<h3>OpenSCAD project to create vacuum hose connectors.</h3>Intended for generating connections that would allow connecting vacuum hoses and tools of different diameters together.Parametric settings support a few connections types. The connections types can be used on ether end of the adapter.&nbsp;The project is actively maintained by myself. Please submit bugs and suggestions at the GitHub repo. <a target="_blank" href="https://github.com/ostat/vacuum-hose-adapter-openscad" rel="nofollow noopener">ostat/vacuum-hose-adapter-openscad</a>.<h2><img class="image_resized" style="width: 38.95%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/009a8b5b-07b6-4bf0-8809-e2ad229be092.gif"></h2>&nbsp;Connector types<figure class="table" style="width: 100%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td> Hose connector  The hose connector is the most generic connector. Its intended to be pushed inside a hose or over an existing connector. We can enable a stop to prevent the adapter being pulled in to the hose, and barbs for soft style pipe.  Options<ul><li>Length<ul><li>The length of the connection end</li></ul></li><li>Diameter<ul><li>Internal or external diameter of the intended connector.</li></ul></li><li>Taper<ul><li> Tapered to allow for a tight push fit</li></ul></li><li>Barbs</li><li>Stop</li></ul>Official Documentation <a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/hose" rel="nofollow noopener">docs.ostat.com/docs/openscad/hose-adapter/connectors/hose</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_ed350451c1e9a.gif"></figure></td></tr><tr><td>NozzleA configurable nozzleOptions<ul><li>Nozzle Shape<ul><li>square: a square tip, where you can control the width and depth of the tip, and the corner radius</li><li>circle: A round tip, where you can control the radius.</li></ul></li><li>Nozzle_Size<ul><li>Size of the nozzle tip, in the format of [width, depth, length]</li></ul></li><li>Wall Thickness</li><li>Nozzle_Radius   </li><li>Nozzle_Offset    </li><li>Nozzle_Chamfer_Percentage     </li><li>Nozzle_Chamfer_Angle</li></ul>Official Documentation<a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/nozzle" rel="nofollow noopener">docs.ostat.com/docs/openscad/hose-adapter/connectors/nozzle</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_470047bc1b6da8.gif"></figure></td></tr><tr><td>FlangeCustomisable flange for attaching to boxes or wall.&nbsp;Options<ul><li>Flange_Width     <ul><li>Width of Flange added to the connector diameter</li></ul></li><li>Flange_Thickness  <ul><li>Thickness of the flange</li></ul></li><li>Flange_Screw_Position <ul><li>Position of the screws added to the connector diameter</li></ul></li><li>Flange_Screw_Border     <ul><li>Minimum amount of the material around the screws</li></ul></li><li>Flange_Screw_Count     <ul><li>Number of Screw holes flange</li></ul></li><li>Flange_Screw_Diameter</li></ul>Official Documentation<a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/flange" rel="nofollow noopener">docs.ostat.com/docs/openscad/hose-adapter/connectors/flange</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_3772a84429e99.gif"></figure></td></tr><tr><td>Magnetic flange connectionIntended for creating a quick removable connection. Allowing the hose to be quickly moved form device to device. The magnets should be slightly recessed so that the two faces get a good seal, allow extra depth if you want to avoid supports.  Main setting:<ul><li>Flange diameter: Internal diameter of the flange connection.</li><li>Flange thickness: The overall thickness of the flange. Magnet thickness plus 4mm seem to work well.</li><li>Connector length: The length of the connector before the tapered section will start.</li><li>Magnet count: Number of magnets to be added to the flange.</li><li>Magnet diameter: Diameter of the magnets (add 0.5 to measurement).</li><li>Magnet border: The amount material around the magnet.</li><li>Magnet thickness: Thickness of the magnets (add 0.5 to measurement, 1.0 to avoid supports).</li><li>lip: If an alignment ring should be supported, can be recessed or protruding, suggest recessed.</li></ul></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_32584b3954dc8.gif"></figure></td></tr><tr><td>Fixed connectorsConnectors that are not configurable as they are designed to be compatible with an existing connector type.