folkconsulting

kriswillcode

<p>After seeing many people&#39;s problems with my <a target="_blank" href="https://makerworld.com/en/models/66672" rel="nofollow noopener">previous fidget switch&#39;</a>s spring, I decided to create a new variant that allows you to adjust the spring&#39;s tension whenever you want. Some days you may want a soft, tactile click; other days you may want a loud, snappy click - this fidget does both! And it even has a more ergonomic form factor!</p><p>&nbsp;</p><p>This little switch consists of just eight parts! And, just like my previous switch, you&#39;ll need to print two of some parts. The body of the switch also has two options, because who doesn&#39;t like choices?</p><p>&nbsp;</p><p>If you&#39;re looking for a fidget switch that has fewer parts, prints quicker, and uses less filament, check out my <a target="_blank" href="https://makerworld.com/en/models/467451" rel="nofollow noopener">Print-in-Place Fidget Toggle Switch</a>.</p><p>&nbsp;</p><blockquote><p><strong>⚠ Heads up, hot shot!</strong></p><p>This is a tricky print. This print has a few small pieces that don&#39;t work with brims. These have limited bed contact, so you&#39;ll need nearly perfect bed adhesion. Because of the small tolerances in this print, your flow rate must also be perfect. Finally, if your printer has any noticeable elephant&#39;s foot, then forget about printing this.</p></blockquote><h4> </h4><h4>Settings</h4><ul><li>Designed for a 0.4mm nozzle</li><li>0.16mm or 0.2mm layer height</li><li>3 walls</li><li>≥5 top/bottom layers</li><li>20% infill (but more <i>feels</i> better)</li><li>Slice with Arachne if available</li></ul><p>All files should be in the correct orientation to print. Supports are not required, but a brim will help when printing the pegs. I do not recommend using a brim on the springs as it&#39;s difficult to remove and any brim remnants will interfere with the action of the switch.</p><p>&nbsp;</p><h4>What to Print</h4><figure class="table"><table><thead><tr><th>Part</th><th>Qty</th><th>Notes</th></tr></thead><tbody><tr><td>Body</td><td>2</td><td>There&#39;s two options: smooth or grip; print two of the same option</td></tr><tr><td>Peg</td><td>2</td><td>A brim helps here!</td></tr><tr><td>Spring</td><td>2</td><td>Don&#39;t use a brim on these!</td></tr><tr><td>Toggle</td><td>1</td><td> </td></tr><tr><td>Slider</td><td>1</td><td>A lower layer height is preferred here: 0.16mm or 0.12mm</td></tr></tbody></table></figure><p>&nbsp;</p><h4>Assembly</h4><p>The last 7 photos demonstrate the assembly process.</p><ol><li>Test your prints: Place the slider between the two body halves and verify the slider can slide freely. Then, place a peg in the toggle and verify the toggle can rotate freely.</li><li>Insert both pegs into one side of the body. These will be extremely tight (that&#39;s intentional!!!). If the pegs absolutely won&#39;t fit, you might need to reprint them with the X and Y scale reduced by 0.2 to 0.4% (99.8 to 99.6%).</li><li>Place the springs into the slider and check the orientation: the &#34;arms&#34; of the springs should point towards each other, and the &#34;bump&#34; on the slider should point towards the arms.</li><li>Move the slider towards the rounded ends of the springs and carefully press the springs into the body half from step 2. The springs should be parallel with the bottom of the body.</li><li>Move the slider away from the rounded ends and slip the toggle on the peg. Use a finger to separate the springs for easy placement.</li><li>Check the motion of the slider and the toggle. If everything looks good, place the other half of the body on top and press the two body halves together. Be sure the springs are properly aligned into their respective slots.</li><li>You&#39;re done! Flick away!</li></ol><h4> </h4><h4>Protips</h4><ul><li>This switch is not designed to be disassembled, so good luck with that.</li><li>A drop of lube between the toggle and the peg works great depending on your filament(s).</li><li>A small amount of beeswax applied to the outside of the springs helps if you find the slider difficult to move. <i>But</i>, the slider may shift during some intense switch flipping.</li><li>The pegs require some force to properly insert, but they have to hold the switch together. No other part (e.g. the springs) should require any significant force.</li><li>If you&#39;re rocking an AMS, use &#34;Others &gt; Print sequence &gt; By object&#34; to quickly print all parts on one build plate while using different filaments!</li></ul><p>&nbsp;</p><p>If you print one of these switches, please post a make: I love seeing all of your creative color combinations!</p>

Adjustable Fidget Toggle Switch

Stuff

MakerJoe

<p>Simple and easy AMS Helper System. The design attachs directly to the first stage feeders filament intake.</p><p>&nbsp;</p><p><strong>Before you print:</strong></p><ul><li>I´ve got feedback, that the size of the first stage feeder port varrys. If you have the larger Port than you should use the print profile for the larger one. (Larger means 3,1mm in height instead of 3mm)</li></ul><p><strong>Advantages </strong>(i have noticed)<strong>:</strong></p><ul><li>No wear out of the grey filament intake port of the first stage feeder</li><li>Fixed filament retraction problem where the filament gets all over the AMS</li><li>Reduced horizontal stress on the first stage feeder</li><li>Fixed spool hopping when filament gets low</li></ul><p><strong>Assembly:</strong></p><ul><li>Just stick a PTFE tube into the clip and slide it on the first stage feeder.</li><li>Optional put a bit of glue in the hole before sticking the ptfe tube in to prevent slipping out</li></ul><p><strong>Notes:</strong></p><ul><li>I use 9cm long PTFE tubes. Maybe the optimal length is different… (Update 18.2: Trying 9cm tubes instead of 13 cm)</li><li>This helper should also work with the Hydra AMS System</li><li>Check also out my PTFE Tube Protector: <a target="_blank" href="https://makerworld.com/en/models/234268#profileId-250844" rel="nofollow noopener">https://makerworld.com/en/models/234268</a></li></ul><p><strong>Installation on the AMS:</strong></p><ul><li>Here you can see how to install the EZ AMS Helper on the AMS. Just slide it on, <u>don´t</u> try to mount it from the top.</li></ul><p><img src="https://makerworld.bblmw.com/makerworld/draft/834356/2024-01-03_a8f165557c9eb.gif"></p>

Stuff

Tools
