Jarvis_labs

Once in a Six Side

Many of you have asked for a bayonet, twist-lock version of this fume extraction system - and so at long last I now proudly bring you..&nbsp;<h2>V3!</h2>&nbsp;No more magnets.Magnets are cool, but let&#39;s be honest.. they&#39;re a pain in the ass. Sometimes they fall out, sometimes you glue them in wrong, and sometimes they&#39;re just too bloody expensive. Worst of all the magnetic system was prone to bumps, and could easily become disconnected. Can be printed 100% without the need for any support material. The steepest overhang is 45° so your printer shouldn&#39;t have any issue at all printing these parts with supports disabled in your slicer.&nbsp;2 different cover options for FREEThe triangle uses the least amount of filament. The Hexagon is the most ergonomic and has the best hand feel, and finally.. DA ORK is DA COOLEST!! - and you can get DA ORK as well as a bunch of other cool exclusive STL files by joining our wonderful community on <a target="_blank" href="https://buymeacoffee.com/onceinasixside" rel="nofollow noopener">BMC</a>, or <a target="_blank" href="https://www.patreon.com/OnceinaSixSide" rel="nofollow noopener">Patreon</a>. I really appreciate the support, and it helps me bring you projects just like this! Adjust the tolerance parameter in the included F360 file to get the PERFECT fit with your printer. The default value is 0.2mm and that goes for the included STL files here. Adjusting the tolerance effects only the Source Coupling component, so you only need to reprint that if your fit is too tight or too loose. Backwards compatible* - PLEASE READ IF UPGRADING AN EXISTING MAGNETIC SYSTEM!! For backwards compatibility for any holes you&#39;ve already drilled, please change the bolt_count parameter to 4, and the bolt_offset parameter to 52.494mm if coming from V1, or 53.25mm if coming from V2. To figure out which version you&#39;re upgrading from, V1 was posted to Printables, and V2 (which was the parametric update) was posted here to Makerworld. Here are the links to V1 and V2 files Version 1: <a target="_blank" href="https://www.printables.com/model/274787" rel="nofollow noopener">https://www.printables.com/model/274787</a> Version 2: <a target="_blank" href="https://makerworld.com/en/models/199062" rel="nofollow noopener">https://makerworld.com/en/models/199062</a> (almost identical to V1, but updated to be parametric)&nbsp;Thank you!If you level up your 3D printing setup with this system please consider saying thank you with a coffee or a sub. The support really helps! And if you join at the STL tier or higher I have loads of great STL&#39;s for you as well, including DA ORK!! So it&#39;s insanely good value 😁 PATREON: <a target="_blank" href="https://www.patreon.com/OnceinaSixSide" rel="nofollow noopener">https://www.patreon.com/OnceinaSixSide</a> BUYMEACOFFEE: <a target="_blank" href="https://www.buymeacoffee.com/onceinasixside/" rel="nofollow noopener">https://www.buymeacoffee.com/onceinasixside/</a> InstallationInstallation couldn&#39;t be simpler - just grab these supplies down below, print off the files and you&#39;ll be setup in no time! I&#39;ll leave a link to the original video down below so you can see exactly how to install this system. Installation Video: <a target="_blank" href="https://www.youtube.com/watch?v=zk9KcGAH_Zc" rel="nofollow noopener">https://www.youtube.com/watch?v=zk9KcGAH_Zc</a> What you&#39;ll need | Affiliate Links &lt;3 4&#34; Inline Fan - <a target="_blank" href="https://geni.us/E31MO" rel="nofollow noopener">https://geni.us/E31MO</a> 4&#34; Vent Hose - <a target="_blank" href="https://geni.us/DSqwco" rel="nofollow noopener">https://geni.us/DSqwco</a> Plank of wood that fits your window or an AC Window Kit <a target="_blank" href="https://geni.us/AEv78e" rel="nofollow noopener">https://geni.us/AEv78e</a> 10x2mm Neodymium Magnets - <a target="_blank" href="https://geni.us/i8uAI69" rel="nofollow noopener">https://geni.us/i8uAI69</a> M3 Bolts (I used a mix of M3x8 and M3x12) - <a target="_blank" href="https://geni.us/TVsnB" rel="nofollow noopener">https://geni.us/TVsnB</a> 80mm Hole Saw (with teeth, not the diamond type) - <a target="_blank" href="https://geni.us/xPTj" rel="nofollow noopener">https://geni.us/xPTj</a> Insect screen mesh - <a target="_blank" href="https://geni.us/17df2" rel="nofollow noopener">https://geni.us/17df2</a> Hose clamps - <a target="_blank" href="https://geni.us/hRDvaG" rel="nofollow noopener">https://geni.us/hRDvaG</a>Tip: Depending where you are it may be significantly cheaper to source the insect screen mesh and hose clamps locally. For most of the other parts I found better deals on ebay so check there as well, but thank you for using my affiliate links. Recommended tools Power Drill Staple Gun Hand saw

