bann70918

BaGooN

This is a handle for the Eibos Polyphemus with a cool hex pattern. I recommend printing it with PETG or ABS, not PLA.

Eibos Polyphemus Hex Pattern Handle

upgrades

3dEd

Every electronic workbench benefits from a well-organized supply of electronic components. This is a system to provide organized storage. There are two case sizes, a 2-drawer and a 4-drawer case. There are six different drawer configurations with 24, 16, 12, 8, 4, or no divisions, allowing for a wide variety of component sizes and quantities. Drawer16 was specifically designed for resistors which provides the formfactor that the rest of the drawers follow.&nbsp;Each case is robust and has feet that fit neatly into the indentation on the top, allowing for stable stacking. The drawers have slots for identifying component values. The slots are sized to use a 1” x 7/8” (25mm x 22mm) piece cut from card stock. &nbsp;The only printing issue to consider is that when printing PLA, the auxiliary fan on the P1S and X1-C should be set to 30% max, either through the filament settings or manually at the control panel. Otherwise, because of the wide footprint, one is likely to get lifting on the side of the print closest to the fan.

Electronic Component Storage and Organizing System

organizer

smittyrn

Edit: I just found out that <a href="https://www.printables.com/@jerrymk_985120" rel="nofollow">@jerrymk_985120</a> made the <a href="https://www.printables.com/model/522164-the-og-clickfinity-clickplates" rel="nofollow">OG Clickfinity</a>. That's where all the magic happened. Sorry I didn't acknowledge all your hard work earlier, Jerry. I couldn't have done what you did. Recently found NoWarrenty's <a href="https://www.printables.com/model/452675-gridfinity-clickfinity-baseplate-no-magnets-univer" rel="nofollow">Clickfinity</a>, and while I love the idea, I wanted something a little more solid for the drawers in my tool cabinet. I've been using grizzie17's <a href="https://www.printables.com/model/413761-gridfinity-refined" rel="nofollow">Gridfinity Refined</a> plates and love the way they can be attached together, so I decided to see if I could combine the two. And after a lot of trial, error, and head scratching, I think I made it work. I also reworked the wedge connectors to better fit these plates. I've also added plates to use as a movable base or just make the entire section more solid, along with trim sections if you just want to dress up the edges.I've added Alignment Squares if you want to include plates into your model. Space the squares 42mm apart to match the size of the plate you are using. Allow 3mm depth and 1mm on the X and Y axis for fitment. Example: if you are using a 3x5 plate measuring 126mmx210mm, have a 127mm x 211mm x 3mm cutout.I print the plates in PETG. Per the original model details; “Print with PETG, ABS, ASA, or Nylon. Do not use PLA or PLA+ as these materials creep under constant load, causing the grid to lose its grip over time.” PLA will work for the trays and trim.I give you Clickfinity Refined. Huge thanks to NoWarrenty, grizzie17, and of course Zack Freedman for the original <a href="https://thangs.com/designer/ZackFreedman/3d-model/Gridfinity%2520Baseplates-60925" rel="nofollow">Gridfinity</a>. This is a result of all of their collective hard work.This is still a work in progress, so comments, suggestions, and remixes are very much welcomed. 7/8/23 - Added a Kobalt Mini Toolbox plate insert.8/1/23 - Added Baseplate Trays for looks and portability. Also added trim sections to dress up the sides without having to print out an entire tray. 8/13/23 - Added <a href="https://www.printables.com/model/543553-gridfinity-storage-box-by-pred" rel="nofollow">Preds Gridfinity Storage Box</a> base modified to accept Clickfinity Refined baseplates. You will need to print out the rest of the hardware from his posting. (These are for the newer, parametric models)8/17/23 - Fixed the corner issue in the Preds box; thanks to <a href="https://www.printables.com/@gniticxe" rel="nofollow">@gniticxe</a> for pointing out my error.8/23/23 - Fixed Preds box models after discovering a height issue. Added Alignment Squares.

Clickfinity Refined Baseplates for use with Gridfinity

gridfini

Christopher Medeiros

These boxes are pretty heavy and would recommend these be printed in PETG at a minimum with 6 walls and 25% infill.&nbsp;Would also recommend ¾" lumber using #10 1-½" wood screws.

Toughbuilt Stacktech Cleats

Stack Tech

Joshua3D

<h3 style="text-align: center">Check out the customizable emoji version here -  <a target="_blank" href="https://makerworld.com/en/models/506170#profileId-421885" rel="nofollow noopener">https://makerworld.com/en/models/506170#profileId-421885</a> </h3>&nbsp;Simple screw cap/cover for the Ikea Skadis Pegboard screws.&nbsp;View my other Ikea Skadis Pegboard models here - <a target="_blank" href="https://makerworld.com/en/u/1173640213/collections/175613" rel="nofollow noopener">https://makerworld.com/en/u/1173640213/collections/175613</a>

Screw Covers / Caps for IKEA Skadis Pegboard

skadis

3Deste

This is my version of soldring wire holder.So simple as funcional.I use it with 250gr spool.Printed with PLA but every material is ok.Support not needed, layer high 0.2mm or higher, minimum 3 wall loops, infill 15%.If you like this model, please, leave a like and publish a picture of your print :)Alex&nbsp;

upgrades

organizer

gridfini

Stack Tech

skadis

solder
