<h2>If you want a commercial license, check out my bio and get it from Patreon.</h2><h2>Personal use only.</h2>&nbsp;This model is design for MakerWorld light contest (2/5). Complete free version is only available on here Makerworld. <h3>Many people have contacted me said they willing to pay for the model. Other platform product manager reach and out said I could use their platform and selling this design for some money, but I have decided to keep it here for free for now. So there will be more people could enjoying it :) So show me your finshed print, I would like to see it. </h3><h3> Anywhere else you see this model upload is Unauthorized (please notify me and report them), beside my own account (SavageLau). </h3>&nbsp;<h2>If you would like purchase LED light needed for this design and filament from Bambu Lab Offical website: Affiliate link is below, so I can get some commission to support my future work. </h2><h2><a target="_blank" href="https://shrsl.com/4h4np" rel="nofollow noopener">https://shrsl.com/4h4np</a> </h2><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-03-23_4ad27b7082fe3.png"></figure><h2>Filaments that I use for this project: (Bambu Lab Offical website:)</h2><h2><a target="_blank" href="https://shrsl.com/4h4ns" rel="nofollow noopener">https://shrsl.com/4h4ns</a> </h2>&nbsp;&nbsp;&nbsp;<h2>You may also like this design:</h2>PeaShooter Lamp Kit 001. <a target="_blank" href="https://makerworld.com/en/models/174475#profileId-191833" rel="nofollow noopener">https://makerworld.com/en/models/174475#profileId-191833</a> &nbsp;&nbsp;&nbsp;My boss saw some Bellsprout light the other day and she want me to design one. I have one LED Lamp kit come with my a1mini and sitting for a while. So why not turning it into what she want. So the design started adpot the lamp kit into Bellsprout.I found this pic on Google, based on the posture and proportion started deisng.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_bc131748fd272.png"></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-01_33679f29d502a.png"></figure><h2>Update: </h2><h3>2/2/2024. A new profile was made for a1mini. Increased infill/walls on base and body part. </h3>Model main body have been reduced in size inorder to meet the build plate size for a1mini with muti-color prints. &nbsp;<a target="_blank" href="https://makerworld.com/en/u/2010665163" rel="nofollow noopener">@Sascha2202</a> feedback it is a bit hard to keep banlance. Weight increased on printing profile by adding more infill and walls. Weight for that part from 160g to 202g, lowered center of gravity. Consider head is around 40g + led weight, it should do well now. <h3>2/1/2024. Joints redesigned. </h3>Improved joints firction load, strength, tolerancing. New turning angle sets around 13.5 degrees max for each joints. <figure class="image image_resized" style="width:36.72%;"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-01_d00693a8b7acb.png"></figure>“Head” part fit and finish improving. <h3>Revisions and Tests today:</h3><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_ffe7e41994dec.png"></figure>&nbsp;<h2>Before you print(Important!):</h2>Run the joint test print first with the filament you are going to use for joints and body, before you doing the full print! This is important. Depend on filaments you use for the joint parts, there will be sinkage rate difference, and firction load on joint will be different.&nbsp;I put very tight tolerancing on design, but it may not work as intended when you printing with your filaments, so run the test and confirm joints is very tight to each other. Other wise You will not get the desired result.&nbsp;&nbsp;Joints with other parts are standard size. There is one “Tight” profile for joints. There are two types of joint, regular and with wire clip one. You will need to print total of 12 or above (maybe less than 15) to get good proportion. &nbsp;Joints designed best work with 4 wall layers, and 10% to 20% infill, adding more infill will not improve the strength, will only leading part failure during assembly. &nbsp;<h2>Hard ware:</h2>This design require Lamp LED Kit 001 from Bambu Lab. All other parts are printable. <figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-31_bca061fd80f1d.png"></figure>&nbsp;<h2>Post work:</h2>Removing brims from all parts, when you remove brim from joints part, confirm it is fully removed. <figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_dec1b2c670225.gif"></figure><h2>Assembly:</h2>Refer these gif image. Joints is a bit hard to push in, refer how I do it, holding the bottom part with you fingure, it will reduce the change of failure. &nbsp;Joints:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_5c978e23e8634.gif"></figure><figure class="image image_resized" style="width:51.25%;"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_9f2e463b2d8a6.gif"></figure>Fully assembly:<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-02-02_9a975d341b61f.gif"></figure>&nbsp;&nbsp;&nbsp;<h2>Design:</h2>Lamp kit is 60mm dia, 8mm thickness. based on that dims and make rough draft to evaluate the overall size.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_34bf66e6b20e5.png"></figure>&nbsp;Working on some parts, and integrate them in the end.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_4880a9ab2336a.png"></figure>&nbsp;I started with wanting ball joint on the head, so it will able to turn angles. End up why not to have more ball joints on the body.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_b08f0ea2e5ee9.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_80ec7f991cbaa.png"></figure><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_80ed16d7dd498.png"></figure>&nbsp;Ball joints is pain in the axx to work with. I want it to have a lot of friction load in normal condition. so the outter shell shall have very small tolerance to the ball or even smaller. Ended spending a lot of time try in truth to testing out different tolerances and make design revisions.Still not perfect, but it work for this application. You gain a lot of DOF, but it is a bit brittle, depends on your materials.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-30_153933e0ba5bb.png"></figure><h2>Revisions and tests:</h2><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/796346/2024-01-31_641c974fd0d58.png"></figure>

