PandaPrints

BUILD YOUR OWN FISHING BELT  the way you want it !!&nbsp;No support needed&nbsp;this is my design for a modular fishing belt you can tailor to your own needs&nbsp;The basis is the belt clip, available for 40mm and 50mm wide belts(i got mine from : <a target="_blank" href="https://nl.aliexpress.com/item/1005005029912906.html?spm=a2g0o.order_list.order_list_main.27.21ef79d2bVafMK&amp;gatewayAdapt=glo2nld" rel="nofollow noopener">ali </a>but any belt will do i think)&nbsp;Two different connectors can be used to attach accessories to the basis * The decagon connector which fits tight and can be fitted in multiple directions this prevents free turning, recommended for the rod holder as it has to stay in the position you set it initially * The round connector is ideal for accessories to freely move and is easier to remove from the basis clip,  recommended for the water bottle and the towel holderThe connectors attach to the accessories with a M3x8 screw (M3x10 also works for most parts) or you can use some glue.They can be extra secured with a 3mm screw in the side of the basis-clip&nbsp;accessories:basic set: * pliers holder * flat and angled rings (for carabiners etc) * rod holder&nbsp;extra accessories: * bottle holder * horizontal and vertical strap holder (for example Velcro straps to hold some gloves) * towel clamp alligator style, this one should be glued to the connector as there was no room for a screw * multifunctional hook * net holder (may or may not fit your net) * magnetic plate (needs 4 pieces of 15x2 neodium magnets * small bait box (needs 2 3mm screws to attach the lid)&nbsp;EXTRA EXTRA: Added a DIY plate which you can glue to anything you want or you can incorporate in your own design to make it compatible with the belt system.also added an extra decagon connector which is a little bit tighter to use when the normal connector would be too loose Print settings: Printed everything in PETG for strength and water resistance (don&#39;t mind the non-camouflage color as i used some petg i had laying around) standard generic petg settings 0.16 layer height 2 walls 15% infill no support needed ! (when having adhesion problems: CLEAN your plate !!  Post printing needs the yellow carabiners in the pictures are not included, you can find them here; <a target="_blank" href="https://makerworld.com/en/models/243919#profileId-260451" rel="nofollow noopener">Flexible Carabiner by Mc2_project3D - MakerWorld</a>&nbsp;Happy Fishing !!

Predator fishing tactical belt , modular system

Fishing

GammaLand

A cute mulitple-color panda holds a board for sticky notes. The sticky notes size in the picture is 50mm * 37.8mm.If you like the design, please download, print it or just give a thumbs-up. Your support is super important, thank you~

