samiimas3d

Sevro

Instruction how to train your dragon.After printing, you have to make some bends.The most important is bending of the tail a little up.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_742i3oxai92n.jpg"></figure>You can also bend it a little into V shape<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_8ysm4b56u0cv.jpg"></figure>Next important thing is bending of wings a little bit up.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_uwh80du8jcaq.jpg"></figure>Beyond that you can play with middle small wings and bend it up or down or just leave them as they are.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_46milndjqctn.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_owq4oq6r94ge.jpg"></figure>With version 2.1 you don't have to add ballast to the head. With 100% infill and PLA, dragon should be good balanced.If you accidentaly printed dragon with lower infill than 100%, add play-doh or plasticine to the head and it will be flying too.Sometimes the model is demand a little refresh shape after hard landing. Good throw technique is also important. Throws it like paper airplane. Prepare that not every flight will be good. But if you train the dragon a little then smooth flight is very satisfactory :)PrintingPrint in place with PLA, with 100% infill (for proper head ballast) and 0.2 mm layer height. You have to have good bed leveling, because wings and tail have only one layer height. With my prusa mk2 with 0.6 nozzle it takes about 30 minutes. FilesThe model has two versions One without horns to quickly print and fly.Second one with horns on the back to fix it to the ceiling and for a better look :) Horns fix with superglue.Besides, there is a desk stand, wall sticker and ceiling hanger. To stick it to the surface, use double side tape. Print it with layer height whatever you want.Flights Below some outdoors exemplary tweaks nad flights.Version 2.1 without ballast. Flights were performed with windy condition so dragon was a little nervous :)<figure class="media"><div data-oembed-url="https://youtu.be/N9rLLoG5ESg"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/N9rLLoG5ESg" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>Version 1 with balast.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_daiibxm95bxl.webp"></figure><figure class="image image-style-align-center"><img src="https://makerworld.bblmw.com/makerworld/user/707210016/draft/2023-08-14_unilyl8lzdjy.gif"></figure>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

Flying Night Dragon

FlorinV

Great desk accessory, to look at, to play with(easy to spin) and to use.&nbsp;Update 27.01.2024: Increase the filament infill and walls of the arm (to better hold it&#39;s shape in time, as the magnetic force tries to deform it). Changed one of the screws to be a shorter version, in case your magnets are too strong and need a shorter one to fit.Update 31.01.2024: Added another pen model (Hexagonal style). There is a new profile for this one. Enjoy !&nbsp;Features:<ul><li>Parts needed: 3 magnets with size 10x2mm. Probably you can use smaller magnets also, but you would have to add maybe one more magnet to the support arm. You need to play with it. Also 8x2mm magnets should be fine, but this is not tested by me (someone else tried).</li><li>No AMS needed to print it multicolor.</li><li>Two different pen designs to choose from. You can use them without support and magnets, if you want.</li><li>The pen design included in the main profile, is the stronger one, clean and with a special cutout that can be used to check the level of ink in your reserve.</li><li>The optional pen design is using a thin insert to make the pen multicolored without using AMS or wasting a lot of filament and time.</li><li>Optional tag caps to attach to the support arm. You can add one character to each cap and form a gamer tag, a name, an abbreviation etc. Or add some color pattern, whatever you like.</li><li>Designed for Pilot reserves ( 0.7mm), but can work with any pen reserve as long as you cut it at 122mm length. Just search with google something similar with: Pilot FriXion Pen Refills, 0.7 mm</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000146589/design/388de27a-0257-4f7d-870e-8d9665c7c1de.jpg"></figure><ul><li>If you use Pilot reserve, you have to use the little spacer as displayed in assembly pictures or video.</li><li>If you choose to use another type of pen reserve, just cut it at 122 mm length and don&#39;t use the spacer anymore. Tested with simple pen reserve like the one bellow, and it works also. Just cut it to 122mm length and don&#39;t add the little spacer provided for Pilot reserves.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000146589/design/2024-01-19_8d03559413d1e.png"></figure>Assembly guide:<ul><li>Please check the video at the end with full setup and please use subtitles, as I&#39;ve added some useful information while assembling it.</li></ul>Pen:<ul><li>Please remove carefully the brim from the body of the pen after printing it. Usually if the bed sticks good, when you pull the body pen, the brim with separate easily. I&#39;ve setup a small gap between pen and brim, to be sure it sticks well, as it&#39;s a tall and narrow part.</li><li>Attention! Before gluing the magnet cap to the pen, be sure the magnet is facing the right direction to be attracted by the magnets on the support.  Carefully glue the magnet cap, to not get glue everywhere.</li><li>Please check bellow all the parts of the pen and how they are connected.</li></ul><figure class="image image_resized" style="width: 71.29%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000146589/design/2024-01-19_6cf57802c8d71.jpg"></figure>Support:<ul><li>Carefully remove the supports from the base part.</li><li>Insert the arm into the base and screw in the provided screw. There are 2 versions of the screw in the profile, one longer and one shorter. Depending on your magnets power, use the one that works better for you.</li><li>Be sure you screw it in enough so that the base can lay flat on the table. Change the screw with the shorter version if you need to.</li><li>Add two magnets (10x2mm) on the top hole of the arm. Before gluing them, be sure they are aligned with the magnet from the pen, so that they attract each other!</li><li>After everything is setup, you can use the bottom screw to fine tune the distance between pen magnet and support arm magnets, so that it holds the pen good, but don&#39;t pull up the pen from the base.</li></ul><figure class="image image_resized" style="width: 78.12%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000146589/design/2024-01-19_ff9970461619c.jpg"></figure><figure class="media"></figure>&nbsp;Step by step on how to customize the letter caps:<ul><li>you open the &#34;8 blank caps to customize&#34; into Bambu studio, </li><li>select one of the caps objects, </li><li>click on the TEXT icon -add one letter into the &#34;Input Text&#34; field </li><li>move your mouse cursor over the cap and click when you center it </li><li>you can move it around again by selecting the &#34;text_shape&#34; object later under the &#34;button.stl&#34; object </li><li>Repeat for each letter you want. (you have 8 caps into the profile, but you can clone them to have more if you want)  </li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000146589/design/2024-03-18_a5b871a5e0d65.png"></figure>

