AU3D

<p>Parametric Skadis board generators are commonly available, but they typically require the installation of CAD software and a fundamental understanding of how to use it. Fortunately, for those who prefer not to engage with CAD, I have good news. Presenting 99 different designs of IKEA Skadis pegboards, these variants all fit on the build plate of your A1, P1P, P1S, and X1. To enhance user convenience, I&#39;ve organized the files based on the number of columns, creating separate print profiles for each. This categorization allows for more straightforward and intuitive navigation.</p><p>&nbsp;</p><h3>Wall Mounting</h3><p>You can use my <a target="_blank" href="https://makerworld.com/en/models/420877" rel="nofollow noopener">IKEA Skadis Wall Mount</a> set<span style="background-color:rgb(255,255,255);color:rgb(13,13,13);font-size:16px;">, designed for seamless mounting of the board to a wall or any wooden surface. This set accommodates M4 screws and comes in two distinct sizes for your convenience: 10mm and 20mm. Opt for the 20mm variant to ensure compatibility with the Skadis board&#39;s original mounting mechanism, although it&#39;s worth noting that this much space isn&#39;t necessary. For most installations, a pair of screws at the top suffices, but you have the option to secure all four corners for added stability. </span>Alternatively, <span style="background-color:rgb(255,255,255);color:rgb(13,13,13);font-size:16px;">consider employing</span> <a target="_blank" href="https://makerworld.com/en/models/421676" rel="nofollow noopener">Screwless Support Feet</a> <span style="background-color:rgb(255,255,255);color:rgb(13,13,13);font-size:16px;">designed for the lower half of the board</span>.</p><h3>Skadis Collection</h3><p>I am constantly developing more IKEA Skadis attachments. Check out my</p><ul><li><a target="_blank" href="https://makerworld.com/en/u/2942852598/collections/453266" rel="nofollow noopener"><strong><u>IKEA Skadis Shelves, Trays and Container Collection</u></strong></a></li><li><a target="_blank" href="https://makerworld.com/en/u/2942852598/collections/188108" rel="nofollow noopener"><strong><u>General IKEA Skadis Collection</u></strong></a></li><li><a target="_blank" href="https://makerworld.com/en/@AU3D/collections/1044616" rel="nofollow noopener"><strong><u>IKEA SKADIS Boards Collection</u></strong></a></li></ul>

IKEA Skadis

Skadis

ochiburi

<p>If you have to remove any 608 bearing from a tight spot, and you cannot simply push it through from the other side, this tool will help. It generates an even all round pull, and as long as its not too tight, the tool will do the job. (Remember its printed in PLA, so if your bearing is absolutely jammed in it may break the plastic)</p><p>&nbsp;</p><p>There are 3 parts that can print on the same plate. I used the .2mm STRENGTH print profile, with auto tree supports (that only generate for one of the parts). If you use my profile, the tree supports are optimised for easier and cleaner removal.</p><p>&nbsp;</p><p>The parts have some tight tolerances but print fine on my Bambu P1S. I have included the step and F360 files in case you want to adapt it. The F360 file is parameter driven for the main dimensions.</p><p>&nbsp;</p><p><strong>How to use it</strong></p><ol><li>Screw the pronged part into the hub so it looks like the pic below. Screw it gently all the way down.</li><li>Gently squeeze the tips of the prongs together and push into the hub of the bearing to be removed. See video below. The first time might be tough as the tolerances are tight, but it will go through - in subsequent uses it will get easier as the fine edges of the prongs wear off. Practice this on a bearing that is not the one you want to pull. </li><li>Carefully insert the pin through the hole in the pronged part (again it will be a tight fit as the edges smooth down, be careful as the pin is VERY DELICATE.</li><li>Once the pin is pushed home, the prongs are locked open and cannot close until the pin is removed.  Gently unscrew the pronged mechanism from the hub. It will pull the bearing from its home.</li><li>Remove the pin.</li><li>Remove the bearing from the prongs and you are done!</li></ol><figure class="media"><div data-oembed-url="https://youtu.be/mWJhrJkPPC0"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/mWJhrJkPPC0" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>

