very solid design and a great idea! but at least my router base is too big to reach the corner while the bracket is on, so I have to install this jig, clamp it in the corners and then remove the screwed bracket, which is tedious at best…

also: a single-color version with indented lettering as a default profile would be nice. I had to modify it myself (lettering -> change type to negative part -> add pause to change filament befor layer 4), so I could not print directly from the mobile app.

p.s. while re-reading the description I noticed: This probably would work nicely with a router TABLE… but not with my hand-held router…

extrawitz

Router Corner Radius Template (15–30 mm)

AMS Version  0.4 nozzle - all printers

The concept is nice, but the supports were tricky to remove, the tolerances are a little off and the pin broke instantly. I printed the bottom part again, this time diagonally, and that solved both the stability and the support issues! (PLA Basic, A1 mini)

tibubufi

Paint Shaker

0.2mm layer, 3 walls, 30% infill

Very tight and secure hold, easy to print, but imho too hard to remove... The idea of opengrid (for me at least) is to adjust everything on the fly and I have a hard time, getting those snaps out, once they're installed, making it hard to install anything else in that slot. (images with only 2 snaps are ca comparison to "normal" snaps).

mitufy

openGrid - Self-Expanding Snap

openGrid Standard, Snaps and Connectors

I love the idea and the concept and it's mostly great! My main gripes are the following:

The holes in the underside for the gridfinity magnets were ~0.75mm too small. I first tried melting the magnets in, using a hot air gun. That resulted in 4 mostly demagnetized magnets, so I drilled the remaining holes out.

Also my changeable-tip nozzles came with tools to unscrew the nozzles which don't have a place here - I added them.

Lastly (personal nitpick) my nozzles are labelled on the side, that lies down in this bin, so I flipped them over.

All those features were integrated in a freshly generated bin for notches in the stacking rim and better bottom holes.

Just for fun (and better readability) I added a color switching pause and I dropped some 4mm magnets into the nozzle-tip holes and flipped their labels' order, because I'll use mostly .2 and .4mm and wanted them on top.

Sadly the license does not allow for a posted remix, so you'll have to make do with my pictures...

Potovzuc

A1/A1Mini Nozzle Box Gridfinity

0.2mm layer, 2 walls, 15% infill