Cute Panda Sticky Memo Board

Office

migueljeronimoa

The provided script generates a 3D model that creates text inside a polygon shape. Utilizing strategic overhangs, the text appears to be almost floating within the shape.&nbsp;<h3>Quick guide:</h3><ul><li>Press the customize button and edit the parameters as you want. </li><li>Option A: Export the model in stl and import it into Bambu Studio and select &#34;Arachne Wall generation&#34; and “no supports”.</li></ul><figure class="image image_resized" style="width: 37.04%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000484240/design/2024-06-12_f77051bb3afec.png"></figure><ul><li>Option B: Download the profile “SuspendedMaker - Model template” and replace the model with the generated stl</li></ul>&nbsp;<img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000484240/design/2024-06-12_7b2c3729df592.png"><h3>Customization:</h3><ul><li>Text Content: The variable text_content contains the text to display in the 3D model. Default: “Miguel.”</li><li>Text_content_2: This variable allows writing a second line of content, if it is empty, it will center the first one.</li><li>Font Type: The font_type variable specifies the font for the text. You can choose from various fonts such as “Noto Sans SC,” “Inter,” “Montserrat,” etc (all available at makerword customizer)</li><li>Font Size: The font_size parameter determines the size of the text.</li><li>Polygon Shape: The script creates a polygon with a specified number of sides (num_sides). This value can be adjusted between 4 and 20.</li><li>Extrusion Width: The width parameter controls the extrusion width of the polygon.</li><li>Frame Width: The frame width.</li></ul><h3>Additional Notes:</h3><ul><li>Expert Options: The script includes advanced parameters for fine-tuning the model, such as vertical_line_offset, line_width, line_spacing, height_gap, and gap_factor. Adjust these parameters if necessary to achieve the desired result.</li></ul><h3>Printing Instructions:</h3><ol><li>Preparation: Download the attached profile, remove the default model, and add your generated model. This ensures the configuration works as expected.</li><li style="text-align: center">Preview Check: Always check the preview tab to confirm the model is complete and the slicer has not removed any parts. <img class="image_resized" style="width: 41.63%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000484240/design/2024-06-04_9ecce09a642c7.png"></li><li>Aracne Wall Generation: Ensure the Aracne wall generation option is active to generate the necessary overhangs.</li><li>Model Orientation: Keep the model orientation as generated to ensure that the overhangs are properly calculated.</li></ol>&nbsp;<h3>Improvements backlog:</h3><ul><li>Allow simpler colouring of the model</li><li>Select if you want the model to be faced up or down for better look of the front layer</li></ul><h3>Changelog:</h3><ul><li>v2: Added support for second line</li><li>v1: Initial release</li></ul>If you like the model, give it a like and share a boost if you have an extra one. All comments, suggestions, features are welcome, so feel free to leave a comment with it.&nbsp;<h3 style="text-align: center">Some of my related work, you will probably like:</h3><figure class="table" style="width: 71.42%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td><a target="_blank" href="https://makerworld.com/en/models/484240#profileId-396575" rel="nofollow noopener">Suspended heart text generator</a><figure class="image image_resized" style="width: 97.26%"><a href="https://makerworld.com/en/models/484240#profileId-396575" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000484240/design/2024-06-12_56c29f05dcdeb.png"></a></figure></td><td><a target="_blank" href="https://makerworld.com/en/models/480593#profileId-392200" rel="nofollow noopener">Lightbox text generator</a><figure class="image image_resized" style="width: 71.13%"><a href="https://makerworld.com/en/models/480593#profileId-392200" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000484240/design/2024-06-12_c10d4f6eefb7d.png"></a></figure></td></tr></tbody></table></figure>&nbsp;<h3 style="text-align: center">  </h3>&nbsp;

Suspended text generator

Logo Prints

franceschellifederico

Description:This 3D-printable cable organizer is designed to keep your workspace tidy and your cables neatly organized. With its sleek and functional design, it accommodates various cable sizes, ensuring a clutter-free environment. Whether it's for your desk, entertainment center, or workspace, this organizer offers versatility and practicality. Its user-friendly design allows for easy printing and assembly, making it an ideal solution for managing multiple cables effortlessly. Embrace a clutter-free setup with this customizable cable organizer!&nbsp;Features:<ul><li>Versatile design fits various cable sizes</li><li>Sleek and functional for any workspace</li><li>Easy to print</li></ul><a target="_blank" href="https://makerworld.com/en/models/134271#profileId-145744" rel="nofollow noopener">Check out my new model: HERE </a> <a target="_blank" href="https://makerworld.com/en/models/134271#profileId-145744" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/388105/2024-01-11_6fed0b403a995.png"></a>

Cable Organizer v2

Organizers

toolmantim313

Simple rack to hold up to 10 build plates. Screws together with 3mmx14mm socket head cap screws. I included both 3mf and stl files with a multi color stand 3mf file, but it's not really necessary as it stands on it's own. Although since the stand does bolt onto the rack, you can use it to mount to the underside of a bench or shelf in the vertical position. I opted to use 3m tape and attached it to the side of the X1.&nbsp;And check out my Hex system adapter mounts so you can mount the rack to a hex wall!&nbsp;https://makerworld.com/en/models/28603#profileId-24991

