randomprints

dedan83

This is a remix of <a target="_blank" href="https://www.printables.com/de/model/396766-iphone-13-case" rel="nofollow noopener">https://www.printables.com/de/model/396766-iphone-13-case</a> . I removed the logo and added a camera protection. It was printed from TPU with a layer height of 0.16mm without supports.

Iphone 13 TPU case with camera protection

case

maCyo42

It&#39;s done!!! All Parts printed and assembled! I started the Riser V2 early December and changed the last Parts yesterday. There&#39;s a lot of work in this design, so many small and big changes. Today i will start to Release the first completed picture of the Riser V2 and the Profiles of the Mainbodies. As you later can see i&#39;ve seperated some Parts so that you can play around with Step Files for your own Design Fronts.&nbsp;<h2>Should I print the Riser V1 or V2? Here are the differences.</h2><ol><li>There are 2 Versions of the V1. The Standard is for 8mm Lightstrips and the 12mm Edition for 12mm Lightstrip and additionaly you can fix the Lightstrip with Cable ties. V2 combines the Features of both V1 Riser in this Case. I received a lot questions: Will 12mm Lightstrips fit? It can but that is not sure. It not depends only on the width. The stiffness is one big issue for the curves. Try it i cannot guarantee! There are different lightstrips on the market.</li><li>V2 is tuned more for function than design. There are additionaly Connectors for Accessories like Tools.</li><li>Early December i began to work on V2. My intention was the big change in the Anti Glare Feature and the Connectors. But meanwhile there where some critics on the V1. Some Makers reported a bad fitting of their Top Glas. To much loose in the Spoolholder fitting and so on. So the logical consequence was to rework many things on V2.</li><li>The Modders. I had so many Mails and Msg… can you please add Hexagons insted of Holes and so on. Because of this i reworked the Covers and seperated them for the Modders. You can now easily create your own designs on the most seen Parts of the Riser.</li><li>The printability. Puh i don´t know how to begin exactly. Makerworld makes a lot very easy. But a project like this is not easy. It´s big, it can fail as any other Print… it can fail! But you can do a lot that the chance that it will fail is very small. You have to know your printer, your Filament, your Buildplate… The condition is not the same as i have. But it´s quite easy to begin if you have a predefined Profile. But it´s not a Microwave, it´s a 3D-Printer, a popular and wonderfull Printer. It makes a lot easier and it´s the by far best for consumer on the marked… and nevertheless you have to know what you do. Please keep in mind! I reworked a lot to make it even easier. Less Supports (less filament usage is everytime the best optimization!) Tuned Overhangs especially on the back which is on the Print surface while printing Part 3 and 4. and many more changes</li></ol>happy printing<h2>Features Description</h2><h4>Accessories Port New second Accessories Connector Port. The Port is redesigned an optimized. Accessories fits tighter. The Spoolholder on V1 was a bit to loose.</h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-16_d57fe6c9f6869.png"></figure><h4>New seperated Drawer Front Cover and Handle</h4>With the new separated Drawer Front you can create easily your own Designs and Text on it and print it upside down for best looking Surface. (STEP File of the Cover included) The new Handle locks both Parts (Drawer and Cover) together. No Glue needed!&nbsp;Compatible Inserts for the Drawer <a target="_blank" href="https://makerworld.com/de/models/44128#profileId-45567" rel="nofollow noopener">Original Inserts &amp; Dividers</a> by <a target="_blank" href="https://makerworld.com/de/u/1818851574" rel="nofollow noopener">tomtom5893</a><a target="_blank" href="https://makerworld.com/de/models/50855#profileId-52695" rel="nofollow noopener">CHT Nozzle Holder</a> by <a target="_blank" href="https://makerworld.com/de/u/2301853465" rel="nofollow noopener">kylecasey4</a><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-16_e7570c3e6befc.png"></figure><h4>New P1S Front Dash Parts with separated Cover for leave Blank or your own Design</h4>In the Standard V2 you have a dummy for the Slot where you can mod different things like a light Switch. The Slot for the MicroSD Card is now protected with a Cover. If you press on the lower Part of the Cover it opens. Yes it´s tricky to get the Card out, but how often you want to get it out… i recommend to use a tweezer or something else. The Covers of Part 5 &amp; 6 is now separated too. You can add your own designs and print it upside down. (STEP Files of the Covers included)<h4><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-16_a2e0b276312d6.png"> Light Strip integration and Anti Glare</h4>The Lightstrip integration is fully redesigned and now combines “V1 Standard” and “V1 12mm Edition” in one sleak Design. You now have a lot of cable tie position to safe your Printer from falling Lightstrip!<ul><li>I strongly recommend COB LED Light Strip with 8mm width. Length 2m and cutable.</li><li>Yes you can also use 10mm or 12mm BUT beware. Most 12mm LED Strip are so stiff that it´s a mess to integrate them.</li></ul>The Anti Glare Feature moved from the Mainbodies to the TPU Gasket Parts because of collisions with the PTFE Tube while printing big Parts. <img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-17_88977cc660f9.png">Why more Light? Do i need more Light? YES i think so! <img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-17_7662231c60b07.png"><h4>The Toolholder Connector</h4>With this Connector you can add whatever you want to the Riser. In the First step i added the Connector for my <a target="_blank" href="https://makerworld.com/en/models/28768#profileId-25133" rel="nofollow noopener">P1S Tools Model (Get it here on Makerworld)</a>. The Toolholder Connector is provided as a Step File as well. With this the Modding Community is able to connect whatever they want. There are 6 Connector Ports 4 of this. 2 on the Left Side and 2 on the Right Side. There are 2 more Connector Ports on the Back in a different design. (STEP File of the Toolholder Connector included)<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-18_6005761ec053d.png"></figure>You can also attach a Spoolholder. <a target="_blank" href="https://makerworld.com/en/models/53455#profileId-55205" rel="nofollow noopener">Get my Version with Bearings here</a><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-01-18_841008088edb2.png"></figure>The “Back Connector” is finally released. Unleash your modding ideas, perhaps for an ESP32 case that can be attached to the back? Use one, two or even all 4 connectors for your modding idea. (STEP File of the Back Connector included)<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-02-23_e06df92819799.jpg"></figure><h4>Where to find the &#34;RAW Files&#34; on Makerworld? e.g. Back Connector …</h4>So there are 2 Options. One you can see in the folowing picture as provided by the designer you can find the Parts under “Download STL” else <figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-05-07_12c13e3925103.png"></figure><h4>Asssembling Guide</h4><ol><li>Push Part 2 on Part 1 <img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-05-07_0b3ee7ecae28a.png"></li><li>Push carefully Part 3 on Part 4 <img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-05-07_719957f53c68.png"></li><li>Then push carefully both Parts 3 &amp; 4 together from the Top to the Bottom in Part 1 &amp; 2 <img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000133452/design/2024-05-07_1d6c733360ed3.png"></li><li>tba</li></ol>