Quick Disconnect Ventilation V3 by OIASS

Workshop

潦草小狗爱吃雪糕

This is a mold for making spinning top from PLA filament purge. The tops made with this mold are very colorful and spin well. I printed the mold with PETG at 100% infill and did not need to use supports (PC might work even better).&nbsp;What you will need:<ul><li>An unused oven</li><li>A silicone mat (it&#39;s easier to flip and roll the melted PLA into a ball on a silicone mat than on a metal baking tray)</li><li>PLA filament purge</li><li>A 3M respirator or N95 mask (the fumes from melting PLA in the oven are stronger, so please protect yourself)</li><li>Work gloves</li><li>Tongs</li><li>Pliers</li><li>A digital scale</li></ul>Process：1. Accurately weigh 6g of PLA filament purge and place it in the oven.Preheat the oven to 200-230°C and heat the filament purge for approximately 5 minutes.2. Use tongs and pliers to shape the melted PLA into a ball. Evenly folded patterns will look better.3. Place the shaped plastic into the mold and press the mold firmly.4. After approximately 3 minutes, open the mold and remove the top. If the top is difficult to remove, use pliers to take it out.「Twisting and shaking the mold after it has cooled completely can aid in part release. I recently tried using a mold release agent (spray), and it has been very effective in ensuring smooth part separation.20240512」（translate from Google Gemini）&nbsp;&nbsp;这是一个使用PLA耗材废料制作陀螺的模具，制作出的陀螺颜色比较漂亮，旋转的很好。我用PETG 100%填充来打印模具，无需添加支撑（PC可能效果会更好）。&nbsp;你需要：一个闲置的烤箱，一个硅胶垫（需要把熔化的PLA翻折并团成一团，这在金属烤盘中很难操作），PLA耗材废料，3M防毒面具或N95口罩（在烤箱中熔化PLA产生的气味更大，请做好防护），工作手套，取盘夹，钳子，电子秤。&nbsp;压模步骤：&nbsp;1，将 6g（请准确称重）PLA耗材废料放入烤箱中，200～230℃加热约5分钟（烤箱需预热）<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000437241/design/2024-04-21_df4dbe446d418.jpg"></figure><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000437241/design/2024-04-21_74bd4a7599ef7.jpg">&nbsp;&nbsp;2，用取盘夹和钳子把熔化的PLA团成一团（翻折均匀的纹理会更漂亮）<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000437241/design/2024-04-21_31b36cc45d107.jpg"></figure>&nbsp;&nbsp;3，把团好的塑料放入模具中，用力挤压模具。&nbsp;<img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000437241/design/2024-04-21_75a96c8b0fc52.jpg"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000437241/design/2024-04-21_06f1d6fa28797.jpg"></figure>&nbsp;&nbsp;4，大约3分钟以后打开模具取出陀螺。如果脱模困难可以用钳子把陀螺取出。<img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000437241/design/2024-04-21_07f0433aa2577.jpg">&nbsp;&nbsp;「充分冷却后扭转并晃动模具将有助于脱模。我最近尝试使用脱模剂（喷雾），它很有效，可以确保顺利脱模。20240512」&nbsp;