BellSprout Lamp LED Kit 001

Sevro

Overview.A Ring Lamp that can be changed to different situations. I designed base with various panels which can adapt to various style and occasion. You can simply change color of it as well as pattern on it, by changing color of diffuser and changing different panels.WARNINGSLed strips can emits some heat depends on what type of led you and voltage you use. In my case temperature of Main Ring achieve 60 °C . Due to this I recommend use filament that can resist that temperature especially for Main Ring. I tested ASA and it works well. Other high temperature filaments should work too (ABS, PETG but I didn&#39;t test it) PLA in this case can bend over time especially if you use heavy panel like budha.So in summary I tested and recommend :Main Ring - ASABase, Diffuser - PLAPanels- ASA ( PLA is possible but can bend )If you want change panel, always wait to cool down the ring lamp, otherwise PLA cover can bend during take off.&nbsp;Two Versions.There are two versions of Ring LampV1  - version 1 - First version of Ring Lamp. It is designed for 8 mm LED stripe.V2  - version 2 - Second version of Ring Lamp. It is larger and stronger. It is designed for both 8mm and 12 mm LED stripes. In V2 version the diffuser has a larger flange and fits better into the main ring. I enlarged each piece by 110% so it now better takes advantage of bed size of the Bambu Lab printers.In the meantime, some designers created their own fronts. If you want to use fronts from other designers, make sure they are the right size. If they are too small, simply enlarge them to 110% in the X and Y axis as in the image below.&nbsp;<figure class="image image_resized" style="width: 38.09%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-03-28_867e2b9fbfc93.png" width="519" height="278"></figure>&nbsp;Electric parts you need.The easiest way is to buy electrical parts designed specifically for a ring light. Provides easy installation without the need for soldering.It is available on Amazon <a target="_blank" href="https://amzn.to/3zAnd6c" rel="nofollow noopener">https://amzn.to/3zAnd6c</a>It works with V1 and V2. <figure class="image image_resized" style="width: 37.08%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-06-30_880ecf419c351.jpg" width="1500" height="1500"></figure>You can also buy only the LED Strip from Bambu Lab Store<a target="_blank" href="https://store.bambulab.com/collections/led-strip-light/products/white-cct-tunable-cob-led-strip-light?skr=yes" rel="nofollow noopener">https://store.bambulab.com/collections/led-strip-light/products/white-cct-tunable-cob-led-strip-light?skr=yes</a>It works only with larger V2&nbsp;<figure class="image image_resized" style="width: 30.92%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2024-06-30_4c071b0333c11.jpg" width="700" height="700"></figure>&nbsp;&nbsp;By purchasing the above products, you support my work&nbsp;&nbsp;Of course, you can also search for each part separately and solder it yourself. You will need<ul><li>led stripe - best are LED COB </li><li>charger for LED strip</li><li>dc connector - I used 2.1/5,5 mm , the diameter of the mounting hole is 11.5 mm</li></ul><figure class="image image_resized" style="width: 21.19%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/8867176f-a9e4-4554-8087-7b1fd3a6b430.webp" width="800" height="565"></figure><ul><li>OFF-ON SWITCH</li></ul><figure class="image image_resized" style="width: 18.17%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/5cf1687e-913a-4186-92f2-75d8d2bac909.png" width="330" height="403"></figure>&nbsp;Printed PartsMain Ring, Base and Panels can be printed in draft mode 0.28-0.30 mm layer height with no issue.Diffuser should be printed with 0.2 mm layer height.<ol><li>After print, glue led strip to inner side of Main Ring</li></ol><figure class="image image_resized" style="width: 539.361px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/55f0a8a9-5b68-4a7a-b60e-def1c0cf337a.webp"></figure>Start from hole on bottom side<figure class="image image_resized image-style-align-center" style="width: 537.429px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/8f453fdd-01d6-476e-baaa-f03826eac490.webp"></figure>2. Put Main Ring into base. It should fit tight without glue.<figure class="image image_resized image-style-align-center" style="width: 538.864px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/f03a229b-e68e-4835-9d5f-37f66a2677d0.webp"></figure>3. Insert the electric part into the base and connect them by soldering<figure class="image image_resized" style="width: 535.014px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/2e73757c-be70-46f0-8fbb-ebc700b2e62a.webp"></figure><figure class="image image_resized" style="width: 531.08px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/75ca1515-ddbf-47b2-ab0d-34d6c3b795b9.webp"></figure>4. Insert Diffuser to Main Ring”. The Main Ring has a groove into which the Diffuser should be inserted and sit steadily. The flat side to the back.<figure class="image image_resized" style="width: 529.148px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/dd5e9b3f-84e4-47dc-8964-6b93b4f6ee46.webp"></figure><figure class="image image_resized" style="width: 527.23px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/3fc14977-a473-4279-b0d1-25f667c08fba.webp"></figure>5. Insert Panel into Main ring. The Panel has cuts at the bottom to avoid cutting the cables<figure class="image image_resized" style="width: 531.08px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/f414f9b5-fc71-4e83-af57-faf01b92199e.webp"></figure><figure class="image image_resized" style="width: 529.148px"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000163227/design/d3004065-f61c-4175-b595-6235c7b8ead8.webp"></figure>&nbsp;If you any question or suggestion write to me&nbsp;Have fun