10 pc Build Plate Rack - Bambu X1/P1

A1 Mods

EPIQ3D

UPDATE 06/17-2024:Im sorry to read that many people have had issues with overhang, and therefore a not so pretty slope.I have rebuild the planter up from the ground, and givin it a less steap overhang, and other minor adjustments.&nbsp;I will set the old print profiles as DISCONTINUED, and mark the new ones with UPDATED&nbsp;I sincerely apologize for the inconvenience this may have brought you.&nbsp;----------------------------------------------------------------------------------------------------------------------------------------------------------------------------&nbsp;Make All your herbs easy in the kitchen.This planter ensures that your herbs stay fresh and hydrated.If you dont yourself use fresh herbs, i know this will be a great gift for those who do.&nbsp;The Design is made to be as simple as possible, and blend into any kitchen aesthetic.There a two different patterns, because i could&#39;nt decide witch i liked best.So why not upload both of them :)&nbsp;<h3>HOW IT WORKS</h3>The self watering planter is designed to slowly absorb water from the reservoir (This needs to be filled up occasionally).Its a one piece print (uni body) with a clear and visible water reservoir, so you dont need to lift a inner pot, or rely on a floater to tell you how much water is left.&nbsp;Simply just look in the in the reservoir, and fill it up if needed.&nbsp;There are 4 water inlets in the planters, where it is recommended to use a wicking material at the bottom.This helps to absorb water into the soil slowly and prevent excess moisture in the soil.To much moisture can reduce oxygen in the soil, damage fine root hairs, and render the root system unable to absorb water.You can place a couple of cotton balls / cotton wool in the bottom of the pot.&nbsp;&nbsp;&nbsp;Basic print settings:<ul><li>Infill : 25%</li><li>Walls: 4</li><li>Top/bottom shell layers: 3</li><li>No support needed</li></ul>Dimensions: Diameter of 92 mm, and a total hight of 130 mm.

Self watering planter

Planter

Sevro

Update:28.03.2024 - I redesigned the lamp a bit. I made it a little thicker, so now it is compatible with 12 mm LED strip and is also stronger.&nbsp;I used to this version LED STRIP from Bambu Lab Store<a target="_blank" href="https://store.bambulab.com/collections/led-strip-light/products/white-cct-tunable-cob-led-strip-light?skr=yes" rel="nofollow noopener">https://store.bambulab.com/collections/led-strip-light/products/white-cct-tunable-cob-led-strip-light?skr=yes</a>&nbsp;&nbsp;The diffuser has a larger flange and fits better into the main ring.I enlarged each piece by 110% so it now better takes advantage of bed size of the Bambu Lab printers <figure class="image image_resized" style="width: 68.55%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-03-28_e7c1da1fbecee.jpg"></figure>I created new print profile with this new design and will be develop this project with this size of lamp.If you want use front panels of other designers make sure that is proper size. If it too small just easy enlarge it to 110 % in X and Y axis <figure class="image image_resized" style="width: 44.26%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-03-28_867e2b9fbfc93.png"></figure>&nbsp;02.02.2024 - New front panel added : Deer in the forest05.02.2024 - New front : Birds in love&nbsp;&nbsp;Overview.A Ring Lamp that can be changed to different situations. I designed base with various panels which can adapt to various style and occasion. You can simply change color of it as well as pattern on it, by changing color of diffuser and changing different panels.WARNINGSLed strips can emits some heat depends on what type of led you and voltage you use. In my case temperature of Main Ring achieve 60 °C . Due to this I recommend use filament that can resist that temperature especially for Main Ring. I tested ASA and it works well. Other high temperature filaments should work too (ABS, PETG but I didn&#39;t test it) PLA in this case can bend over time especially if you use heavy panel like budha.So in summary I tested and recommend :Main Ring - ASABase, Diffuser - PLAPanels- PLA or ASAIf you want change panel, always wait to cool down the ring lamp, otherwise PLA cover can bend during take off.Electric parts you need.<ul><li> led stripe - I used: LED COB 8W/1M 12 V, 8mm wide - choose one that can be cut every 2.5 cm</li></ul><figure class="image image_resized" style="width: 430.185px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/6db55f53-37bb-4cbb-ba60-486465aa3c52.webp"></figure><ul><li>dc connector - I used 2.1/5,5 mm , the diameter of the mounting hole is 11.5 mm</li></ul><figure class="image image_resized" style="width: 424.403px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/8867176f-a9e4-4554-8087-7b1fd3a6b430.webp"></figure><ul><li>OFF-ON SWITCH</li></ul><figure class="image image_resized" style="width: 424.332px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/5cf1687e-913a-4186-92f2-75d8d2bac909.png"></figure><figure class="image image_resized" style="width: 425.98px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/4ed0768e-9f72-45b5-9dc0-72aa2a703338.png"></figure><ul><li>Charger 12V</li></ul><figure class="image image_resized image-style-align-center" style="width: 434.759px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/1b0daae1-d790-41b4-a6da-4028c899a774.webp"></figure>Printed PartsMain Ring, Base and Panels can be printed in draft mode 0.28-0.30 mm layer height with no issue.Diffuser should be printed with 0.2 mm layer height.<ol><li>After print, glue led strip to inner side of Main Ring</li></ol><figure class="image image_resized" style="width: 539.361px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/55f0a8a9-5b68-4a7a-b60e-def1c0cf337a.webp"></figure>Start from hole on bottom side<figure class="image image_resized image-style-align-center" style="width: 537.429px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/8f453fdd-01d6-476e-baaa-f03826eac490.webp"></figure>2. Put Main Ring into base. It should fit tight without glue.<figure class="image image_resized image-style-align-center" style="width: 538.864px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/f03a229b-e68e-4835-9d5f-37f66a2677d0.webp"></figure>3. Insert the electric part into the base and connect them by soldering<figure class="image image_resized" style="width: 535.014px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2e73757c-be70-46f0-8fbb-ebc700b2e62a.webp"></figure><figure class="image image_resized" style="width: 531.08px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/75ca1515-ddbf-47b2-ab0d-34d6c3b795b9.webp"></figure>4. Insert Diffuser to Main Ring”. The Main Ring has a groove into which the Diffuser should be inserted and sit steadily. The flat side to the back.<figure class="image image_resized" style="width: 529.148px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/dd5e9b3f-84e4-47dc-8964-6b93b4f6ee46.webp"></figure><figure class="image image_resized" style="width: 527.23px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/3fc14977-a473-4279-b0d1-25f667c08fba.webp"></figure>5. Insert Panel into Main ring. The Panel has cuts at the bottom to avoid cutting the cables<figure class="image image_resized" style="width: 531.08px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/f414f9b5-fc71-4e83-af57-faf01b92199e.webp"></figure><figure class="image image_resized" style="width: 529.148px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/d3004065-f61c-4175-b595-6235c7b8ead8.webp"></figure>&nbsp;If you any question or suggestion write to me&nbsp;Have fun