Magnetic Levitating Holder & 3 pen models

gift

Pirate_The_Captain

Pen and pencil holder made from a real CT scan of the human cervical vertebra.&nbsp;A truly original pen stand that will stand out on your desk.&nbsp;The model of the pen and pencil holder can be printed in one unit (spine_pen_holder.stl). I recommend using organic supports.You can also print the model in two parts and then glue them together. To assemble, use the spike_1.stl and spike_2.stl.

Spine Pen Holder

Muath

Whopper Printing

<a target="_blank" href="https://www.etsy.com/listing/1509591113" rel="nofollow noopener">Get the V-Twin here</a>!&nbsp;Print the weights at a higher infill percentage to actually give them weight (I used 70-80% infill on the weights).This entire print is around 180g of filament, but it's been designed to share parts with my other engines I'm working on as well as the brand new <a target="_blank" href="https://www.etsy.com/listing/1509591113" rel="nofollow noopener">V-Twin engine</a>! This means you only have to print a couple different parts to build whole new engines! Other models coming soon.Join <a target="_blank" href="https://www.patreon.com/whopperprinting" rel="nofollow noopener">Patreon</a> to get every new paid model released for free (only Advanced and Commercial Tiers), including new engines I release!Please post your makes, I love seeing them!&nbsp;If you would like to support me, consider these options:&nbsp;Social Links:<ul><li><a target="_blank" href="https://whopperprinting.com/" rel="nofollow noopener">WhopperPrinting.com</a></li><li><a target="_blank" href="https://patreon.com/whopperprinting" rel="nofollow noopener">Patreon</a></li><li><a target="_blank" href="https://whopperprinting.Etsy.com" rel="nofollow noopener">Etsy</a></li><li><a target="_blank" href="https://instagram.com/whopperprinting" rel="nofollow noopener">Instagram</a></li><li><a target="_blank" href="https://discord.gg/UfyQhUfn4N" rel="nofollow noopener">Discord</a></li><li><a target="_blank" href="https://www.tiktok.com/@whopperprinting" rel="nofollow noopener">TikTok</a></li></ul>&nbsp;

Single Piston Engine - Fully Printed Buildable Kit (With Printed Screwdriver!)