AMS Riser V2

Kocyns

Thanks for video: @marsgizmo (ytb)<h4>PRINT SETTINGS</h4><ul><li>Height: 100 mm</li><li>Recommended material is PLA and layer 0,12mm</li><li>Minimal scale 75%!</li><li>Optimized model for printing without support!</li></ul><h4>Remix: <a target="_blank" href="https://makerworld.com/en/models/173902#profileId-191118" rel="nofollow noopener">Heart for Rose Bear</a></h4><figure class="image image_resized" style="width: 40.76%"><a href="https://makerworld.com/en/models/173902#profileId-191118" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000152175/design/2024-02-06_bdaecc3a4c139.png"></a></figure>&nbsp;If you want permission for commercial use: <a target="_blank" href="https://www.patreon.com/kocy/" rel="nofollow noopener">patreon.com/Kocy</a>

Rose Bear

PrintedByJohn

Have fun upgrading your printer with a variety of different 3d printed upgrades.

dust cover p1p, p1s, x1, and more

Marc Elbichon

☕Checkout my other Nespresso designs : <a target="_blank" href="https://makerworld.com/en/u/3864875302/collections/90969" rel="nofollow noopener">https://makerworld.com/en/u/3864875302/collections/90969</a>&nbsp;&nbsp;Nespresso Vertuo capsules tower/carousel. Stackable, can hold from 8 to whatever number of capsules you wish !&nbsp;No tool or bearing needed, just some drop of grease to improve rotation (optional)&nbsp;The tower is provided in different capacities, and they can be stacked (with the connector), so you can get the height you want.Also, the 355 and 535ml capsules are bigger, so it need more space between capsules. &nbsp;The ‘regular' tower handle capsules from 40 to 230ml, the ‘tall’ can handle any size, but needs more space and filament… It's your choice ;)&nbsp;Regular (handle capsules from 40ml to 230ml) :<ul><li>regular-tower_2u.stl : 8 capsules (66mm height)</li><li>regular-tower_4u.stl : 16 capsules (132mm height)</li><li>regular-tower_6u.stl : 24 capsules (198mm height)</li><li>regular-tower_8u.stl : 32 capsules (264mm height, doesn't fit X1/P1 volume)</li></ul>Tall tower (handle capsules from 40ml to 535ml)<ul><li>tall-tower_2u.stl : 8 capsules (82mm height)</li><li>tall-tower_4u.stl : 16 capsules (164mm height)</li><li>tall-tower_6u.stl : 24 capsules (246mm height)</li><li>tall-tower_8u.stl : 32 capsules (328mm height, doesn't fit X1/P1 volume)</li></ul>All pieces should connect and stay in place, but you can glue it to assemble permanently.&nbsp;Note : If you don't want to turn it into a carousel, just don't print the ‘Rotating Base’ part&nbsp;Update 2024-01-05:Adde new ‘tall’ tower parts to handle capsules up to 535ml&nbsp;Update 2023-12-21:As suggested in the comments, I modified the towers to add a chamfer to avoid some internal bridges. STL files and print profile updated&nbsp;Update 2023-12-16:<ul><li>Added knurling on the handle for a better grip</li><li>Added 2 new handles, a bigger one with Nespresso logo on top, and one that looks like a capsule. To be backward compatible it seats on the small handle (it acts as a connector)</li><li>Added forgotten file tower-connector.stl (was into print file already)</li></ul>Update 2023-12-13:<ul><li>Adjusted the top hole size for a better fit with the handle, the previous was a little bit too big. Also, I modified the top part to close the hole, to be easier to seat the handle.</li><li>Improved rotating base, now more stable, specially with taller tower</li></ul>&nbsp;
