carlchanhm

thrutheframe

<figure class="media"><oembed url="https://www.youtube.com/shorts/7O7hjxvXUPo"></oembed></figure><h3> </h3><h3>IMPORTANT</h3><ul><li>Please download the &#34;BentoBoxV2 2023XXXX.3mf&#34; project 3mf file and “BentoBox20 User Guide 2023XXXX.pdf” Descriptions, BOM and build instructions are in there. I try my level best to make it as comprehensive as possible.</li><li>Use only ACID-FREE activated carbon pellets.</li><li>I do my best to double-check and test the print profiles I created. Therefore, I will only take feedback and update for those profiles. I cannot vouch for profiles uploaded by others, so please do due diligence.</li><li>Please use the print profile that I upload. Print profiles created by others may not have the most updated parts.</li><li> </li></ul>UPDATE 8 APR 2024I believe in working with local small businesses when selecting regional vendors. Unlike established companies that are good at managing logistics and sales, small businesses or new start-ups are still learning the ropes, and sometimes make mistakes. Everyone makes mistakes, but it&#39;s important to make things right and work towards improvement. &nbsp;BentoBox V2 is now available with Australia vendor JC-3D. They have improved their ops &amp; logistics. There will also be no more pre-orders to prevent late fulfilment. &nbsp;&nbsp;UPDATE 16 FEB 2024The grills on the CMAG are slicer-generated. If you are using Bambu Slicer or Orca Slicer. click slice and the settings will generate the grill holes. If you are using Prusa Slicer, there is a version for Prusa Slicer in the download. If you are using Cura, please read the user manual for the slicer setting to produce the grill holes.&nbsp;&nbsp;<h3>VENDORS</h3>The US vendor for BentoBoxV2 is now available for sale. This is a collaboration between ThrutheFrame and Voxelpla to offer a complete set (printed in PET-g) with HEPA filter and acid-free activated carbon included. For more information, please visit <a target="_blank" href="https://voxelpla.com/products/bento-box" rel="nofollow noopener">Voxelpla Store</a><figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2024-05-10_0277a634c3772.png"></figure>&nbsp;The EU vendor for BentoBoxV2 is now available for sale. A partnership between ThrutheFrame and Veetec3D to offer a complete set (printed in PET-g Galaxy Black) with HEPA filter and acid-free activated carbon included. For more information please visit <a target="_blank" href="https://veetec3d.etsy.com/listing/1544593634/preorder-bentobox-filtration-system" rel="nofollow noopener">Veetec3D Store</a>.<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2024-04-08_1da06d6c23a7a.png"></figure>&nbsp;The AUS vendor for BentoBox V2 is available for sale on JC-3D. It is printed in PET-g and comes complete with HEPA filter and activated carbon as a kit. For more information please visit <a target="_blank" href="https://jc3dmelb.com.au/products/bento-box-v2" rel="nofollow noopener">JC-3D</a>.<figure class="image image_resized" style="width: 50.03%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2024-04-08_45e607e9e5419.png"></figure>&nbsp;<h4>Where to Buy Your Consumables:</h4>( links below are not affiliated unless stated)&nbsp;Acid-free activated carbon:US - Voxelpla offers acid-free activated carbon in a 1lb pack and HEPA filter replacement. You can support the BentoBox project by buying it from this affiliated link: <a target="_blank" href="https://voxelpla.com/thrutheframe" rel="nofollow noopener">https://voxelpla.com/thrutheframe</a>EU - Veetec3D offers acid-free activated carbon in 150gm &amp; 450gm. You can support the BentoBox project by buying it from Veetec3D Store for <a target="_blank" href="https://veetec3d.etsy.com/listing/1545297808/veetec3d-acid-free-activated-carbon" rel="nofollow noopener">Activated Carbon</a> and <a target="_blank" href="https://veetec3d.etsy.com/listing/1563529764/carbon-hepa-filter-refill-pack" rel="nofollow noopener">HEPA filter</a>.JPN<ul><li>「KOTOBUKI パウーバイオ」はテストしました、酸は含まれていません</li><li>This <a target="_blank" href="https://www.monotaro.com/p/2090/5517/" rel="nofollow noopener">seller</a> in Japan was recommended by a user it has a PH of 9.8.</li></ul>&nbsp;The HEPA filters:BentoBox uses the same HEPA filter as iLife vacuum robots. It is 80mmx40mmx15mm you can get it on <a target="_blank" href="https://www.amazon.com/Electropan-Filter-Replacement-Robotic-Cleaner/dp/B0782T7L6P" rel="nofollow noopener">Amazon</a> or <a target="_blank" href="https://www.aliexpress.com/item/1005002687133564.html?spm=a2g0o.store_pc_groupList.8148356.9.79237784J9PuMx&amp;pdp_npi=2%40dis%21SGD%21SG%24%205.57%21SG%24%201.35%21%21%21%21%21%40211b88f116797536610071881edc06%2112000025636802474%21sh" rel="nofollow noopener">Aliexpress</a>&nbsp;<h3>INTRODUCTION</h3>BentoBox is an air scrubber that sits inside the X1C or enclosed P1P. It removes VOCs and fumes in the air within the printer. Mainly used for printing ABS, ASA, Nylon, and other high VOCs filaments. If you are still unsure if you need an air scrubber, there are numerous write-ups and discussions online on which you can do