Engen

jr2142

I came up with this dry box holder after using 22L Samla boxes for a while to store my filament. Here are the advantages of using a 45L Samla box instead:<ul><li>It fits up to 10 spools compared to the 8 spools in 2x22L boxes while requiring the same space</li><li>Filament swaps are less of an hassle as the likelihood of having to open multiple boxes is at least halved</li><li>The setup is cheaper, as 2x22L boxes are more expensive than 1x45L</li></ul>The 45L box is perfect for PLA and PETG, I have between 40-50% humidity in my area and with desiccant I can store it below 20% for 6+ months depending on how frequently I have to open the box. I still use 22L boxes for hygroscopic material like Nylon, TPU or PVA, but with a <a target="_blank" href="https://makerworld.com/en/models/226204#profileId-243947" rel="nofollow noopener">gasket</a>.<h4>Change Log:</h4><ul><li>2024-03-29 v1.1: Added loose fit variant of connectors and original tight ones are printed in PETG now</li><li>2024-02-24 v1.0: Initial release</li></ul><h4>Features</h4><ul><li>This design has been optimized to minimize waste of filament<ul><li>One frame piece is 30g which is possible as it is only there to position the rod holders</li><li>The complete print is 215g, that is less than many 22L spool holders out there</li></ul></li><li>The rods have been tested with double the load (5 stacked spools instead of 2.5 per section) for multiple days</li><li>The rod holders are designed to leverage the additional space in the upper part of the box, generating the required space to fit 10 Bambu spools</li><li>Optimized for loose desiccant as you can more easily see the color-change. Use the clips to easily get the frame out in one piece, when it is time to dry the desiccant</li><li>Includes a hygrometer holder that is angled 45 degrees to be easily readable, when the box is on the floor</li></ul><h4>Printing instructions</h4>Note that the design requires a print bed of 250x170mm or bigger. You could split the frames in the middle, though. Print each plate in the profile once, except the last two. The last two plates are containing connector clips and hygrometer holder, which are optional. The tight fit variant is designed to be printed in PETG and the loose fit variant for PLA. Here are the key settings should you use another slicer than Bambu Studio:<ul><li>Print the frame with two perimeters/walls at 0.28mm layer height and 15% cubic infill</li><li>Print the rods with 4 perimeters at 0.28mm layer height and 25% cubic infill and <a target="_blank" href="https://www.youtube.com/watch?v=qBvTWFEd7rk" rel="nofollow noopener">reduce the speed</a>, if you have a high-speed printer with stock nozzle</li><li>Print the hygrometer holder with 0.16mm layer height and 15% infill, it has been designed to print without supports, but there is a small overhang benefiting from the lower layer height<ul><li>The tight fit connectors are recommended to be printed in PETG. PLA does work, but requires proper flow calibration and the latches of the connectors might break apart when not assembled carefully</li><li>Loose fit connectors can be printed in PLA</li></ul></li></ul><h4>Assembly</h4><ul><li>Put the 4 frames together as shown in the assembly view below or use the assembly view in your slicer</li><li>Put the 4 rods together and install them onto the rod holders. Note that the angled side of the rod holders have to face the outside rod holders</li><li>Optional: Put the digital hygrometer into the holder and clip it on one of the long edges. The holder is for hygrometers with a 41mm diameter on the inside (not the top). I bought the hygrometer on <a target="_blank" href="https://amzn.to/3IdfOuK" rel="nofollow noopener">Amazon</a></li><li>Optional: Use the other two connectors to keep the 2x2 frames together. Only required, if you put loose desiccant into the box and want to more easily remove the holder in one piece without removing the hygrometer first</li></ul>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/785813/2024-02-24_8170d0ddc7328.png"><figcaption>Assembled View</figcaption></figure>

Trådförvarare: Dry Box Spool Holder IKEA Samla 45L

RobH2

I tried the PTFE Guide here but it still banged on the door of my P1S pretty drastically. The maximum distance from the filament inlet to the front of the head cover/fan is only 20mm. I shortened this model even more and now I don't have any banging on the door. The original file obviously works well for a lot of people. But if you are like me and it didn't, give this one a try. It might solve your banging issue.

