My AMS overlay design with slot numbers. I used gray and white to make the numbers as visible as possible, but you can of course use any color combination.&nbsp;&nbsp;I designed a version for users who mount their AMS lite on top of an A1 printer (AMS lite Top Mount for A1). link in the image.<figure class="image"><a href="https://makerworld.com/en/models/168898#profileId-185503" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000116582/design/2024-02-03_e53ecb69887dd.jpg"></a></figure>&nbsp;<h3>Update !</h3>I noticed that some users wanted to protect their Bowden tubes from the excessive wear and tear of tugging, and I thought it might make sense, so I added Bowden tube holders to my earlier design.The standard version and the version with Bowden tube protection have upside-down versions for people who mount the AMS on the wall or on dedicated stands.&nbsp;&nbsp;Check the flow ratio before printing. My print has a few flaws, but they are visible only in photos, normally they are almost invisible.&nbsp;<h3>Updated May 9, 2024</h3><ul><li>I replaced the source files from stl to step, which makes the model walls smoother.</li><li>Due to the information from the comments that the model is too tight in some cases, I increased the length by 0.5 mm, which should solve the problem. (the width is the same so I shouldn&#39;t be too loose)</li><li>Attention! Models with increased length are only in my print profiles!</li></ul>&nbsp;&nbsp;<figure class="image"><a href="https://www.buymeacoffee.com/wojciechkawa" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000116582/design/2024-01-30_46d010488f47e.webp"></a></figure>
