<h2>ABOUT STEALTH PRESS</h2><p><strong>Stealth Press is a highly precise, mostly printed DIY heat set insert tool for generic, TS100/101, and Pinecil soldering irons.</strong><br><br>There are multiple projects like this available for free download and build. Most of them rely on Misumi standard 2020 or 4020 extrusions to provide precision which adds extra cost, time, and complexity to the build.</p><p>&nbsp;</p><p>Stealth Press build<strong> relies on precision provided by 300mm MGN12H linear rail</strong> instead which provides a stable spine to build every other component around it.</p><p>&nbsp;</p><p><strong>Integrated, printable build plate</strong> adds another critical element for precision and easiness to work with.</p><p>&nbsp;</p><p>Stealth press uses KEY-BAK key reel with kevlar belt loop to <strong>ensure longevity</strong> (proven to last more than 1 million pulls) and has some <strong>other quirks, features, and QoL improvements</strong> compared to similar projects.<br> </p><h2><strong>WHERE TO GET MECHANICAL PARTS OF THE BUILD?</strong></h2><h3><strong>Option 1 </strong>— Order ready-to-build kits <span style="color:#E14747;">(supported vendors)</span></h3><ul><li><a target="_blank" href="https://dfh.fm/collections/stealth-press?ref=iconic-fab" rel="nofollow noopener">Stealth Press KIT</a> — <strong>DFH.fm</strong></li><li><a target="_blank" href="https://kb-3d.com/store/tools-equipment/1002-pre-order-iconic-fab-stealth-press-kit-for-heat-set-inserts-1698787283366.html?affp=14933" rel="nofollow noopener">Stealth Press KIT (US)</a> — <strong>KBD3D.com</strong></li><li><a target="_blank" href="https://lecktor.com/en/stealthpress/1565-stealthpress-hardware-kit.html" rel="nofollow noopener">Stealth Press KIT (EU)</a> — <strong>Lecktor.com</strong></li></ul><p>Stealth Press is now available as a comprehensive mechanical parts KIT, streamlining the process of sourcing the necessary components. In many cases, purchasing the KIT proves to be a quicker and more convenient option than sourcing the parts individually. Availability and selection may vary depending on your location and existing inventory.<br><br><strong>Each listed KIT source offers a unique selection of parts, all adhering strictly to the BOM and carefully chosen to guarantee the highest quality build.</strong></p><p>&nbsp;</p><h3><strong>Option 2</strong> — Self-source using BOM (bill of materials)</h3><figure class="table" style="width:100%;"><table><thead><tr><th><strong>Mechanical parts</strong></th><th style="width:50px;"><strong>QTY</strong></th></tr></thead><tbody><tr><td>M3x8 SHCS — Bolts (Source: <a target="_blank" href="https://s.click.aliexpress.com/e/_DD5xFM1" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">40</td></tr><tr><td>M5x25 SCHS — Bolts (Sources: <a target="_blank" href="https://s.click.aliexpress.com/e/_Dne9xOV" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">2</td></tr><tr><td>F695-2RS — Bearings <i>(F = Flanged) </i>(Source: <a target="_blank" href="https://s.click.aliexpress.com/e/_DBulKpf" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">4</td></tr><tr><td>M3 — Threaded Inserts — M3x5x4 (<i><strong>M3 x </strong>(OD)<strong>5 x </strong>(L)<strong>4</strong> —<strong>VORON) </strong></i>(Source: <a target="_blank" href="https://s.click.aliexpress.com/e/_DnK00Kp" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">30</td></tr><tr><td>MGN12H — Linear Rail <strong>—</strong> 300mm — <strong>Black</strong> (Source: <a target="_blank" href="https://s.click.aliexpress.com/e/_Dd5YJTr" rel="nofollow noopener">INT</a>) or <strong>SS</strong> (Source: <a target="_blank" href="https://s.click.aliexpress.com/e/_DeKhmdr" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">1</td></tr><tr><td>KEY-BAK — Super48 36&#34; 13oz (Source: <a target="_blank" href="https://www.amazon.com/KEY-BAK-Retractable-Keychain-Polycarbonate-Oversized/dp/B0088MQA10/ref=sr_1_1?crid=11NSAAWHG3GP6&amp;keywords=key-bak%2Bsuper48%2B36%22%2B13oz&amp;qid=1704371600&amp;sprefix=KEY-BAK%2B%E2%80%94%2BSuper48%2B36%22%2B13oz%2Caps%2C409&amp;sr=8-1&amp;th=1" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">1</td></tr></tbody></table></figure><figure class="table" style="width:100%;"><table><thead><tr><th colspan="2">Printed Parts</th></tr><tr><th colspan="2"><i>The most current revision is <strong>R1.1</strong> - check the change log below!