fred2u

Boba Boy

xTool D1 Pro Honeycomb Guider.&nbsp;Two options for the pin,1. print the pins.2. Honeycomb Pins from Amazon (<a target="_blank" href="https://www.amazon.ca/gp/product/B0BX51BSP2" rel="nofollow noopener">https://www.amazon.ca/gp/product/B0BX51BSP2</a>) not an affiliate link

xTool Honeycomb Guider

Xtool M1

thrutheframe

<figure class="media"><oembed url="https://www.youtube.com/shorts/7O7hjxvXUPo"></oembed></figure><h3> </h3><h3>IMPORTANT</h3><ul><li>Please download the &#34;BentoBoxV2 2023XXXX.3mf&#34; project 3mf file and “BentoBox20 User Guide 2023XXXX.pdf” Descriptions, BOM and build instructions are in there. I try my level best to make it as comprehensive as possible.</li><li>Use only ACID-FREE activated carbon pellets.</li><li>I do my best to double-check and test the print profiles I created. Therefore, I will only take feedback and update for those profiles. I cannot vouch for profiles uploaded by others, so please do due diligence.</li><li>Please use the print profile that I upload. Print profiles created by others may not have the most updated parts.</li><li> </li></ul>UPDATE 8 APR 2024I believe in working with local small businesses when selecting regional vendors. Unlike established companies that are good at managing logistics and sales, small businesses or new start-ups are still learning the ropes, and sometimes make mistakes. Everyone makes mistakes, but it&#39;s important to make things right and work towards improvement. &nbsp;BentoBox V2 is now available with Australia vendor JC-3D. They have improved their ops &amp; logistics. There will also be no more pre-orders to prevent late fulfilment. &nbsp;&nbsp;UPDATE 16 FEB 2024The grills on the CMAG are slicer-generated. If you are using Bambu Slicer or Orca Slicer. click slice and the settings will generate the grill holes. If you are using Prusa Slicer, there is a version for Prusa Slicer in the download. If you are using Cura, please read the user manual for the slicer setting to produce the grill holes.&nbsp;&nbsp;<h3>VENDORS</h3>The US vendor for BentoBoxV2 is now available for sale. This is a collaboration between ThrutheFrame and Voxelpla to offer a complete set (printed in PET-g) with HEPA filter and acid-free activated carbon included. For more information, please visit <a target="_blank" href="https://voxelpla.com/products/bento-box" rel="nofollow noopener">Voxelpla Store</a><figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2024-05-10_0277a634c3772.png"></figure>&nbsp;The EU vendor for BentoBoxV2 is now available for sale. A partnership between ThrutheFrame and Veetec3D to offer a complete set (printed in PET-g Galaxy Black) with HEPA filter and acid-free activated carbon included. For more information please visit <a target="_blank" href="https://veetec3d.etsy.com/listing/1544593634/preorder-bentobox-filtration-system" rel="nofollow noopener">Veetec3D Store</a>.<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2024-04-08_1da06d6c23a7a.png"></figure>&nbsp;The AUS vendor for BentoBox V2 is available for sale on JC-3D. It is printed in PET-g and comes complete with HEPA filter and activated carbon as a kit. For more information please visit <a target="_blank" href="https://jc3dmelb.com.au/products/bento-box-v2" rel="nofollow noopener">JC-3D</a>.<figure class="image image_resized" style="width: 50.03%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2024-04-08_45e607e9e5419.png"></figure>&nbsp;<h4>Where to Buy Your Consumables:</h4>( links below are not affiliated unless stated)&nbsp;Acid-free activated carbon:US - Voxelpla offers acid-free activated carbon in a 1lb pack and HEPA filter replacement. You can support the BentoBox project by buying it from this affiliated link: <a target="_blank" href="https://voxelpla.com/thrutheframe" rel="nofollow noopener">https://voxelpla.com/thrutheframe</a>EU - Veetec3D offers acid-free activated carbon in 150gm &amp; 450gm. You can support the BentoBox project by buying it from Veetec3D Store for <a target="_blank" href="https://veetec3d.etsy.com/listing/1545297808/veetec3d-acid-free-activated-carbon" rel="nofollow noopener">Activated Carbon</a> and <a target="_blank" href="https://veetec3d.etsy.com/listing/1563529764/carbon-hepa-filter-refill-pack" rel="nofollow noopener">HEPA filter</a>.JPN<ul><li>「KOTOBUKI パウーバイオ」はテストしました、酸は含まれていません</li><li>This <a target="_blank" href="https://www.monotaro.com/p/2090/5517/" rel="nofollow noopener">seller</a> in Japan was recommended by a user it has a PH of 9.8.