Stuart

ninja

<p>This is a handy, screw in wall or desk mount for your Unifi USW-Flex-Mini switch </p><p>&nbsp;</p><p>I found a simple design and remixed it, changed the sizing &amp; added wording. </p><p>Printed it multiple times in PLA &amp; PETG, both profiles added here </p>

Unifi USW Flex Mini Mount USW-Flex-Mini

Network

MelisekVojtisek

<h3>Introduction</h3><p>Hello, this is the Adjustable fully-printable modular system with which you can create a holder for your workshop tailored to your needs. For example, you can build a bracket for soldering, a bracket for painting miniatures, a vise and much more! If you have a suggestion for improvement, feel free to leave a comment. I will be glad for any feedback. You can also show which holders you have built and inspire others!</p><p>&nbsp;</p><h3>Sample holders</h3><h5>Little painter</h5><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/ff1aaad0-5bbe-417a-a8d7-3712800f165a.jpg"><img class="image_resized" style="width: 49.96%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/3e64bcbe-dd40-40fe-8ef6-aaf3afdfc795.jpg"></p><ul><li>2x legs</li><li>2x small console</li><li>1x right-hand thread stick</li><li>1x rotating connector</li><li>2x connection stick</li><li>2x rotating handle</li><li>1x painting attachment</li></ul><h5>Wire soldering station</h5><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/3ad1d0d2-57af-4bcf-8753-0c82b8b30c30.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/515882d7-e8a3-476b-861a-379f62202e53.jpg"></p><ul><li>2x legs</li><li>1x medium console</li><li>2x short console</li><li>3x right-hand thread stick</li><li>1x left-hand thread stick</li><li>4x rotating connector</li><li>4x rotating handle</li><li>5x connection stick</li><li>2x free connection stick</li><li>2x peg part 1</li><li>2x peg part 2</li><li>2x peg mount</li></ul><h5>PCB soldering station</h5><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/b9b87300-07f1-4d5a-bfe5-b0471877d916.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/5f026187-e457-4153-9742-fd828218146f.jpg"></p><ul><li>2x legs</li><li>1x medium console ( or long console)</li><li>2x short console</li><li>3x right-hand thread stick</li><li>1x left-hand thread stick</li><li>4x rotating connector</li><li>4x rotating handle</li><li>5x connection stick</li><li>2x free connection stick</li><li>2x pcb holder</li></ul><p><strong>Vise</strong></p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/051a0881-73b3-415d-8e8e-35f39c8390e3.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/6612669f-ea81-4dc9-a712-37ed3b2b2c71.jpg"></p><figure class="image image_resized" style="width: 75%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/2024-06-22_8eusjo7son7l.jpg"></figure><ul><li>2x medium console</li><li>2x short console</li><li>4x legs</li><li>4x rotating connector</li><li>2x right-hand thread stick</li><li>2x left-hand thread stick</li><li>2x offset ring</li><li>4x connection stick</li><li>2x rotating handle</li><li>2x end cap</li><li>2x vise attachment</li></ul><p><strong>The Ultimate holder</strong></p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/70704cca-8a16-4bf6-a552-aa15160233f4.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/4a93615e-a15d-47e0-a0fc-d776f2374173.jpg"></p><ul><li>4x medium console</li><li>3x short console</li><li>4x legs</li><li>2x semi RA-connector</li><li>2x free RA-connector </li><li>7x rotating connector</li><li>1x solder holder part 1</li><li>1x solder holder part 2</li><li>1x solder holder part 3</li><li>2x peg part 1</li><li>2x peg part 2</li><li>2x peg mount</li><li>6x rotating handle</li><li>9x connection stick</li><li>4x right-hand thread stick </li><li>4x left-hand thread stick</li><li>2x end cap</li><li>1x offset ring</li><li>2x free connection stick</li></ul><h3>Parts description</h3><h5>Consoles</h5><p>The consoles are the main parts of this system. They have three different sizes: <i>short console</i>, <i>medium console</i> and <i>long console</i>. One <i>thread stick</i> can be clicked into the <i>short console</i>, two into the <i>medium console</i>, and three into the <i>long console</i>. You can freely combine <i>right-hand thread stick</i>s and <i>left-hand thread stick</i>s. There are threads at the end of the consoles that allow the consoles to be screwed into the rotating connector.</p><p><img class="image_resized" style="width: 75%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/f4b82e64-579f-4a30-befe-e2641740cb55.jpg"></p><h5>Legs</h5><p>The <i>legs</i> are used to keep the holder standing on the table. They slide onto the <i>console</i> and have holes in them for attaching to the table top.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/b53488f2-ea1e-4906-a394-0c7801d63737.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/81b8320a-9c01-4e85-93b4-1747a685e609.jpg"></p><h5>Connection sticks</h5><p>There are two types of connection sticks: normal <i>connection stick</i> and <i>free connection stick</i>. Connection sticks are used to connect individual <i>thread sticks</i> to each other. The normal <i>connection stick</i> is also used to connect the <i>thread stick</i> and <i>rotating handle</i>. The <i>free connection stick</i> is used additionally to connect the <i>thread stick</i> and the <i>rotating connector</i>.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/160fddad-13fe-4530-906a-bb0e347dd4ba.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/362f71a1-b6cc-4715-b8b5-cc7dc4320616.jpg"></p><h5>Thread sticks</h5><p>There are two types of thread sticks: <i>right-hand thread stick</i> and <i>left-hand thread stick. Thread stick</i> is used to click into the <i>console</i>.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/70a0cf02-6c72-49a9-86a3-69832e62765c.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/2baddddd-64b3-4e21-9e52-4f7f779fbd3e.jpg"></p><h5>Rotating handle</h5><p>This part is used to rotate with <i>thread stick.</i></p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/77806999-9866-4138-b77a-07f15b6cfbb8.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/005e0eb7-eafc-4527-b078-9d590403b251.jpg"></p><h5>End cap</h5><p>You can also attach <i>thread stick</i> in <i>console</i> with this part.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/feb25f81-069f-4411-96bd-8541aa837b01.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/7dfcef12-4c0e-48d0-87a4-4d043b88b04a.jpg"></p><h5>RA-connectors</h5><p>You can use RA (right angle) connectors to attach two consoles together. The <i>fixed RA-connector</i> has a thread on both sides so it can be moved around the <i>console</i> using <i>thread stick.  The semi RA-connector </i>has a thread only on one side and the<i> free RA-connector </i>has no thread so you can move around<i> console </i>freely.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/eb1d645b-38a7-4b3d-a006-e750a7af16ff.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/cb6bc7ff-1783-48d3-8ced-7a89acb5c2f2.jpg"></p><h5>Rotating connector</h5><p>Rotating connector slides onto the <i>console</i> and can be moved with a <i>thread stick</i>. One end of the <i>console</i>, <i>peg mount</i>, <i>pcb holder</i> or <i>solder holder</i> can be attached to the thread. I recommend printing on the side with supports only on the printing plate. After printing, remove the supports and press the wheel from the top until you hear a click sound. You can then rotate the wheel.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/97a97e23-f7a3-4e42-b0fb-9d69726c392b.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/90ca3c25-5ad6-4732-96d7-5674ba021f09.jpg"></p><h5>Offset ring</h5><p>If you want to move the part in the <i>rotating connector</i> freely, you can attach the <i>offset ring</i> to the part first.</p><p>.<img class="image_resized" style="width: 60.39%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/3b906208-d33d-409c-9496-d54c9e94a92b.jpg"><img class="image_resized" style="width: 33.89%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/96a9484e-9ed3-4fe1-b599-ef68561e9ad9.jpg"></p><h5>Painting attachment</h5><p>You can screw the <i>painting attachment</i> on <i>console </i>to use like a painting handle.</p><p><img class="image_resized" style="width: 63.78%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/4bb64369-b16f-4f57-8b18-cd42fb100ea5.jpg"><img class="image_resized" style="width: 36.22%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/a3dce50c-6908-4b71-988f-5225192a368d.jpg"></p><h5>Pegs</h5><p>To make a peg you need a <i>peg mount</i> and then <i>peg part 1</i> and <i>peg part 2</i> and a spring from a normal peg. I know, I wrote that this system is fully printable, so there is an option to print a <i>fully printable peg</i> model instead of <i>peg part 1</i> and <i>peg part 2</i>. However, this peg does not work as well as the spring peg.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/990bdf44-c727-439a-ba80-78ee4f793218.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/8586c404-117c-432d-8778-9728003abd1c.jpg"><img class="image_resized" style="width: 35.75%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/3f8c32c0-2ea4-44ed-8ac6-3971447a282d.jpg"><img class="image_resized" style="width: 63.39%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/26aeba02-633f-458d-9a35-578003e7bc0e.jpg"></p><h5>PCB holder</h5><p><i>Pcb holder</i> is used to attach PCB, but maybe you find another usage of this part.</p><p><img class="image_resized" style="width: 63.67%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/cb1d5f03-f593-4627-abd3-42e276e9bf9c.jpg"><img class="image_resized" style="width: 36.1%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/4014a7c1-ea36-4dbd-b908-1e45d0585f69.jpg"></p><h5><strong>Solder holder</strong></h5><p>To assemble the solder holder you need print <i>solder holder part 1</i>, <i>solder holder part 2</i> and <i>solder holder part 3</i>. Then screw part 2 into part 3 and you can use the model to attach the solder.</p><p><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/fa3ca037-6b70-45aa-9215-3a90818cca67.jpg"><img class="image_resized" style="width: 50%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/792707fb-a689-4f83-8c53-9cddeffbf94b.jpg"></p><h5>Vise attachment</h5><p>This part slides onto the console.</p><figure class="image image_resized" style="width: 75%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000505778/design/2024-06-22_s7e4k5hm0nmz.png"></figure>

