<p><span style="color: #E14747"><i>This model is intended for continual development, fostering openness. If you have suggestions or requests, please share them in the comments or via direct message. Please <strong>do not upload different sizes as remixes or add profiles of it</strong>, use the customize button to make your own version.</i></span></p><p><span style="color: #E14747"><i><strong>If you like it, press the button!</strong></i></span></p><h2>Parametric Sorting Tray</h2><p>This model is designed to build trays with customizable dimensions. The length and width can range from 80 to 300mm, while the height can go from 10 to 300mm. Although I don&#39;t recommend a 300mm height for a sorting tray, it&#39;s up to you to decide what works best for your needs. The trays have small chamfers on the outside and fillets on the inside to make it easier to retrieve objects. You can customize the corner radii with default options of 10mm, 20mm, and 30mm. The inner corners will adapt automatically based on your choices.</p><p>&nbsp;</p><p>To ensure the model generates correctly, the corner radius might be adjusted depending on your configuration of columns, rows, width, and length. I tried to make the model as robust as possible, but please check it in the slicer afterwards to ensure it meets your expectations. Unfortunately, I couldn&#39;t find a way to output the generated sizes directly to the tool, and adding text would result in it being printed, so I didn&#39;t use that option.</p><p>&nbsp;</p><p>You can adjust the number of columns and rows from 1 to 6. I&#39;ve found that more than this can make the tray unusable, but if you need more columns or rows, let me know. The first cell has a spanning option, allowing it to cover multiple rows or columns, which provides more customization options. Due to current limitations with MakerWorld, we&#39;re restricted to this first cell for now.</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000476243/design/2024-05-27_4055492226df7.png"></figure><h3>Available Parameters</h3><h4>Dimensions</h4><ul><li><strong>Length</strong>: 80 to 240 mm -<i> Default 160mm</i></li><li><strong>Width</strong>: 80 to 240 mm - <i>Default 160mm</i></li><li><strong>Height</strong>: 10 to 240 mm - <i>Default 20mm</i></li><li><strong>Radius</strong>: 10 / 20 / 30 mm - <i>Default 10mm</i></li></ul><h4>Columns and Rows</h4><ul><li><strong>Columns</strong>: 2 to 6 - <i>Default 2</i></li><li><strong>Rows</strong>: 2 to 6 - <i>Default 3</i></li></ul><h4>First Cell Spanning</h4><ul><li><strong>Colspan</strong>: 2 to 6 - Default 2</li><li><strong>Rowspan</strong>: 2 to 6 - Default 2</li></ul><p>&nbsp;</p><h3>Updates</h3><p><strong>28.05.2024</strong></p><ul><li>I was asked to be able to make even bigger trays. Even they will not fit any “known” BambuLab printer anymore. I´ve raised the limit for width, length and height to 300.</li></ul><h3>More Parametric Models</h3><figure class="table"><table><tbody><tr><td style="width: 50%"><figure class="image"><a href="https://makerworld.com/en/models/392542#profileId-293647" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000476243/design/2024-03-24_ff2c3f05d69cc.jpg"></a></figure><p><a target="_blank" href="https://makerworld.com/en/models/392542#profileId-293647" rel="nofollow noopener"><strong>Stackable Box / Boxes</strong></a></p></td><td style="width: 50%"> </td></tr></tbody></table></figure><p>&nbsp;</p><p><strong>I hope you enjoy the design, please leave a comment/rating if you enjoy it or share your feedback!</strong></p>

Parametric Sorting Tray / Trays

organizing

KYZ Design

<p>After watching standard 1x1 bins print infill layer after infill layer that could have been used for storage, this is one of the first 3D print models I've designed. I've since refined it, with the following features:</p><ul><li>0.84mm thick walls - a 0.4mm nozzle will do this in 2 passes</li><li>0.75mm thick base - designed for 3 layers of 0.25mm (but prints fine with 0.20mm layers)</li><li>Label shelf versions have 7mm wide label areas designed for 6mm wide labels</li><li>No magnet holes</li><li>Changes to fillets and chamfers</li><li>Other minor changes</li></ul><p>It is highly recommended to print 2 more at a time for a more consistent outer wall surface gloss. With just one bin, you might see that some sections are more glossy than others due to your filament profile's layer time limitations.</p><p>&nbsp;</p><p>Check out <a target="_blank" href="https://makerworld.com/en/u/11128021/collections/26498" rel="nofollow noopener">this collection</a> for my other Gridfinity models and</p><p>check out <a target="_blank" href="https://makerworld.com/en/u/11128021/collections/18964" rel="nofollow noopener">this collection</a> for my other Honeycomb Storage Wall models.</p>