ptfe_guide_103PCT_20mm Overhang_NV4D_FINAL.3mf

BmbuLab X1C

3Dacores

Bambu Lab where innovation meets craftsmanship in the world of 3D printing! Your 3D printing room adorned with this 3D logo is where your ideas come to life.&nbsp;The Bambu Lab symbolizes the vibrant energy that fuels the passion of this company for pushing the boundaries of 3D printing technology.&nbsp;Join their journey of innovation, where technology meets artistry, and see your visions materialize with unparalleled precision under the gentle radiance of the Bambu Lab.&nbsp;<blockquote>Disclaimer: The use of the logo or character in this design is for illustrative purposes only and does not imply endorsement or sponsorship. All trademarks, logos and characters are the property of their respective owners. Any reference to specific brands is not intended to infringe upon or challenge the ownership rights of the trademark holders. I respect the intellectual property of all brands and/or characters mentioned or used in this design. If you think this design infringes on the ownership rights of the trademark, please submit a copyright complaint, and this design will be removed immediately.</blockquote>

Bambu Lab logo 3D emboss letters

marekzeman91

<h3>Study board with numbers for kids.</h3>For easier studying try to print it with more colors. I decided to make each row with different color so the kids can learn in groups by color.<h3> </h3><h3>Printing tips</h3><ul><li>Infill: use as little as possible for the board (I used 10%) to keep the board light.</li><li>Bending: use glue stick or spray to keep your print hold on the plate.</li><li>Size: suggested to print at 100%. Should print fine even at 50% due to added spacing.</li><li>Numbers: print them as they are in the model, it will make the top surface perfect.</li></ul>

Board: Numbers

Educations

Jorge Rui

This design is free for the benefit of the community, but If you like my designs and want to contribute, you can make a donation to <a target="_blank" href="https://www.buymeacoffee.com/designrepcom" rel="nofollow noopener">buymeacoffee </a>or <a target="_blank" href="https://www.paypal.com/donate/?business=BUM67EMDJRXSN&no_recurring=0&currency_code=EUR" rel="nofollow noopener">paypal, </a>that will be greatly appreciated.If everyone contributes even with a small amount, that can make the difference to allocate more time doing this (<a target="_blank" href="https://www.paypal.com/donate/?business=BUM67EMDJRXSN&no_recurring=0&currency_code=EUR" rel="nofollow noopener">PayPal</a> and <a href="buymeacoffee.com/designrepcom" rel="nofollow">buymeacoffee</a>). But the best and more reliable way to support is with a regular contribution, like <a target="_blank" href="https://www.patreon.com/Design_repcom" rel="nofollow noopener">patreon</a> or <a target="_blank" href="https://ko-fi.com/designrepcom" rel="nofollow noopener">ko-fi</a>. ———<h4>Introduction and context </h4>This item was something I particularly like, not just by is aesthetic and function, but particularly because is something you have to spend time putting all pieces together. this creating an intention and forcing concentration on the doing.Still regarding the design, it holds a storage compartment on the back (see photo), where the digit segment stays together without mixing. we can make any combination you like when using more than one. With large digits and easy to read, is a nice item for office or even a guesthouse. you can complement with a QRcode os something else, like a Logo.<h4> Assembly instructions </h4>the assembly is quite simple, but it takes time. Time that you to be focus. For more information, see drawing<figure class="image"><img src="https://media.printables.com/media/prints/541697/rich_content/219dc9b6-1c6a-47f5-8b36-9db5b25e9ae1/screenshot-2023-07-31-190925.png#%7B%22uuid%22%3A%22bb83d22d-1810-4467-8ebe-167666b4f095%22%2C%22w%22%3A1774%2C%22h%22%3A1233%7D"></figure><h4>Print instructions </h4>This assembly uses tight fits, precision on print is required. the Elephant foot problem can be an issue. I’ve designed it to circumvent this, but remember to make a test of a small portion (use Boolean operations in slicer for that). Particularly in the digit segments , if you find the fit not perfect, and your printer does not want to cooperate (elephant foot, input-shaping and others) the scale command is your friend. I now this will be a problem for some, does o read the instructions will have solutions, and life will be easy :) <h4>Encores </h4>(forgive me, I’m finishing writing this on my holidays, and have to much spare time… Btw, I’m sketching some nice things. So, don’t forget to “support the designer“.

