dean1969cox

pixelwave

For a boat installation I created a custom electrical box to have one central place for all wiring, relays, smart LED controllers as well as switches.This is a work in progress so expect updates soon.The box has a magnetic lid and a custom Wago rail system to mount different configurations (3x or 5x 221 Series) in a slight angle to preserve space. It als features an additional lower modular part fitted with M3 nuts to mount custom hardware like controllers, relays, etc …On each side (L/R) there are 4x M16 mounting holes with custom caps for sealing. On the bottom are 3x M12 mounting holes.The rear has 4x M5 Threads for mounting.Printed Parts:<ul><li>1x Box Base</li><li>1x Box Lid</li><li>2x Box Lid Handle</li><li>8x M16 Caps (Screw & NutCaps) - optional</li><li>3x M12 Caps (Screw & NutCaps) - optional</li><li>6x Wago Clamp Holder</li></ul>Sourced Parts:<ul><li>13x M3 Melting Nuts</li><li>4x M2 Melt-In-Nuts</li><li>4x M5 Melt-In-Nuts</li><li>4x M5x10 Hex Screw</li><li>4x M3x6 Flat Head Screw</li><li>4x M2x6 Hex Screw</li><li>8x 12x2.5 Magnets (https://de.aliexpress.com/item/1005001627825816.html?spm=a2g0o.order_detail.0.0.291d6368zpX5w3&gatewayAdapt=glo2deu)</li></ul>&nbsp;-------- UPDATES --------&nbsp;09.12.2023<ul><li>“L” Box Size → added a larger box version (+20mm larger in height)</li><li>O-Ring Seal → added a seal indent around the lid (2mm rubber tube seal)</li><li>Rear Mounting → added additional rear mounting holes</li></ul>&nbsp;10.09.2022<ul><li>Box Lid → revised design with fewer parts / single print</li><li>Wall Mount → added 2 bars to wall mount the box while being detachable</li></ul>17.08.2022<ul><li>M16 Nut_8x → offset inner thread diameter for better fit</li><li>M12 Nut_3x → offset inner thread diameter for better fit</li></ul>_______If you like my uploads buy me a coffee -> <a target="_blank" href="https://bit.ly/pwave-donate" rel="nofollow noopener">https://bit.ly/pwave-donate</a>

Electrical Junction Box for Wago Clamps with Modular Mounts and Magnetic Lid

print room electrics

Dingus Dude

To be sure you're always downloading the most up to date file, use my “DD” profiles. See changelog below for detailed updates.&nbsp;BetterBoxPrint In Place Double Storage Customizable Divider Parts BoxNot just for Bambu Lab parts! Makes a great jewelry box, too!&nbsp;This is another version of my Print In Place Hinged Box and part of my BetterBox series!Check out the rest of the lineup below to find the ones that fit your needs!<figure class="table" style="float:left;width:35%;"><table class="ck-table-resized" style="border:2px solid hsl(0, 0%, 100%);"><colgroup><col></colgroup><tbody><tr><td><figure class="image"><a href="https://makerworld.com/en/models/45645#profileId-47422" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/377353/2023-10-28_e2af4207409738.jpg"></a></figure></td></tr><tr><td style="border:2px solid hsl(0, 0%, 100%);"><a target="_blank" href="https://makerworld.com/en/models/22697#profileId-20609" rel="nofollow noopener">BetterBox</a> <a target="_blank" href="https://makerworld.com/en/models/45645#profileId-47422" rel="nofollow noopener">Customizable Dividers</a></td></tr><tr><td><figure class="image"><a href="https://makerworld.com/en/models/22697#profileId-20609" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/377353/2023-10-27_f53e9d31a992f8.jpg"></a></figure></td></tr><tr><td style="border:2px solid hsl(0, 0%, 100%);"><a target="_blank" href="https://makerworld.com/en/models/22697#profileId-20609" rel="nofollow noopener">BetterBox</a> <a target="_blank" href="https://makerworld.com/en/models/22697#profileId-20609" rel="nofollow noopener">Original Bambu Parts Box</a></td></tr><tr><td><figure class="image"><a href="https://makerworld.com/en/models/45918#profileId-47727" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/377353/2023-10-27_50d65c4b44a158.jpg"></a></figure></td></tr><tr><td style="border:2px solid hsl(0, 0%, 100%);"><a target="_blank" href="https://makerworld.com/en/models/22697#profileId-20609" rel="nofollow noopener">BetterBox</a> <a target="_blank" href="https://makerworld.com/en/models/45918#profileId-47727" rel="nofollow noopener">Empty Storage Box</a></td></tr></tbody></table></figure>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;-Now back to the box that you came here for-&nbsp;FEATURES:&nbsp;Print In Place Hinged Box&nbsp;Compartments:<ul><li>Fully customizable! Use all the included dividers or print any of the ones you want plus more. Whatever you want to store, this box can accommodate. Please share how yours is arranged! There are litterally HUNDREDS of variations! Mix and match divider colors to help organize!</li></ul>Flip Top Lid:<ul><li>Allows for double the storage! The Flip Top prints on a separate plate and is super easy to install. When the Flip Top snaps closed it sits tight to the top dividers so even the tiniest screws won't fall out or move to another compartment! In short, your parts STAY where you put them!</li></ul>&nbsp;Flip Top Installation:<figure class="table" style="float:left;width:50%;"><table style="border:2px solid hsl(0, 0%, 100%);"><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/377353/2023-10-31_5a34a1d06579c.gif"></figure></td></tr><tr><td style="border:2px solid hsl(0, 0%, 100%);"> </td></tr></tbody></table></figure>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;Box Dimensions175mm length107mm width (not including hinge and latch)61mm height (closed)&nbsp;&nbsp;&nbsp;Of course it's not necessary but if you want to add to my <a target="_blank" href="https://paypal.me/davebarbier?country.x=US&locale.x=en_US" rel="nofollow noopener">beer fund</a> it would be much appreciated! 😄&nbsp;

