Gnometech

<h2>Scale Bar for RealityCapture (Customizable)</h2>A scale bar is used during photogrammetry to ensure that the produced object mesh is the same size as the real world object. A coded scale bar such as those produced by this model are used by photogrammetry software (like RealityCapture) to automatically perform this sizing.&nbsp;While there are many possible marker types for coded scale bars, this model is focusing on 36h11 AprilTags, which is a common format. Using the power of OpenSCAD and Maker World, you can customize the printed scale bar&#39;s width, height, thickness, and the unique AprilTag marker that is generated on each end.<h3>Features</h3><ul><li>Customizable 36h11 AprilTag scale bar for RealityCapture photogrammetry software</li><li>Supports all 587 36h11 AprilTags in RealityCapture&#39;s proprietary ordering</li><li>Modify width, height, thickness, left 36h11 AprilTag marker number, and right 36h11 AprilTag marker number</li></ul><h3>AMS Print Instructions</h3><ol><li>Load up the AMS with white (filament 1) and black (filament 2) filament.</li><li>Make the primary color of the scale bar white.</li><li>As OpenSCAD models cannot perform a color change on their own, you&#39;ll need to set it up manually:<ol><li>Optionally change the model&#39;s Top surface pattern from Monotonic line to Hilbert Curve if you prefer that look.</li><li>Slice the plate.</li><li>Right-click on the last layer (layer 10 if using the standard 2mm thickness for the bar) to open the layer menu.</li><li>Choose Change Filament → Filament 2, which should be filled with black.</li><li>Slice the plate again.</li><li>The top layer should now be black with the rest of the scale bar white.</li><li>Print the scale bar.</li></ol></li></ol><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000512060/design/2024-06-25_862209ad15849.png"></figure><h3>Single Spool Print Instructions</h3><ol><li>Optionally change the model&#39;s Top surface pattern from Monotonic line to Hilbert Curve if you prefer that look.</li><li>Slice the plate.</li><li>As OpenSCAD models cannot perform a color change on their own, you&#39;ll need to set it up manually:<ol><li>Right-click on the last layer (layer 10 if using the standard 2mm thickness for the bar) to open the layer menu.</li><li>Choose Add Pause to have the printer pause before printing this layer.</li><li>Slice the plate again.</li><li>Load the printer with white filament.</li><li>Print the scale bar.</li><li>When the printer pauses just before the final layer unload the white filament and load the black filament.</li><li>Continue with the printing.</li></ol></li></ol><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000512060/design/2024-06-25_b65011e740e38.png"></figure><h3>Notes</h3><ul><li>The size of coded scale bars is measured from the centers of the AprilTags. While it is easy to determine the distance from the centers mathematically based on the scale bar&#39;s width and the ApriltTags&#39; size, in reality the printing process will not exactly match this theoretical value. For an accurate coded scale bar size that is entered into RealityCapture, it is best to measure the distance from the centers of the AprilTags on the printed scale bar yourself.</li><li>RealityCapture uses its own AprilTag ordering that is different from the industry standard, and numbers them 1 to 587 instead of 0 to 586. For example, RealityCapture&#39;s 001 36h11 AprilTag marker is the same as the industry standard&#39;s 476 36h11 AprilTag marker. The provided model and OpenSCAD&#39;s code follow RealityCapture&#39;s AprilTag ordering, and is only directly compatible with it. See this <a target="_blank" href="https://forums.unrealengine.com/t/ids-of-april-tags/1430876" rel="nofollow noopener">forum post</a> for more information.</li><li>Find out more about using coded scale bar in RealityCapture from this <a target="_blank" href="https://dev.epicgames.com/community/learning/tutorials/yXna/unreal-engine-capturing-reality-scale-the-alignment" rel="nofollow noopener">tutorial</a> written by the RealityCapture developers. Their example uses circle markers, but it is the same procedure for 36h11 AprilTags.</li><li>The OpenSCAD code is copyright Gnometech Inc., and written by David Wyand (the author of this model on Maker World).</li><li>The original 36h11 AprilTag makers are are extracted from this <a target="_blank" href="https://github.com/AprilRobotics/apriltag-imgs/tree/master" rel="nofollow noopener">repo</a>. Copyright (c) 2013-2016, The Regents of The University of Michigan. All rights reserved. Used under the BSD 2-Clause License.</li></ul>&nbsp;

Scale Bar for RealityCapture (Customizable)

OpenScad

chuuubert

The GoPro camera mount is available in various lengths and shapes to provide versatility and the ability to adopt to different recording scenarios. &nbsp;Three different lengths are available:<ul><li>44mm </li><li>72mm</li><li>100mm</li></ul>