due diligence.BentoBox can also be used for other printers. Voron, Vzbot, Enclosed Prusa or Ender 3, your hamster cage, etcBentoBox V2.0 can be run:<ol><li>standalone with a separate 5V power source (5V fans),</li><li>connect to the printer&#39;s 24V PSU (24V fans)</li><li>or piggyback on the chamber fan with a cable splitter. (24V fan)</li></ol>&nbsp;Please download the user guide for BOM and how to install BentoBox V2.0<figure class="image image_resized image-style-align-center" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/589fb0e7-05a1-47e7-aecb-d48a92a2af4f.png"></figure>&nbsp;I know some people may be disappointed that version 2.0 does not incorporate 5015 blower fans. Below is the reason why.Using either 5015 (push) or 4020 (pull) makes very little difference because both are relatively low-pressure fans. What makes a difference in performance is the unobstructed distance of the fan to the carbon pellets.I notice remixes of BentoBox where 5015 fans push air through the HEPA filter followed by the carbon pellets. If you imagine the blower fan is waves and the HEPA filter is the wave breaker on the beach. Once waves hit the breaker, a lot of initial force is lost. There will be very little air movement through the carbon pellets. On the other hand, BentoBox pulls air by creating a low-pressure system directly below the carbon pellets. In my opinion, it is a more efficient system.Do not use Noctua fans. It does not have enough static pressure to pull air through the carbon pellets. You can get the 4020 fans from Aliexpress here: <a target="_blank" href="https://www.aliexpress.com/item/32769608982.html?spm=a2g0o.store_pc_groupList.8148356.3.782a7e1f2o83nX&amp;pdp_npi=2%40dis%21SGD%21SG%24%2010.87%21SG%24%207.07%21%21%21%21%21%40210318bb16625658822601771e6ac5%2166639444053%21sh" rel="nofollow noopener">4020 24V GDSTime 9.0cfm 7000rpm</a>Redesigned the base (fan duct Voron_Trident.stl) to be used on my Voron Trident. It can fit both 250 and 300. Will require 2 sets of M3x8mm + M3 T-nut. Wire it to one of the pwm fan port and bam you have a HEPA and activated carbon filter. For Bambu Lab printers, please use “fan duct Bambulan.stl”. Everything else is the same.<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/3df84fcc-44b6-4698-9346-c339ea299385.png"></figure><figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/de68e9b0-f01b-45a9-8c25-2e8daa788775.png"></figure>&nbsp;<h4>Dimension of BentoBox V2</h4>There are requests for me to show the dimensions of BentoBox V2 to be able to visualise in different enclosures. They are H=215.6mm D=52.8mm L=112.8mm.<figure class="image image_resized" style="width: 50.02%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/c7bc644d-5627-4532-9c71-2cb0bb6ee013.png"></figure><figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/1470deea-cf1d-4944-9b56-32cb44c26252.png"></figure>&nbsp;<h4>BentoBox V2 in other printer Enclosures</h4>While the BentoBox was originally designed for Bambu Lab printers and subsequently Voron Trident, I hope to make it fit on most enclosed printers ie Creality K1 series, Qidi, Prusa Enclosure, etc. Hence, I will need the community&#39;s help as I will not be able to have access to all the different make and models. As always, BentoBox stl will be free for the community, with no club membership, no Patreons, no paid wall, etc.&nbsp;<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/42368a89-96f8-4238-9e3d-0ff0f4a5f2cb.png"></figure>BentoBoxV2 in a Snapmaker J1 <figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/2023-08-27_227bd3ad86af3.jpg"></figure>BentoBoxV2 in a tent with a resin printer&nbsp;Some have requested I add a switch to the design. But there are so many different types and shapes of switches. Therefore, I have added the step file of the BentoBox fan_case_duct.step which you can edit to add a switch or mod it.<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/003d4110-7f18-4e69-88e3-a34b13b6dfea.png"></figure>&nbsp;I printed the design in PLA for a fitting test and then PETG for the final prototype. If you are using ABS or ASA, please print the test piece to check for dimension accuracy and if there is a need to do X and Y compensation. 14mmx36mmx10mm (LxBxH)<figure class="image image_resized" style="width: 50%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000012786/design/1d08706c-1972-4b37-8c51-e82cbb497ef0.png"></figure>&nbsp;&nbsp;<figure class="media"><oembed url="https://www.youtube.com/watch?v=xZiEzQH7WFQ"></oembed></figure>&nbsp;&nbsp;To date, my designs are free to download and use. There is no Patreon or OnlyFan (hahaha). If you like what I designed and want to contribute to my coffee addiction, software subscription and filaments I need for prototyping, a donation of $5-$10 to <a target="_blank" href="https://ko-fi.com/thrutheframe" rel="nofollow noopener">Ko-fi</a> or <a target="_blank" href="https://www.paypal.com/paypalme/shannonheng" rel="nofollow noopener">paypal.me</a> will be greatly appreciated.&nbsp;CaveatAs with all my designs, it may and may not work for you. So print and install at your discretion.<h3> </h3><h3> </h3>

