<h2>Alternative Rotary spool holder with Automatic rewinding for AMS lite 自动回卷AMS lite料盘架，可替代原配</h2><h3>Please be patient and read the page, thank you！ 请耐心看完页面，谢谢！</h3>I highly recommend you bookmark this model, as you may need it whenever you have an AMS lite.我强烈建议您收藏这个模型，只要你有AMS lite就可能会用到。&nbsp;I already have the original accessories, what else do I need this model for?我已经有原装的配件了还要这个模型干什么？1.In case the original rotary shaft is damaged, you can print one yourself and it will not affect your normal use of the AMS lite. 万一原装的回转轴损坏，你可以自己打印一个，不会影响你对AMS lite的正常使用。2.This model can be optionally fitted with multiple sizes of Claw bushing and Threaded bushing to fit most filament spools（It is no longer limited to a diameter of 53~58mm）.这个模型可以选装多尺寸的爪套和螺纹套，能适配绝大多数料盘（不再局限于53~58mm）。3.The cost of owning it is low, less than the price of half a paw in the original accessories（BambuLab please don&#39;t mind）.拥有它的成本很低，不到原装配件里面半个爪子的价格（拓竹请不要介意）。4.While retaining the original functionality, you can match the color style you like to make the AMS lite even cooler.保留原有功能的同时，你可以搭配出自己喜欢的颜色样式，让AMS lite更酷。<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_6a7b8d92b5336.png"></figure><h3>Basic Information（基本信息）：</h3>The name of the model（模型名称）：Alternative Rotary spool holder with Automatic rewinding for AMS lite（自动回卷AMS lite料盘架，可替代原配） Key features（主要功能）：It is not lower than the original rewind capacity and a wider range of filament spools adaptation不低于原配的回卷能力及更广的料盘适配范围 Current Version（当前版本）：1.0.0 (20240412)Update Notes（更新说明）：1.0.0 (20240412) ： Model publishing（模型发布） Rewind angle（回卷角度）：80°~100°（The original parts are about 80°，原配件约80°） Rewind distance（回卷距离）：depends on the filament thickness（取决于耗材丝厚度） Need for Support（是否需要支撑）：No（不需要） Need for Brim（是否需要边缘）：It has been added by customization, and can be removed if not needed（已定制添加，如不需要可去掉） Need for Non-Printing Accessories（是否需要非打印配件）：None,print-only（不需要，纯打印件） Need multi-colored（是否需要多色）：No, but you can print in parts if you like, but it is advisable to distinguish the color of the shaft（否，但可以根据自己喜好分件打印，但建议区分轴的颜色） Number of base kit parts（基础套件零件数量）：Green - Base kit 10，Orange - Base kit 10 Filament consumption（耗材消耗量）：100g Base kit Print the number of Plate（基础套件打印分盘数量）：3Slicing software info（切片软件信息）:Bambu Studio 1.9.0 Public beta（Recommended推荐使用）【Since I couldn&#39;t pass the review with the 1.9.0 public beta configuration, I switched back to 1.8.4.51 first】【由于我使用1.9.0 Public beta配置无法过审核，所以先换回1.8.4.51】 Detailed installation instructions（详细的安装说明）：Scroll down the page to see（下滑页面后查看）<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_58116b9ac6702.gif"></figure><h3>Special Instructions（特别说明）：</h3>Because it is necessary to adapt the base axis of green and orange on the AMS lite, the corresponding printing configuration is also green and orange, the 3mf file is configured with color, and the shaft cover is also marked with letters, so don&#39;t make a mistake.因为需要适配AMS lite上绿色和橙色两种颜色的基轴，对应的打印配置也有绿色和橙色两种，3mf文件配置了颜色，且轴盖上也标注了字母，千万不要装错了。&nbsp;The correspondence between the letters and colors on the shaft cover（轴盖上的字母及颜色对应关系）：G = Green shaft（绿色轴） = 1,3 slot（槽位）O = Orange shaft（橙色轴） = 2,4 slot（槽位）&nbsp;As the version is updated, the appearance of some parts of the model will change accordingly, and the pictures on the page are for reference only.随着版本更新，模型一些部件的外观会随之改变，页面上的图片仅作为参考。&nbsp;The function of this model depends on the friction and resilience of the filament, so there will be some differences in the performance of the model printed with different filaments, the main accessories that determine the rewinding angle are the round lid at the bottom of the central shaft and the resistance ring, and the experimental model uses PolyLite (logo color) for printing and testing. By default, the 3-blade resistance ring can achieve satisfactory results, and the standard for suitable resistance is that when the shaft bushing is rotated, the resistance ring begins to rotate when the spiral ring of the Inner bushing is basically compressed. If the resistance is too small, you can choose to print the resistance ring of more blades. If the resistance is too high, the resistance blades can be cut to reduce the resistance. The resistance of the newly printed accessories is relatively large, so it is recommended to manually turn it a few times to make it run in to a relatively stable state before starting to use it officially. Finally, it is recommended not to use filament silk screen printing base covers and resistance rings that are too smooth or too brittle (ordinary PLA is fine). 