</i></th></tr></thead><tbody><tr><td>Printed parts</td><td style="width:50px;"><i>16</i></td></tr></tbody></table></figure><figure class="table" style="width:100%;"><table><thead><tr><th colspan="2">Soldering iron-related parts</th></tr><tr><th colspan="2"><i><strong>Heat-set insert tips vary for the type of soldering iron used!</strong></i></th></tr></thead><tbody><tr><td>Soldering iron (<a target="_blank" href="https://s.click.aliexpress.com/e/_DdkRD1j" rel="nofollow noopener">Generic</a>, <a target="_blank" href="https://s.click.aliexpress.com/e/_DBwFzCh" rel="nofollow noopener">TS100/101</a> or <a target="_blank" href="https://s.click.aliexpress.com/e/_DdcI3Lr" rel="nofollow noopener">Pinecil</a>)</td><td style="width:50px;">1</td></tr><tr><td>Soldering Adapter for heat-set inserts (Source: <a target="_blank" href="https://cnckitchen.store/collections/soldering-tips-and-sets" rel="nofollow noopener">INT</a>)</td><td style="width:50px;">1</td></tr></tbody></table></figure><h2><strong>ASSEMBLY MANUAL</strong></h2><p><a target="_blank" href="https://files.printables.com/media/prints/609644/other_files/4843265_e59cfc31-fcd8-4017-8f65-f14361245270_7bd9886b-26d0-468e-92d9-ef99138e9d90/stealth_press_assembly_manual_rev10-20231010_iconic-fabcom.pdf" rel="nofollow noopener">Download the full assembly manual with visuals and a step-by-step guide</a>.</p><h2><strong>VIDEO BUILD GUIDES</strong></h2><h4>Iconic FAB video build guide</h4><figure class="media"><div data-oembed-url="https://www.youtube.com/watch?v=TIkG8giLG9g"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/TIkG8giLG9g" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><h4>Live build by Nero3D the Canuck Creator</h4><figure class="media"><div data-oembed-url="https://www.youtube.com/watch?v=G3Zb9F8HbCo"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/G3Zb9F8HbCo" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><p><strong>Live build by ModBotArmy</strong></p><figure class="media"><div data-oembed-url="https://www.youtube.com/watch?v=mqJDLKIEuqs"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/mqJDLKIEuqs" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure><h2><strong>SUPPORTED SOLDERING IRONS</strong></h2><p><a target="_blank" href="https://s.click.aliexpress.com/e/_DdzrJd3" rel="nofollow noopener">Generic</a>, <a target="_blank" href="https://s.click.aliexpress.com/e/_DBwFzCh" rel="nofollow noopener">TS100/101</a> or <a target="_blank" href="https://s.click.aliexpress.com/e/_DdcI3Lr" rel="nofollow noopener">Pinecil</a>.</p><p>&nbsp;</p><h2><strong>PRINT GUIDELINES</strong></h2><p>Here are print guidelines for you to follow and have decent success with printing parts:</p><figure class="table" style="width:100%;"><table><tbody><tr><td>3D PRINTING PROCESS</td><td>FDM (fused deposition modeling)</td></tr><tr><td>INFILL TYPE</td><td>Grid, Gyroid, Honeycomb, Triangle or Cubic</td></tr><tr><td>MATERIAL</td><td>ASA, ASA-CF, ABS, ABS+, ABS-CF</td></tr><tr><td>INFILL PERCENTAGE</td><td>40% - 60%</td></tr><tr><td>LAYER HEIGHT</td><td>Recommended: 0.2mm</td></tr><tr><td>WALL COUNT</td><td>Recommended: 4</td></tr><tr><td>SOLID TOP/BOTTOM LAYERS</td><td>Recommended: 5</td></tr><tr><td>EXTRUSION WIDTH</td><td>Forced 0.4mm</td></tr></tbody></table></figure><h4>Side notes to the print guidelines:</h4><p>You can succeed with Support cubic infill type (slicer support may vary) and as little as 25% infill for all parts if are aiming for faster print speeds and less filament usage. PLA, PLA+, and PETG are also considerable filament choices. However, take into account that soldering iron radiates some indirect heat. <strong>The usage of less temperature-stable filaments may result in part deformations over time.</strong></p><p>It is recommended to use ASA or ABS at least for “arm” and “iron mount” parts. A wall count of 4 is an <strong>absolute must</strong> to ensure the structural integrity of the parts. There is no need to go over the top with this. <strong>4 are for this particular build.