Gridfinity Deep 1x1 Divider Bins

gridfinity

design element

<p>I designed a connecting silicone sealant holder set to be attached to a sliding door of a van but can be used on any wall or flat surface. The holders attach with two screws and slot over each other as a guide and fixing point. One starting holder and one end holder required and then add as many middle section holders as you require.</p>

silicone sealant tube holders

around the house

TheMiguelBi

<p>A few times I find poop leaking out of the chute and container.<br>This will solve the problem!</p><p>&nbsp;</p><p>&nbsp;</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/473042/2024-01-30_ca37d38508a62.jpg"></figure><p>&nbsp;</p><p>&nbsp;</p><p>Leaving room for an external coil:</p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/473042/2024-01-30_fc42dc0766428.jpg"></figure><p>&nbsp;</p><p>You will only need a screw slightly longer than the original. <br>I used an <strong>M3 screw</strong> (even though it is not a metric M3 supplied).</p><p>&nbsp;</p><p>→ If you are looking for the file for the <a target="_blank" href="https://makerworld.com/en/models/84867#profileId-90722" rel="nofollow noopener">magnetic ramp</a>, you can find it here:<br><a target="_blank" href="https://makerworld.com/en/models/84867#profileId-90722" rel="nofollow noopener">https://makerworld.com/en/models/84867#profileId-90722</a></p><p>&nbsp;</p><p>→ And if you want to attach a <a target="_blank" href="https://makerworld.com/en/models/84815#profileId-90663" rel="nofollow noopener">fake padlock</a> to your container, you can find it here:<br><a target="_blank" href="https://makerworld.com/en/models/84815#profileId-90663" rel="nofollow noopener">https://makerworld.com/en/models/84815#profileId-90663</a><br> </p><p>&nbsp;</p><p>&nbsp;</p><p>Enjoy!</p><p>&nbsp;</p><p>&nbsp;</p>