GoPro Mounts

mounts

Luke's 3D

I saw some of the toothpaste tube squeezers and thought there's room to improve. So here's brief description of this ratchet toothpaste tube squeezer:<ul><li>ratchet mechanism ensures the tube doesn't unwind</li><li>no supports</li><li>just 4 parts which clicks into each other, no glue etc. needed, no part will get lost when swapping tubes</li><li>fits 55mm wide tube</li><li>shaft printed horizontally to prevent snapping</li><li>toothpaste tube shape</li><li>easy to assemble and use</li></ul>I recommend to print out the Shaft and Ratchet in PETG.If you don't have a 3D printer and want one of these, don't worry, I am also selling these on my <a target="_blank" href="https://www.etsy.com/shop/Lukes3D" rel="nofollow noopener">Etsy shop</a>!Check out the assembly and how to use video here:<figure class="media"><div data-oembed-url="https://youtu.be/QRoGfiVkEOM"><div style="position: relative; padding-bottom: 100%; height: 0; padding-bottom: 56.2493%;"><iframe src="https://www.youtube.com/embed/QRoGfiVkEOM" style="position: absolute; width: 100%; height: 100%; top: 0; left: 0;" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen=""></iframe></div></div></figure>As always, multiple formats are available including .stl, .3mf, .step and .obj.I also prepared .stl and .3mf with all parts preloaded and in their correct orientation.UPDATE 9.2. 2023 - V2 version <ul><li>stiffened body</li><li>body also connected on top - shaft rotates smoother and doesn't get caught on</li><li>larger toothpaste opening on the body with chamfer for easier insertion</li><li>shaft tolerances adjusted </li><li>reworked handle for better experience </li></ul>If you like practical things you can also check out my other <a target="_blank" href="https://www.printables.com/social/11728-lukes-3d/models" rel="nofollow noopener">projects </a>or have a look at my <a target="_blank" href="https://makerworld.com/en/models/219260" rel="nofollow noopener">Two-way ratchet stubby screwdriver</a>:<figure class="image"><img src="https://media.printables.com/media/prints/265248/rich_content/5f730c0e-c06d-4a3f-8862-7a8721d3c214/1.jpg#%7B%22uuid%22%3A%22c729e4ce-6e30-435a-aead-2f9d85356531%22%2C%22w%22%3A3704%2C%22h%22%3A2778%7D"></figure>Cheers!Luke