BetterBox - Flip Top Storage Box

blabs stuff

Many24

Collection of all parts needed to make a drybox out of the famous <a href="https://www.ikea.com/cz/cs/p/samla-krabice-s-vikem-transparentni-s69440822/" rel="nofollow">IKEA SAMLA</a><h4>This collection contains:</h4><ul><li>Pneumatic air fitting holder</li><li>Magnetic box for silica gel </li><li>PTFE tube plug</li><li>Cover clips - made by <a href="https://www.thingiverse.com/thing:2110134" rel="nofollow">Wookbert</a></li><li>PVC pipe mount with outside filament holder - made by <a href="https://www.thingiverse.com/thing:743280" rel="nofollow">wstein</a></li></ul><h4>Hardware required:</h4><ul><li>Pneumatic air fitting - PC4-01</li><li>M4x10mm bolts</li><li>M4 nuts</li><li>6x3mm magnets</li><li>32mm PVC pipe</li><li>4/2mm PTFE tube</li><li>Silica gel</li><li>Humidity sensor (optional)</li><li>Seal for cover (optional)</li><li>and of course IKEA SAMLA box</li></ul>

IKEA SAMLA Drybox set with magnetic silica holder

dry boxes

holonda3d

I have designed these holders for my Wera bags and have the option of storing them on a Skadis wall and having them ready to use.Thera are two versions, 2 and 3,look at the pictures and STL Models.

Wera Ikea Skadis Bag Holders

Ikea Skadis

race85com

Easy to load & unload!3 sizes including Standard, Large, Extra Large<ul><li>only 3.3 grams of material needed</li><li>will hold even thicker 230V/110V cables, LAN cables,…</li><li>designed to act as a spring when fed fully :)</li></ul>Printing instructions:<ul><li>print on its side, no brim, no supports</li><li>use maximum layer height - pictured is 0.32mm @ 0.4mm nozzle</li><li>use 4 perimeters</li></ul>Version history:v1.1 17.10.2023<ul><li>added 2 more sizes:<ul><li>L (scaled 125%)</li><li>XL (scaled 150%)</li></ul></li></ul>v1.0 4.10.2023<ul><li>initial release</li></ul>

Cable Clip - Yet Another Cable Organizer Holder

cable stuff

TechnoLab

Charging station for Apple watch / Airpods / Iphone. Easily printable after plugging all the cable, easily snap the bottom cover.

Apple dock station

Phone Stuff

PhaseworksCA
