<h2><span style="color:#E14747;">NOTICE: REMIX ARE NOT ALLOWED</span></h2><h2><span style="color:#E14747;"><strong><u>NOTICE: DO NOT POST ANY OF YOUR PROFILE</u></strong></span></h2><p>&nbsp;</p><p>&nbsp;</p><p>I remixed my model “PURGE CHUTE COVER WITH SILICON NOZZLE WIPER” , link: <br><a target="_blank" href="https://makerworld.com/en/models/145723#profileId-158569" rel="nofollow noopener">https://makerworld.com/en/models/145723#profileId-158569</a> .The last version was only in one color and the logo was engraved.</p><p><strong>You find here the model for the X1C and X1E.</strong></p><p>Benefits:</p><ul><li>Suitable for ABS. <strong>BUT I STILL RECOMMEND HIGHER TEMPERATURE FILAMENT , LIKE PA6-GF/CF , PATH-CF OR PC</strong></li><li><strong><u>NO WARPING USING ABS WITH BED TEMPERATURE AT 97°C</u></strong></li><li>Tighter fit</li><li>Bambu Lab logo not engraved, 0.01 offset</li><li>Multicolor : white , black and green</li><li>Purged filament doesn&#39;t jump on the plate</li><li>Nozzle is better cleaned</li><li>Pieces of purged filament don&#39;t go everywhere , each corner of the printer remains clean</li></ul><p>&nbsp;</p><h2>How to install THE MODELS WITH and WITHOUT THE LOGO:</h2><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-01-18_da9c61bb4c7ec8.webp"></p><h2> </h2><h2>How it works:</h2><p>&nbsp;</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-04-06_5a4d4791d37da.gif"></figure><p>&nbsp;</p><p>&nbsp;</p><h3><span style="color:#E14747;">INSTRUCTIONS</span></h3><h3>What is the nozzle wiper made of?</h3><p>It is made from a piece of silicone from the molds used to make pancakes. Like this one you see in this pic:</p><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-01-08_c6bbefaa222f68.jpg"></p><h2> </h2><h2>How big should the silicone piece to be cut be?