Ratchet toothpaste tube squeezer

homeimprovement

ostat

<h3>OpenSCAD project to create vacuum hose connectors.</h3>Intended for generating connections that would allow connecting vacuum hoses and tools of different diameters together.Parametric settings support a few connections types. The connections types can be used on ether end of the adapter.&nbsp;The project is actively maintained by myself. Please submit bugs and suggestions at the GitHub repo. <a target="_blank" href="https://github.com/ostat/vacuum-hose-adapter-openscad" rel="nofollow noopener">ostat/vacuum-hose-adapter-openscad</a>.<h2><img class="image_resized" style="width: 38.95%" src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/009a8b5b-07b6-4bf0-8809-e2ad229be092.gif"></h2>&nbsp;Connector types<figure class="table" style="width: 100%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td> Hose connector  The hose connector is the most generic connector. Its intended to be pushed inside a hose or over an existing connector. We can enable a stop to prevent the adapter being pulled in to the hose, and barbs for soft style pipe.  Options<ul><li>Length<ul><li>The length of the connection end</li></ul></li><li>Diameter<ul><li>Internal or external diameter of the intended connector.</li></ul></li><li>Taper<ul><li> Tapered to allow for a tight push fit</li></ul></li><li>Barbs</li><li>Stop</li></ul>Official Documentation <a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/hose" rel="nofollow noopener">docs.ostat.com/docs/openscad/hose-adapter/connectors/hose</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_ed350451c1e9a.gif"></figure></td></tr><tr><td>NozzleA configurable nozzleOptions<ul><li>Nozzle Shape<ul><li>square: a square tip, where you can control the width and depth of the tip, and the corner radius</li><li>circle: A round tip, where you can control the radius.</li></ul></li><li>Nozzle_Size<ul><li>Size of the nozzle tip, in the format of [width, depth, length]</li></ul></li><li>Wall Thickness</li><li>Nozzle_Radius   </li><li>Nozzle_Offset    </li><li>Nozzle_Chamfer_Percentage     </li><li>Nozzle_Chamfer_Angle</li></ul>Official Documentation<a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/nozzle" rel="nofollow noopener">docs.ostat.com/docs/openscad/hose-adapter/connectors/nozzle</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_470047bc1b6da8.gif"></figure></td></tr><tr><td>FlangeCustomisable flange for attaching to boxes or wall.&nbsp;Options<ul><li>Flange_Width     <ul><li>Width of Flange added to the connector diameter</li></ul></li><li>Flange_Thickness  <ul><li>Thickness of the flange</li></ul></li><li>Flange_Screw_Position <ul><li>Position of the screws added to the connector diameter</li></ul></li><li>Flange_Screw_Border     <ul><li>Minimum amount of the material around the screws</li></ul></li><li>Flange_Screw_Count     <ul><li>Number of Screw holes flange</li></ul></li><li>Flange_Screw_Diameter</li></ul>Official Documentation<a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/flange" rel="nofollow noopener">docs.ostat.com/docs/openscad/hose-adapter/connectors/flange</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_3772a84429e99.gif"></figure></td></tr><tr><td>Magnetic flange connectionIntended for creating a quick removable connection. Allowing the hose to be quickly moved form device to device. The magnets should be slightly recessed so that the two faces get a good seal, allow extra depth if you want to avoid supports.  Main setting:<ul><li>Flange diameter: Internal diameter of the flange connection.</li><li>Flange thickness: The overall thickness of the flange. Magnet thickness plus 4mm seem to work well.</li><li>Connector length: The length of the connector before the tapered section will start.</li><li>Magnet count: Number of magnets to be added to the flange.</li><li>Magnet diameter: Diameter of the magnets (add 0.5 to measurement).</li><li>Magnet border: The amount material around the magnet.</li><li>Magnet thickness: Thickness of the magnets (add 0.5 to measurement, 1.0 to avoid supports).</li><li>lip: If an alignment ring should be supported, can be recessed or protruding, suggest recessed.</li></ul></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-01_32584b3954dc8.gif"></figure></td></tr><tr><td>Fixed connectorsConnectors that are not configurable as they are designed to be compatible with an existing connector type.