ljhtom (Javier Hernando)

Rear cover fan mod 80 qidi X MAX 3Rear cover model, to house a 80x10 fan, strategically placed for the cooling of the main processor and the 3 drivers of the electronics. As the fan is big, take it from low revolutions, it doesn't go over 23db being much more silent and more flow than the standard 40x10. Two extra holes have been made in the board in case you want to secure the two printed parts, although it is not necessary, they screw on the plastic case without problems.It is possible to put it on the back of the cover, as well as on the inside, as it is only 10 mm. I leave image of measures taken directly on the plate, I also leave the original f3d model if you want to adapt or modify to other fans.

Rear cover fan mod 80x10 model Qidi_X-MAX3

Qidi

patas para la sapphire plus , aumenta el hueco de abajo hacerlas en material tipo boun o con pocas capas para que no sean rigidas.

patas two sapphire plus

Shappire plus

Bottle organizer*New model for bed 220x220 , six models. with pins diameter6 and dioameter1.5* *New model for only 7-8 drinks , 250 mm long*Always have cold drinks, thanks to this dispenser, fill the dispenser with 10 units. (33 cl Diam 61 x 228 long)The drink below is always the coldest, designed for the refrigerator.Printing with 3 contours and 4 upper layers and 4 lower layers, 10% infill is sufficientModel 3 pieces for bed 300 x 300 mm rotation 45 degrees. (2 complete models and one central)The bolts are also printed for their union.The design is prepared for a bottle with a diameter of 61 mm x 230 mm in height, it corresponds to a 33 cl glass bottle.If you have other dimensions it is very easy to adapt it by scale.For example, bottle with a diameter of 54/61 = 0.885 long X-axis scale (Y optional)Length of 197/228 measurements = 0.864 Z scale.So that you can make the design for any bottle, a photo is added with the formula to calculate the scale in your laminator. .<figure class="media"></figure><figure class="media"></figure><h3>Print Settings</h3>Printer:Two trees Sapphire PlusRafts: NoSupports:NoResolution: 200Infill:10Filament:Fervi Esencial -Fiberlogy Petg PLA-PETGthe one you like Post-Printing =============&nbsp;<figure class="media"></figure>&nbsp;&nbsp;&nbsp;Category: Kitchen & Dining

Rotary Glass beer Dispenser

Dispenser and organizer

Pants protector and chain guard megamo ridonTo protect the pants, at the same time that makes chain guard, preventing it from coming off on the ebike. For the Ridon10 model, with mid mid motor. It is placed with a screw of M4X25 mm.

Qidi

Shappire plus

Dispenser and organizer

Megamo