本模型的功能实现依靠耗材丝的摩擦力及回弹力，所以不同耗材打印的模型表现会有一些差异，决定回卷角度的主要配件为中心轴底部圆盖和阻力圈，实验模型采用的是PolyLite（标志颜色）进行打印和测试。 默认情况下3叶阻力圈即可实现满意效果，阻力合适的标准表现为转动轴套时，内轴套的螺旋圈基本压缩完全时阻力圈开始转动。 如果阻力过小可以选择打印更多叶片的阻力圈。 如果阻力过大可以剪掉阻力叶片来降低阻力。 新打印的配件阻力相对较大，建议手动转几圈使其磨合到相对稳定的状态后再开始正式使用。 最后建议不要使用过于光滑或者过于脆的耗材丝打印基盖和阻力圈（普通PLA就行）。  <h3>Optional（选装件）：</h3><a target="_blank" href="https://makerworld.com/models/424607#profileId-328035" rel="nofollow noopener">Small Claw bushing 小爪套(43-53mm)</a> Medium Claw bushing 中爪套(53-63mm) - [Included in the Base kit 包含在基础套件中] <a target="_blank" href="https://makerworld.com/models/424607#profileId-328036" rel="nofollow noopener">Large Claw bushing 大爪套(63-80mm)</a> <a target="_blank" href="https://makerworld.com/models/424607#profileId-328038" rel="nofollow noopener">Threaded bushing 螺纹套(43-80mm) </a>- [Supported by the vast majority 支持于绝大多数] 3-blade resistance ring 6叶阻力圈 - [Included in the Base kit 包含在基础套件中]<a target="_blank" href="https://makerworld.com/models/424607#profileId-328043" rel="nofollow noopener">6-blade resistance ring 橙轴6叶阻力圈</a> <a target="_blank" href="https://makerworld.com/models/424607#profileId-328045" rel="nofollow noopener">6-blade resistance ring 绿轴6叶阻力圈</a><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_7b054688e06af.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_d7f19d79c41a.png"></figure><h3>Problems with use（使用问题）:</h3>Does it have an impact on print quality（是否对打印质量产生影响）:After a period of use and testing, I didn&#39;t find any noticeable effects, at least I didn&#39;t feel it obviously.If you&#39;re concerned about this, you can manually disable the rewind function when printing.经过我一段时间的使用和测试，没有发现有明显的影响，至少我没有明显感觉出来。如果你担心这个，在打印时可以手动停用回卷功能。Will it put a large burden on AMS lite and extruder（是否会对AMS lite及挤出机带来较大负担）:The tension of the extruder is so strong that it can even break the filaments directly, so this burden on the rewinding spool holder should not be a problem (Moreover, there is also a moment amplification effect of the spool radius), at least in my limited tests，The functionality of the AMS lite is also working fine.挤出机的拉力是很强大的，甚至能将耗材丝直接拉断，所以回卷架的这点负担应该不成问题（而且还有料盘半径的力矩放大作用存在），至少在我有限的测试中一切都是正常，AMS lite的功能也一切正常。Disabling the rewind feature（停用回卷功能）： use your thumb against the shaft cover, and pull the Claw bushing or Threaded bushing outward by 10 mm (Don&#39;t worry about slipping, there is also a layer of protective buckle at this time) 用拇指顶住轴盖，将抓套或螺纹套向外拉出10毫米即可（不用担心滑落，此时还有一层保护卡扣存在）<img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_2468477ea254a.png"> Adjust the rewind angle（调节回卷角度）： Adjust the amount of resistance, as described in the special instructions 调整阻力大小即可，见特别说明中的描述 Filament spool installation and replacement（耗材料盘的安装与更换）:The Claw bushing or threaded bushing can be removed and the spool can be installed before inserting the AMS lite (recommended), or it can be installed directly可以把爪套或螺纹套取下后安装好料盘再装入AMS lite（推荐），也可以直接安装<img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_a901d5ad15ee5.png">Uninstall the model（解除模型安装）： Do as shown in the figure below 按下图所示操作<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_d2281d2d19d7.png"></figure><h3>Known issues（已知问题）：</h3>1.There will be a slight noise during use. 使用中会有很轻微的噪音。2.The space is increased and it is 23 mm longer than the original shaft.空间占用增加，比原装轴长了23毫米。 3.After using the resistance ring for a period of time, the resistance will become smaller to a certain extent, because the grinding is smooth, and the rewinding angle will be reduced. 阻力圈在使用一段时间后阻力会一定程度的变小，因为磨光滑了，回卷角度会缩小。 4.Claw bushing of various sizes are tight when installed in spool that support the lower limit of size, and require force to be loaded. 各种规格的爪套，安装在其支持尺寸下限的料盘时会比较紧，需要用力才能装入。