<h3>Arm mounting system </h3>It is a universal set of holders and arms. You can use this system as a notebook holder, tablet holder, monitor holder, camera or any other device holder or you can have it as a shelf holder.If you print a pair, you can made various tables.You can attach more arms togehter. I made some connecting parts and other accessories. There are no limits to imagination. I made it with increased strength and durability. If you add few perimeters the holders/arms can hold pretty good weight. &nbsp;&nbsp;&nbsp;Small light versionHolders reduced x 0.6 and then adjusted (hole sizes, gaps, etc.)<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_ygt4l1gyz0rx.jpg"></figure><h4>Základní informace</h4><figure class="table"><table><tbody><tr><td>&nbsp;<figure class="image image_resized image-style-align-left" style="width:75%;"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_1vuk35qftkm3.jpg"></figure>&nbsp;</td><td>&nbsp;You can adjust the angle in ten degrees. Screw and nut fit on both sides. &nbsp;&nbsp;&nbsp;</td></tr><tr><td>You can tight and loose from both sides no matter where the nut is. </td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_5bbkp2ve4kgr.jpg"></figure></td></tr><tr><td><figure class="image image_resized" style="width:75%;"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_l4f3cs4r4hsf.jpg"></figure></td><td>There are various nuts and screws. Of of them counts with the allen screw (hex bolt) M8x40&nbsp;</td></tr><tr><td>You can also print the crew which can be tight and loose without gear- with the printed hex bolt screw. </td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_7dyjbvq16pqm.jpg"></figure></td></tr><tr><td><img src="https://media.printables.com/media/prints/165239/rich_content/5d2096ce-0223-4834-ade9-1fd6b3aec194/resize_img_6432.jpg#%7B%22uuid%22%3A%2292583698-0623-4e34-94da-bb853c30ae47%22%2C%22w%22%3A2016%2C%22h%22%3A1512%7D"> <img src="https://media.printables.com/media/prints/165239/rich_content/4dd49cb0-b7a2-4690-8a96-9c03407d2c2e/resize_img_6427.jpg#%7B%22uuid%22%3A%225c571a00-83c6-45bf-a6bb-97f04a44ed33%22%2C%22w%22%3A2016%2C%22h%22%3A1512%7D"></td><td>The holes for key in the screw and two arms have the same size as the holders in Honeycomb storage wall (https://www.printables.com/cs/model/152592-honeycomb-storage-wall). That means that you can hang different accessories on the arms. </td></tr><tr><td>There are various of arms. </td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_bdrw6oh1oh1y.png"></figure></td></tr><tr><td><figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_u06b8t58ztlv.jpg"></figure></td><td>ClampI made 3 different types - <ol><li>for the screw M5/M6 mounting spacing for holders 30x30mm</li><li>for the screw M5/M6 mounting spacing for holders 40x40mm</li><li>for the screw M5 mounting spacing for holders 40x40mm</li></ol>&nbsp;</td></tr><tr><td><figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_t3u1ipn1agdd.jpg"></figure></td><td>VESA rotating holder - 75mm</td></tr><tr><td>Combination for possitioning along the axis Z<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_7m1sfrwcw20k.jpg"></figure>&nbsp;&nbsp;</td><td>System - high table for tablet holder <img src="https://media.printables.com/media/prints/165239/rich_content/228c6e5e-a2a4-41ce-a79e-962f4006c973/resize_img_6430.jpg#%7B%22uuid%22%3A%22da81a7de-4dd3-453e-96dc-6c179e6bc32e%22%2C%22w%22%3A1512%2C%22h%22%3A2016%7D"></td></tr><tr><td><figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_11nh0grq3czm.jpg"></figure></td><td>There are holders for three tablets. Bottom width<ol><li>196 mm</li><li>250 mm</li><li>305 mm</li></ol>screw spacing 30mm</td></tr></tbody></table></figure><h4>Basic arms</h4>The only difference is the grid<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_0qsfmal86eys.png"></figure>&nbsp;<h3>Holders</h3>A few basic handles<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_wjg38olir4sz.png"></figure>&nbsp;<h4> </h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_ej2zf1avpe73.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_2ujybj6hyhzb.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/181205/2023-09-26_3i0br0eesaay.png"></figure>&nbsp;I printed small parts on the Prusa Mini, the arms on the Ender 3.&nbsp;My printing settings<ul><li>material: PETG</li><li>perimeters: 8 and more</li><li>infill : 30% and more</li><li>layer height 0.3 (with nozzle 0.6 layer height 0.4) (screw and nuts only 0.2mm layer height) </li></ul>&nbsp;

Multifunction Arm mounting system

OlleMark

Updates:01-11-2023 - Added a 95% sized container that fixes the printing over the edge if the plate is not attached all the way to the left, print this to be safe. :)03-11-2023 - Made the standard sized model 97% size to prevent any issues.&nbsp;A poop container in the style of a real container with a bambulabs logo+text version available.&nbsp;OBS! When printing any of my profiles make sure your plate is attached as far left as possible because otherwise it could print outside of the plate. :)OBS2! This models was designed with the P1 and x1 series not the a1 series :)&nbsp;A painted version for ams users is available but it is sadly untested because i dont have an ams so if any tweaks is needed please tell me or upload your own profile! :)&nbsp;My recommended settings:0.25mm layer height0.42mm line width10-20% infill&nbsp;