&nbsp;Options<ul><li>Dyson V6 connector<ul><li>Compatible with Dyson V6 vacuums. </li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/dyson" rel="nofollow noopener">Doco</a></li></ul></li><li>CAMLOCK connector<ul><li>Compatible with PeterH&#39;s </li><li><a target="_blank" href="https://www.printables.com/model/461256-shopvac-50mm-camlock-connectors-with-magnetic-catc" rel="nofollow noopener">camlock connectors</a> <a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connector/camlock" rel="nofollow noopener">Doco</a></li></ul></li><li>Dewalt DW735x<ul><li>Dewalt DW735 Planer </li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/dw735" rel="nofollow noopener">Doco</a></li></ul></li><li>Cen-Tec quick connect <ul><li>Cen-Tec Female</li><li>Cen-Tec Male</li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/centec" rel="nofollow noopener">Doco</a></li></ul></li><li>Makita quick connect<ul><li>Makita quick connect compatible (not tested)</li></ul></li><li>osVAC<ul><li>osVAC M32<ul><li>Male connector compatible with Original osVAC</li></ul></li><li>osVAC Male<ul><li>Male connector compatible with Original osVACneo, support variable diameter</li></ul></li><li>osVAC F32<ul><li>Female connector compatible with Original osVAC</li></ul></li><li>osVAC Female<ul><li>Female connector compatible with Original osVACneo, support variable diameter</li></ul></li><li><a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/connectors/osvac" rel="nofollow noopener">Doco</a></li></ul></li></ul></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-03_fc82126a83115.gif"></figure></td></tr></tbody></table></figure>&nbsp;TransitionsUsing the above listed connectors we have a few options of how to transition between the end1 and end2.<figure class="table" style="width: 100%"><table class="ck-table-resized"><colgroup><col><col></colgroup><tbody><tr><td>Options<ul><li>Transition_Style<ul><li> taper+bend: Taper then bend</li><li>bend+taper: Bend then taper</li><li>organicbend: fully tapered bend</li><li>hull: Hull for multiple end count</li><li>flat: basic flat transition.</li></ul></li><li>Transition_End2_Count<ul><li>one to many adapter</li></ul></li></ul>&nbsp;There are many other options available,Official Documentation<a target="_blank" href="https://docs.ostat.com/docs/openscad/hose-adapter/transition" rel="nofollow noopener">https://docs.ostat.com/docs/openscad/hose-adapter/transition</a></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-02_d89390625a92a8.gif"></figure></td></tr><tr><td>Support for three unique connectors&nbsp;Updated 2024 to add support for an adapter with three different connectors.When using the Hull transition. You have the option to add a center adapter. This third adapter can be, end1, end2 or end3. (previously it could only be end2)<ul><li>pink, end1</li><li>blue, end2, you can adjust the angle and count.</li><li>purple, can be end1, end2 or end3</li></ul>  &nbsp;&nbsp;</td><td><figure class="image image_resized" style="width: 97.2%"><img src="https://makerworld.bblmw.com/makerworld/model/DSM00000000481868/design/2024-06-06_602056cb886a38.png"></figure></td></tr></tbody></table></figure>  Related models, for pre-generated adapters. <a target="_blank" href="https://www.printables.com/social/210306-max/collections/357939" rel="nofollow noopener">Hose Fittings collection</a><ul><li><a target="_blank" href="https://www.printables.com/model/316283" rel="nofollow noopener">Vacuum nozzles for all common hose sizes</a></li><li><a target="_blank" href="https://www.printables.com/model/297912" rel="nofollow noopener">Vacuum hose flanges to connect to flat surfaces</a></li><li><a target="_blank" href="https://www.printables.com/model/303766" rel="nofollow noopener">Dyson V6 hose attachments</a></li><li>Vacuum hose adapters<ul><li><a target="_blank" href="https://www.printables.com/model/283238" rel="nofollow noopener">Straight hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/325999" rel="nofollow noopener">Y connector / splitter for all common sizes</a></li><li><a target="_blank" href="https://www.printables.com/model/284701" rel="nofollow noopener">30° elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284834" rel="nofollow noopener">30° tapered elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284846" rel="nofollow noopener">45° elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284877" rel="nofollow noopener">45° tapered elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284879/" rel="nofollow noopener">90° elbow hose adapters</a></li><li><a target="_blank" href="https://www.printables.com/model/284929" rel="nofollow noopener">90° tapered elbow hose adapters</a></li></ul></li><li>Magnetic Hose connectors<ul><li><a target="_blank" href="https://www.printables.com/model/283250" rel="nofollow noopener">50mm magnetic hose connectors</a></li><li><a target="_blank" href="https://www.printables.com/model/283255" rel="nofollow noopener">100mm magnetic hose connectors</a></li></ul></li><li>Barbed tube connectors<ul><li><a target="_blank" href="https://www.printables.com/model/328572" rel="nofollow noopener">Tube Fittings 4mm-24mm</a></li><li><a target="_blank" href="https://www.printables.com/model/328599" rel="nofollow noopener">Vacuum hose to tubing adapters for all common sizes</a></li><li><a target="_blank" href="https://www.printables.com/model/328572" rel="nofollow noopener">Tube Y connector / splitter fittings 4mm-24mm</a></li></ul></li></ul>