<h3>Installation instructions（安装说明）：</h3>Special note: Pay attention to the color of the shaft and before the installation begins, insert the central shaft into the Inner bushing to test whether the rotation is smooth, if not, dispose of the uneven place or apply vaseline to make the rotation smooth(Note that warping can also cause stuttering when printing the central shaft).特别注意：注意轴的颜色，且在安装开始前，请将中心轴插入内轴套中，测试旋转是否顺滑，如果不顺畅请处理掉不平的地方或抹凡士林使之旋转顺滑。<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_4dd694dafc949.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_1eb3b4fad0c8c.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_9c7496c97b641.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_83207a03ce32e.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_a2d0577b09687.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_28237013a69b7.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_85a10d12199df.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_e67aec5c1a231.png"></figure><h3>Special note: Step 8 needs to be rotated to align the buckle at the bottom!</h3><h3>特别提示：第八步需要通过旋转对齐底部的卡扣!</h3><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000424607/design/2024-04-12_24e1335c24a28.png"></figure><h3>Other（其他）：</h3>R&amp;D time（研发时间）:three weeks（三周） Model software（模型软件）:Autodesk Fusion Test filament dosage（测试耗材用量）:10kg Test filament types（测试耗材种类）:Bambu PLA Basic, Polymaker PolyLite PLA, BASF PLA Basic, KINGROON PLA, JAYO PLA, Lanbo PLA+, CHG PETG, PXA<h4>---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------</h4>This model is affected by different filaments and printer accuracy, and the final result may not be completely satisfactory to you, but even so, I hope you will enjoy this model,Comments and discussions are welcome. I have some other original models.,If you&#39;re interested, you can also take a look.,It&#39;s better to be able to follow me.,Thank you!(I&#39;m so tired of the documentation~~~) 这个模型受不同耗材丝及打印机精度的影响，最终效果不一定能令你完全满意，但即便如此依然希望你可以喜欢本模型，欢迎评价和讨论。 我还有一些其他的原创模型，有兴趣的话也可以看看，能够关注我就更好了，谢谢！（说明文档写的我好累~~~）&nbsp;Warning: This model is an original design of Noker and should not be used for commercial purposes without authorization.警告：本模型为Noker的原创设计，在未经授权的情况下请勿用于商业用途。&nbsp;Noker&#39;s original designs list（Noker的原创设计列表）：<a target="_blank" href="https://makerworld.com/models/503432" rel="nofollow noopener">Mi Thermohygrometer 2 Magnetic Bracket（小米温湿度计2磁吸支架）</a>- [20240620] ★★★<a target="_blank" href="https://makerworld.com/models/500793" rel="nofollow noopener">Scattered filament holder for AMS lite（AMS lite散料支架）</a>- [20240618] ★★★★<a target="_blank" href="https://makerworld.com/models/494496" rel="nofollow noopener">Scattered filament holder for A1（A1散料支架）</a>- [20240613] ★★★★<a target="_blank" href="https://makerworld.com/models/491928" rel="nofollow noopener">Scattered filament holder for A1 mini（A1 mini散料支架）</a>- [20240611] ★★★★<a target="_blank" href="https://makerworld.com/models/424607" rel="nofollow noopener">Alternative Rotary shaft with Automatic rewinding for AMS lite（自动回卷AMS lite料盘架，可替代原配）</a> - [20240412] ★★★★★<a target="_blank" href="https://makerworld.com/models/416063" rel="nofollow noopener">Rotary spool holder with Automatic rewinding for A1（带自动回卷功能的A1料盘架）</a> - [20240406] ★★★★<a target="_blank" href="https://makerworld.com/models/413755" rel="nofollow noopener">Rotary spool holder with Automatic rewinding for A1 mini（带自动回卷功能的A1 mini料盘架）</a> - [20240405] ★★★★<a target="_blank" href="https://makerworld.com/models/172972" rel="nofollow noopener">A1 / A1 mini fan Cover Guard（部件冷却风扇保护罩）</a> - [20240226] ★★★<a target="_blank" href="https://makerworld.com/models/171024" rel="nofollow noopener">Hamster series - Urine sand shovel（仓鼠系列 - 尿砂铲子）</a> - [20240204] ★<a target="_blank" href="https://makerworld.com/models/116787" rel="nofollow noopener">AMS lite filament spool anti-drop ring（料盘防掉落圈）</a> - [20240101] ★★<a target="_blank" href="https://makerworld.com/models/87466" rel="nofollow noopener">Trouser strap buckle（裤带卡扣）</a> - [20231209] ★<a target="_blank" href="https://makerworld.com/models/75527" rel="nofollow noopener">AMS Lite Large diameter spool adapter（大直径料盘适配器）</a> - [20231127] ★★★★<a target="_blank" href="https://makerworld.com/models/75541" rel="nofollow noopener">A1 &amp; A1 mini Purge poop Cleaner（喷嘴清洁板）</a> - [20231127] ★