Digit Info Board

funny

<h4>Description and contextualization</h4><blockquote>A present to you, a Rack for the Mutil-Modular Storage System (MMSS) that I've been developing. Don't go running to buying a ton of filament, first you must understand how this work....You can do it step by step.You can start with a simple model, and store it in your closet, some drawer, or card box; a month later, you may buy something else and print the corresponding module to store your precious component or accessories. Someday, you may need a box or maybe a case (if you have to transport your things) to store the modules you already have…In the limit, some people, need a complete rack, because they have a lot of things (maybe a print farm).But this rack, on its own, has the Build plate dispenser, and for most people, this project ends there. But you are like my, and make things scalable and that's why this is all modular.</blockquote><h3>Introduction</h3>This rack serves as a support to the different projects carried out around what I can already call an ecosystem, namely; <ul><li><a target="_blank" href="https://www.printables.com/model/556159-multi-modular-storage-system-mmss" rel="nofollow noopener">Multi-Modular Storage System -MMSS</a> </li><li><a target="_blank" href="https://www.printables.com/model/557727-box-with-lid-for-mmss" rel="nofollow noopener">Box with lid for MMSS</a></li><li><a target="_blank" href="https://www.printables.com/model/556615-case-for-the-mmss" rel="nofollow noopener">Case for the MMSS</a></li></ul><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_yakhnxubxzta.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_h8ksq5b2vafv.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_opyjqt3vl1be.jpg"></figure></td></tr><tr><td><a target="_blank" href="https://www.printables.com/model/556159-multi-modular-storage-system-mmss" rel="nofollow noopener">Multi-Modular Storage System -MMSS</a> </td><td><a target="_blank" href="https://www.printables.com/model/557727-box-with-lid-for-mmss" rel="nofollow noopener">Box with lid for MMSS</a></td><td><a target="_blank" href="https://www.printables.com/model/556615-case-for-the-mmss" rel="nofollow noopener">Case for the MMSS</a></td></tr></tbody></table></figure><ul><li>The amount of modules you can add is growing fast:<ul><li><a target="_blank" href="https://www.printables.com/model/557566-mmss-2x4-module-glue-stick-and-hexagonal-keys" rel="nofollow noopener">MMSS 2x4 Module - Glue Stick and Hexagonal Keys</a></li><li><a target="_blank" href="https://www.printables.com/model/557452-mmss-1x1-module-microsd" rel="nofollow noopener">MMSS 1x1 Module - MicroSD</a></li><li><a target="_blank" href="https://www.printables.com/model/557397-mmss-1x1-module-nozzle-wipper" rel="nofollow noopener">MMSS 1x1 Module - Nozzle Wipper</a></li><li><a target="_blank" href="https://www.printables.com/model/557390-mmss-1x1-module-filament-cutter-microsd" rel="nofollow noopener">MMSS 1x1 Module - Filament Cutter + MicroSD</a></li><li><a target="_blank" href="https://www.printables.com/model/570948-mmss-1x1-module-filament-cutter" rel="nofollow noopener">MMSS 1x1 Module - Filament Cutter</a></li><li><a target="_blank" href="https://www.printables.com/model/559405-mmss-1x2-module-hotend-and-silicon-sock" rel="nofollow noopener">MMSS 1x2 Module - Hotend and Silicon Sock</a></li><li><a target="_blank" href="https://www.printables.com/model/561092-mmss-1x3-module-complete-hotend" rel="nofollow noopener">MMSS 1x3 Module - Complete Hotend</a></li><li><a target="_blank" href="https://www.printables.com/model/561215-mmss-2x3-module-small-scraper" rel="nofollow noopener">MMSS 2x3 Module - Small Scraper</a></li><li><a target="_blank" href="https://www.printables.com/model/564616-mmss-2x5-module-liquid-glue" rel="nofollow noopener">MMSS 2x5 Module - Liquid Glue</a></li><li><a target="_blank" href="https://www.printables.com/model/563208-mmss-various-size-modules-pocket-with-lid" rel="nofollow noopener">MMSS various Modules - Pockets with Lid</a></li><li><a target="_blank" href="https://www.printables.com/model/580675-mmss-2x3-module-spool-holder" rel="nofollow noopener">MMSS 2x3 Module - Spool Holder</a></li><li><a target="_blank" href="https://www.printables.com/model/567939-mmss-1x5-module-original-bambu-lab-scraper" rel="nofollow noopener">MMSS 1x5 bambu lab original scraper</a></li><li><a target="_blank" href="https://www.printables.com/model/618034-mmss-2x4-module-pocket-with-lid-for-bolts-and-magn" rel="nofollow noopener">MMSS 2x4 Bolts and Magnets Pockets with Lid</a></li><li><a target="_blank" href="https://www.printables.com/model/686267-mmss-2x2-module-extruder" rel="nofollow noopener">MMSS 2x2 