Ring Lamp with replaceable panels

Lights

WhiskeyCoder

Remix of Design by Marcel Frehe on Printables. Alot of people seemed to be having issues with mirroring and wanted an STL version. So I decided to create it as an STL and have the mirrored part so that it can be imported and printed. Meta Quest 3 Sound Enhancing Attachment for Original Strap. This design works on acoustics much like cupping your hands over your ears to hear better, dosnt work with boboVR strap, I will be remixing the design for that soon enough.

Meta Quest 3 Sound Enhancer - STL

Meta Quest

CippyO

This design is based on konseben's original design, that was working fine, but i wanted to fine tune it a bit. Print it with at least petg, as pla will melt there under load.here are the changes that i made:made it 0.18mm longer(35.62mm to 35.8mm) moved the C side pin 0.4mm outwards, for better alignment longer pins(7mm from 2mm) smaller corner radius(0.5mm from 0.75mm) moved, shrunk C connector hole, for thicker, stronger partUpdate: The v2 design is just to add better compatibility with different printers. I modified the pins to have different size, depending on your printer's accuracy, you can choose between 5 different size: the original and +/- 0.1mm or 0.2mm.&nbsp;i also included the step file as konseben did, so further refinement can be done if needed.

ROG ALLY dock cover v2

ROG Ally

Easy to print wall mount for the new Unifi Cloud Gateway Ultra.Print orientation is laid flat.<ul><li>3 wall loops</li><li>20 infill (I prefer gyroid)</li><li>0.20mm layer height</li><li>Supports required on the overhang</li></ul>I have added a revision 2 model with an additional screw hole at the bottom, to aid in mounting this under a shelf/desk.

