<h2>GRIDFINITY SWAPPABLE LABEL SYSTEM</h2>I love the look of printed labels, but I hated re-printing my bins whenever I needed to move my parts to a larger bin. I also hated how difficult it was to find consistent themed icons for all of the different kinds of screws and their drivers.<h3>Mix and match screw types and driver types:</h3><figure class="image image_resized image-style-side" style="width: 35.62%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000446624/design/2024-04-28_0939b6db6508d.jpg"></figure>I generated a huge variety of screw types and driver types and to use them simply add them to your slicer and combine them, making hundreds of combinations possible!&nbsp;I&#39;ve added several print profiles for you to use, but these are just for convenience and you are free to create whatever labels your hardware requires.&nbsp;<h3>Available icons currently in the collection:</h3>Screw types:<ul><li>Machine screw with round head</li><li>Machine screw with socket head</li><li>Machine screw with pan head</li><li>Machine screw with countersunk head</li><li>Tapping / wood screw with round head</li><li>Tapping / wood screw with socket head</li><li>Tapping / wood screw with pan head</li><li>Tapping / wood screw with countersunk head</li><li>Partially Threaded Machine screw with round head</li><li>Partially Threaded Machine screw with socket head</li><li>Partially Threaded Machine screw with pan head</li><li>Partially Threaded Machine screw with countersunk head</li></ul>Driver types:<ul><li>Hex</li><li>Phillips</li><li>Phillips + Slot</li><li>Phillips + Square</li><li>Slot</li><li>Square</li><li>Torx / Star</li><li>Triangle</li><li>Security Bit Nub (combine with any driver above)</li></ul>Hardware types:<ul><li>Nuts</li><li>Washers</li><li>Locking washers</li><li>Threaded inserts</li><li>T-Nuts</li></ul>Pre-generated size text:<ul><li>M2x[3-75]</li><li>M3x[3-75]</li><li>M4x[3-75]</li><li>M5x[3-75]</li><li>M6x[3-75]</li></ul><h3>Available pre-made bins in the collection:</h3>In addition to <a target="_blank" href="https://makerworld.com/en/models/466168#profileId-375085" rel="nofollow noopener">generating your own click-label bins here</a>, I have packaged pre-made bins with the collection.&nbsp;Pre-made bins are available in 3U, 4U, 5U, and 6U tall variants:<ul><li>1x1</li><li>1x2</li><li>1x3</li><li>2x1</li><li>2x2</li><li>2x3</li><li>3x1</li><li>3x2</li></ul><h3>Compatible with almost any bin using negative volumes</h3><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000446624/design/2024-04-28_a5952dc038c6e8.png"></figure>&nbsp;In the collection I include a vertical and horizontal negative volume STEP file which you can use in your slicer to carve out the required space for the labels to be placed.<h2>Slicer settings:</h2><figure class="image image_resized image-style-side" style="width: 37.58%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000446624/design/2024-05-01_acad35aed01c28.png"></figure>I recommend the following settings in your slicer:<ul><li>Brim: Disabled</li><li>Wall Generator: Arachne</li><li>Prime Tower: Optional, but recommended</li><li>Layer Height:<ul><li>0.2mm nozzle: 0.1mm layer heights</li><li>0.4mm nozzle: 0.2mm layer heights</li></ul></li></ul><h2> </h2><h2>How to download the complete collection:</h2>&nbsp;&nbsp;It&#39;s not very obvious how to download the .zip file containing all of the .step files needed to create your own labels, so here are some instructions.&nbsp;Click “Download or Print” and then “Download STL”<figure class="image image_resized" style="width: 35.67%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000446624/design/2024-04-29_d0ec009687599.png"></figure>&nbsp;Click the download icon next to “Complete Collection” <figure class="image image_resized" style="width: 33.74%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000446624/design/2024-04-29_bac4b9510395d8.png"></figure><h2>Changelog:</h2><ul><li>v1.0.0 released 2024-04-28<ul><li>Launch release!</li></ul></li><li>v1.1.0 released 2024-05-02<ul><li>Geometry change: Updated label latch. Backwards compatible, but much more satisfying click!</li><li>New screw icons: Added partially threaded machine screws!</li><li>New hardware icon: Added nuts!</li></ul></li></ul><h3>Future changes and additions planned:</h3><ul><li>Request screw / driver / hardware icons in the comments! I&#39;ll do my best to add them to the collection.</li><li>SMD / THT icons (resistors, capacitors, etc.)</li><li>Pre-generate text sizes for M2.5x[3-75]</li><li>Improve vertical label slot fitment. It works but it doesn&#39;t have that “click” fitment that I like about the horizontal slot.</li></ul><h3>Tools, bins, or labels made by the community:</h3><ul><li><a target="_blank" href="https://github.com/ndevenish/gflabel/" rel="nofollow noopener">GFLABEL by Nicholas Devenish</a> - A python script to generate click labels as seen here, or “pred”  style labels, also includes other icons such as resistors and other electrical components.</li><li><a target="_blank" href="https://github.com/ostat/gridfinity_extended_openscad" rel="nofollow noopener">Gridfinity Extended by Chris Heazlewood</a> - An OpenSCAD model for many Gridfinity bins and tools. Recently integrated the click labels. You can also use the Makerworld Model Maker to generate these bins right in your browser by <a target="_blank" href="https://makerworld.com/en/models/466168#profileId-375085" rel="nofollow noopener">visiting this model page</a>.</li></ul>&nbsp;<h2>License:</h2>This project inherits the MIT license from <a target="_blank" href="https://www.youtube.com/watch?v=ra_9zU-mnl8" rel="nofollow noopener">the original Gridfinity project as released by Zack Freedman</a>, AKA Voidstar Lab. The MIT license is not an option on this website so I have chosen a similar license, but the MIT license should be considered the active license.<h2> </h2>
