E0516实验室

p4800x

cw cww适应不同出风方向，侧面有空位固定转接板，用m3远投螺丝固定

4090改12cm散热风扇框

其他

Watkins

Supports minimum volume of 10cmx10cm smt steel meshBOM：<ul><li>8x M3x4x4.2mm Heat Insert Nut (M3 thread with 4.2mm outer diameter, 4mm length)</li></ul> <img src="https://media.printables.com/media/prints/741194/rich_content/a58d3865-7d2e-46c7-81f2-533326ae58eb/thumbs/cover/800x476/png/qqjie-tu-20240129194406.webp"><ul><li>8X M3X5mm Phillips countersunk screws</li></ul> <img src="https://media.printables.com/media/prints/741194/rich_content/a1e82756-7e98-4a09-ab13-d641ea72f922/qqjie-tu-20240128151344.png"><ul><li>2X Hinge </li></ul> <img src="https://media.printables.com/media/prints/741194/rich_content/2c484390-e733-41e0-8c88-e7d81f088185/thumbs/cover/800x524/png/qqjie-tu-20240128152729.webp">&nbsp;<ul><li>3X M4X16mm Hand screws</li></ul> <img src="https://media.printables.com/media/prints/741194/rich_content/d087ba4b-459c-46dd-bed1-30f757c5c7b4/qqjie-tu-20240128153600.png">&nbsp;<ul><li>7X M4 Nut</li></ul> <img src="https://media.printables.com/media/prints/741194/rich_content/0793a118-9e4c-4bc2-bc41-86f7836e4567/thumbs/cover/800x258/jpg/m4luo-mu-7ge.webp"><ul><li>4X M4X15mm Phillips Pan Head Screws</li></ul> <img src="https://media.printables.com/media/prints/741194/rich_content/3ca6733b-d881-44e3-ad6b-071ea4e61003/thumbs/cover/800x798/png/qqjie-tu-20240128155209.webp">&nbsp;&nbsp;&nbsp;Printing Tips：<ul><li>If you print with AMS, you need at least 5 layers on top of the four sliders</li><li>Four of the weaker parts of the base needed to be strengthened. In the 3mf file I provided, I used the modifier and increased the fill to 60%</li></ul> <img src="https://makerworld.bblmw.com/makerworld/draft/561763/2024-02-21_dba4ebc71f4a6.png">&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/561763/2024-02-21_74cb771efe4d7.png"></figure>&nbsp;Gdemon X Watkins

SMT Solder Paste Stencil Printer 钢网夹具

焊接工具

19evdominta3

First off, thank you to <a target="_blank" href="https://makerworld.com/en/models/123024#profileId-132528" rel="nofollow noopener">https://makerworld.com/en/models/123024#profileId-132528</a> for the inspiration behind this model. I wanted to support both the hotend cable as well as the tube for the external spool and keep it from rubbing where it should not be rubbing. In addition I wanted the entry point for the cables to be at the back (just enough to get in without popping out), add height for a smoother path for both cable/tube while adding as much strength as possible with sizing as well as with unobtrusive chamfers/rounding. Hopefully this means no snapping where it shouldn't.&nbsp;Printing profile: The profile is setup by default for the A1 mini, by just changing the printer (as we normally do to A1/P1/X1 from supplied profiles) and transferring the settings makes it workable on whatever you printer you have idel. I've printed on both my X1C and A1 mini with these changes while going through the various iterations of the model. NOTE: In addition to the stl file, I've also included my original OpenSCAD model should you wish to make changes (for this you need BOSL2)

其他

焊接工具

打印工具