Spinning top mold   陀螺模具

recyling

Hugo

<h3>The reason behind this project</h3>I absolutely love 3D-printed storage systems, but there&#39;s one thing I don&#39;t like about them: how the bins connect to each other. With most systems out there, you need to print a base grid or tiny connecting pieces, which is a bit of a hassle. And the attempts at interconnecting storage systems are not aestheticly pleasing. That&#39;s why I came up with this new design! I wanted interlocking bins of various sizes that can connect on each side but with a sleek and simple design.I&#39;ve also added small bumps on the inside, which means you can add accessories and customise each bin to a dedicated task.And to create custom storage boxes, I&#39;ve adapted my <a href="https://www.printables.com/model/761101-snaplock-storage-boxes" rel="nofollow">SnapLock </a>model to accommodate the bins.&nbsp;<h3>How to choose the size</h3>The standard bin, Bin_1x1x1, is 60x60x50mm outer dimensions.All the dimensions in the STL names are based on those dimensions*Every bin is named as follow : Bin_length x width x heightThe other flat components such as lids are named : Lid_length x width&nbsp;*The other bins are not exact multiples of the standard bin as I take into account the interconnecting part&nbsp;<h3>Test print</h3>I encourage you to test the fit by printing 2 Bin_1x1x0.5It should be a nice, snug fit, but not so tight that it&#39;s impossible to split.&nbsp;<h3>Printing</h3>All the STLs are oriented to be printed directly No support neededYou can use any materialThe sweet spot between material use and rigidity for me is 2 walls ans 5% infill with a 0.4mm nozzle (bigger nozzle should work as well)&nbsp;<h3>Accessories </h3>You can even put the bins on their side to act as drawers.For the moment I have designed several accessories that fit inside or outside the bins :<ul><li>Drawers (I used the plastic&#39;s elasticity to lock them in place while closed)<ul><li>Assembled drawer</li><li>Screw drawer</li></ul></li><li>Lid (to close any bin</li><li>Screw organizer</li><li>Tray</li><li>Battery holder</li><li>Pen holder</li><li>SnapLock storage box</li></ul>&nbsp;Feel free to give me some feedback if you give this project a try :)