Poop Blocker for Magnetic Slide

printer

Brian Dean

<h2><strong>Embedded Magnet Dispenser Tool for Multiple Diameters and Thicknesses</strong></h2><h3>PROFILE NOTE</h3><p><strong>Please use the “Designer” profile as it guarantees the latest files and version with all new magnet sizes and features. The Designer Profile will be listed at the top.</strong></p><h3>Latest Update (2024-04-21): Quick summary</h3><ol><li>additional magnet sizes</li><li>magnet size text embossed on the barrel and also included on the slider</li></ol><p>See below for the more detailed update notes.</p><h2><strong>Magnet Dispenser for 3D Prints: Simplify Magnet Insertion with Precision</strong></h2><p><span style="color:rgb(55,65,81);font-size:16px;">The Magnet Dispenser Tool is expertly designed to streamline the insertion of magnets into 3D prints. This tool not only speeds the process of inserting magnets into 3D Prints, it also ensures correct orientation and secure fitting, making it ideal for projects that require precise magnet placement.</span></p><h3><strong>Key Features</strong></h3><h4><strong>Dual Dispensers for Perfect Alignment</strong></h4><ul><li>Includes two dispensers for each magnet size – one for north-up and one for south-up orientations</li><li>Use different colors (e.g., red for north-up and blue for south-up) to help easily identify the dispenser&#39;s orientation</li><li>Eliminates the hassle of misaligned magnets</li></ul><h4><strong>Design and Utility</strong></h4><ul><li>Developed after extensive refinement</li><li>Allows for friction-fit insertion and is also suitable for magnets that are glued</li><li>Tapered tip facilitates use in tight spaces</li></ul><h4><strong>Ease of Use</strong></h4><ul><li>The dispensers are designed to accommodate the specified magnet sizes for their internal holding magnets, but can dispense magnets of any thicknesses for the specified diameter. For example, for the 6x3mm dispenser, you will need 6x3mm magnets to assemble the dispenser, but once assembled, that dispenser can dispense any 6mm diameter magnet such as 6x1, 6x2, 6x3, 6x5, etc.</li></ul><h4><strong>Convenience and Storage</strong></h4><ul><li>Features a snap-on cap with an embedded magnet and a top slider magnet</li><li>Ensures secure storage and prevents accidental magnet spillage</li></ul><h4><strong>Customization and Printability</strong></h4><ul><li>No supports needed for printing</li><li>STL and STEP files included for personal customization</li><li>Compatible with PETG, PLA, ASA, ABS, etc</li><li>Adjust x/y hole compensation if needed for perfect fit</li></ul><h4><strong>Visual Guide</strong></h4><ul><li>Fusion 360 images provided for easy assembly and understanding of the internal mechanism</li></ul><h4><strong>Use the Magnet Dispenser for a hassle-free, precise, and efficient magnet insertion experience in your 3D printing projects.</strong></h4><h3>Supported Magnet Sizes</h3><h4>Dispensers are now provided for the following magnet sizes as of <i>Version 5</i></h4><ol><li>2x1mm</li><li>2x2mm</li><li>2x3mm</li><li>3x1mm</li><li>3x2mm</li><li>3x3mm</li><li>4x1mm</li><li>4x2mm</li><li>4x3mm</li><li>5x1mm</li><li>5x2mm</li><li>5x3mm</li><li>6x2mm</li><li>6x3mm</li><li>7x2mm</li><li>7x3mm</li><li>8x2mm</li><li>8x3mm</li><li>8x4mm</li><li>9x2mm</li><li>9x3mm</li><li>10x1mm</li><li>10x2mm</li><li>10x3mm</li><li>12x2mm</li><li>12x3mm</li><li>15x2mm</li><li>15x3mm</li><li>20x2mm</li><li>20x3mm</li></ol><p>NOTE 1: The 1mm magnet thickesses are just too thin to work reliably with the friction-fit of the slider and caps. Therefore, I have made the pockets of the “1mm” thickness magnet dispensers to be that of the 3mm variety so that they work. So to assemble a 1mm magnet thickness dispenser, you will need to purchase a few 3mm thick magnets to assemble the dispenser. A 2mm thickness will likely work ok, too. Note that the text on the dispenser will still say “D x 1 mm” for the barrel, “Dx1” on the cap, and “D/1” on the slider, so you know what magnets you have loaded into it.</p><p>&nbsp;</p><p>NOTE 2: the above are the sizes needed to assemble the dispenser. The dispenser can still dispense any thickness of magnet as long as the diameter is the same. So if don&#39;t see your specific magnet thickness listed above, you can still print the correct diameter, assemble the dispenser with the correct magnet thickness, and dispense other thicknesses.</p><p>&nbsp;</p><p>STEP and STL raw files are included if you do not wish to use the provided profile.</p><h3>Quality Assurance Testing</h3><ul><li><span style="color:rgb(55,65,81);font-size:16px;">All dispenser sizes have been printed by me and extensively tested</span></li><li><span style="color:rgb(55,65,81);font-size:16px;">I have purchased all magnet sizes at significant expense to myself to ensure fit</span></li><li><span style="color:rgb(55,65,81);font-size:16px;">Magnet diameters are tricky for press-fit tolerance and controlled by no less that 5 Fusion 360 parameters that must be balanced to achieve good fit</span><ul><li><span style="color:rgb(55,65,81);font-size:16px;">Multiple iterations of each dispenser were printed and refined</span></li><li><span style="color:rgb(55,65,81);font-size:16px;">Many kilograms of filament and hundreds of hours of print-time were consumed during this process</span></li><li><span style="color:rgb(55,65,81);font-size:16px;">All to ensure the best quality printing and fit-up for each dispenser size</span></li></ul></li></ul><h3>About the Profiles</h3><ol><li>Please use the “Designer” profile as it guarantees the latest files and version with all new magnet sizes and features. The Designer Profile will be listed at the top.