Unifi Cloud Gateway Ultra Wall Mount | UCG

Unifi

redfoxdude

<h3>WDT is an art. Its chaotic nature takes skill to master consistently.</h3><h4>Umikot is a Tagalog word which means: to spin; to turn around; to revolve; to rotate; to circle; to go around; to swirl; to gyrate.</h4>In that spirit, this 3D printable tool utilizes a print-in-place planetary gear mechanism to create spirographic needle motion. This is the 58mm version. Looking for the 54mm version? <a target="_blank" href="https://makerworld.com/en/models/169733" rel="nofollow noopener">See here.</a> <a target="_blank" href="https://paypal.me/vjapolitzer" rel="nofollow noopener">Like what I'm doing and want to share the love? Buy me a coffee – any donation is much appreciated (paypal.me/vjapolitzer) 😊</a>This design is provided to you for free under a Creative Commons CC-BY-NC-SA license. Make and enjoy, but do not sell. Check out the latest and greatest version featured by Brian Quan:OnShape SourcesMake it your own! Custom needle depth, tweak tolerances, or remix! Easily export STLs and STEPs. Check out the open source design on OnShape. (Note: when exporting STLs, make sure you select Units→Millimeter and Resolution→Fine.) <a target="_blank" href="https://cad.onshape.com/documents/fdee3216b2ace613c56a762c/w/55cc5d213829db35d543848e/e/7b791a2208f50895265ad90c" rel="nofollow noopener">58mm workspace</a> <a target="_blank" href="https://cad.onshape.com/documents/fdee3216b2ace613c56a762c/w/cbc59c062608bee77d058aba/e/7b791a2208f50895265ad90c" rel="nofollow noopener">58mm S (Short) workspace</a>Changelog<blockquote>UPDATE February 3 2024:<ol><li>V2.1: Thicken the stationary needle post for easier printing</li></ol>UPDATE September 2 2023:<ol><li>V2 release! New for V2:<ol><li>Maximum coverage for needle pattern (due to this change, V2 is all new and not backwards compatible with previous release candidates, nor V1.7)</li><li>Stationary edge-needle - one needle has been repurposed to a perimeter sweeping role. This reduces hotspotting in the center and improves distribution at the edges</li><li>Needles insert from below - easier replacement with less disassembly</li><li>LongTab version - better needle protection and easy to use. Also, ShortTab and NoTab versions to support tamping stands. Magnets only available for NoTab version, but if you really want magnets, that can be easily generated on OnShape.</li><li>Improved basket lip interface</li><li>Shorter threaded portion on the base - faster to print and faster to swap</li><li>Optional 58mm~S~ (short) upper parts for needles with shorter, 20mm handles. More compact design!</li><li>STLs only on Printables - fewer files for me to manage for updates. Export STEPs from OnShape if you want them!</li><li>All prior files and instructions placed into zip archive. The previous OnShape workspace can be found <a target="_blank" href="https://cad.onshape.com/documents/fdee3216b2ace613c56a762c/v/79657c9fc60b3f3089981757/e/7b791a2208f50895265ad90c" rel="nofollow noopener">here</a></li></ol></li></ol>UPDATE July 15 2023:<ol><li>Added tip for random z-seam for Upper Mech to improve smoothness and reduce snagging</li></ol>UPDATE July 5 2023:<ol><li>V2rc1 Upper Mech and Spin Ring - reduce lateral play and integrate spin grip<ol><li>Release candidate - needs more testing! Mine works great, but let's improve this together!</li><li>Reduced radial forces on the gears help with binding issues</li><li>The V2rc1 Spin Ring is bushing style. Lubricate with some paraffin wax for smooth action</li><li>V2rc1 Spin Ring is NOT backwards compatible with previous versions of the Upper Mech</li></ol></li></ol>UPDATE May 29, 2023:<ol><li>V1.7 Upper Mech and Spin Ring - Improved mechanism smoothness.<ol><li>Reduced helix angle for more forgiving print.</li><li>Outer lip on Spin Ring to better stabilize and hold the gears at their ideal vertical position. V1.7 Spin Ring is backwards compatible with V1.6 Upper Mech.</li><li>See updated assembly instructions for achieving good alignment ("Attach the spin ring and handle" step)</li></ol></li></ol>UPDATE May 20, 2023:<ol><li>Compensate for material shrinkage, more forgiving basket fit (58mm)</li></ol>UPDATE May 18, 2023:<ol><li>Initial release of 54mm version for Breville machines! The magnet versions have not been tested for fit of the magnets - please let me know if you can test this. The hole tolerances may need to be tweaked.</li><li>V1.6 Upper Mech: Improved tolerance for both 58mm and 54mm. Calibration to achieve ~0.2mm XY tolerance is advised.</li></ol></blockquote>A common problem with many commercially available WDT tools is that they utilize concentric motion, which creates trenches in the coffee. The spirographic pattern avoids needles crossing the same path, with the goal of a more homogeneous particle distribution.I have optimized the needle pattern for even coverage, and no more than 8 rotations of the handle should be necessary. Two different needle lengths provide deep and top of the bed distribution.