</h2><p>10mm x 2mm x 15mm</p><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-01-08_11d23ec8214f98.jpg"></p><p>&nbsp;</p><h2>PRINT THE POOP STOP WITH THE NOZZLE WIPER</h2><p>&nbsp;</p><h2>CUT THE PIECE:</h2><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-01-08_ac17a4c0705dd.jpg"></p><p>&nbsp;</p><p>&nbsp;</p><h2>APPLY THE SILICON PIECE IN THE SEAT OF THE POOP STOP AND INSTALL THE POOP STOP IN THE POOP BUCKET</h2><p>&nbsp;</p><p>AS YOU SEE IN THIS PIC , MY MODEL IS SUPER FLAT, SO WARPING MUSTN&#39;T BE ON IT TO AVOID CRASHED OR SCRATCHES AGAINST THE HOTEND, TOOLHEAD OR FAN DUCT ,<span style="color:#E14747;"><strong> SET THE BED TEMPERATURE AT 97°C </strong></span>:</p><p>&nbsp;</p><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-04-06_8923754839a4b8.jpg"></p><p>&nbsp;</p><p>I have tested this model so many times and it works smoothly! No issue.</p><p>&nbsp;</p><h4>ALL THE MODELS ARE AVAILABLE ON MY PAGE: <a target="_blank" href="https://makerworld.com/en/@EngineeringProj" rel="nofollow noopener">https://makerworld.com/en/@EngineeringProj</a> </h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-04-06_3f58358be73948.jpg"></figure><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p><h2>NOTICE:</h2><h2>DON&#39;T MODIFY THE ORIENTATION!</h2><p>&nbsp;</p><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-04-06_1130109f29ca28.jpg"></p><p>&nbsp;</p><h4><span style="color:#E14747;"><strong>NOTICE: THE FOLLOWING PHOTO SHOWS THE EXTRUDED FILAMENT BEING HELD ON THE SILICON NOZZLE WIPER, <u>BEFORE</u> PRINTING.</strong></span></h4><h4><span style="color:#E14747;"><strong>THIS IS ONE OF THE MAIN REASONS WHY I DESIGNED THIS MODEL. THAT EXTRUDED FILAMENT COULD RUIN YOU FIRST LAYER!</strong></span></h4><h4><span style="color:#E14747;"><strong>PLEASE CHECK ALWAYS IF THE SILICON NOZZLE WIPER IS CLEAN AND IF YOU SEE THAT SOME EXTRUDED FILAMENT HAS BEEN DEPOSITED ON IT, REMOVE THE EXTRUDED FILAMENT AND ENJOY 3D PRINTING.</strong></span></h4><p><span style="color:#E14747;"><strong>THE PHOTO WAS MADE AS EXAMPLE AFTER 3h PRINTING.</strong></span></p><p><span style="color:#E14747;"><strong>MY MODEL HAS ALREADY BEEN TESTED, FOR A MONTH AND I DON&#39;T FIND ANY PROBLEMS.