BentoBox V2.0 Activated Carbon Filter

toPrint

TrendtB

UPDATE 13th December: A Christmas Angel version is also now available: <a target="_blank" href="https://makerworld.com/en/models/91216#profileId-97549" rel="nofollow noopener">https://makerworld.com/en/models/91216#profileId-97549</a>&nbsp;A charming Christmas decoration that can be displayed with, or without, an LED tealight candle!<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/261711/2023-12-03_bd3f5c038459a.gif"><figcaption>Charming lighting for your home</figcaption></figure>&nbsp;Great for gifts, or for subtle decoration around your home. The example was printed in Bambu Lab PLA Matte White and looks fantastic even without the tea light.&nbsp;<h3> FEATURES</h3><ul><li>Fits any LED tealight up to 39mm diameter</li><li>Two part print for easy assembly</li><li>Multi-material compatible (Wireframe and outer edge are separate objects)</li></ul>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/261711/2023-12-03_947a27edb315f.gif"><figcaption>Easy assembly</figcaption></figure>&nbsp;OTHER VERSIONS&nbsp;If you like this decoration, there is a Christmas Angel version available here: <a target="_blank" href="https://makerworld.com/en/models/81794#profileId-87041" rel="nofollow noopener">https://makerworld.com/en/models/81794#profileId-87041</a>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/261711/2023-12-13_f1288a2373a84.gif"><figcaption>Christmas Angel version available at <a target="_blank" href="https://makerworld.com/en/models/91216#profileId-97549" rel="nofollow noopener">https://makerworld.com/en/models/91216#profileId-97549</a></figcaption></figure><h3>PROFILE NOTES</h3>There are some challenging overhangs in this design, but it should print without supports. If you're tweaking things, be careful of adjusting speed - there are some very fine details in the wireframe and will likely fail at high speed.&nbsp;