<figure class="image image-style-align-center"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_ray4uaae3dcj.jpg"></figure>The needles are inserted from the top and are replaceable, and the base is swappable, allowing for configurable needle depth for different baskets, without needing to change out the needles. Optionally, you can print versions of the base that can house eight magnets and/or include a flange to interface with the portafilter lugs. A little de-bossed label to indicate a given base's depth is included for easier identification.<h3>Instructions</h3><h4>Gather your parts and materials.</h4><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_qs894dwer08d.jpeg"></figure>For the non-printed things, you will need:<ul><li>5x M3 x 12mm flathead/countersunk screws (if you have non-flathead/countersunk screws you would like to use, try the noCountersunk files)</li><li>10x 0.35mm acupuncture needles with a 30mm handle (Compatible with the same as the popular 9-prong tool, 0.35x75mm from <a target="_blank" href="https://www.aliexpress.com/item/1005001467649993.html" rel="nofollow noopener">aliexpress</a>)<ul><li>OR! 10x acupuncture needles with a 20mm handle for the 58s (short) upper. 30mm handled needles can work with the 58s upper, but the handles will reach the basket lip with the 25mm depth base.</li></ul></li><li>[OPTIONAL] 8x 5x3mm magnets for the each base you wish to print</li><li>Cheap flush-cutters you don't mind dedicating to needle cutting, or even better, a hardened cable cutter</li><li>Screw-driver/Allen-key for the M3 screws</li><li>A 3D printer</li></ul><h4>Print your parts!</h4>I printed mine with PLA. You may want to print the Base part with PETG.Personally, the contact time with the hot basket/portafilter has been short enough that I have not had issues with PLA - however, PETG, with its higher glass transition temperature, would certainly have reduced risk of softening.Settings:<ul><li>0.2mm layers</li><li>4 top/bottom layers</li><li>2 walls are sufficient</li><li>11% gyroid minimum (consider higher for more heft!)</li><li>No supports</li><li>Concentric top pattern for Spin Ring V2</li><li>Concentric bottom pattern for Mech V2</li><li>Random z-seam for Upper Mech can help with snagging and improve smoothness [Thanks to zumicroom in EAF]</li></ul>The gears and needle holes require a good calibration (0.2mm XY print-in-place tolerance) and good quality filament!Printed Parts:<ul><li>1x Mech (choose the short version for needles with 20mm handles)</li><li>1x Spin Ring</li><li>1x Handle (see Handle Options below)</li><li>1x Base (see Base Options below)</li><li>1x Stand (see Stand Options below)</li></ul>Handle OptionsThe Handle is available in Small and Large. Which to use comes down to preference.The pictured Umikot is fitted with a Small, which is good for small hands or those that want a delicate-operation feel (that is my personal preference, but go with what feels good for you!)Base OptionsThe Base part is available in different versions for:<ul><li>Various needle depths</li><li>With or without a flange that interfaces with the portafilter lugs/ears (LongTab/ShortTab/NoTab)<ul><li>The Long Tab version protects the needles, but is not compatible with many tamping stands.</li><li>The Short Tab version provides the stability of the tabs, but loses the protection of the needles in favor of more tamping stand compatibility</li><li>The No Tab version should be compatible with any tamping stand, and is available with holes for 5x3mm magnets (5x3Mag)</li></ul></li></ul>Pick the needle depth that fits your 58mm basket. The filenames include the depth (i.e. Umikot58 - Base V2 25mm LongTab.stl). This is how deep the needles extend below the lip of the basket. See below for some common needle depths.My favorite is the LongTab base.Note that the default Lug files support PF lugs/ears <27mm wide. For a more tailored fit, or for wider lugs/ears like on some La Marzocco portafilters, check out the OnShape link to generate different widths.I prefer versions without magnets, as it is easier to gently lift Umikot after distribution without disturbing the grounds. You may like the feeling of the magnets and the easier one-handed use they provide - pick what you like!Common 58mm basket needle depths are:<ul><li>15g basket<ul><li>21mm</li></ul></li><li>18g basket<ul><li>23mm</li></ul></li><li>20g basket<ul><li>25mm</li></ul></li><li>22g basket<ul><li>27mm</li></ul></li><li>25g basket<ul><li>30mm</li></ul></li><li>Sworks 18-20g basket<ul><li>23mm</li></ul></li><li>Weber Workshops 18-22g basket (old version)<ul><li>24mm</li></ul></li><li>Pullman 19-20g basket, Weber Workshops 20g basket<ul><li>25mm</li></ul></li></ul>Note: For the very best fit, measure the internal depth of your basket. The above are based on specifications and have not all been tested. Please let me know if these recommendations need adjustments!Stand OptionsPrint the corresponding stand, LongTab, ShortTab, or NoTab, depending on the base you choose.