chburnham

Haydn Bao

<h3>👉All 3mf's include individually optimized profile and material settings for Bambulab printers.</h3>The Modular Attached Storage Stack (<a target="_blank" href="https://modcase.com.au/products/nas?variant=43668432584952" rel="nofollow noopener">link</a>) is a compact 3D printed NAS enclosure with expandable storage support. Delivered by instant download, MASS is a digital product of ready to print files with limitless color options, unlimited spare parts and ongoing updates!<h4><a target="_blank" href="https://drive.google.com/file/d/1wRKaiGE79QRi65ESduj2JVp_4RWADkE1/view?usp=sharing" rel="nofollow noopener">MASS_Instructions.pdf</a> (v1.1)</h4>Enjoy. Like and follow for more cool stuff!&nbsp;Haydn BaoDesigner<h2>Features</h2><ul><li>Modular Body Stackable Drive expansion up to 10x 3.5” + 3x 2.5” drives.</li><li>Fully 3D Printable unlimited colors, spare parts, instant digital delivery and downloadable updates.</li><li>Vertical design Minimal foot print with straight up airflow.</li><li>Customizable Official MODs and optional mounts.</li><li>Simple assembly consolidated parts and 1 screw type for all.</li></ul><h2>Specifications</h2><figure class="table" style="width:38.13%;"><table class="ck-table-resized" style="border:1px dashed rgb(204, 204, 204);"><colgroup><col><col><col></colgroup><tbody><tr><td> </td><td>MASS PREMIUM</td><td>MASS FREE</td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Drive Bays</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">Up to 10x3.5” + 3x2.5"</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">4x3.5”+ 3x2.5"</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">PCI-E Slot</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">1 Slot Low-Profile</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">NA </td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">PSU</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">SFX, SFX-L, FlexATX</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">SFX, SFX-L</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Fans</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">4x 140mm or 120mm</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">3x 140mm or 120mm</td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">CPU Cooler</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">66mm tall</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">55mm tall</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Printer Requirements</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">Min. Bed 210x210mm 240°C Nozzle</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">Min. Bed 200x200mm 240°C Nozzle</td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Core Size (APU)</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">210x199x162mm 6.7L</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">203x199x151mm 6.1L</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Bay Module</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">199x162x150mm 4.8L</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">199x150x150mm 4.5L</td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Motherboard</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">ITX</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">ITX</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Material</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">1-2kg PETG</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">1-2kg PETG</td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Handles</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">Low profile and standard options</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">NA</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Display Mod</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">Top or Sides (Labs feature)</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">NA</td></tr><tr><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Additional 2.5" Bays</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">Optional mounts for 2x2.5" drives in a 3.5" bay</td><td style="background-color:rgb(245, 245, 245);border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">NA</td></tr><tr><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:155.729px;">Mechanical PBT</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.125px;">Optional: use keyboard switch as power button.</td><td style="border:1px solid rgb(204, 204, 204);padding:4px !important;width:183.146px;">NA</td></tr></tbody></table></figure><h3>Required to complete</h3>Screws: M3x20 (40pcs) - <a target="_blank" href="https://www.aliexpress.com/item/1005003981975435.html?pdp_ext_f=%7B%22sku_id%22:%2212000027634066519%22%7D" rel="nofollow noopener">Link</a> Power Button: Ø16mm - <a target="_blank" href="https://www.aliexpress.com/item/1005003623296396.html?pdp_ext_f=%7B%22sku_id%22:%2212000026547329693%22%7D" rel="nofollow noopener">Link</a>&nbsp;<h3>Download backups: </h3><a target="_blank" href="https://drive.google.com/file/d/1wRKaiGE79QRi65ESduj2JVp_4RWADkE1/view?usp=sharing" rel="nofollow noopener">MASS_Instructions.pdf</a> (v1.1)<a target="_blank" href="https://delivery.shopifyapps.com/-/9ae7a4af5f0c2fe7/0d88a691b57bec15" rel="nofollow noopener">MASS_FREE.zip</a> (v1.1)<h2>FAQ</h2>▶How much does it cost to print?1-2kg of filament. MASS is tested on generic PETG. You can typically find 1kg rolls for $13/kg each (<a target="_blank" href="https://www.ebay.com.au/itm/155179063326" rel="nofollow noopener">Link</a>), $12/kg if you buy 4 (<a target="_blank" href="https://www.ebay.com.au/itm/155179063326" rel="nofollow noopener">Link</a>), $10/kg if you buy 10 (<a target="_blank" href="https://www.ebay.com.au/itm/133654876065" rel="nofollow noopener">Link</a>). &nbsp;▶Premium vs Free difference?Premium has PCIE slot support, holds 5 drive per caddy, supports up to 13 drives, has handles, extra 2.5” drive adapters, Flex PSU bracket, addon Fan modules and ongoing updates. It supports development of more awesome designs.&nbsp;▶Can Free version use premium modules?No. MASS Free Version was the original model without PCIE slot, making it slimmer by 11mm on the width of the tower, and thus not compatible with the PCIE equipped Premium model.MASS Free is still a potent enclosure with 4x3.5” bay support and can technically stack up to 8 drive bays using M.2 HBA.&nbsp;▶Is MASS durable?MASS is built with an intimate understanding of the non-anisotropic strength properties of FDM. The parts are appropriately designed to overcome layer splitting issues by orientation and print settings. MASS development is committed also to ongoing improvement to ensure it is a durable and reliable option for your NAS setup.&nbsp;▶How to connect more than 4 drives?To expand the beyond the 4 sata ports on most ITX motherboards, you can install a Low profile <a target="_blank" href="https://amzn.asia/d/0uUTo9h" rel="nofollow noopener">PCIE SATA card</a> on the premium model. You can also use an <a target="_blank" href="https://www.aliexpress.com/item/1005004417694518.html" rel="nofollow noopener">m.2 SATA controller</a> to add a few more.