Module - Hardened Steel Extruder Unit</a></li><li><a target="_blank" href="https://www.printables.com/model/613965-bambu-lab-ams-service-and-spares-parts-for-the-mms" rel="nofollow noopener">MMSS for AMS Modules</a> <ul><li>4x Active extrusion wheel assembly;</li><li>4x Active support shaft assembly;</li><li>4x PTFE Tube Fast Connector;</li><li>4x Driven Support Shaft Assembly</li><li>1x First Stage Feeder</li></ul></li><li>More to come… I'm always adding new modules, please check <a target="_blank" href="https://www.printables.com/@jorge_rui" rel="nofollow noopener">my profile </a> and here on <a target="_blank" href="https://makerworld.com/pt/u/3059492201" rel="nofollow noopener">makerworld.com</a> for the later information, some are free, others are only available as exclusives for members of "<a target="_blank" href="https://www.printables.com/@jorge_rui/exclusive-models" rel="nofollow noopener">my club</a>".</li></ul></li><li>This rack adds now support for the build plates.</li></ul><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_028behu1ai4g.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_r0t2wpt4b0hc.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_iynsbv28k7qz.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_e0zdl1u2l61m.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_0xxhhupg1j68.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_b96wxyl4ivi0.jpg"></figure></td></tr></tbody></table></figure>… and more<h3>Assembly info</h3><blockquote>Read carefully the explanation that fallows. I've tried to be systematic for anyone to understand. This os not a print of a small toy or a vase, you will need to make decision, so make them informed.</blockquote>1- Start here - Assemble the base that will serve the build plates. if you have many you can stack them together. 1.1 - All you need, and more, is available withing the file “rack_lower_module.3mf”.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_90fcltoa6t1b.png"></figure>2 - Now you have a choice to make: 2.1 - Stop here on the basic module for the build plates, or; 2.2 - continue to add other parts from the MMSS ecosystem.If MMSS = 2.1 then; You will need a cover like this to finish the job, you will find that part on the 3mf file regarding the rack for build plates<figure class="image image_resized" style="width:75%;"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_v5wp6a6k3st9.jpg"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_6wmgn4kaqu97.png"></figure>Tip:For the <a target="_blank" href="https://shrsl.com/4cpnz" rel="nofollow noopener">PETG </a>springs, flex the back plate a little for them to slide on the dovetail. <figure class="image image_resized" style="width:75%;"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_cg9pvea3vxof.png"></figure>If MMSS = 2.2 then;<ul><li>you can add other rack for build plates, if really like build plates :) or;</li><li>add a MMSS box or case, or several of them. </li></ul> 2.2.1 Ok, you need to add more modules on top of the “Base module" that serves the build plates. Now you can choose to continue with the barebone or the complete version.<figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_xvcygijnz78z.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_dgrggf1uh6w5.jpg"></figure></td></tr><tr><td>2.3 - Barebone rack</td><td>2.4 Complete rack</td></tr></tbody></table></figure>If MMSS = 2.3 then;2.3 Barebone RackIf you go this way, you will need some new parts that you can find on the 3mf file “rack_middle_modules.3mf”.<blockquote>This drawing will help you choose the right heights for the spacers, almost all the parts are the same for any modules you choose, with the exception of the top.</blockquote><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_ezkcpjon3vvn.png"></figure>Easy, isn't it? ;) 2.3.1 There are some parts that you will need to go up, in what I call, the middle steps. These parts can be found on the 3mf file stated on 2.3 point. You can stack modules on top of each other, most parts are the same, just be careful to choose the “Pillars” A, B or C depending on what you need, these will give you the space necessary for each module (see drawing above).&nbsp;&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_max8ix3ip37e.png"></figure><blockquote>See does red pins? They have to go with a tight fit, if you notice them loose on the guides or on the Pilar’s see if the filament is calibrated, sometime, certain materials shrink more than others, petg tends to be more stable… anyways if all fails, use the scale tool on the slicer to compensate.</blockquote> 2.3.2 At some point you will reach the top, and you will need to close the rack top.<figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_mzlwingfk9g9.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_572cuaywt1k1.png"></figure></td></tr><tr><td>2.3.2.1 - Normal top</td><td>2.3.2.2 - Top made with the lid from the Box for the MMSS</td></tr></tbody></table></figure> 2.3.3 After choosing the top, you can print the corresponding modules from the “rack_tops_modules.3mf”.If MMSS = 2.4 then;2.4 The complete rack - This will add some panels to the side of the rack, making it look like this:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_kft5olj06k4q.jpg"></figure><blockquote>The aspect may vary depending on the modules you have chosen on the previous steps.</blockquote> 2.4.1 You can see that you will need different panels depending on the height of the modules, something very similar to the situation of the Pillars A, B and C.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/354238/2023-09-18_qren5ivpbsnu.png"></figure>To print this, you must choose what you need on the file “rack_lateral_panels.3mf”<blockquote>If you have the “<a target="_blank" href="https://www.printables.com/model/556615-case-for-the-mmss" rel="nofollow noopener">Case for the MMSS</a>” with the lower Lid for the PTFE tubes, use the “Cover E”If you plan to use the case with lid in one of the middle stages, you should use Pillar C and a new Cover; Cover F (Cover lateral panel_F.step)</blockquote>Material to use<ul><li>If you use this affiliate links to buy filament, it will cost you the same and I will get a small "kickback". Thanks !<ul><li><a target="_blank" href="https://shareasale.com/r.cfm?b=2354730&u=4026304&m=138211&urllink=&afftrack=" rel="nofollow noopener">Filament used on this project</a>, choose any color you like. For the greatest result and if your printer can do it, use <a target="_blank" href="https://shrsl.com/4cvrd" rel="nofollow noopener">PLA with carbon fiber</a>, amazing finish! Maybe it is time to test that sample you may have received with your printer (X1C users).</li><li>I've used in this project some <a target="_blank" href="https://shrsl.com/4cpnz" rel="nofollow noopener">PETG </a>too.</li></ul></li></ul><h3>Change log:</h3><ul><li>19-09-2023 - change the diameter of the TPU feet for better fitting. If you already have them, just put a little of TPU filament on the side if you find it to lose. </li><li>21-09-2023 - Better layout of the “rack_lower_module.3mf” file . Thanks to <a target="_blank" href="https://www.printables.com/@amateur3d_939146" rel="nofollow noopener">Amateus3D</a></li><li>22-09-2023 - Back_plate_narrow has now stronger “pegs”. File changed “rack_middle_modules.3mf”. Thanks to <a target="_blank" href="https://www.printables.com/@hoonu_203988/makes" rel="nofollow noopener">hoonu</a>.</li><li>22-09-2023 - Lateral panels pegs should be stronger now. Change to some aspects of the layout on the 3mf file.</li><li>24-09-2023 - Small change to the small pin diameter, for stronger fit. File changed “rack_middle_modules.3mf”.</li><li>01-10-2023 - Added a new panel if you decide to use the box with lid in one of the middle stages (see description above in 2.4.1) - Thanks to <a target="_blank" href="https://www.printables.com/@thedevilsjeste_18993" rel="nofollow noopener">thedevilsjester</a></li><li>10-10-2023 - Some members(1) reported some instability of the structure, namely the configuration that presents the top the “normal top” and already has some modules, so already with a certain height. This update is intended to address those issues. Thus, the updated components are:<ul><li>rack_tops_modules.3mf - in there the steps updated are:<ul><li>Top_plate_for_back.STEP</li><li>Top_plate_for_front.STEP</li><li>Top_plate_for_Front_right.STEP</li><li>Top_plate_for_Front_left.STEP</li><li>Top_plate_for_BPlate_right.STEP</li><li>Top_plate_for_BPlate_left.STEP</li></ul></li><li>If the structure is ok to you, that's because the fits are ok and all is working fine.</li></ul></li><li>12-10-2023 - Bambu Lab logo was inverted, this can be found on file: “rack_tops.3mf” <ul><li>A new version of the pin was added that may offer a better fit in some situations. This new pin is found on file: “rack_middle_modules.3mf”</li></ul></li><li>18-10-2023 - Added a lid for the plain drawer: “lid_simple_drawer.step”</li></ul><h4>Support the designer:</h4>This design is free for the benefit of the community, but If you like my designs and want to contribute, you can make a donation to <a target="_blank" href="https://www.buymeacoffee.com/designrepcom" rel="nofollow noopener">buymeacoffee </a>or <a target="_blank" href="https://www.paypal.com/donate/?business=BUM67EMDJRXSN&no_recurring=0&currency_code=EUR" rel="nofollow noopener">PayPal</a>.

WOW