BinLink

Storage

JayRay

This is the original #3DBenchy directly from Creative Tools. Not a download of a download, nor all the slightly modified versions found elsewhere (ie, BambuLab Studio, Printables, etc…)&nbsp;I would like to introduce the #3DBenchy to Maker World. During the close beta period, there was no #3DBenchy available to send to the printer from the phone app so I uploaded it here. &nbsp;Please add your profiles as you see fit for the community to use to run tests. Thanks!&nbsp;Community members have provided a ton of different profiles. I hope you find one that fits your testing needs. Remember, a bad Benchy print could mean your filament calibrations are off, or a sign of mechanical error (for Bambu Printers.)&nbsp;All models uploaded and the below content is extracted from 3Dbenchy.com.<figure class="media"><div data-oembed-url="https://youtu.be/_epwuDI9FBI"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/_epwuDI9FBI" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>&nbsp;<figure class="image"><a href="http://www.3dbenchy.com/features/" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy__Low-slope_surfaces_1-300x300.png"></a></figure>#3DBenchy is designed to offer a large array of challenging geometrical features for 3D printers, and touch on different issues related to additive manufacturing.The 3D model is designed to print at 1:1 scale without support materials. It is challenging for most 3D printers but the small volume (15.55 cm3) typically prints in well under two hours and does not require much material.The different surfaces of the #3DBenchy model reveal typical issues regarding surface finish, model accuracy, warping, etc.Visit <a target="_blank" href="http://www.3dbenchy.com/sample-page/features/" rel="nofollow noopener">this link</a> to see a complete list of each feature and correspondent descriptions.<figure class="image"><a href="http://www.3dbenchy.com/dimensions/" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_about_features-300x287.png"></a></figure>Use #3DBenchy to test and calibrate your 3D printer by adjusting hardware and software settings for optimal results.The shape and size of this 3D model is designed to challenge 3D printers. Compare your #3DBenchy results with the dimensions illustrated in <a target="_blank" href="http://www.3dbenchy.com/dimensions/" rel="nofollow noopener">this link</a>. These are easy to measure with a caliper.Print and check your 3D-printer’s result for dimensional accuracy, tolerances, warping and deviations related to changes in printing parameters and material types.&nbsp;<h2>Features</h2><figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_page_features_main_image.png"></figure>#3DBenchy is designed to offer a large array of challenging geometrical features for 3D printers, and touch on different issues related to additive manufacturing.The 3D model is designed to print at 1:1 scale without support materials. It is challenging for most 3D printers but the small volume (15.55 cm3) typically prints in well under two hours and does not require much material.The different surfaces of the #3DBenchy model reveal typical issues regarding surface finish, model accuracy, warping, etc.Please see a complete list of each feature and correspondent descriptions below.&nbsp;<h2>The Hull</h2>The hull is a large, smooth overhanging curved surface that is challenging to 3D-print, and clearly reveals any surface deviations.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_hull_curved_overhang-300x300.png" alt="Feature_hull_curved_overhang"></figure>&nbsp;<h2>Symmetry</h2>#3DBenchy is perfectly symmetrical which makes any skewness and warping easy to detect.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_symmetry-300x300.png" alt="Feature_symmetry"></figure>&nbsp;<h2>High-Resolution STL file</h2>The STL file is triangulated at a very high resolution which yields smooth surfaces. The maximum deviation from the original CAD file is set to 0.001 mm.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_high-res_stl_mesh-300x300.png" alt="Feature_high-res_stl_mesh"></figure>&nbsp;<h2>Planar Horizontal Faces</h2>The top surfaces of the deck, box and chimney are planar, horizontal and parallel to the bottom plane.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_planar_horizontal_faces-300x300.png" alt="Feature_planar_horizontal_faces"></figure>&nbsp;<h2>Tiny Surface Details</h2>If you have a high-resolution 3D printer, this is where you can shine! The letters on the stern are less than 2 mm tall and the thickness of #3DBenchy’s nameplate is just 0.1 mm.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_3DBenchy_nameplate_tiny_detail-300x300.png"></figure>&nbsp;<h2>Cylindrical Shapes</h2>The chimney is designed to define concentrical cylindrical shapes with inner and outer diameters. These clearly show deviations in roundness.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_conentrical_cylindrical_shapes-300x300.png" alt="Feature_conentrical_cylindrical_shapes"></figure>&nbsp;<h2>Overhang Surfaces</h2>Overhang issues are the Achilles’ heel of 3D printing. #3DBenchy offers several challenging areas such as in the difficult-to-reach inside of the bridge.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_overhang_bridge-300x300.png" alt="Feature_overhang_bridge"></figure>&nbsp;<h2>Low-Slope-Surfaces</h2>Low-slope-surfaces clearly show the layered structure of 3D printing. If printed horizontally, #3DBenchy’s gunwale and roof of the bridge will reveal the layer-steps.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_low-slope-surfaces-300x300.png" alt="Feature_low-slope-surfaces"></figure><h2>Large Horizontal Holes</h2>The rear window offers a large circular horizontal hole and the boat’s wheel offers a round difficult-to-reach secluded feature.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_large_horizontal_hole-300x300.png" alt="Feature_large_horizontal_hole"></figure>&nbsp;<h2>Small Horizontal Holes</h2>The hawsepipe represents a small short horizontal hole and has a very thin flange against the hull.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_hawsepipe_small_hole-300x300.png" alt="Feature_hawsepipe_small_hole"></figure>&nbsp;<h2>Slanted Small Holes</h2>The fishing-rod-holder provides a very small slightly-slanted blind hole.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_fishing-rod-holder_slanted_small_hole-300x300.png" alt="Feature_fishing-rod-holder_slanted_small_hole"></figure>&nbsp;<h2>First-Layer-Details</h2>The shallow letters at the bottom of the boat clearly reveal typical first-layer-squashing.&nbsp;<figure class="image"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/Feature_shallow_letters_bottom_plate-300x300.png" alt="Feature_shallow_letters_bottom_plate"></figure><h2> License</h2><figure class="image"><a href="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_frontpage_slider_sea_v041.jpg" target="_blank" rel="nofollow noopener"><img src="http://www.3dbenchy.com/wp-content/uploads/2015/04/3DBenchy_frontpage_slider_sea_v041-1024x402.jpg"></a></figure>&nbsp;#3DBenchy by <a target="_blank" href="http://creative-tools.com/" rel="nofollow noopener">Creative-Tools.com</a> is licensed under a <a target="_blank" href="http://creativecommons.org/licenses/by-nd/4.0/" rel="nofollow noopener">Creative Commons Attribution-NoDerivatives 4.0 International License</a>. Permissions beyond the scope and typical usage examples are explained below.&nbsp;<h2>Feel free to …</h2><ol><li>… download the <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a> and 3D-print it as you please.</li><li>… give away and even sell 3D-prints of the <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a>.</li><li>… <a target="_blank" href="http://www.3dbenchy.com/share/" rel="nofollow noopener">publish</a> images and videos of your 3D-prints – you own them!</li><li>… redistribute the unmodified <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">#3DBenchy STL file</a> as you please. Such as hosting your own downloads, attaching to emails, including the file on DVDs, USB-sticks, and in software distributions, bundling the STL or pre-sliced print file with 3D printer kits, etc.</li><li>… experiment, be inventive and creative! We made #3DBenchy as a tool for playing around with and testing 3D printers. Improve your skills and challenge your machine and its software. Try every setting, variation and material you can think of!</li><li>… modify #3DBenchy for personal use. Feel free to publish texts, images and videos of your experimentation (these are your work and you own them!). Please respect the above list items regarding not distributing modified STL files of #3DBenchy.</li></ol><h2>Consistency</h2>#3DBenchy is designed to be a calibration tool for testing 3D print settings and comparing the performance of different 3D printers. Therefore it is important that the same unmodified <a target="_blank" href="http://www.3dbenchy.com/download/" rel="nofollow noopener">STL</a> file is consistently used for this purpose.<h2>Attribution</h2>We designed the little #3DBenchy boat and this expanding web page to help 3D printer operators on this planet to better navigate the vast sea of 3D printing possibilities!It is also meant to be a fun object to experiment with and discover 3D printing. If you enjoy #3DBenchy and the content on this site, please give us attribution in your publishings. Simply include the word <a target="_blank" href="https://www.google.se/webhp?sourceid=chrome-instant&ion=1&espv=2&ie=UTF-8#q=%233dbenchy" rel="nofollow noopener">#3DBenchy</a> and the URL <a target="_blank" href="http://3dbenchy.com/" rel="nofollow noopener">3DBenchy.com</a>. The team behind #3DBenchy highly appreciates your help!