Modular adjustable holder system

tools

Filamentking

<blockquote><h3><i><strong>I RECCOMEND PRINTING THIS AT .1 LAYER HEIGHT SO IT'S WATER TIGHT AND IN EITHER PETG ANY HEAT RESISTANT MATERIAL IF YOU'RE SETTING OUT IN THE SUN!</strong></i></h3><p><i><strong>the model is 66mm in diameter, fits most mason jar lids.</strong></i></p></blockquote><h4><strong>I designed this because i had quite a bit of pods leftover after starting them in my gardens. I added holes to hopefully help </strong><i><strong>aerate</strong></i><strong> the plant, but I've realized it makes no difference either way, so I've uploaded both with and without holes for your personal preference.</strong></h4>

Aerodome

Plants

Maoirae

<p>Due to hotend design there is problem, that hotend fan can take air to cool down from bad places where is hot air, like bellow from around heatblok and heatbed and that can lead to melt filament too soon before heatblok and cause clog. So to prevent this heat creep I designed a little fan duct to prevent that. Its made to take air directly from the side of hotend housing. Its made simply to just screw directly to part cooling fan, than you can assemble front hotend housing as normal. Hope it will help you.</p><p>&nbsp;</p><p>Print from PETG or ABS for better heat resistance.</p><p>&nbsp;</p><p>There is also model for P1P/P1S in my published models: <a target="_blank" href="https://makerworld.com/de/models/91769#profileId-98170" rel="nofollow noopener">https://makerworld.com/de/models/91769#profileId-98170</a></p>