Alternative Rotary spool holder for AMS lite（料盘架）

干燥箱，回卷

RestoreDoctor

Radius Gauge R1-30mmSimple tool for determining the radius. A must for being able to draw parts!&nbsp;Settings:<ul><li>0.20mm Standard </li><li>Infill 20 %</li><li>no support</li><li>PLA/ PETG</li><li>Use Multimaterial painting - Smart fill in Prusa Slicer. (Bambu Lab see below)</li></ul><figure class="image"><img src="https://media.printables.com/media/prints/578621/rich_content/fa528cba-7f9d-4977-a2a8-8de6a90157df/thumbs/cover/800x466/png/screenshot-2023-09-10-171052.webp"></figure>

Radius Gauge R1-30mm

可售卖

rauberdaniel

This is a hot shoe cover optimized for the Multi-Interface Shoe that is being used on all Sony cameras. It should fit on any other camera brand as well though. I modeled it similar to the original that ships with the cameras but improved the grip on top.&nbsp;The shown version is a bit more challenging and slow to print, but I’ve also added a simplified model that is much easier and faster to print.

Hot Shoe Cover / Sony Multi Interface Shoe Cover

摄影工具

Maintainer

从游戏里抠出来的模型，做了水平切割，通过三个插槽和插销进行固定，预留了0.2mm的间隙方便装配。分享的版本是平切的，还有一个根据外形凹陷异形切割的版本因为自己要用就没有共享。 -推荐用树状支撑。 -尽量按照我上传的角度进行打印，这样不容易出现问题，是我测试多次得到的较优的打印方案。 -推荐用0.2层高打印。 -插销要是尺寸不合适的话可以自己微调一下缩放再打印，建议先打一个试一试。&nbsp;The model extracted from the game was horizontally cut and fixed with three slots and pins, leaving a 0.2mm gap for easy assembly. The shared version is flat cut, and there is also a version that is cut according to the concave and irregular shape of the shape, so it was not shared because I wanted to use it myself. -Recommend using tree support. -Try to print according to the angle I uploaded as much as possible, so as not to encounter problems easily. This is the best printing solution I have tested multiple times. -Recommend printing with a height of 0.2 layers. -If the size of the plug is not suitable, you can make slight adjustments to the scale before printing. It is recommended to try printing one first.

|VALORANT|瓦洛兰特|瓦罗兰特-异星霸主/ARAXYS

玩具

Capybara Robot

In our quest to make pulling PTFE (Teflon) tubes out of quick connectors feel like a piece of cake, we've jazzed up the design of our extractor tool a bit. You know how it usually goes: trying to yank a PTFE tube out and having to press down all over the connector—tough and kinda awkward to get the pressure right all around that circle. So, we thought, why not throw in a few bumps (protrusions, technically) on the extractor? These little guys are designed to give your efforts more oomph, making the whole tube-pulling gig a lot smoother and more user-friendly. After you've given it a go a few times, you'll get the hang of it so well that it'll feel almost effortless. We're all about making things easier and boosting your efficiency with this neat trick. 要是你試過從快接頭裡硬拉PTFE（就是鐵氟龍）管，你就知道有多費勁。但別擔心，我們給拔取器添了點小花樣，讓這事變得簡單多了。老式的做法得把力氣平均地分布到接頭的每一個角落，聽著就累吧？我們加了幾個小突起在拔取器上，這樣一來，你用力時就能更有感覺，拔管過程也順暢多了。用不了幾次，你就能輕鬆掌握，省時又省力。我們就是想用這個小改變，讓你的體驗更上一層樓，效率更高。

Effortless PTFE Tube Removal Tool

tool

Vixvvo 3D

Stackable Dividing Box, Efficient storage solution. Customizable 3D Print Dividers: Organize & Versatile storage for any space.&nbsp;All Commercial License, Will be available on my Patreon "Vixvvo3D" For a Low Price of 6$/Month. (currently trying to post & model 1/Weeks) <a target="_blank" href="https://patreon.com/Vixvvo3D" rel="nofollow noopener">https://patreon.com/Vixvvo3D</a>&nbsp;