</li></ul>&nbsp;The HEPA filters:BentoBox uses the same HEPA filter as iLife vacuum robots. It is 80mmx40mmx15mm you can get it on <a target="_blank" href="https://www.amazon.com/Electropan-Filter-Replacement-Robotic-Cleaner/dp/B0782T7L6P" rel="nofollow noopener">Amazon</a> or <a target="_blank" href="https://www.aliexpress.com/item/1005002687133564.html?spm=a2g0o.store_pc_groupList.8148356.9.79237784J9PuMx&amp;pdp_npi=2%40dis%21SGD%21SG%24%205.57%21SG%24%201.35%21%21%21%21%21%40211b88f116797536610071881edc06%2112000025636802474%21sh" rel="nofollow noopener">Aliexpress</a>&nbsp;<h3>INTRODUCTION</h3>BentoBox is an air scrubber that sits inside the X1C or enclosed P1P. It removes VOCs and fumes in the air within the printer. Mainly used for printing ABS, ASA, Nylon, and other high VOCs filaments. If you are still unsure if you need an air scrubber, there are numerous write-ups and discussions online on which you can do due diligence.BentoBox can also be used for other printers. Voron, Vzbot, Enclosed Prusa or Ender 3, your hamster cage, etcBentoBox V2.0 can be run:<ol><li>standalone with a separate 5V power source (5V fans),</li><li>connect to the printer&#39;s 24V PSU (24V fans)</li><li>or piggyback on the chamber fan with a cable splitter. (24V fan)</li></ol>&nbsp;Please download the user guide for BOM and how to install BentoBox V2.0<figure class="image image_resized image-style-align-center" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/589fb0e7-05a1-47e7-aecb-d48a92a2af4f.png"></figure>&nbsp;I know some people may be disappointed that version 2.0 does not incorporate 5015 blower fans. Below is the reason why.Using either 5015 (push) or 4020 (pull) makes very little difference because both are relatively low-pressure fans. What makes a difference in performance is the unobstructed distance of the fan to the carbon pellets.I notice remixes of BentoBox where 5015 fans push air through the HEPA filter followed by the carbon pellets. If you imagine the blower fan is waves and the HEPA filter is the wave breaker on the beach. Once waves hit the breaker, a lot of initial force is lost. There will be very little air movement through the carbon pellets. On the other hand, BentoBox pulls air by creating a low-pressure system directly below the carbon pellets. In my opinion, it is a more efficient system.Do not use Noctua fans. It does not have enough static pressure to pull air through the carbon pellets. You can get the 4020 fans from Aliexpress here: <a target="_blank" href="https://www.aliexpress.com/item/32769608982.html?spm=a2g0o.store_pc_groupList.8148356.3.782a7e1f2o83nX&amp;pdp_npi=2%40dis%21SGD%21SG%24%2010.87%21SG%24%207.07%21%21%21%21%21%40210318bb16625658822601771e6ac5%2166639444053%21sh" rel="nofollow noopener">4020 24V GDSTime 9.0cfm 7000rpm</a>Redesigned the base (fan duct Voron_Trident.stl) to be used on my Voron Trident. It can fit both 250 and 300. Will require 2 sets of M3x8mm + M3 T-nut. Wire it to one of the pwm fan port and bam you have a HEPA and activated carbon filter. For Bambu Lab printers, please use “fan duct Bambulan.stl”. Everything else is the same.<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/3df84fcc-44b6-4698-9346-c339ea299385.png"></figure><figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/de68e9b0-f01b-45a9-8c25-2e8daa788775.png"></figure>&nbsp;<h4>Dimension of BentoBox V2</h4>There are requests for me to show the dimensions of BentoBox V2 to be able to visualise in different enclosures. They are H=215.6mm D=52.8mm L=112.8mm.<figure class="image image_resized" style="width: 50.02%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/c7bc644d-5627-4532-9c71-2cb0bb6ee013.png"></figure><figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/1470deea-cf1d-4944-9b56-32cb44c26252.png"></figure>&nbsp;<h4>BentoBox V2 in other printer Enclosures</h4>While the BentoBox was originally designed for Bambu Lab printers and subsequently Voron Trident, I hope to make it fit on most enclosed printers ie Creality K1 series, Qidi, Prusa Enclosure, etc. Hence, I will need the community&#39;s help as I will not be able to have access to all the different make and models. As always, BentoBox stl will be free for the community, with no club membership, no Patreons, no paid wall, etc.&nbsp;<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/42368a89-96f8-4238-9e3d-0ff0f4a5f2cb.png"></figure>BentoBoxV2 in a Snapmaker J1 <figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2023-08-27_227bd3ad86af3.jpg"></figure>BentoBoxV2 in a tent with a resin printer&nbsp;Some have requested I add a switch to the design. But there are so many different types and shapes of switches. Therefore, I have added the step file of the BentoBox fan_case_duct.step which you can edit to add a switch or mod it.<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/003d4110-7f18-4e69-88e3-a34b13b6dfea.png"></figure>&nbsp;I printed the design in PLA for a fitting test and then PETG for the final prototype. If you are using ABS or ASA, please print the test piece to check for dimension accuracy and if there is a need to do X and Y compensation. 14mmx36mmx10mm (LxBxH)<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/1d08706c-1972-4b37-8c51-e82cbb497ef0.png"></figure>&nbsp;&nbsp;<figure class="media"><oembed url="https://www.youtube.com/watch?v=xZiEzQH7WFQ"></oembed></figure>&nbsp;&nbsp;To date, my designs are free to download and use. There is no Patreon or OnlyFan (hahaha). If you like what I designed and want to contribute to my coffee addiction, software subscription and filaments I need for prototyping, a donation of $5-$10 to <a target="_blank" href="https://ko-fi.com/thrutheframe" rel="nofollow noopener">Ko-fi</a> or <a target="_blank" href="https://www.paypal.com/paypalme/shannonheng" rel="nofollow noopener">paypal.me</a> will be greatly appreciated.&nbsp;CaveatAs with all my designs, it may and may not work for you. So print and install at your discretion.<h3> </h3><h3> </h3>