BENCHY

KYZ Design

This model was originally uploaded <a target="_blank" href="https://www.printables.com/model/460255-hsw-single-walls-with-integrated-frame-and-fasteni" rel="nofollow noopener">here</a>, check it out for past makes and comments.&nbsp;Update 30/04/2023<ul><li>"HSW Single Wall - 11x7 HD" added</li><li>“HSW Test Wall HD” added</li><li>All files renamed</li></ul>----------------My new Honeycomb Coffee Wall just needs one section of the Honeycomb Storage Wall, and I found the regular wall pieces to be too flexible and asymmetrical for my liking, so I made one with:<ul><li>Integrated borders, making the piece much more rigid and have higher weight capacity</li><li>Mounting holes on the rigid frame for secure attachment, and so you don't have to use any of the hexes,</li><li>Mountable with double sided tape,</li><li>And most importantly… Symmetry.</li></ul>SizesI just needed the big one but I made a few extra sizes for you guys to print on smaller printers as well as smaller work spaces. The first size number denotes number of cells horizontally and the second size number denotes number of cells vertically so size 11x9 means 11 cells wide, 9 cells high.Thicknesses<ul><li>Standard Duty (SD) 8mm thick</li><li>Heavy Duty (HD) 10mm thick - warning, all inserts will fit very snug as the cell walls are more rigid</li></ul>MountingScrew on with "Gauge 6" or 4mm countersunk head screws. The piece is 8mm thick so 16mm or 20mm screw will be suitable to mount to timber.Mounting is also possible with double sided tape (such as 3M VHB tape) - particularly good if you want to mount to bathroom/kitchen tiles. If you plan to tape this on and want to remove any of the screw holes, make an 8mm thick cylindrical “add part” modifier and place on top of the hole. (I would leave the holes there in case you change your mind or move it)Enjoy!&nbsp;Check out <a target="_blank" href="https://makerworld.com/en/u/11128021/collections/18964" rel="nofollow noopener">this collection</a> for my other Honeycomb Storage Wall models andcheck out <a target="_blank" href="https://makerworld.com/en/u/11128021/collections/26498" rel="nofollow noopener">this collection</a> for my Gridfinity models.&nbsp;&nbsp;

Workshop

recyling

Storage

Cal

HSW
