silvatech

SigmaT4

Hi,&nbsp;I have created this concealed hinge that print in place.There is one functional version, robust enough for real applications, and one version just to play with. (It is oddly satisfying).&nbsp;EDIT 2024/02/25 : Fixed the toy version (bad versionning sorry). Built in supports will now work as intended&nbsp;Please note that the files are LEFT side hinges. You will have to mirror the mechanism for a right side hinge.&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/584700/2024-02-21_24e7d16b89731.gif"><figcaption>It is a concealed hinge</figcaption></figure><figure class="image image_resized" style="width:39.07%;"><img src="https://makerworld.bblmw.com/makerworld/draft/584700/2024-02-21_57b7f16f52964.gif"><figcaption>The toy version</figcaption></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/584700/2024-02-21_370785be4cdf9.gif"><figcaption>Mechanism mounted</figcaption></figure>&nbsp;In order to have a robust mechanism, the tolerance are quite thin.After printing, you will have to force a little to free the model the first time.(There are 8 little pillars around the arms which will break, it is normal. They are built-in supports)&nbsp;The functional version contains 3 items : the mechanism and 2 trapezoids.Mounting the hinge is very easy : One trapezoid is screwed in the door and the other one is screwed in the furniture.The mechanism will then be pressfit on these.Be carefull, the trapezoids have an orientation !The figure below illustrate where you should screw the trapezoids.&nbsp;EDIT : You can find in the link below, a model helping to drill holes at the right place. It includes a custom print in place caliper<a target="_blank" href="https://makerworld.com/en/models/198787#profileId-219386" rel="nofollow noopener">https://makerworld.com/en/models/198787#profileId-219386</a>&nbsp;<figure class="image image_resized" style="width:75.16%;"><img src="https://makerworld.bblmw.com/makerworld/draft/584700/2024-02-21_de621c1cd5a2f.png"></figure>&nbsp;The cinematic of the hinge allows up to 21mm of overlap.&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/584700/2024-02-21_bf7d3d3110fb5.jpg"></figure>&nbsp;You are free to inprove the design, you will find the sources here:https://cad.onshape.com/documents/007e254c011e844549e4a4bd/w/c7896a26d83ada10650c00e2/e/cb414f8844a48c4622f0780c?configuration=List_DVwExgKQQXkqD7%3DDefault&renderMode=0&rightPanel=variableTablePanel&uiState=65d6778603d7d900d85e7f80&nbsp;If you like my work, please download or print, it helps :)&nbsp;Alexandre