</strong></span></p><p>&nbsp;</p><p>&nbsp;</p><p><img src="https://makerworld.bblmw.com/makerworld/draft/822654/2024-01-17_3a990be51d02c8.jpg"></p><p>&nbsp;</p><p><span style="color:#E14747;"><strong>𝙽𝙾𝚃𝙸𝙲𝙴:</strong></span></p><p><span style="color:#E14747;"><strong>𝚃𝙷𝙸𝚂 𝙸𝚂 𝙰 𝚂𝙸𝙼𝙿𝙻𝙴 𝙿𝚁𝙸𝙽𝚃. 𝙰𝚂 𝚈𝙾𝚄 𝚂𝙴𝙴 𝙸𝙽 𝚃𝙷𝙴 𝙿𝙸𝙲𝚃𝚄𝚁𝙴𝚂 , 𝙼𝚈 𝙼𝙾𝙳𝙴𝙻 𝚂𝚃𝙸𝙲𝙺 𝚅𝙴𝚁𝚈 𝙶𝙾𝙾𝙳 𝙾𝙽 𝚃𝙷𝙴 𝙱𝙴𝙳. 𝚂𝙾 𝙱𝙴𝙵𝙾𝚁𝙴 𝚈𝙾𝚄 𝙶𝙸𝚅𝙴 𝙱𝙰𝙳 𝚁𝙰𝚃𝙸𝙽𝙶 𝚃𝙾 𝙼𝚈 𝙿𝚁𝙾𝙵𝙸𝙻𝙴𝚂, 𝙱𝙴 𝚂𝚄𝚁𝙴 𝚈𝙾𝚄 𝙷𝙰𝚅𝙴 𝙰 𝙶𝙾𝙾𝙳 𝙱𝙴𝙳 𝙰𝙳𝙷𝙴𝚂𝙸𝙾𝙽 𝙰𝙽𝙳 𝙰𝚂𝙺 𝚃𝙾 𝚈𝙾𝚄𝚁𝚂𝙴𝙻𝙵 , 𝚆𝙷𝚈 𝚈𝙾𝚄 𝙳𝙾𝙽&#39;𝚃 𝙷𝙰𝚅𝙴 𝙰 𝙶𝙾𝙾𝙳 𝙱𝙴𝙳 𝙰𝙳𝙷𝙴𝚂𝙸𝙾𝙽. 𝙸 𝙳𝙾𝙽&#39;𝚃 𝚆𝙰𝙽𝚃 𝚃𝙾 𝚄𝙿𝙻𝙾𝙰𝙳 𝙰 𝙻𝙾𝚃 𝙾𝙵 𝙿𝚁𝙾𝙵𝙸𝙻𝙴𝚂 𝙵𝙾𝚁 𝙴𝙰𝙲𝙷 𝚂𝙸𝙽𝙶𝙻𝙴 𝙿𝚁𝙾𝙱𝙻𝙴𝙼 𝚈𝙾𝚄 𝙷𝙰𝚅𝙴 𝙰𝙽𝙳 𝙵𝙾𝚁 𝙴𝚅𝙴𝚁𝚈 𝚂𝙸𝙽𝙶𝙻𝙴 𝙼𝙾𝙳𝙴𝙻! 𝙴𝚅𝙴𝙽 𝚈𝙾𝚄 𝚆𝙰𝙽𝚃 𝚃𝙾 𝚂𝙷𝙰𝚁𝙴 𝙾𝙽𝙴 , 𝙸𝚃 𝙳𝙾𝙴𝚂𝙽&#39;𝚃 𝙼𝙰𝙺𝙴 𝚂𝙴𝙽𝚂𝙴 𝙵𝙾𝚁 𝚃𝙷𝙴 𝚂𝙸𝙼𝙿𝙻𝙴 𝙼𝙾𝙳𝙴𝙻 𝙸𝚃𝚂𝙴𝙻𝙵!</strong></span></p><p><span style="color:#E14747;"><strong>𝙿𝙻𝙴𝙰𝚂𝙴, 𝙻𝙸𝙺𝙴 𝙸 𝚂𝙰𝙸𝙳 𝚃𝙷𝙴 𝙼𝙾𝙳𝙴𝙻 𝚂𝚃𝙸𝙲𝙺𝚂 𝙾𝙽 𝚃𝙷𝙴 𝙱𝙴𝙳 𝙴𝙰𝚂𝚈! 𝙽𝙾𝚃 𝙰𝙻𝚆𝙰𝚈𝚂 𝚁𝙴𝙳𝚄𝙲𝙸𝙽𝙶 𝚃𝙷𝙴 𝚂𝙿𝙴𝙴𝙳 𝙲𝙰𝙽 𝙷𝙴𝙻𝙿 𝚈𝙾𝚄 𝚃𝙾 𝚂𝚃𝙸𝙲𝙺 𝙴𝚅𝙴𝚁𝚈 𝙼𝙾𝙳𝙴𝙻 𝙾𝙽 𝚃𝙷𝙴 𝙿𝙻𝙰𝚃𝙴! 𝚃𝙷𝙰𝙽𝙺 𝚈𝙾𝚄 𝙵𝙾𝚁 𝚃𝙷𝙴 𝚄𝙽𝙳𝙴𝚁𝚂𝚃𝙰𝙽𝙳𝙸𝙽𝙶!</strong></span></p><p>&nbsp;</p><h2><strong>ᴵᶠ ʸᵒᵘ ʰᵃᵛᵉ ᵖʳᵒᵇˡᵉᵐˢ ᵃᵇᵒᵘᵗ ᵗʰᶦˢ ᵐᵒᵈᵉˡ, ʲᵘˢᵗ ˢᵉⁿᵈ ᵐᵉ ᵃ ᵖʳᶦᵛᵃᵗᵉ ᵐᵉˢˢᵃᵍᵉ ᵃⁿᵈ ᴵ&#39;ˡˡ ʰᵉˡᵖ ʸᵒᵘ.</strong></h2><h2><strong>ᴳᶦᵛᵉ ᵐᵉ ᵃ ˡᶦᵏᵉ ᵃⁿᵈ ᶠᵒˡˡᵒʷ ᵐʸ ᵖᵃᵍᵉ.</strong></h2><h2><strong>ᵀʰᵃⁿᵏ ʸᵒᵘ ᵗᵒ ˢᵘᵖᵖᵒʳᵗ ᵐᵉ ᵃⁿᵈ ʰᵃᵖᵖʸ ᵖʳᶦⁿᵗᶦⁿᵍ.</strong></h2>

PURGE CHUTE COVER WITH SILICON WIPER IN MULTICOLOR

Sevro

Sitting Lion

speelgoed

DrJones

<p>Easily start a siphon: Just shake! Sized for a 12mm (1/2 &#34;) garden hose.</p><p>&nbsp;</p><p>If you want to empty a barrel etc using a siphon but find it uneasy to start the siphon - this is an easy way to do so. This shaker siphon is a actually just a valve. By shaking it down into the water (or other liquid), that water can easily flow in, but when you pull up again, the water is trapped and comes up, too. By shaking up and down, the valve and the water&#39;s inertia pump enough water up to start the siphon effect.</p><p>&nbsp;</p><p>I tried to design it to have low flow resistance and not to be prone to catch debris.</p><p>&nbsp;</p><p>Added a version with gardena adapter (check “raw files”).</p><p>&nbsp;</p><p>Printing: It worked without a brim for me, but if it comes loose while printing, try adding a brim.</p>

x1c

speelgoed

garden tools
