gruvin

RP47 Designs

I decided to make a large version of my elephant face hueforge. This one prints in 4 pieces that will need to be glued together in some way.1kg roll of filament to show scale in the cover picture.&nbsp;Link to the original sized one: https://makerworld.com/en/models/179228#profileId-197121&nbsp;Print at 100% infill with a layer height of 0.08mm with a base layer of 0.16mm&nbsp;Filaments Used: PLA+ Sunlu Black Transmission Distance: 0.6 PLA+ Sunlu Grey Transmission Distance: 2 PLA+ Sunlu White Transmission Distance: 5&nbsp;Swap Instructions: Start with Black At layer #15 (1.28mm) swap to Grey At layer #30 (2.48mm) swap to White for the rest.

Giant 4pc Elephant Hueforge

Art / Decor

LoboCNC

This is a 3D printable version of the <a href="https://www.irwintools.com/product/59200cd/handi-clamps" rel="nofollow">Irwin Handi-Clamp</a>. Squeeze the handles to close it on your workpiece and the self-locking lever mechanism keeps it closed. Just press on the lever to release. Great for clamping jobs needing light pressure and one-handed operation. Opens 0 - 39mm (0 - 1.5 in).Everything presses or snaps together without glue or fasteners. If you want the clamp to automatically spring open, you will need one small rubber band, like the kind that comes on green onions.Printing You want to print this as rigid as possible. I used PLA with 5 perimeter lines and 30% infill. CF filled PLA would be even better. I used 0.2mm layer thickness.The bar and lever sides of the clamp do need some supports in specific areas, as indicated last photo. I recommend manually painting on supports as indicated rather than turning on automatic supports everywhere.Assembly The leaf spring has some built-in mouse-ear brims that need to be broken away first. Then insert the short leg of the spring into the slot in the lever-side handle. It should press into place. Then, slide the lever over the curved bar on the bar-side of the handle and place the two handle pieces together. The D-shaped pin should be a press fit into place but you may need to tap it into place lightly with a small hammer. (If your pin happens to be a little loose, you might try reprinting it scaled up by 0.5% or so.)To make it spring open automatically, you'll need to loop a thin rubber band through the eyelet in the bar-side of the handle and then hook the other end over the little nub on the other side as shown in the fifth photo.Operation Squeezing the clamp closed will cause the lever to slide along the curved bar and it self-locks into place when you stop squeezing. Pressing on the end of the lever will cause it to unlock. Note that the little leaf spring may not contact the end of the lever once the clamp is locked. The spring's job is to initially apply a light pressure to the lever to get it to start locking on the bar. When you stop squeezing the clamp, it will flex back and the spring will no longer touch the lever, but the self-locking will still stay engaged.And <a href="https://youtu.be/pHbJEg4Dp80." rel="nofollow">here </a>3Dprintsmith has posted a video of his build of the clamp.

Handi-Clamp

Tools

Nanodesigner

Stepper Motori. Serie 17HS2408 - 17HS3401 - 17HS4401 - 17HS8401 - 17HS6401.Creati con solidworks con passaggio semplificato*. per le misure complete consultare il file in allegato Step motor_datasheet.jepg Sono inclusi file solidworks parts ed stl.Ps. scusa, non ho trovato un datasheets esatto sul connettore a 4 pin, quindi ho usato le misure di immagini internet.*I file con passaggio semplificato possono essere stampati e usati per prototipazione rapida, le misure sono esatte al datasheets, ma non corrispondono per uso reale non rispecchiando la meccanica dell'oggetto. Per effettuare modifiche usare i file solidworks.<hr/>EnglishStepper Engines. Series 17HS2408 - 17HS3401 - 17HS4401 - 17HS8401 - 17HS6401.Created with solidworks with simplified passage*. for complete measurements consult the attached file Step motor_datasheet.jepg Solidworks parts and stl files are included.Ps. sorry, I didn't find an exact datasheets on the 4-pin connector, so I used internet image measurements.<ul><li>Files with simplified passage can be printed and used for rapid prototyping, the measurements are exact to the datasheets, but do not correspond for real use, not reflecting the mechanics of the object. To make changes, use the solidworks files.</li></ul>Category: 3D Printers

Stepper Motors serie 17HS2408 - 17HS3401 - 17HS4401 - 17HS8401 - 17HS6401

Reference Models

Anthorin

Note: There is no point printing the versions with a slot/hole for a Hygrometer/Hydrometer. Being so close to the dessicant it will give a false reading compared to inside the AMS which is the measure you actually need!&nbsp;So print 3 of these boxes!&nbsp;Also, I changed these so they have a sliding lid (with a handle!) so now the dessicant doesnt puor out when you drop it. Note the lid only fits one way due to a small block at one end deliberately. That means it will only fit one way so if it seem like it doesnt fit, turn it round!&nbsp;I have also added a funnel lid to help with filling the dry box.

Bambu Dry Box

Printer Enhancements

martin.taichl

This is my model of the Raptor Class Light Cruiser from the Show the Expanse. This ship appeared as the infamous Pella in the Free Navy colours. I however made it in its original MCRN colours and with my own name. (The colour structure is my own design based on the previous MCRN ships). The ship is made to be in scale with my previous MCRN ships so it is fricking huuuge and heavy - over a meter long. The ship also comes with the standard features for the MCRN ships: - Retractable PDCs 9x - Retractable Airbridges 2x - Openable Torpedo Tubes with torpedos 4x - Openable Drone Hub with a Drone 1x - Stand with a Placket The ship is a kit and does not require a single drop of glue. The assembly is however quite complex so I highly recommend to watch the entire Playlist on my YT channel where I go step by step with it, &nbsp;<figure class="media"><div data-oembed-url="https://youtu.be/r2WJjA7KOys"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/r2WJjA7KOys" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>

Art / Decor

Tools

Reference Models

Printer Enhancements

The Expanse