MASS - Stackable NAS ITX Enclosure

planes01

<h3>Model</h3><h3>Overview</h3>SR-71 kit card that was created to showcase a true aviation engineering marvel and is an inspiration for kids and adults of all ages in pursuit of science, technology, engineering, and math (STEM). This particular model uses color and sliced 3D format to really bring a highly contoured airplane to life upon assembly. The kit format is great for gifting the model to engineering clubs, friends, family, or coworkers that enjoy building and showcasing aviation engineering history. The kit includes a stand that is assembled to display the model.&nbsp;Check out the <a target="_blank" href="https://makerworld.com/en/models/199176" rel="nofollow noopener">SR-71</a>, <a target="_blank" href="https://makerworld.com/en/models/242106" rel="nofollow noopener">B-52</a>, <a target="_blank" href="https://makerworld.com/en/models/436445" rel="nofollow noopener">A-10</a>, <a target="_blank" href="https://makerworld.com/en/models/402126" rel="nofollow noopener">787</a>, and <a target="_blank" href="https://makerworld.com/en/models/405459" rel="nofollow noopener">Darkstar</a>!Check out the full airplane kit card collection → <a target="_blank" href="https://makerworld.com/@planes01/collections/991821" rel="nofollow noopener">linked here</a>!<h3>Profiles</h3><ul><li>Small Kit with Frame<ul><li>small plane kit with frame ideal for gifting to others</li></ul></li><li>Large Kit with Frame<ul><li>large plane kit with frame ideal for gifting to others</li></ul></li><li>Small Model Pieces<ul><li>small plane without frame ideal for assembly right off the printer</li></ul></li><li>Large Model Pieces<ul><li>large plane without frame ideal for assembly right off the printer</li></ul></li></ul><h3>Filament</h3>As shown:<ul><li>Bambu Lab PLA Black</li><li>Overture PLA Cement Gray</li><li>Overture PLA Space Gray</li><li>Esun PLA+ Fire Engine Red</li></ul><h3>Tips</h3><ul><li>Model requires close tolerances to ensure snug but not tight or loose fit<ul><li>Make sure the model cools to room temperature before assembly</li><li>Ensure filament is properly calibrated with no excessive over extrusion</li></ul></li><li>Ensure good bed adhesion<ul><li>Make sure printer is fully calibrated</li><li>Make sure print bed is clean &amp; dry (soapy water is my favorite for cleaning - simple &amp; works)</li><li>Make sure filament is dry (wet filament can generate non-continuous flow that can cause bed adhesion issues)</li><li>Cooling &amp; Temps - make sure they are correct for your printer, build plate, and filament</li></ul></li></ul><h3>Assembly</h3><ul><li>Remove all pieces from the kit</li><li>Debur as needed to smooth edges</li><li>Insert connector between engine halves<ul><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-24_81f8b94fa9812.jpg"></li></ul></li><li>Press engine halves together<ul><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-24_499c3e2a6c543.jpg"></li></ul></li><li>Insert engine into fuselage (snaps together). Note LHS &amp; RHS engine positions below!<ul><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-24_5e37007ed5a03.gif"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-24_2572f2daa805a.jpg"></li></ul></li><li>Insert outboard wing into engine (snaps together)<ul><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-24_582fe33443f7.jpg"></li></ul></li><li>Insert vertical tail into engine (snaps together; recommend to insert aft end of vertical tail first and then press down on forward end)<ul><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-24_02853c5841433.jpg"></li></ul></li><li>Place airplane onto stand<ul><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-02-25_3244aa356b7fb.jpg"></li></ul></li><li>Enjoy!</li></ul>&nbsp;<h3> FAQ</h3><ul><li>How do you make the airplane kit card models?<ul><li>Fusion 360! All of my models are created by me in a CAD environment. I love to design &amp; print my creations!</li><li>Here is a view of this SR-71 model showing sketches &amp; bodies!</li><li><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000199176/design/2024-03-05_8bcb3d1b0e6e1.png"></li></ul></li><li>How can I learn how to make kit card?<ul><li>Learn the tools &amp; keep exploring! (YouTube is a great starting place)</li><li>The basic steps:<ul><li>Create sketch for each of the major components: wing, fuselage, vertical tail, joints, etc..</li><li>Create solid bodies using those sketches (extrusions, lofts, etc…)</li><li>Add any details like blends, fillets, chamfers</li><li>Create the stand over the center-of-gravity (note the maker point on the image above!)</li><li>Fine tune tolerances in the joint (here is where a lot of 3D printing prototyping comes into play!)<ul><li>Fun Fact: This SR-71 had 6 prototypes before publishing to the community</li></ul></li><li>Add kit frame</li></ul></li></ul></li></ul>

