James

Fennrox

This is a remix of this file here - so all credit goes to this: <a target="_blank" href="https://makerworld.com/en/models/124488#profileId-134416" rel="nofollow noopener">https://makerworld.com/en/models/124488#profileId-134416</a> I changed the opening and the circle shape, so this stand / station will work with the basic lelit mara X portafilter, which comes with the machine. I've used eSUN PLA-CF (black) for this print - 0.4 nozzle, 0.16 layerhight, 15% gyroid infill, 3 walls, no supports - works quite well for me. If your portafilter tends to get hotter before preping / tamping the coffee, it could be advised to use a filament with better temp resistance (PLA+, PETG, ASA, etc)

Tamper Station for Lelit Mara X Portafilter

Coffee

SNASA

This is a small and stealthy minimalist heat insert press designed for CNC Kitchen TS100 heat insert set. I didn&#39;t want to use a counterweight so I made an invisible spring and belt system hidden in the vertical part. Its size makes it perfect for small job on the workbench :<figure class="image image_resized" style="width: 42.73%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000430484/design/2024-04-18_a86cd65962c1d.jpg"></figure><figure class="image image_resized" style="width: 42.59%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000430484/design/2024-04-18_4f0eadde94f.gif"></figure>&nbsp;The sides are super convinient to store everything you need (there is also a spot for a small alen key).&nbsp;I have added the step files if you want to design your own soldering iron mount or use a different base.&nbsp;Miscellaneous:<ul><li>20 * M3 brass insert</li><li>22* M3x8</li><li>1 * M3x6 screw</li><li>2 * M3 Nut</li><li>3 * M3x25 screw</li><li>7 * M5 nut</li><li>6 * M5x10 or M5x12 screw</li><li>1 * M5x16 thumb screw</li><li>2 * GT2 idle pulley ID Ø3mm</li><li>1 * GT2 belt (200mm should be enough)</li><li>1 * Spring or elastic band</li><li>1 * LML12B 200mm linear rail</li><li>1 * <a target="_blank" href="https://cnckitchen.store/products/ts100-101-adapter-tips-set-m2-x-m3-m4-m5-m6-1-4-m8-100-lead-and-cadmium-free" rel="nofollow noopener">CNC kitchen Heat Insert Set</a></li><li>Optional :<ul><li>1 * M4x8 Screw</li><li>1 * M4 nut</li></ul></li></ul>Assembling:<ul><li>Insert M3 brass insert (see red arrow below)</li><li>Use M3x8 screw everywhere except 1 * M3x25 (see orange arrow below)</li><li>Use 1 * M3x6 screw to lock the spring or elastic band</li><li>Use 2 M3x25 to mount the GT2 idle pulley</li><li>Insert M5 Nut (see yellow arrow below)</li><li>Make sure to run the belt before assembling the GT2 idle pulley</li><li>Use a small piece of adhesive tape to secure the belt on the arm mount (makes it so much easier to mount the belt on the sliding carriage)</li></ul><figure class="image image_resized" style="width: 79.45%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000430484/design/2024-04-18_86b4fd1a3ef78.png"></figure><figure class="image image_resized" style="width: 35.29%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000430484/design/2024-04-18_75b2c88e1b92e.png"></figure>&nbsp;Print settings:<ul><li>PETG for the soldering iron holder, other part can be printed in PLA</li><li>Layer height : 0.2 mm</li><li>No support</li><li>Print orientation as shown below :</li></ul><figure class="image image_resized" style="width: 54.24%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000430484/design/2024-04-18_75456e3a941b9.jpg"></figure>

Minimalist Heat Insert Press

Tools

akidone

A simple model that makes good use of the limited space in my cellar.&nbsp;Currently consists of three elements, suitable for:<ul><li>Unifi Gateway Ultra</li><li>Unifi Switch 8 Lite POE</li><li>Cableguide to route the cables to the rear</li></ul>Updated 28th june 2024:Added base and top plate, so that the fit is even better. Also added some cable guide stopper to clean things up, they perfectly fit the Monoprice Slimrun and the Unifi cables.&nbsp;I printed everything in Bambu Labs PETG, it has some little stringing on the overhanging parts, but everything fits snug into each other.&nbsp;If you need any special product to be included, just send me a msg!

Coffee

Tools

UniFi