Parametric vacuum hose connector

connectors

LayerCake

Based on the excellent Gridfinity system by Zach Freedman Wiki: <a target="_blank" href="https://gridfinity.xyz/" rel="nofollow noopener">https://gridfinity.xyz/</a>&nbsp;Differeces from the standard design:<ul><li>The interface has an added 0.4 mm flat section on top.</li><li>The bottom chamfer has been extended for improved print bed adhesion.</li><li>The base units can be overwritten which breaks compatibility but can use all space available.</li></ul>Please do not share print profiles here that break compatibility. Label print profiles well according to their settings.<h3>Customization Options</h3>The basic customization starts at the width and depth of the base plate in gridfinity units. Additionaly margins can be added on all sides and the rounded outside corners can be configured or completely removed.On top of that the base units for the grid can be redefined. This will break compatibility with the standard gridfinity containers etc. but will allow for much more flexibility when filling a drawer completely with containers.An equally modifiable container can be found in my other models <a target="_blank" href="https://makerworld.com/en/models/25376" rel="nofollow noopener">here</a>.<h3>Notes</h3>The OpenSCAD file is licensed as MIT.Source files included.

Gridfinity Parametric Base Plate

Gridfinity

superboske

Hi this is my first share.&nbsp;Here are some stencils based on popular google search, I just recreate them and adjust some stuff.They are 0.3-0.4mm thick so it can be really flexible in two layers in the A1 quality standard.&nbsp;Happy airbrushing

Airbrush Stencils

tools

Klexer

<h3>Unterschiede zwischen dem Remix und dem Original</h3>Remix vom Bambu X1C / P1S seitlich montierter Spulenhalter v3Bestehend aus 3 Teilen:<ul><li>Untere Rollenaufnahme</li><li>Obere Halterung für PC4-M10</li><li>Bolzen für Verbindung der Teile</li><li>2x Kugellager 608ZZ</li></ul>Danke @BC76 für diese <a target="_blank" href="https://makerworld.com/en/models/16172?from=search#profileId-18923" rel="nofollow noopener">https://makerworld.com/en/models/16172?from=search#profileId-18923</a>&nbsp;das untere Teil ohne Stützen druckbar

X1C / P1S seitlich montierter Spulenhalter v3.1

P1S improvement

The Wanderer

Various containers with knurled midsection. All container models are broken into top, middle, bottom, and threads so you can easily color individual sections in Bambu Studio (Process &gt; Objects &gt; expand each plate).&nbsp;Container Sizes (Diameter x Height)<ul><li>62x90mm – Bambu PLA Marble White with Inland PLA+ Silver</li><li>62x55mm – Inland PLA+ Black with Sunlu PLA+ Silk Black</li><li>46x62mm – Inland PLA Tough Illumination Blue</li><li>87x109mm – Inland PLA Red, Yellow (Silk), Green, and Black</li></ul>Let me know if you&#39;re looking for a specific dimension or size.&nbsp;

Knurled Containers With Screw Tops

Containers

3Demon

This is a digital 3D printable kit card of Dragonfly! Kit cards are fun, all-inclusive 3D prints that are printed flat and then assembled. This compact, 3D printable design combines the concept of a postcard with the joy of 3D printing. The download contains a model ready to be 3D printed flat on a 200 mm print bed (STL). You can scale the model as you wish but we can’t guarantee that at a much smaller size, the model will print well.3D PRINTING SETTINGS We use these settings for most of our prints: Layer height 0.2 mm Infill 15 % No supportsASSEMBLY: <ul><li>Use small cutting pliers to free the pieces from the kit card. Then assemble! 🙂</li></ul>Do you like the model and don’t have a 3D printer? There are lots of people who offer 3D printing services these days. Try searching for someone who offers them in your area. This model was brought to life by 3Demon. We are a group of modeling and 3d printing enthusiasts based in Prague, Czech Republic. We’ve been making 3D printable models for more than a decade. We make a lot of cosplay accessories but we also make all sorts of interesting 3D models. You can join our community or just look at more of our creations <a href="https://3d-mon.com/links/" rel="nofollow">here</a>.

Dragonfly Kit Card

deco

Vodvarek_Vodvar

Another Hotwheels Jump, supportless…

Hot Wheels Jump track

toys

BubsBuilds

<a href="https://jfs-agri.com/index.php/bubsbuilds-projects/pet-stuff/24-automated-cat-toy-laser-turret" rel="nofollow">Complete parts list and additional info here</a>A laser pointing turret for feline friends! Fairly compact assembly housing two rc servos providing two axis of rotational enjoyment.A fun feature of the design that is both functional and aesthetic (or at least it's my kind of aesthetic!) is the diaphram flexure used to preload the laser holder. While the light laser module doesn't really need the additional bearing support, I think the jewel-bearing style support and flexure add a nice touch of over-engineering.

Automated Cat Toy Laser Turret

cat stuff

I made this little winch for a project I'm working on for automating my window blinds, but I've found the little fella kinda fun more generally so thought I'd share it. So far I've tested it to about 20N with a 24V motor, but that was definitely starting to sound a bit sketchy. I'm currently using a couple of them with 100RPM, 12VDC motors for ~10N pull force and they seem to be liking it just fine.<a href="https://jfs-agri.com/index.php/bubsbuilds-projects/assorted-hopefully-useful-stuff-projects/64-lilwinch" rel="nofollow">I've put full details on the build here</a>, and you can find the design files on <a href="https://cad.onshape.com/documents/26bd81bee8e2d3da8f345059/w/d6f575149d43e2b2fab8f5ef/e/ecf5f938aee9485fadc92f42?renderMode=0&uiState=65930bb9369490051f3d4572" rel="nofollow">OnShape here</a>.Category: Gadgets

LilWinch

construction

dragonx081

improve the connection between the blade and the coilbased on <a target="_blank" href="https://www.thingiverse.com/thing:6344617/files" rel="nofollow noopener">https://www.thingiverse.com/thing:6344617/files</a> with license creatives commons attribution share alike

Improved otf without rubber

Whimsii3D

<h2>Print the model, give the wings a bit of a twist and then let it fly. Works best outdoors, you don't get much of the floating autorotation effect inside.</h2>