<h4>Cut the needles to size.</h4>The designed needle depth for the various base files assumes the needle length to be cut precisely. If anything, favor slightly short. You only need to cut to the lengths described below. The base you choose is what adjusts the effective needle depth.The needles are likely harder than the cutting edges of most cheap flush cutters, so be prepared to dedicate them to the cause. I used a very inexpensive one from a multi-pack I got off of Amazon. Even better, use a proper, hardened cable cutter.Be very careful to safely dispose of the cut ends of these needles!First, cut 5 of your 10 needles to a total length of 65mm (35mm needle + 30mm handle):<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_ju27nji1fm2a.jpg"></figure>Cut the remaining 5 needles to a total length of 55mm (25mm needle + 30mm handle):<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_q5tv7k8tgprv.jpg"></figure>NOTE! For the Umikot58s SHORT version of the mechanism, cut all your 20mm handled needles 10mm shorter (55mm and 45mm).<h4>Give the needle handles a slight bend</h4><figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_z3srpu33b7tn.jpg"></figure>To secure the needles in their places in the gears, give them a little bend, like in the above photo. This way they won't rattle around, but can still be removed if they ever need to be replaced.<h4>[Optional] “Tap” the gears' screw-holes</h4>This step is optional, particularly if your screw holes are quite tight. To make our lives a bit easier later, “tap” the holes with one of your M3 screws. Carefully screw them into each of the gears' holes, stopping when you feel the resistance noticeably increase (you've hit the bottom) and then remove the screw. Repeat for each of the 4 larger gears. You will need to hold the gears carefully to keep them from rotating while you do this. Be careful you do not get pinched!<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_cpcbcra9tqh4.jpg"></figure><h4>[Optional] Lubricate the Spin Ring</h4>For the smoothest operation, the V2 mechanism can benefit from some lubrication. I recommend rubbing some paraffin wax (such as from a tealight candle) on the inner surfaces of the Spin Ring.<figure class="image image_resized image-style-align-center" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_ny5x8vldpfs4.png"></figure><h4>Attach the spin ring and handle</h4>Gently screw in 4 of the M3 screws to attach the spin ring. Fully tighten until they stop (the mechanism should be locked). Then back out 1 turn, which will align the gears vertically to the outer ring gear.<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_d78ytpulg4w7.jpg"></figure>Then, do the same for the handle, but only back out ~¼ turn:<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_048qzrr41byh.jpg"></figure><h4>Insert the needles!</h4>Be careful during this step - the trimmed needles are still thin and sharp! Gently insert each needle fully into the gears from the bottom. Do not force them! The slight bend in the handle will secure them. If a needle is too loose, make the bend a touch more.<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_toy5c8wid5bi.jpg"></figure>(58mm Short version pictured)See below for the needle pattern with respect to the different needle lengths:<figure class="image image_resized" style="width:75%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_tk7vpzmg4n6c.jpg"></figure><h4>Attach your base</h4>[Optionally, press in the magnets if you went with the 5x3Mag version.] Screw on your chosen base. You can change bases at any time, but be very careful when doing so, as the needles are pokey!<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_zmnc06swdtlh.jpg"></figure>(58mm Short version pictured)<h4>Distribute some coffee!</h4>And that is it! If you chose the NoMagnet NoLug base or the Magnet NoLug base but your basket isn't very magnetic, you will need to hold Umikot down while turning the mechanism. Gently give it several rotations. At least 8 gives the pattern nearly full coverage, but I like to do as many as 12 - whatever gives you the best results!The distribution must be done with the basket in a level position - otherwise, the grounds will tend towards whichever direction the basket is tilted.Finally, remove Umikot, give the portafilter a tap to settle the grounds, tamp, pull, and enjoy your espresso!<figure class="image image_resized" style="width:50%;"><img src="https://makerworld.bblmw.com/makerworld/draft/643836/2024-02-04_25a4ng5b0e66.jpg"></figure>Disclaimer: not all filaments, nor the 3D-printing process, are certified food safe. Use of this tool is at your own discretion. <a target="_blank" href="https://ko-fi.com/redfoxdude" rel="nofollow noopener">Like what I'm doing and want to share the love? I always appreciate any support on Ko-Fi 😊</a>

