<h3>Filament Purge/Poop Shadow Box</h3>UPDATE 1 : New faceplates added (Butterfly, Mushroom, Dolphins, Palm Tree, Peacock, Mouse Ears, Weiner Dog)UPDATE 2 : <ul><li>New faceplates added (Dragon Ball Z, Motorcycle, Cat, Ghost, Magic Lamp, Ice Cream, Mandalorian)</li><li>Fusion 360 Design file, Print Profiles and RAW Files have all been modified to include a lip at the bottom of the box to help hold the faceplate and window. The Window_Thickness was not references in the sketch, it is now fixed and changing this parameter will modify the design.</li></ul>&nbsp;&nbsp;We all know multi-color printing with the Bambu printers produces a lot of waste, mostly in the form of filament poop. My design doesn&#39;t help reduce the waste produced but it does help with giving it a purpose. This shadow box with customizable size and face plates is a great way to display the colorful waste in a fun manner. It can be a great way to add a pop of color to your living room, your office or even your kid&#39;s room.&nbsp;For this design, you will need to purchase some small acrylic sheets such as these ones from <a target="_blank" href="https://www.amazon.ca/dp/B088LLCJBK?ref=ppx_yo2ov_dt_b_product_details&amp;th=1" rel="nofollow noopener">Amazon CA</a> or <a target="_blank" href="https://www.amazon.com/SimbaLux-Plexiglass-Transparent-Protective-Replacement/dp/B088LLCJBK/ref=sr_1_4?crid=22ER4N5UCMCUJ&amp;dib=eyJ2IjoiMSJ9.cdhOOX0nvijtRW_PjncZZO9dR0XJxrsNqs-evrSjIDHN_SiO4qta_my5eOF0M_pMk3Z97aFjZ6oJu9tWmE2HeKJ_8B9hq6tdb615aZra4T52WZ84XVRqd-o6pW_ElRcEcjQYYtgLlSl9tf6GsgJVYudqCmGdCqLdB3349Qk_ybm7FkDFap3QYkyu4-dkjX4CO7k12Vrb8RACnrhOzCy4q-zIef3bU9Y0gBr9gyP7UPw.ZNML7UenX66MZWG6reYkhF12HsjFSHDd9xPRDr88l_c&amp;dib_tag=se&amp;keywords=simbalux%2Bacrylic%2Bsheet%2Bclear%2Bcast%2Bplexiglass%2B5x7&amp;qid=1711399238&amp;sprefix=simbalux%2Bacrylic%2Bsheet%2Bclear%2Bcast%2Bplexiglass%2B5x7%2Caps%2C115&amp;sr=8-4&amp;th=1" rel="nofollow noopener">Amazon US</a>. Do not worry if you can&#39;t find these exact ones, as I have also included the Fusion 360 design file that is parametrized for you to customize the shadow box for yourself.&nbsp;As of right now, the face plates available in the print profile and RAW files are the following :*Note that I will be taking requests for face plates of the provided dimensions, but you can also customize one in your slicer or in Fusion 360<ul><li>Vertical Blank</li><li>Vertical Bambu Logo</li><li>Vertical Brick man</li><li>Vertical Sunflower</li><li>Horizontal Blank</li><li>Horizontal Excavator</li><li>Horizontal Golden Ratio</li><li>Horizontal Star Wars</li><li>Horizontal Brick Logo</li></ul>Assembly instructions :<ol><li>Slide the acrylic sheet and the face plate into the grove at the front of the box. I suggest having the face plate be the outermost item, that way you will be able to easily change it without making a mess</li><li>Add in the filament poop using the optional feeder funnel</li><li>Slide the cover on and you&#39;re done, it is an intentional tight fit so nothing comes out.<ol><li>An optional looser cover is provided in both of the boxes print profiles</li><li>For a 100% secure cover, use a bit of glue</li></ol></li></ol>&nbsp;How to make a custom face plate in the slicer :<ol><li>Right-Click on the blank face plate of your choice</li><li>Click on ‘’add negative part&#39;&#39; then select the ‘’load&#39;&#39; option</li><li>Select your intended file, scale it up or down and place it where you want it to be</li><li>When you slice the file, it should then cut out the loaded file from the blank face plate</li></ol>&nbsp;How to modify the Fusion 360 design fileHere are the parameters that you can change in the Fusion 360 file :<ul><li>Tolerance is used around the sliding cover and between the face plate/acrylic sheet and the walls of the shadow box. It is currently set as 0,2 mm and it worked perfectly for me.</li><li>Window_Thickness is for the thickness of the acrylic sheet. This will not affect the thickness of the face plate (1 mm)</li><li>Window_Horizontal is for the horizontal measurement of the acrylic sheet and face plate. Add the exact value without tolerance in mind.</li><li>Window_Vertical is for the vertical measurement of the acrylic sheet and face plate. Add the exact value without tolerance in mind.</li><li>Box_Depth is to adjust the depth of the shadow box as in making it more slim or thicker. This is the total outside measurement, I don&#39;t recommend you go under 30mm.</li></ul>To change these parameters, you will need to :<ol><li>in the ‘’Solid&#39;&#39; menu, expand the ‘’modify&#39;&#39; tab and select ‘’Change Parameters&#39;&#39;</li><li>You will then have this new window open up, simply change the parameter of your choice in the ‘’Expression&#39;&#39; column</li></ol><figure class="image image_resized" style="width: 66.51%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000408882/design/2024-04-01_52deddc4daa6d.png"></figure>&nbsp;Commercial License available on my <a target="_blank" href="https://cults3d.com/en/3d-model/art/filament-purge-poop-shadow-box" rel="nofollow noopener">Cults3D page</a>