Christmas Tree Tea Light Ornament

Nice

Iconic FAB

<h3>General</h3>I was unable to find a refillable activated carbon air filter (box) for Bambu Lab X1 / X1C / P1P so I rolled up my sleeves and designed my own version.<h3>Features</h3><ul><li>Allows to save a decent amount of money using this instead of the original activated carbon air filter. Just replace carbon pallets and go.</li><li>Designed for easy use and fast to print.</li><li>No supports required.</li></ul>The filter box size is 82mm x 48mm x 29mm. Please check against your existing filter.<h3>Recommended print settings</h3><ul><li>Extrusion width: 0.4mm, forced</li><li>Layer height: 0.2mm</li><li>Walls: 4</li><li>Infill percentage: Any (will print as walls only)</li><li>Solid top/bottom layers: 4</li><li>Supports: None.</li></ul><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/1939759783/draft/2023-09-25_3ir8i4ik6rqw.png"></figure><h3>Very important stuff (this is not a joke)!</h3><h4>Use a decent heat-resistant filament.</h4>Please Print in ASA, ASA-CF, ABS or at least PETG.<h4>Source propper acid-ree carbon pellets.</h4><a href="https://en.wikipedia.org/wiki/Volatile_organic_compound" rel="nofollow">VOCs (Volatile Organic Compounds)</a> are common in daily life but VOCs generated from 3D printing are known to cause severe health issues and even cause cancer in some cases.The optimal carbon pellets for 3D printer's VOCs absorption are sourced from virgin coconut, not wood/bitumen/charcoal or other materials. The porosity for each and every source will vary greatly.3D Printer VOCs are generally less than 0.5 nm, meaning that for optimal capture rate and efficiency, you need carbon with a high microporosity ratio, defined as <1nm. A higher iodine count >1000 usually indicates at least some micro/mesoporosity, and a higher hardness (>95%) will create less dust in air filtration.<h5>Avoid acid-washed carbon at all costs.</h5>Residues have oxidized printers! Go for steam activated, non-acid-washed. A blend of neutral carbon and alkaline KOH carbon might be the best blend in the future, but impossible to currently source from trustworthy manufacturers.Finding carbon that fills all criteria is hard. My recommendation is to use Nevermore premium carbon commonly used in Voron, Annex, and other DYI 3D printing communities.It doesn't come cheap compared to bulk carbon from Amazon, but it's safe and has an unbeatable performance.<h4>Where to source.</h4>US: <a href="https://kb-3d.com/store/voron/662-original-nevermore-activated-carbon-filter-media-multiple-sizes.html" rel="nofollow">KBD-3D,</a> <a href="https://www.fabreeko.com/products/nevermore-carbon" rel="nofollow">Fabreeko</a>, <a href="https://dfh.fm/products/nevermore-printer-carbon" rel="nofollow">DFH.</a>EU: <a href="https://3do.eu/accessory/1068-nevermore-carbon-pellets.html?SubmitCurrency=1&id_currency=4" rel="nofollow">3DO.eu,</a> <a href="https://fermio.xyz/nevermore-activated-carbon-filters/nevermore-activated-carbon-small-bag-0.8-l/" rel="nofollow">Fermio Labs</a>, <a href="https://lecktor.com/en/nevermore/870-nevermore-carbon.html" rel="nofollow">Lecktor</a>UK: OneTwo3d, Printy PleaseISR: Rav MeimadAU: Unique Prints, PhaserFPV, DREMC<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/user/1939759783/draft/2023-09-25_dkn2ltb4ifuy.png"></figure>

toPrint

Nice

Useful