</li><li>NOTE: The “Designer” profile is a single profile that contains plates for all magnet sizes so far. Please ignore the “total time” reported by MakerWorld for the profile. You only need to print the plate(s) that you need. Each plate takes about 2.5-2.9 hours on my X1C using the included “PETG” profile which is slowed down for good PETG layer adhesion and quality.</li><li>While the other profiles may be ok, their file / update version may be out of date. So if you want the latest sizes and model improvements, please choose the top “Designer” profile.</li></ol><h3>Accessories</h3><p>Be sure and check out some nice accessories that other folks have created to work with these dispensers.</p><ul><li><strong>Tip Caps</strong> - these are nice caps for the dispensor tip. Not only do they help keep the magnets contained within, but they also protect the tip. Additionally, they are labeled with the magnet size, which is nice. Thank you @onegotowned ! <a target="_blank" href="https://makerworld.com/en/models/149038#profileId-162633" rel="nofollow noopener">https://makerworld.com/en/models/149038#profileId-162633</a></li><li><strong>Vertical Workbench Stand</strong> - This is a very nice stand for select diamagers made by @nickramsey57. A number of folks have asked about stands / organizers for the dispensers, so this model will likely be useful to a number of folks. Thank you @nickramsey57 ! <a target="_blank" href="https://makerworld.com/en/models/206388#profileId-226561" rel="nofollow noopener">https://makerworld.com/en/models/206388#profileId-226561</a></li><li><strong>Vertical Workbench Stand (parametric)</strong> - Here is another very nice stand made by @RevHazlett. You can specify the dispenser sizes that you want it to hold and then generate, making it customizable to your needs and the common magnet sizes that you use. Thank you @RevHazlett! <a target="_blank" href="https://makerworld.com/en/models/435087#profileId-340031" rel="nofollow noopener">https://makerworld.com/en/models/435087#profileId-340031</a></li></ul><h2>Update History</h2><h3>Version 5: 2024-04-21</h3><ol><li>Emboss the magnet size text on the Barrel (see photos), allowing one to view the size from the side, and also allowing one to print all of the barrels on a single plate and not get the barrels mixed up as to what size they are for.</li><li>Include the magnet size text on the Slider (see photos), allowing one to print all of the sliders and caps together on one plate and not get the sliders mixed up as to what magnet size they are for. Also provides additional text identification of the magnet size within.</li><li>Include 11 new magnet sizes:<ol><li>3x1mm</li><li>4x1mm</li><li>5x1mm</li><li>7x2mm, 7x3mm</li><li>8x4mm</li><li>10x1mm</li><li>15x2mm, 15x3mm</li><li>20x2mm, 20x3mm</li></ol></li><li>Re-organize the plates so that they are a little easier to manage. All dispenser sizes for each “diameter” are spread across three plates now - the Barrels, the Red Caps and Sliders, and the Blue Caps and Sliders. This allows one to “print-by-layer” instead of “print-by-object”, and the text also comes out better. Additionally, it is now easier to construct a plate with all of the size variations on 3 individual plates and print them all at once.</li></ol><h3>Version 4: 2023-12-26</h3><ol><li>Fixed an issue where the smaller diameter magnets such as the 2mm, 3mm, and possibly the 4mm magnet diameters could inadvertently slip through the vertical barrel slider stem slot. Prior to this update, the slider stem was a fixed 3mm + tolerance width. With Version 4, the slider slot is now dynamic based on the magnet diameter. So now, the smaller diameter magnets are captive within the barrel and cannot slip out inadvertently.</li><li>Tighten up the tolerances between the “slider” and the “barrel” for a better fit and smoother operation.</li><li>Use the Profile: “Version 4: All Sizes …” for the latest from this update.</li></ol><h3>Version 3: 2023-12-22</h3><ol><li>Added additional magnet sizes<ol><li>2x1mm, 2x2mm, 2x3mm</li><li>9x2mm, 9x3mm</li></ol></li><li>Text is now added within the Fusion 360 Model File, eliminating the need to add the text using Bambu Studio<ol><li>Ensures consistent text placement and easier colorizing of the text</li></ol></li><li>All plates are included for all magnet sizes, two dispensers per plate, print sequence: print-by-object</li></ol><h3>Version 2.1: 2023-11-28</h3><ol><li>Added additional magnet sizes<ol><li>3x2mm</li><li>4x2mm, 4x3mm</li><li>5x2mm, 5x3mm</li><li>6x2mm</li><li>8x2mm, 8x3mm</li><li>10x2mm, 10x3mm</li><li>12x2mm</li></ol></li><li>The magnet size text is included on the cap for easy identification - see photo</li></ol><h3><strong>Version 2: 2023-11-20</strong></h3><p>Updated to “Version 2”. Significant updates an enhancements have been made, some seen, some unseen.</p><ol><li>Added additional magnet sizes<ol><li>3x3mm</li><li>12x3mm</li></ol></li><li>Each magnet size is on its own plate, two dispensers per plate, print sequence: print-by-object</li><li>Redesigned “thumb slider” for greater comfort and stronger press force</li><li>Slider stem has been reinforced</li><li>Many enhancements for smoother operation with internal chamfers and fillets, enhanced tolerances, and strengthening of key internal components</li></ol><p>&nbsp;</p><p>&nbsp;</p><p>&nbsp;</p>

organizing

gridfinity

around the house

printer

tools
