Update 12/10/2023I redesigned this model to print with zero supports<a target="_blank" href="https://makerworld.com/en/models/89061#profileId-95325" rel="nofollow noopener">No Support Multicolor Nozzle Sign with Nozzle installed Text by straight606 - MakerWorld</a>&nbsp;&nbsp;Update 12/2/2023I uploaded another Version of this design, I added the Nozzle Steel Type to the bottom. Go check it out!<a target="_blank" href="https://makerworld.com/en/models/81777#profileId-87020" rel="nofollow noopener">Nozzle Installed Sign Version 2 by straight606 - MakerWorld</a>&nbsp;&nbsp;There are 4 Raw Files to download. They are the same settings&nbsp;Multicolored No TextSingle Color No TextMulticolor Nozzle Installed TextSingle Color Nozzle Installed Text&nbsp;This is my very first published print. I usually have too many things going on at once and I forget what nozzle size I have in the printer. So this is my fix and its helped me remember. I designed it in FreeCad. I did print it with Bambu Lab PLA Support Filament. There is a little post processing to get the doors to slide easy. The end cap needed a little trimming as well. I hope you like this print, for most its probably not needed but for those that have too many things going on at once like I do its helpful.&nbsp;&nbsp;Any feedback would be greatly appreciated, for being my first published model I feel like it is pretty good and im still learning the CAD portion of this hobby.&nbsp;Thanks!

Nozzle Installed Sign

Bambu Parts

laisch

This is a scaled flyable micro version of the ASW20 sailplane from Schleicher. The model was created to be lightweight and printable in normal PLA.Because of it's lightweight behaviour it's a little bit fiddly to get it together properly but it's still strong enouth to survive crashes. So please read the Instructions before you build it.&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_7930ef971b4078.gif"></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_b32700811d73d.gif"></figure>&nbsp;<h3>Printing:</h3>Make sure you align the STL-Files flat with the build plate like in the pictures.&nbsp;The Fuselage and the Nose have to be printed in Vase Mode (0.12mm) for best quality and perfect stability. Make sure you geht your part cooling right otherwise the thin tail section won't print properly because of overheating. Turn Bottom Layers to 1 Layer.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_2xua1hjiurid.jpg"></figure>The Wing parts are printed in normal Mode with 0.12mm Layerheight. Make sure that the first layer prints in 0.2mm.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_9yaljcx3l44z.jpg"></figure>After printing carefully remove the wings from your print bed and make sure not to overbend them.&nbsp;<h3>Assembly</h3>Clean up the parts from any print defects<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_mmrpjuqrlmyo.jpg"></figure>&nbsp;Testfit if the wings fit inside the fuselage. The reinforcement part of the wing should touch the fuselage. If not, just cut away the parts wich are too big.<figure class="table"><table><tbody><tr><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_k461jxekhpvj.jpg"></figure></td><td><figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_p3zauy5szoj1.jpg"></figure></td></tr><tr><td>Wing not aligned with fuselage</td><td>Wing aligned with fuselage</td></tr></tbody></table></figure>&nbsp;When the testfit is ok, put some superglue onto the wings and glue them in place.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_v2l13jrwi32n.jpg"></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_4dvxkmto8krd.jpg"></figure>&nbsp;Make a testfit if the rudder fits in to the elevator. If not you can take a cutter knife to clean it up a little bit.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_hiskzgmshhkj.jpg"></figure>&nbsp;After that put the rudder and elevator together and secure them with some CA glue. Try to not use too much glue because of extra weight.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_c5669idp5zad.jpg"></figure>&nbsp;Glueing the rudder/elevator assembly to the fuselage is the hardest part of the build. It works the best if you put one small drop onto the fuselage and temporary secure it. After that you can check the alignement and adjust it properly.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_sklgvblwtn24.jpg"></figure>If it looks fine, just secure the whole thing with more superglue.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_58pkfcwdk5pu.jpg"></figure>&nbsp;To make the whole thing fly you have to add weight to the nose and adjust the center of gravity. For me a 4,5mm steelball did the trick. You can temporary secure the nose to the rest of the plane with some tape and check it's flight properties.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_9hxutt2kk35r.jpg"></figure>&nbsp;<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_ui9nlrtydip2.jpg"></figure>&nbsp;For checking the center of gravity you can balance it on two screws. The COG should be at ⅓ of the wing measured from the front.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_vbnmudk1iyhh.jpg"></figure>if it does'nt fly properly you can also try to give it a little bit of lift by bending the elevator up.&nbsp;If it flys, you now can finally glue the nose to the rest of the sailplane.<figure class="image"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-11-30_jasr1r5920mo.jpg"></figure>Have Fun!&nbsp;&nbsp;<figure class="table" style="width:92.21%;"><table class="ck-table-resized"><colgroup><col><col><col></colgroup><thead><tr><th colspan="3">If you like this model you may have a look at my other flying toys too</th></tr></thead><tbody><tr><td><figure class="image"><a href="https://makerworld.com/en/models/81500" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-12-03_bc748d83c35e18.jpg"></a></figure><a target="_blank" href="https://makerworld.com/en/models/81500" rel="nofollow noopener">Geared Propeller Launcher</a></td><td><figure class="image"><a href="https://makerworld.com/en/models/76104" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-12-03_eadf473572ad4.jpg"></a></figure><a target="_blank" href="https://makerworld.com/en/models/76104" rel="nofollow noopener">Flying Bat</a></td><td><figure class="image"><a href="https://makerworld.com/en/models/21091" target="_blank" rel="nofollow noopener"><img src="https://makerworld.bblmw.com/makerworld/draft/231668/2023-12-03_a8fc21a53267c8.jpg"></a></figure><a target="_blank" href="https://makerworld.com/en/models/21091" rel="nofollow noopener">Cross Bow</a></td></tr></tbody></table></figure>