Print in place concealed hinge mechanism + fidget toy

Householdimprovementrepairs

Wcad00

UPDATE 9 - 25.03.2024<ul><li>updated profile REQUESTS - added plate 17 - user @gurthyy  wanted a new module to accomodate a mac mini on its side - added a new two space combo module for mac mini and keyboard/mouse</li><li>updated profile REQUESTS - added plate 18 - user @wmeringolo wanted a new module for miniature painting  - added a new combo module for cup + brushes</li></ul>&nbsp;UPDATE 8 - 16.03.2024<ul><li>updated profile REQUESTS - added plate 13 - user @bambibam  wanted a new combo 1x module for sd/ microsd/usbA/ usbC  - so there is a new combo module available</li><li>updated profile REQUESTS - added plate 14,15,16 - user @gurthyy wanted a way to angle the organizer after specific desktops - introducing Pizza Slices - angled 30degrees modules coming in two snap-on formats for now, but with room for much more customisation. Plate 14 has the universal pizza slice base + simple catch all top; plate 15 has an split/organized top, and plate 16 has a slide-on interchangable name plate - see photos in print profile. Everything was printed and tested for a perfect fit - check photos</li></ul>UPDATE 7 - 05.03.2024<ul><li>updated profile ACCENTS - user @Xanders_Builds noticed an issue i missed with the ‘’steps' accent brims not fitting corectly - too loose - now it is updated and fits fine</li><li>updated profile REQUESTS - added plate 10 -one new module  ASP @user_2207529250  and @bluebeansisradi requested a stand for a ps5 and xbox controller - new module that occupies two spaces and needs to be snapped into place - stand for ps5 and xbox controller - i tested a ps5 controller but i dont have a xbox, but it has some tollerance so it should fit fine - in case it does not, i made the module from two parts , so the stand can be exchanged - please let me know if that is the case</li><li>updated profile REQUESTS - added plate 11 -one new mod  for DRAWER MAX. user @Nerraw asked for a method of separating the drawer into smaller spaces - i made a very simple method of doing that - 4 interconnectible separators that can also be printed individually or by neccesity i guess</li><li>updated profile REQUESTS - added plate 12 -one new module User @zach13 asked for a method of organizing documents vertically so this is my take on it. The iddea was to make it sturdy because it is a little tall and not to waste too much material - it is made from 3 pieces - a base plate and to organizing stands that fit slightly different from each other so that the papers will stay a little cuved to maintain vertical position</li></ul>&nbsp;UPDATE 6 - 15.02.2024<ul><li>updated profile REQUESTS - added plate 7  - Reinforced top plate for the DM. @bosho.liviu requested a top plate so modules could be placed on top - Now you can do that, it is symetric and compatible in every direction</li><li>updated profile REQUESTS - added plate 8,9  - Two new modules . @bdwilson asked for two modules that have removable interior trays - plate 8 has a new 1space tray module and plate 9 has a new tilted marker combo with one large tray on the bottom. The front part of the removable tray is also slanted for easy removal</li></ul>&nbsp;UPDATE 5 - 11.02.2024<ul><li>updated profile REQUESTS - added plate 5  - Tough Plate for the DM. @Heimwerkerbienchen requested a tougher top plate so monitor could pe placed on top of the DrawerMax - has all the toughness required bells and whistles but i really cant guarantee how it will hold up in time - in my oppinion the entire assembly should be printed in a tougher filament, because altough the new plate has a support structure, the drawer modules themselfs are pretty thin so the weight of the monitor will be on the walls</li><li>updated profile REQUESTS - added plate 6  - Half Bow ties. @bdwilson had a very good ideea to close the holes on exterior modules so introducing half bow ties </li></ul>&nbsp;UPDATE 4 - 28.01.2024<ul><li>updated profile REQUESTS - added plate 4  - Steps + Tape dispenser combo unit. altough it was not a request, the plate has the name of the user that gave me the ideea - thank you for that @lilrepete</li><li>the new module is compatible with existing ACCENTS, plus the security wheel and the blade can be printed in other colours to keep things fresh</li><li>the blade slides into the module and is interchangable in case teeth break or you just want another colour. if you feel it fits too tight just trim the seam of it and it will slide more easily</li></ul>UPDATE 3 - 23.01.2024<ul><li>updated the printing order to outer/inner - not a big issue but some had problems - now all is well</li></ul>UPDATE 2 - 22.01.2024<ul><li>added a new print profile called ACCENTS</li></ul>In keepign with the modularity theme and ultra customizability i aim to develop, i made some mix or match brims to add an extra touch of colour to your organizer. everything fits in place without glue or force and same as everything else it is easily changable in case you want to switch up your look and keep it fresh.photos attached in the profile so please check them out. i know the colours i actually printed are not the best but it was all the filament i have till i get my new shipment&nbsp;UPDATE 1 - 19.01.2024<ul><li>added a new print profile called DRAWER MAX</li></ul>it is a drawer module that occupies 4 slots, is stackable and also highly customizablethe first tray for it, as you can see in the pictures is for the spare parts that come with the BambuLab printer + some extras. Fits the parts for two printers.make sure you follow the instructions in its profile to get perfect fits everywhere<ul><li>added a new print profile called REQUESTS</li></ul>this profile contains the user requests for modules. each plate will have the users name on it. this is going to be the profile i will update regularly, based on requests.&nbsp;&nbsp;I’ve been wanting to do this project since I made the first desktop organiser.The problem I wanted to address was, what if in a month you want or need something else, more, or less space, something specific, more room for usb, cards, crayons, etc, how do you keep a new look with minimal to no effort?&nbsp;I’ve seen there have been many attempts to do this but none really took of, so I asked myself why? I think the main reason was lack of interest derived from lack of support. If newer modules aren’t created, interest goes down, and it becomes the same thing as a normal organiser.Of course we have the gridfinity system witch is great honestly and other similar to it, but they all rely on the same premise, a base to keep everything together, so if you are full, you need another base, but does the base you need right away exist? or are you going to be left with extra slots.&nbsp;Maybe I didnt do my research right, and there are other options, all I tried to do was to make something universal, easy to print, elegant, very customisable, and most of all, something that doesn’t depend on screws, magnets and on a base to keep it all tied. I printed 10 bowties In less than 20 minutes on standard, and hold together 7 modules (the ones I use) and you can lift and move them as a whole, without having them fall or break&nbsp;The bow tie joint isn’t my ideea, it’s been used in woodworking for centuries. It is a robust way of holding things together and works quite well here too, especially printed the way I arranged it on the plates . All the modules can be connected in whatever orientation you want, except the laptop stand, because it needs room on the small sides for the length of the laptop/tablet. But that is it - I kind of made that specifically for me, because I use it as an end piece that fits under my P1S (like my first organiser)&nbsp;I am starting with 12 modules and will make a new one every other week, based on suggestions I hope, because I dont think I have enough creativity. I will put out my own ideas because I do have more, but everyone has diferent needs so if you think you can get on board with the ideea I welcome all input, and I will try to make whatever you want. Remix culture is strongly encouraged.&nbsp;Modules in the 3mf:&nbsp;PLATE 1<ul><li>Usbcombo1 (11 usb sticks + 5 full size memory cards + tray for usb caps)</li><li>Phone combo (fits iphone 15 promax + airpods pro)</li><li>Post-its (two full size stacks of postits)</li><li>Steps (4 equal holders - superglue, ties, hex set, mini uv lamp)</li></ul>PLATE 2<ul><li>12 bow tie joints - enough for about anything</li></ul>&nbsp;PLATE 3<ul><li>Hex single - roomie organizer - can be further split with the splitters on plate 8</li></ul>&nbsp;PLATE 4<ul><li>Laptop wedge - macbook pro + ipad pro 12.9 + apple microfiber slot - made to be wedged under the x1 or p1</li><li>Laptop standard - - macbook pro + ipad pro 12.9 + apple microfiber slot + additional slot</li></ul>PLATE 5<ul><li>Tilted marker combo - 12 thick markers + pens and other + paperclip 3 + misc tray</li></ul>PLATE 6<ul><li>apple watch dock double - 2 apple watch charger pucks - like the original - cable management + full size post it tray</li></ul>PLATE 7<ul><li>Hex double - double the size of the single - can be further split with the splitters on plate 8</li></ul>PLATE 8<ul><li>5 split plates for the hex series</li></ul>PLATE 9<ul><li>apple watch dock single - 1 apple watch charger puck - like the original - cable management</li></ul>PLATE 10<ul><li>Usbcombo A - 6 usb sticks + 5 full size memory cards + tray</li></ul>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