Umikot (58mm Version) - Planetary Gear Spirograph Espresso WDT Tool

Espresso

IndomReps

Be sure to read the different applications of the different tool holders below to make sure you are printing the correct model for your application. Please be aware that your filament brand, age, and print profile can affect the fit of your printed parts, if you have significant issues with fit consider trying a test print with a different roll or brand of filament.&nbsp;*** UPDATE 1 *** 2/14/24&nbsp;Received some feed back that the tool mounts will not work with tools that have the belt clips installed on them. I never considered this in the original design since I typically take them off my tools. I have made 2 options available so those of you that use the belt clips can still use these mounts.&nbsp;The first option I simply increased the thickness of the mount and then hollowed out the back a bit to try and keep the amount of material used down a bit. I designed it in a way that it can be printed without supports and a little bit of bridging.&nbsp;The second option is a simple spacer that is printed separately and then placed behind the original tool mount. This is a good option for those of you who have already printed the original as it has a recess in so that the original mount can sit down in to keep the screw holes aligned. I intentionally designed this to be on the tighter side for fit so mileage may vary depending on what brand you use and your filament calibration. Comment if you do have fitment issues of the spacers so I know if I need to make more updates. &nbsp;Please note I have not verified this with every Dewalt tool available.                                                        &nbsp;Tool and Battery mounts for Dewalt 20v tools&nbsp;These things are nearly universal and will fit a good amount of the Dewalt 20v tools and is universal for all 20v batteries. They are also quite strong and have no issues supporting the weight of the ½" impact drivers weight and then some.&nbsp;Attach them to whatever surface you want with two #8 screws. Tool mounts are best used as under mount but they can certainly be mounted horizontally if it suites your application. The battery mounts can be mounted in whatever orientation you want as they use the batteries locking mechanism to hold the batteries in place.&nbsp;There are 3 different print models for the tool mounts, choose which one best suits your needs.&nbsp;Dewalt Tool Holder: Base file, print these for tools that do not have the belt clips.&nbsp;Dewalt Tool Holder - Integrated Belt Clip Spacer: print these for tools that you want to consistently hang tools from that have belt clips on them. The skid plate is a bit thicker to allow clearance and I have hollowed out the back of it a bit to save on material usage. No support is needed for this print.&nbsp;Dewalt Tool Holder - Belt Clip Spacer: This is for previous users who printed the original and would like to be able to able to mount their tools that have belt clips, or users that want a more modular function.&nbsp;I've printed these in normal PLA and didn't have any strength issues but you can use PETG or Pro PLA if you want. If you want to use these in a work truck or something that can get really hot in warm weather you should probably use ABS otherwise its probably overkill.&nbsp;Default profile uses .2 layer height but bump it up for a faster print as layer height really doesn't matter for these. I've even printed these on ludicrous speed and had them still fit fine.

DeWalt 20V - Tool and Battery Mounts

Proslat

niltsh

This is the updated version of <a target="_blank" href="https://makerworld.com/zh/models/39368#profileId-38480" rel="nofollow noopener">https://makerworld.com/zh/models/39368#profileId-38480</a>&nbsp;I am really glad that there are many guys like this collapsible katana, and I do appreciate your suggestions and opinions.&nbsp;So I found some time and made a new one, addressing the following issues in the old one.<ol><li>The strength of the handle-guard connector. This time I combined the handle and connector together to enforce the strength.</li><li>The decoration on the handle is better to be multi colorred. So I made a new structure with the outer shell and inner shell to form the handle. With different colors of the shell, the handle now looks more real.</li><li>The blade guide is thicken so should not be easy to break now.</li><li>the disassemble structure are located at the tail now. And now only two pieces of filament could lock it.</li></ol>&nbsp;Some important suggestion and notes<ol><li>When printing the slide lock, I suggest to use the Cool/Smooth Plate. As when using Textured Plate, the thickness of slider sole is a little bit thicker than it should be, it might cause hard to slide.</li><li>Still need to use a little bit instant glue for the handle and guard, do not apply too much as it might glue the slider too. Don&#39;s ask why I know it :)</li><li>The holes to lock the tail and handle are printed without any support, so it might not be perfect. This might cause the filament hard to insert. I suggest to use a Hex Key 1.5 to clear the holes first.</li><li>The folding diameter of the rubber ring is 60 mm.</li><li>This time, the handle is printed with Support, and I have tuned it many times to perfect the rhombic holes. BUT it is still not perfect.</li></ol>If some one has better ideas, please let me know, or update your configuration here.
