articulated dragon model. resize for your needs.

Articulated Crystal Dragon

EEEEEE

This project is the culmination of 100+ hours of remodeling and printing. &nbsp;There was no miniature handheld glider that could be printed and thrown straight all in less than a half hour, which I wanted to change&nbsp;The main features of the glider are its unparalleled accuracy and consistently, allowing a skilled used to soar the plane 30 feet before it lowers by even an inch. &nbsp; Pitch Stability     Yaw Stability     Ease Of Use     Consistency      Durability       Airtime           ★★★★★          ★★★★★         ★★★★         ★★★★★          ★★★        ★★★★★&nbsp;This was printed on the Bambu P1P and printed in 23 minutes(17 minutes of actual printing) with white PLA basic. It used just under 10 grams of filament.Instructions-Print in PLA at 100% infill with no brim or raft. Wait for the hotbed to cooldown before gently using a scraper tool to remove the glider.<figure class="image image_resized" style="width:31.52%;"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000083624/design/2023-12-05_h3ph93i1hm0i.jpeg"></figure>Bend the tail segments up 90 degrees.<figure class="image image_resized" style="width:31.52%;"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000083624/design/2023-12-05_rtzdaumbtly8.jpeg"></figure>Bend the elevators down about 25 degrees, and flip over the plane.<figure class="image image_resized" style="width:30.98%;"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000083624/design/2023-12-05_ll74i2pc6mdz.jpeg"></figure>Hold the glider from between the main and tail wings, and throw lightly. The tail segments should be facing downwards when thrown, and the elevators should be facing up. If the plane seems to lean to one side, try to throw the plane with more power.The design fits on most build plates if positioned diagonally, but if it doesn&#39;t fit, print Left Simple Indoor Glider V2 and Right Simple Indoor Glider V2 separately and glue them together with hot glue or a 3d pen. Tape or rubberbands could also work.You can reverse the tail wings if you want the plane to look better and land more smoothly at the cost of slightly worse performance. Just make sure the weight on the front of the plane is facing downwards to increase stability.

Simple Indoor Glider V2

飞机

HMJ花喵菌

这个P1S增高散热配件的设计初衷就像它的标题一样简单明了，它提供了最基础的增高和顶部散热的功能，且只增高4cm(去掉机器本体的下凹槽位，实际增高高度约为38mm），在设计上极度简化，所以它的打印难度并不高，也相对节省打印材料，这里我推荐PETG打印，我并未测试其他的打印耗材，不能保证其他品类的耗材打印效果，如果使用我提供的3mf配置文件进行打印，那么增高件的主体部分仅需357g的耗材即可。主体部分的组装用的是榫卯插销结构，不需要任何螺丝固定就能组装完成。&nbsp;<figure class="image image_resized" style="width:78.35%;"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-20_e4e0069df059a.png"></figure><figure class="image image_resized" style="width:49.52%;"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-16_15a12be63b0dd.png" alt="主体部分可以一次性打印完成"><figcaption>主体部分可以一次性打印完成</figcaption></figure> <figure class="image image_resized" style="width:47.54%;"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-16_c3d6363b9a441.jpg"><figcaption>已在两台机器上验证可行性</figcaption></figure>&nbsp;&nbsp;&nbsp;它所需额外购买的安装配件如下：1，6mm直径3mm厚度的圆形磁铁38个【至少需要38个，但最好多买一点】2，502胶水【只要能黏住磁铁可以选择其他种类胶水，我本人使用的是饰品胶】3，15mm宽，1mm厚度的3m eva单面泡沫胶带【这个是可选项，不安装这个泡沫胶也不影响增高散热的使用】&nbsp;<figure class="image image_resized" style="width:50.16%;"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-23_abfa06affee198.png"><figcaption>3m Eva胶带的黏贴位置如图所示，除了图片展示的位置以外，增高架底部也可以粘贴胶带。胶带的作用是给玻璃盖板一个缓冲层，这样可以避免玻璃盖板和增高散热支架的直接接触。</figcaption></figure>&nbsp;磁铁辅助安装工具的使用方法<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-30_ed552a5d90ad9.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-30_f124d1be0334.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-30_1793b45e69d28.png"></figure>&nbsp;&nbsp;Q&A 为什么要安装增高散热1，因为在不安装增高散热的情况下，打印头顶部的料管有很大概率会和顶部玻璃摩擦2，可以在不打开打印机舱门和掀起顶部玻璃的情况下提供被动散热的空间，你仅需要把磁吸盖板移除即可，优雅且高效。&nbsp;&nbsp;提供STEP工程图文件这个增高散热在设计上不可能令所有人都满意，这也是我制作这个配件的初衷，它满足了我所有的需求，且避免了我不满意的部分，上传这个作品也仅仅是给大家多提供了一个选择，并且我希望任何人都能基于此项目制作出自己满意的作品，且少走一些弯路，所以我提供了step工程文件提供参考，至少可以参考它的参数部分。&nbsp;&nbsp;如果你缺一个竹屎（废料）筒的话，你可以试着打印由我设计的模型。可以点击下方图片跳转至模型详情页面：<figure class="image image_resized" style="width:40.96%;"><a href="https://makerworld.com/zh/models/67388#profileId-71326" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-24_6350e0fe33fb9.webp"></a><figcaption>竹屎筒链接</figcaption></figure>&nbsp;------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------如果你的磁铁有多余的话，那么你可以考虑打印一个我设计的解压小玩具，跳转页面点击下图：<figure class="image image_resized" style="width:40.04%;"><a href="https://makerworld.com/zh/models/71625#profileId-75829" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/509268/2023-11-23_c2d52b045c0f8.png"></a><figcaption>拇指开关链接</figcaption></figure>

P1S  X1C Riser 增高散热

工具等

Bluebox

原有的竹屎收集器都太小了不够用，于是我自行设计了一个超大容量的。由于我用的是P1S combo，机身是金属的，所以我采取了磁吸设计，给这个收集器的四角各加上了一枚磁铁，这样收集器就能牢牢的吸在机器上了。 大家要按照这个尺寸购买磁铁，磁铁尺寸是：直径：6mm，厚度：3mm&nbsp; 安装的时候，最好往磁铁洞里面滴一滴胶水，这样保证磁铁安装的更牢固。&nbsp;The original Filament Poop Bin were too small for use, so I designed an extra-large capacity one myself. Since I am using a P1S combo and the body is made of metal, I adopted a magnetic design and added a magnet to each of the four corners of the collector so that the collector can be firmly attached to the machine.&nbsp;You should buy magnets according to this size. &nbsp;The magnet dimensions are: diameter: 6mm, thickness: 3mm&nbsp;When installing, it is best to put a drop of glue into the magnet hole to ensure that the magnet is installed more firmly.<figure class="image image_resized" style="width:77.39%;"><img src="https://makerworld.bblmw.com/makerworld/draft/475023/2024-01-31_f41a6141b6784.jpg"></figure>&nbsp;&nbsp;&nbsp;&nbsp;