</strong></p><h4>File naming for printed parts:</h4><p>The parts use this naming convention:</p><ul><li><strong>PRIMARY COLOR</strong> — These files will have nothing at the start of the filename. <i>Example: buildplate_x1.stl</i></li><li><strong>ACCENT COLOR</strong> — Files have “[a]” to the front of any STL file that is intended to be printed with accent color. <i>Example: </i><strong>[a]</strong><i>_bushing_x1.stl</i></li><li><strong>COUNT OF PARTS </strong>— Files have “x1” to “x4” at the end of any STL file. The number represents the count of identical parts to be printed. <i>Example: </i><strong>[a]</strong><i>_m5_1mm_spacer_x4 (In this case you will need to print 4 identical spacers).</i></li></ul><p>&nbsp;</p><figure class="table" style="width:100%;"><table style="background-color:#f9cd4218;border-color:#f9cd42;border-style:solid;"><tbody><tr><td><h3><strong>CREDITS AND ACKNOWLEDGEMENTS</strong></h3></td></tr></tbody></table></figure><p>Special thanks to Stefan and Alexander from<strong> </strong><a target="_blank" href="https://www.cnckitchen.com/" rel="nofollow noopener"><strong>CNCKitchen</strong></a><strong> </strong>for backing this project by providing a generous set of soldering-iron tips and heat-set inserts for building and testing purposes.</p><p><strong>Here is the list of other open-source projects used for sourcing multiple CAD parts</strong>. Models are used as-is or modified to fit the project purpose and design:</p><ul><li>VORON TAP: <a target="_blank" href="https://github.com/VoronDesign/Voron-Tap" rel="nofollow noopener">https://github.com/VoronDesign/Voron-Tap</a> <i>[CAD models for heat-set inserts and bolts]</i></li><li>VORON Switchwire: <a target="_blank" href="https://github.com/VoronDesign/Voron-Switchwire" rel="nofollow noopener">https://github.com/VoronDesign/Voron-Switchwire</a> <i>[Base for remix of KEY-BAK mounting parts]</i></li><li>Ender SW: <a target="_blank" href="https://github.com/boubounokefalos/Ender_SW" rel="nofollow noopener">https://github.com/boubounokefalos/Ender_SW</a> <i>[Base for remix of Support arms]</i></li></ul><figure class="table" style="width:100%;"><table style="background-color:#F5F5F5;border-color:#808080;border-style:solid;"><tbody><tr><td><h3><strong>CHANGELOG</strong></h3></td></tr></tbody></table></figure><figure class="table" style="width:100%;"><table><tbody><tr><td style="width:100px;"><strong>Date</strong></td><td><strong>Change</strong></td></tr><tr><td>14.11.2023</td><td>STLs for variations of generic soldering iron mounts were added <strong>supporting 18mm and 19mm (OD) irons.</strong></td></tr><tr><td>12.11.2023</td><td>Minor update preparing for Dremel Add-On release. leg_x1_r1.1.stl is updated to <strong>leg_x1_r1.1_1</strong>.stl removing safety buffers.<br><br><i>This was necessary to ensure cross-compatibility in between base parts and multiple add-ons in development.</i></td></tr><tr><td style="width:100px;">04.11.2023</td><td><p>Printed files updated to R1.1. with cosmetic changes to <strong>ALL</strong> parts. <i>(Note that mechanical parts - BOM is not affected, zero changes there.)</i><br><br>What&#39;s new:<br><br>— <strong>All heat-set insert hole sizes are now reworked to 4.7mm</strong> solving the issue of being too tight and pushing out excessive plastic. Holes now have 0.4mm fillets on both the entry and the end.</p><p>— <strong>Wire strain reliefs now have an extra opening for the M3 bolts</strong> solving an issue that the bolts were too hard to fit in.</p><p>— The <strong>LEG plate now has specific safety buffers </strong>preventing linear rail bearing carriage accidental slide-offs (Sometimes referred to as <i>dropping balls :)</i> Do not do that.)</p><p>— <strong>Ton of other incremental improvements</strong> optimizing general printability of parts even better than it was in Rev.1.0</p></td></tr><tr><td style="width:100px;">10.10.2023</td><td>.STEP files added for <strong>soldering iron mounts only</strong> (for all 3 currently supported types - Pinecil, TS100 / 101, and “Generic”.</td></tr><tr><td>26.10.2023</td><td>Minor changes in BOM - Key-bak Super48 36&#34; 13oz variant as recommended.</td></tr><tr><td style="width:100px;">11.10.2023</td><td><strong>Initial version (Rev1)</strong></td></tr></tbody></table></figure>