BentoBox V2.0 Activated Carbon Filter

Creality K1 fan improvement

Gatto

One Piece - Monkey D. Luffy Chibi Figure&nbsp;From the popular manga and anime series, One Piece, comes this adorable chibi figure of the main character, Monkey D. Luffy! Our pirate who knows no fear is 7 cm tall but can be resized to your liking. No print supports are needed with these dimensions, but if you modify them, they may be necessary!  <a target="_blank" href="https://makerworld.com/en/@Gatto" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000428600/design/2024-04-15_4fefedc8921d9.gif"></a><figure class="image"><a href="https://makerworld.com/en/@Gatto" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000428600/design/2024-06-23_dbf03a232872e.jpg"></a></figure><a target="_blank" href="https://makerworld.com/en/@Gatto" rel="nofollow noopener">Check out my profile for other models and follow MEOW!</a>&nbsp;

Luffy Chibi Figure - ルフィ

Things to make

needitmakeit

**NOTE some printers may need a short back riser, I have included a shorter version which angles up slightly more to compensate, I recommend printing all parts at the same time and choosing the one that suits your printer.&nbsp;<figure class="media"><div data-oembed-url="https://youtu.be/XxNdunDD21k"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/XxNdunDD21k" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>&nbsp;If you want the best performance and the lowest noise from your K1, this is the way to do it.  This is simple, it looks good (Like nothing has been added) as long as you print from grey or black, and it gets the chain up higher and away from the head and motor shroud to give it the space it needs. The chain will still make contact with the inside of the top when printing towards that side, I also recommend using silicone weather stripping along that side on the inside of the top to stop that little bit of possible noise that's left. &nbsp;Will require:&nbsp;1 Pc - Thin walled PTFE @ 19mm Long (Head)1 Pc - M3 x 25mm Machine Screw (Head)1 Pc - M3 Washer (Head)2 Pcs - M3 x 10mm Machine Screws (Rear Riser)&nbsp;This print should be made from ABS or PC, PETG may work, but I don't recommend it.&nbsp;PRINT SETTINGS<ul><li>Layer Height - 0.16</li><li>Walls - 5</li><li>Infill - Gyroid 35%</li><li>Btms - 4</li><li>Tops - 4</li><li>Cooling - Full (All Fans)</li></ul>Print slower or with more parts, these are small parts and cooling can be a problem.&nbsp;ENJOY!