The Organizer

Office Organizers

cv6Channel

I enhanced my last Remix of the Y-Splitter with a bar with the option, to plug into Filament from the side.You need in total now one more PTFE Connector.<ul><li>4x PC4-M10 pneumatic connector, inner diameter: 4 mm</li><li>2x M3 6mm</li></ul>I moved the Splitter a bit more to the edge to fit better for X1. I read some complaints in my Splitter Remix.&nbsp;To connect just use a 18cm to 20cm long PTFE Tube and place him between the upper connector from the splitter and the end at the bar.&nbsp;Its still/again based on Harald Geisler Splitter, which I liked most of all others.&nbsp;If you need only a Y-Splitter which is more inner but no sideload, check my <a target="_blank" href="https://makerworld.com/en/models/30469#profileId-26959" rel="nofollow noopener">Y-Splitter</a>.

Sideload for Filament incl. Y-Splitter

X1upgrades

KYZ Design

I really liked the original concept but wanted shorter brackets that fit 6 gauge screws well so I modeled one from scratch.Also made a 3-panel corner bracket (otherwise you'd need 3 of the 2-panel brackets to achieve the same thing).Print in the orientation it loads (rotate the overhangs towards your parts cooling fan if necessary), no supports.Update: small rounds at weak points added. Bambu Slicer likes to put seams at the weak point, even with a radius (Super Slicer does not), consider manually painting seams in your slicer if your slicer is putting seams on the stress concentration. The yellow brackets in my pictures are of the earlier version - you can see that the seams are at the worst place.