608 Blind Bearing Puller

Tools

Jendapce

<p>Ferrari F1 logo coaster, shopping basket token (removable)</p><p>&nbsp;</p><p>A simple quick and easy printable coaster for FERRARI fans</p><p>&nbsp;</p><p>Easy and fast multi-color FERRARI coaster printing</p><p>&nbsp;</p><p>In color printing, I recommend printing the logo on the mat for a better effect and connecting the layers.</p><p>&nbsp;</p><p>I also have a version for monochrome printing without AMS</p><p>&nbsp;</p><p>Here you can use the coaster holder for 8 pcs with the F1 logo<br><a target="_blank" href="https://makerworld.com/en/models/189754#profileId-209329" rel="nofollow noopener">https://makerworld.com/en/models/189754#profileId-209329</a></p><p>&nbsp;</p><p>Keychain with logo for shopping cart. Unlock the cart and you can take out the key fob</p><p>&nbsp;</p><p>&nbsp;</p><p>Forza FERRARI!!!</p><p>&nbsp;</p><p>Look my Phone stand FERRARI</p><p>&nbsp;</p><p><a target="_blank" href="https://makerworld.com/en/models/200778#profileId-221134" rel="nofollow noopener">https://makerworld.com/en/models/200778#profileId-221134</a></p><p>&nbsp;</p>

