an Oogie Boogie with Jack Skellington LED light box.

Oogie Boogie and Jack Skellington LED Light Box

Halloween

JamesThePrinter

***Christmas and Halloween Cases are identical - Just add your new scenes*** Light up different Christmas scenes in this display. An LED tea light candle is required. &nbsp;The display features a door that opens to allow access to the tea light. Use a section of 1.75mm filament inside the hinge to connect the door to the case. Depending on your printer/setup, this hole may be on the tight side or a bit loose. If tight, drilling out the hole may help. If it is slightly oversized, I suggest melting the end of the filament piece with a soldering iron or lighter.&nbsp;I have included a separate liner. This allows you to print the case in a dark color, but line the inside with a lighter color to allow for more reflection of light outward, making everything brighter.&nbsp;For a complete display, you will need:<ul><li>1x Case</li><li>1x Door</li><li>1x Knob</li><li>1x Snap Ring</li><li>1x Liner - Optional</li><li>1x (minimum) Scene - You can easily remove the snap ring to swap out scenes as desired</li></ul>Check out the rest of my Christmas models <a target="_blank" href="https://makerworld.com/en/u/1360890085/collections/69417" rel="nofollow noopener">here</a>!&nbsp;<h4>Print Settings</h4>No special setting are needed for the display case, door, knob, snap ring and liner. &nbsp;Scenes Print SettingsPrint the scenes with 100% infill. The scenes also require color changes:<ul><li>The bottom 3 layers <ul><li>white or clear</li></ul></li><li>The top 2 layers <ul><li>should be black for most scenes</li><li>Blue works well for the snowflake</li><li>If you have an MMU/AMS, other colors can be added as well</li></ul></li></ul>&nbsp;<h4>Assembly</h4>Glue the knob into the door. Only a very small amount is needed.<figure class="image image_resized" style="width: 535.5px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000041177/design/c2ff42e5-4f47-41e8-8905-382ea68f6cfe.webp"></figure>Put the door in place and latch it. Use a 20mm piece of 1.75mm filament to connect the 3 sections of the hinge. If the filament goes in very easily, it may be a good idea to heat up the top end of the filament ‘pin’ and press it flat. This will prevent the pin from falling through later on.<figure class="image image_resized" style="width: 535.5px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000041177/design/230e3f93-7a69-4e0a-8026-060800c5ea3a.webp"></figure>Open the door. Insert a scene into the opening (image facing outward). Insert the snap ring behind the scene by gently squeezing and placing it into the groove (see red arrow below).<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000041177/design/164034e6-1484-4bc7-a435-e0a956565206.webp"></figure>If you are using a liner, slide it inside the case. This may be a tight fit. Go slowly and be sure to slide it in evenly on all sides.<figure class="image image_resized" style="width: 535.5px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000041177/design/96f9e1cf-982a-4e8f-be08-881a51506e3b.webp"></figure>Turn on your tea light and close the door.&nbsp;&nbsp;<a target="_blank" href="https://www.buymeacoffee.com/JamesThePrinter" rel="nofollow noopener">Buy Me A Coffee</a>&nbsp;The following filaments were used in the pictures above:Display Cases<ul><li>Bambu Lab Matte Charcoal PLA</li><li>Bambu Lab Matte Dark Green PLA</li><li>Bambu Lab Matte Dark Red PLA</li><li>Bambu Lab Silk Gold PLA</li></ul>Liners<ul><li>Bambu Lab Matte Ivory White PLA</li><li>Bambu Lab Basic Bambu Green PLA</li></ul>Scenes<ul><li>Bambu Lab Matte Ivory White PLA</li><li>GIANTARM Transparent Clear PLA</li><li>Bambu Lab Matte Charcoal PLA</li><li>Bambu Lab Matte Mandarin Orange PLA</li><li>Bambu Lab Matte Lemon Yellow PLA</li><li>Bambu Lab Matte Marine Blue PLA</li></ul>