Corner Brackets - Designed for 3D Printing

2020extrusions

Jorge Rui

<blockquote>This design is free for the benefit of the community, but If you like my designs and want to contribute, you can make a donation to <a target="_blank" href="https://www.buymeacoffee.com/designrepcom" rel="nofollow noopener">buymeacoffee </a>or <a target="_blank" href="https://www.paypal.com/donate/?business=BUM67EMDJRXSN&amp;no_recurring=0&amp;currency_code=EUR" rel="nofollow noopener">paypal, </a>that will be greatly appreciated.&nbsp;For a small help use this affiliate link to buy fillament, it will cost you the same. Thanks !<a target="_blank" href="https://shareasale.com/r.cfm?b=2354730&amp;u=4026304&amp;m=138211&amp;urllink=&amp;afftrack=" rel="nofollow noopener">Filaments used on this project</a><a target="_blank" href="https://shrsl.com/4cpox" rel="nofollow noopener">Complete hotend for the X series</a><a target="_blank" href="https://shrsl.com/4cpoy" rel="nofollow noopener">Hotend with nozzle X series</a><a target="_blank" href="https://shrsl.com/4cpov" rel="nofollow noopener">Other Accessories</a>&nbsp;</blockquote><h2>A note about this model</h2>There is a nes and updated version of this, with a modular approach, based on my <a target="_blank" href="https://makerworld.com/en/models/13415?profileId=13268" rel="nofollow noopener">MMSS</a>, and is available <a target="_blank" href="https://www.printables.com/@jorge_rui" rel="nofollow noopener">here</a>.&nbsp;<figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012950/design/2023-09-07_37429ce72890f.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012950/design/2023-09-07_b69a4d08ab4d8.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012950/design/2023-09-07_8fb4405968195.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012950/design/2023-09-07_de4c9a7b9700e.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012950/design/2023-09-07_97413a6c36b6a.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012950/design/2023-09-07_b12c00384f143.jpg"></figure></td></tr></tbody></table></figure>Nevertheless, this one was my first take on this, and I think it’s nice for you to have something to store your tools and accessories ;)&nbsp;This is a debugged version of the initial release. It presents all the updates and some improvements that have been implemented in the meantime. This version will be updated over time.The entire production sequence was updated in order to translate the comments that were made over time by members. However, you are free to define your own printing strategy. The colored areas are already found as separate objects, therefore it is not necessary to use the painting tool, an exception for the areas where the accessories come reside; in this situation, I chose not to create different bodies, as it is my opinion it would take too long to print, increasing the potential for errors. In this last situation, and if you want, you can simply use the “area painting tool”.<h2>Instructions</h2>ClipsSome examples regarding fits and snapfits. <a target="_blank" href="https://youtu.be/TNyjlRgM0HY" rel="nofollow noopener">(youtube link)</a>&nbsp;Extra material:<ul><li>For the hinges, you will need 2x M4x30 CHC ISO 4762, or a FHC of the same size. If you don&#39;t have that you can print.</li><li>You may want the scrape… you can find it <a target="_blank" href="https://www.printables.com/model/531116-small-scraper-tool" rel="nofollow noopener">here, it is a model that I&#39;ve Remixed</a></li><li>spacer_ silicon_sock.STEP - needed if you have a narrow silicon sock on the hotend (most people will need this)</li></ul><h3>Change Log:</h3><ul><li>(31-08-2023) Revised Latch - More functional<ul><li>Optimizations and various dimensional compensations.</li><li>New 3mf file, which I hope will make the printing process simpler and with a higher success rate.</li></ul></li><li>(29-04-2024) Revised Latch - More functional <ul><li>Optimizations and various dimensional compensations.</li><li>New 3mf file, which I hope will make the printing process simpler and with a higher success rate.</li></ul></li></ul>&nbsp;

Householdimprovementrepairs

Office Organizers

X1upgrades

2020extrusions

X1 Organizers