FERRARI F1 coaster, keychain, color AMS

Cool Stuff

benlevi

<h2>BLV - AMS Riser for X1C V3.1 Final</h2><figure class="table"><table><tbody><tr><td style="background-color: hsl(0, 0%, 30%)"><h3><span style="color: hsl(0,0%,100%)">Introduction</span></h3></td></tr><tr><td><p>I&#39;m Ben Levi, and I want to talk to you about this BLV AMS Riser that I designed:<br>So, when the AMS is sitting on top of the printer, you can&#39;t really see what the printer is doing, and you can&#39;t even open the top glass cover to let some air in when you&#39;re printing High temp stuff. basically, something that will hold the AMS and free your Glass top cover will be a good solution for that. Now I&#39;ve seen some similar AMS risers before, but none of them really wowed me.. i think..</p><p>That&#39;s why I decided to come up with this sleek BLV AMS Riser design, easy to use, easy to put together, and reliable. I even added two handy drawers for your tools and stuff, a special shelf that can hold up to 4pcs Build Plates, built-in Dual LED strips. Sure, it took me a while, but I got it (almost..) done.</p><p>As some of you may know, I love contributing to this wonderful community, which is why I chose to share with you my project without any fee or money. Among other things, I&#39;ve also given you access to the original CAD files (F3D,STEP) so that you can easily make changes, add, and improve as you see fit. Please, if you publish a remix, make sure to link it to the original project as a remix so that others can benefit from your effort. I kindly request not to use the files for commercial purposes without explicit permission from me.</p><p>&nbsp;</p><p>Thanks,<br><strong>Ben Levi</strong></p><p><a target="_blank" href="https://www.paypal.com/paypalme/BenBLV" rel="nofollow noopener">If you want, buy me a beer </a>:)</p><p>&nbsp;</p></td></tr></tbody></table></figure><figure class="image image_resized" style="width: 58.95%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-09-25_370cc55ef0c1d.png"></figure><h2>Main features</h2><p>These are just a few design features I&#39;ve planned. If you have more ideas, please share them with me, and I can incorporate them into the design. Also, feel free to add remixes (CAD files are available for download).</p><ul><li>Easy installation</li><li>Dual LED strip<br>installed in optimal angle for LiDAR.</li><li>AMS riser</li><li>Top glass Holder</li><li>2 drawers for tools (with version for tools)</li><li>4 x Build Plates holder</li><li>Rubber Gasket for the glass</li><li>Customised Panels</li><li>access to original buttons</li><li>No screws required</li><li>CAD files available (F3D,STEP)</li></ul><figure class="table"><table><tbody><tr><td><p>&nbsp;</p><figure class="image image_resized" style="width: 92.39%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_18d41f48cf37f.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_a237ff37d0da5.png"></figure></td></tr></tbody></table></figure><h2> </h2><h2>How to print and where to begin?</h2><p>I must admit, if you&#39;re in search of a quick two-hour print and you&#39;re finished, this may not be the right place for it. To initiate and successfully complete this project, a considerable amount of filament and time investment is necessary. Here are the essential resources you&#39;ll be required to invest:</p><figure class="table" style="width: 70.13%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td><p style="text-align: center"><strong>Printing Time</strong></p></td><td>70~85 print hours - including color switching!</td></tr><tr><td><p style="text-align: center"><strong>Printer</strong></p></td><td>X1 Carbon, P1S, P1P, X1 or Other + AMS (Optional).</td></tr><tr><td><p style="text-align: center"><strong>Filament</strong></p></td><td><ul><li>2 kg - PLA/PETG Main filament color (GREY)</li><li>0.5 kg - PLA/PETG Secondary filament color (GREEN)</li><li>14 g - PLA/PETG Black filament for text (BLACK)</li><li>34 g - TPU flexible filament for your Gasket (BLACK)</li></ul><p>* Feel free to choose your own colors.</p></td></tr><tr><td colspan="2"><figure class="image image_resized" style="width: 98.07%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-04_77b29f1dbec36.jpg"></figure></td></tr></tbody></table></figure><p>I tried to keep the project in as few parts as possible and minimize the use of screws and glue. I&#39;ve also included three images that show all the parts and file names to help you easily know what to print and what to remove. <strong>Click on the pictures to enlarge.</strong></p><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_5539d72c1e42.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_1698b67225759.jpg"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_34f66213cbfb2.jpg"></figure></td></tr></tbody></table></figure><p>&nbsp;</p><p>&nbsp;</p><h2>Printing settings</h2><p>Under each file name, I&#39;ve added a recommendation on how to print that component. Please note that these are just suggestions, and you can choose the filament type, infill percentage, and wall count according to your preferences.</p><p>Additionally, I&#39;ve attached an image below that illustrates how to orient each component on the print bed for optimal results <strong>(click to enlarge):</strong></p><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_c8a5b6a960393.jpg"></figure><p>Please note that you will find in also wonderful print profiles from the community too :)</p><h2> </h2><h2>Assembly instructions</h2><p>I think the best way to demonstrate the assembly is through a video. Therefore, I&#39;ve created a short animation video for you that illustrates the assembly process and the sequence of the project&#39;s components. Enjoy:</p><figure class="media"></figure><h3> </h3><figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_f7b5fb7649351.