SR71 Kit Card

figures

Shaztech.info

Complete open source project with cheap and easily available parts. All 3d printable parts are available, Gerber PCB are packed in zip for easy drag-drop in your prefered provider (JCLPCB, PCBWay, etc). Software are available in pre-compiled (bin files) for the ESP32, or all Arduino files are there so you can edit them. I&#39;ve included all the library I used. The full LCD interface is in Squareline Studio. Just follow the guides in order to assemble it once you have all the parts.&nbsp;<a target="_blank" href="https://github.com/Shaztech/Pilldispenser" rel="nofollow noopener">Go see my github for all the files and guides needed</a>&nbsp;Features: USB Powered (5V, 500mah) Wifi configuration directly on the screen NPT automaticaly updated time (Need Wifi for the time to work) UTC/DST configurable on the screen Time/Date screensaver (can be disabled) Full interface on the touch screen Multiples users can be defined by colors Audio/Visual Alarms for each tray/users (audio alarms are repeated every minute till dispensed) Alarms are mp3 files on the SD card (so can be changed by the user) Can stack up to 10 trays 30 sections (can accomodate multiple/large pills) for each tray Manual dispense of each tray Visual indication of remaining pills (P-Touch label 30 to E) Web interface for easy configuration with browser Telegram integration (v1.2+)&nbsp;<a target="_blank" href="https://www.buymeacoffee.com/shaztech_info" rel="nofollow noopener">Buy me a coffee</a>&nbsp;Thanks to <a target="_blank" href="https://makerworld.com/en/@johnyohanna" rel="nofollow noopener">johnyohanna</a> for this jig to help with the soldering of the boards.<a target="_blank" href="https://makerworld.com/en/models/445245#profileId-351648" rel="nofollow noopener">https://makerworld.com/en/models/445245#profileId-351648</a>&nbsp;

Automatic pill dispenser

stuff

agepbiz

<figure class="media"><div data-oembed-url="https://www.youtube.com/watch?v=jj3vnPYccS4"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/jj3vnPYccS4" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>Simple and clean looking Xbox Controller Standfits 8x3mm anti slip rubber pads (optional)&nbsp;Subscribe or follow me on:Instagram: <a target="_blank" href="https://www.instagram.com/agepbiz/" rel="nofollow noopener">https://www.instagram.com/agepbiz/</a> YouTube: <a target="_blank" href="https://www.youtube.com/user/agepbiz" rel="nofollow noopener">https://www.youtube.com/user/agepbiz</a> Twitter: <a target="_blank" href="https://twitter.com/agepbiz" rel="nofollow noopener">https://twitter.com/agepbiz</a>&nbsp;Printsettings: No raft Support Structures for best results where the rubber pads are 0,1-0,2mm layer height

Minimalistic Xbox Controller Stand

Gaming

Scubafan

Update 15.11.2023: New Version with Logo is now online<a target="_blank" href="https://makerworld.com/de/models/65379#profileId-68693" rel="nofollow noopener">https://makerworld.com/de/models/65379#profileId-68693</a>&nbsp;Over the years I collected quite a few Apple Watch Bands but I couldn't find a good solution to store my Bands in a good way. So I came up with my own design wich is based on the Rugged Box<h3>Printing & Assembling</h3>I would recommend printing at a 0.2mm layer height. 2 latches are needed. Printing the TPU seal isn't needed unless you want to water tighten the case. The latches and hinges are made to fit M3x20.The Insert sits very tight in the bottom part of the box, no glue is needed.<h3>The Slots</h3>There are 3 different sizes of SlotsS fits the Solo Loop and Silicon Solo LoopM fits the Sport Loop, Trail Loop, Alpine Loop, Milanese Loop and thin Leather BandsL fits the Ocean Band and thinker leather bands<h3>Inserts</h3>There are different inserts with different slot sizes. Pick the one you need. More variations will come in the future.