&nbsp;Options<ul><li>Dyson V6 connector<ul><li>Compatible with Dyson V6 vacuums. </li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/dyson" rel="nofollow noopener">Doco</a></li></ul></li><li>CAMLOCK connector<ul><li>Compatible with PeterH&#39;s </li><li><a target="_blank" href="https://www.printables.com/model/461256-shopvac-50mm-camlock-connectors-with-magnetic-catc" rel="nofollow noopener">camlock connectors</a> <a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connector/camlock" rel="nofollow noopener">Doco</a></li></ul></li><li>Dewalt DW735x<ul><li>Dewalt DW735 Planer </li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/dw735" rel="nofollow noopener">Doco</a></li></ul></li><li>Cen-Tec quick connect <ul><li>Cen-Tec Female</li><li>Cen-Tec Male</li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/centec" rel="nofollow noopener">Doco</a></li></ul></li><li>Makita quick connect<ul><li>Makita quick connect compatible (not tested)</li></ul></li><li>osVAC<ul><li>osVAC M32<ul><li>Male connector compatible with Original osVAC</li></ul></li><li>osVAC Male<ul><li>Male connector compatible with Original osVACneo, support variable diameter</li></ul></li><li>osVAC F32<ul><li>Female connector compatible with Original osVAC</li></ul></li><li>osVAC Female<ul><li>Female connector compatible with Original osVACneo, support variable diameter</li></ul></li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/osvac" rel="nofollow noopener">Doco</a></li></ul></li></ul></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-03_fc82126a83115.gif"></figure></td></tr></tbody></table></figure>&nbsp;TransitionsUsing the above listed connectors we have a few options of how to transition between the end1 and end2.<figure class="table" style="width: 100%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td>Options<ul><li>Transition_Style<ul><li> taper+bend: Taper then bend</li><li>bend+taper: Bend then taper</li><li>organicbend: fully tapered bend</li><li>hull: Hull for multiple end count</li><li>flat: basic flat transition.</li></ul></li><li>Transition_End2_Count<ul><li>one to many adapter</li></ul></li></ul>&nbsp;There are many other options available,Official Documentation<a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/transition" rel="nofollow noopener">https://docs.ostat.com/docs/openscad/hose-adapter/transition</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-02_d89390625a92a8.gif"></figure></td></tr><tr><td>Support for three unique connectors&nbsp;Updated 2024 to add support for an adapter with three different connectors.When using the Hull transition. You have the option to add a center adapter. This third adapter can be, end1, end2 or end3. (previously it could only be end2)<ul><li>pink, end1</li><li>blue, end2, you can adjust the angle and count.</li><li>purple, can be end1, end2 or end3</li></ul>  &nbsp;&nbsp;</td><td><figure class="image image_resized" style="width: 97.2%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-06_602056cb886a38.png"></figure></td></tr></tbody></table></figure>  Related models, for pre-generated adapters. <a target="_blank" href="https://www.printables.com/social/210306-max/collections/357939" rel="nofollow noopener">Hose Fittings collection</a><ul><li><a target="_blank" href="https://www.printables.com/model/316283" rel="nofollow noopener">Vacuum nozzles for all common hose sizes</a></li><li><a target="_blank" href="https://www.printables.com/model/297912" rel="nofollow noopener">Vacuum hose flanges to connect to flat surfaces</a></li><li><a target="_blank" href="https://www.printables.com/model/303766" rel="nofollow noopener">Dyson V6 hose attachments</a></li><li>Vacuum hose adapters<ul><li><a target="_blank" href="https://www.printables.com/model/283238" rel="nofollow noopener">Straight hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/325999" rel="nofollow noopener">Y connector / splitter for all common sizes</a></li><li><a target="_blank" href="https://www.printables.com/model/284701" rel="nofollow noopener">30° elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284834" rel="nofollow noopener">30° tapered elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284846" rel="nofollow noopener">45° elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284877" rel="nofollow noopener">45° tapered elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284879/" rel="nofollow noopener">90° elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284929" rel="nofollow noopener">90° tapered elbow hose adapters</a></li></ul></li><li>Magnetic Hose connectors<ul><li><a target="_blank" href="https://www.printables.com/model/283250" rel="nofollow noopener">50mm magnetic hose connectors</a></li><li><a target="_blank" href="https://www.printables.com/model/283255" rel="nofollow noopener">100mm magnetic hose connectors</a></li></ul></li><li>Barbed tube connectors<ul><li><a target="_blank" href="https://www.printables.com/model/328572" rel="nofollow noopener">Tube Fittings 4mm-24mm</a></li><li><a target="_blank" href="https://www.printables.com/model/328599" rel="nofollow noopener">Vacuum hose to tubing adapters for all common sizes</a></li><li><a target="_blank" href="https://www.printables.com/model/328572" rel="nofollow noopener">Tube Y connector / splitter fittings 4mm-24mm</a></li></ul></li></ul>