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_0604a5a98bf6d.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_4edcdff3d535e.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_f3764fb52c104.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_7b9abe53ec9f3.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_611a02308f5c5.png"></figure></td></tr><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_d8d2275f63acd.png"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2024-05-03_f59c54b41a2bd.png"></figure></td></tr></tbody></table></figure><h3>Buttons assembly:</h3><p>Please print x2 Button insert.stl files and assemble as the photo below:</p><p><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-09-29_89172a00d321c.jpg"></p><p>&nbsp;</p><h2>Recommended Remix:</h2><ul><li><a target="_blank" href="https://makerworld.com/en/models/27690#profileId-24067" rel="nofollow noopener">Front Panels for P1P remix</a></li><li><a target="_blank" href="https://makerworld.com/en/models/28098#profileId-24385" rel="nofollow noopener">new Drawers with Clean look and version with Text</a></li><li><a target="_blank" href="https://makerworld.com/en/models/28948" rel="nofollow noopener">Spool Holder add on on the rear</a></li><li><a target="_blank" href="https://makerworld.com/en/models/29315" rel="nofollow noopener">Honeycomb panels for the sides</a></li></ul><h2>Links:</h2><ul><li><a target="_blank" href="https://s.click.aliexpress.com/e/_Dk1tOEL" rel="nofollow noopener">COB 5mm Dimmable LED strip</a> suitable to the project.<br>please make sure to choose: “white” and “Strip-USB Button” options.<br> </li></ul><h2>Colors ideas:</h2><figure class="image image_resized" style="width: 59.65%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_5f2218eae1ea7.jpg"></figure><h2>How to download CAD (f3d,Step) files:<br><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-03_16ad19d8f61ba.jpg"></h2><h2> </h2><h2>Selected User makes:</h2><figure class="table" style="width: 90.79%"><table class="ck-table-resized" style="border: 1px solid hsl(0, 0%, 100%)"><colgroup><col><col><col></colgroup><tbody><tr><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-04_3aaa07d5a3c1e.png"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 86.34%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-03_f5f9b0b8d1086.jpg"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 100%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-03_ee05726581f83.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr><tr><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 100%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_8efeadcf004be.jpg"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 79.61%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-04_c0866329e4121.jpg"><figcaption>click to enlarge</figcaption></figure></td><td style="border: 1px solid hsl(0, 0%, 100%)"><figure class="image image_resized" style="width: 92.92%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_f106d497bd601.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr><tr><td style="border: 1px solid hsl(0, 0%, 100%)" colspan="3"><figure class="image image_resized" style="width: 94.67%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_d8fbe88a9ea.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr><tr><td style="border: 1px solid hsl(0, 0%, 100%)" colspan="3"><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000019535/design/2023-10-01_0d0d9ff1ec084.jpg"><figcaption>click to enlarge</figcaption></figure></td></tr></tbody></table></figure><p>&nbsp;</p><figure class="table"><table><tbody><tr><td style="background-color: hsl(0, 0%, 60%)"><h2><span style="color: hsl(0,0%,100%)">Changelog</span></h2></td></tr><tr><td><ul><li>19/9/23 - published first prototype. not meant yet to print.</li><li>19/9/23 - uploaded v1.1 with angled glass holder and fixed Size drawer, stronger rear part.</li><li>23/09/23 - Left/Right/Rear Panel edges optimization for better surface finish.</li><li>24/9/23 - Huge update v1.2 !<ul><li>Extreme optimization to main parts, now it&#39;s 6 parts but much less support and faster to print.</li><li>Added wire channel for the LED&#39;s wires.</li><li>Added lock pins to TPU gasket.</li><li>new secure method to front and rear parts in addition to the dovetails.</li><li>Optimization to all decorative panels.</li><li>2 x Button frame cover with logo for P1P and P1S.</li><li>increased glass holder degrease to prevent movements.</li><li>Deeper AMS leg&#39;s socket, securing the AMS in it&#39;s place.</li><li>Added special drawer with accessories. it has a place for the H1.0-H2.0 HEX keys, 2 x Hotends, 5 cutters, 4 x wipers, screws, glue and needle.</li></ul></li><li>25/09/23 - updated new version 1.3 with measurements fix.</li><li>29/9/23 - added 2 remixes: clean front drawer, drawers with text, Dash front parts for P1P.</li><li>29/9/23 - added Button insert.stl + button images assembly.</li><li>30/9/23 - remix section update! spool holder, honeycomb panels added.</li><li>4/10/23 - New optimized slicing profile! faster, less filament, better support!</li><li>02/03/24 - added more support to side model.</li><li>04/04/24 - changed print profile for wider base.</li><li>22/05/24 - optimized structure for vibrations.</li><li>31/05/24 - changed Internal structure to be more rigid.<br> </li></ul></td></tr></tbody></table></figure>

Skadis

Tools

Cool Stuff

3D Printer Stuff
